SpeedyBee

SpeedyBee 1404 Motor - 4500Kv

The SpeedyBee 1404 Motor is a 4500KV motor with 250W maximum power designed for 3-4S voltage.&nbsp

The SpeedyBee 1404 Motor is a 4500KV motor with 250W maximum power designed for 3-4S voltage.

SpeedyBee 1404 Motor - 4500KV

Brushless or Brushed

The motors spin with the propellers to lift your quad off the ground. If you’ve picked a frame already, we show you which motors are appropriate for your frame. Beginners can choose motors with a similar stator size that others have used for the frame you’ve selected. Alternatively, calculate the thrust required for a particular thrust-to-weight ratio and learn to read motor thrust tables to select the best motors for your needs.

Motors

Motor KV

Motor Stator Size

T-Motor

T-Motor M1106 Motor - 6000Kv

This motor is a tiny monster. As a perfect match to our Driblet frame, this motor can make you feel like you're flying a 5" and still be able to fit in the house.
Also available in solder-free!
Specifications


Kv: 6000Kv


Input Voltage: 3-4S LiPo


Configuration: 9N12P


Max Continuous Current: 14.9A


Internal Resistance: mΩ


Motor Dimensions: Φ14.5mm x 16.75mm


Stator Dimensions: Φ11mm x 06mm


Shaft Diameter: 1.5mm

Mounting Pattern: Φ7mm

Wire Dimensions: 24AWG x 75mm


Weight: 7.2g


Includes


1x M1106 1106 6000Kv Motor


Solder Free: Everything is 100% plug-n-play, the MX125 Quick Connection System makes assembly a breeze and removes the need for any soldering! This motor is a tiny monster. As a perfect match to our Driblet frame, this motor can make you feel like you're flying a 5" and still be able to fit in the house.

M1106 1106 6000KV Motor

Tiger Motors

The&nbspT-Motor M1106&nbspis a 6000KV micro-sized motor that is perfect for your 3-4S toothpick builds!

The T-Motor M1106 is a 6000KV micro-sized motor that is perfect for your 3-4S toothpick builds!

T-Motor M1106 Micro Motor - 6000KV

T-Motor M1104 Motor - 7500Kv

Introducing T-Motors new "Micro" motor, perfect for small lightweight toothpick builds. Check out the rest of our Micro Motors as well as the rest of our T-Motor Collection! Specifications Model: M1104 KV: 7500 Configuration: 9N12P No. of Cells(Lipo): 2-4S Idle Current (4V): 0.44A Max Power (10s): 198W Peak Current (10

T-Motor M1104 1104 7500KV FPV Drone Motor - Blue

The&nbspT-Motor M1104&nbspis a 7500KV micro-sized motor that is perfect for your 2-3S toothpick builds!

The T-Motor M1104 is a 7500KV micro-sized motor that is perfect for your 2-3S toothpick builds!

T-Motor M1104 Micro Motor - 7500KV

T-Motor Hobby

T-Motor brings us the next level of micro motor with this M1104. Tmotor is known for their top performing motors and this one is no different! Fly with insane power and crash time after time without worry of breaking a motor.
Check out our vast motor selection and all our T-Motor products!
Specifications

KV: 7500
Stator Size: 11x4mm
Shaft Diameter: 1.5mm
Idle Current: .4A
Max Power: 198W
Peak Current: 13.1A
Configuration: 9N12P
Rated Voltage (Lipo): 2-4S


Includes

1x T-Motor M1104 7500Kv Micro Motor

1x Spare Parts Bag




T-Motor brings us the next level of micro motor with this M1104. Tmotor is known for their top performing motors and this one is no different! Fly with insane power and crash time after time without worry of breaking a motor. Check out our vast motor selection and all our T-Motor products! Specifications  KV: 7500 Stat

T-Motor M1104 7500Kv Micro Motor from WREKD Co.

T-Motor M1104 7500Kv Micro Motor

TMOTOR

Foxeer

Foxeer Datura 1404 Motor - 3850Kv

Introducing Foxeer's entry into the FPV motor scene. The Datura line of motors feature aluminum allow shaft, rubber dampener ring for shock absorption, high quality N52H magnets, and Military grade 260 Degree Celsius radiation resistant high temperature windings. Check out all our 14XX Motors and the rest of our Foxeer

Foxeer Datura 1404 FPV Motor - 3850KV

FOXEER

Foxeer has come out with a brand new motor for 2022, the Datura! In their effort to perfect every aspect of FPV flying, they have decided to focus on the motors this time with great results! Try them for yourself and feel the power of Datura.
Make sure to check out the rest of our motors as well as our entire Foxeer line-up!
Specifications

Kv: 3850
Input Voltage: 3-4S
Configuration: 9N12P
Internal Resistance: 240Ω

ldle Current@10V: 0.6A
Motor Dimensions: 19.2x16.9mm
Stator Dimensions: 14x4mm
Shaft Diameter: 1.5mm
Mounting Pattern: 9x9mm
Weight (w/ wires): 9g

Includes

1x Foxeer Datura 1404 3850Kv Micro Motor


Foxeer has come out with a brand new motor for 2022, the Datura! In their effort to perfect every aspect of FPV flying, they have decided to focus on the motors this time with great results! Try them for yourself and feel the power of Datura. Make sure to check out the rest of our motors as well as our entire Foxeer li

Foxeer Datura 1404 3850Kv Micro Motor

The&nbspFoxeer Datura 1404 FPV Motor&nbspis one of Foxeer's new line of motors! This is an ultralight micro motor equipped with aluminum sheets and a rubber ring which is excellent for shock absorption.

The Foxeer Datura 1404 FPV Motor is one of Foxeer's new line of motors! This is an ultralight micro motor equipped with aluminum sheets and a rubber ring which is excellent for shock absorption.

Foxeer Datura 1404 FPV Motor

Foxeer Datura 1404 3850Kv Micro Motor from WREKD Co.

T-Motor F1203 Motor - 7000Kv

The F 1203 is a killer option for 2.5-3" 2-3S light racing builds. Equipped with 1.5mm T prop mounting and high efficiency arc magnets, this motor is designed for explosive power and high top speed!
Check out all our motors and all our T-Motor products!
Specifications

Kv:  7000Kv
Input Voltage:  2-3S
Configuration: 9N12P
Max Continuous Current: 10.85A
Internal Resistance: 198mΩ


Motor Dimensions: Φ15.5x14.05mm


Stator Dimensions: Φ12x3mm
Shaft Diameter: 1.5mm
Mounting Pattern: Φ9mm, 4x M2

Wire Dimensions:  28AWG, 75mm

Weight: 5.25 (w/ wire)

Includes

1x T-Motor 1203 7000Kv Micro Motor


A classic T-Motor with a new stunning look. This new 1203 motor is sure to make your build stand out like none other.

T-Motor F1203 7000Kv Micro Motor

T-Motor F 1203 7000Kv Micro Motor - For Sale At RaceDayQuads

The F1203 motors from T-Motor are ultralight motors that are specially made for toothpicks and whoops! The F1203 motor comes with a 1.5mm shaft to fit more props and features high efficiency, better cooling, and fast response. Suitable for 2.5-3" builds! Checkout all our 12XX Motors and the rest of our T-Motor collecti

T-Motor F1203 7000KV Motor

The F 1203 is a killer option for 2.5-3&quot 2-3S light racing builds. Equipped with 1.5mm T prop mounting and high efficiency arc magnets, this motor is designed for explosive power and high top speed!
Check out all our motors and all our T-Motor products!
Specifications

Kv:  7000Kv
Input Voltage:  2-3S
Configuration: 9N12P
Max Continuous Current: 10.85A
Internal Resistance: 198mΩ


Motor Dimensions: Φ15.5x14.05mm


Stator Dimensions: Φ12x3mm
Shaft Diameter: 1.5mm
Mounting Pattern: Φ9mm, 4x M2

Wire Dimensions:  28AWG, 75mm

Weight: 5.25 (w/ wire)

Includes

1x T-Motor 1203 7000Kv Micro Motor


The F 1203 is a killer option for 2.5-3" 2-3S light racing builds. Equipped with 1.5mm T prop mounting and high efficiency arc magnets, this motor is designed for explosive power and high top speed! Check out all our motors and all our T-Motor products! Specifications Kv:  7000Kv Input Voltage:  2-3S Configuration: 9N1

T-Motor F1203 7000Kv Micro Motor from WREKD Co.

Enjoy a smooth flight with the&nbspF1203 7000KV motor by&nbspT-Motor. The&nbspF1203 motor has a 1.5mm shaft and comes with a 9x9 mounting pattern so you can have more options for props and frames in the market!&nbsp

Enjoy a smooth flight with the F1203 7000KV motor by T-Motor. The F1203 motor has a 1.5mm shaft and comes with a 9x9 mounting pattern so you can have more options for props and frames in the market!

T-Motor F1203 7000KV Motor

BrotherHobby

BrotherHobby TC 2004 Motor - 3150Kv

Ultra-light 2004 micro motor designed for sub 250g racing or long range builds, just throw on your favorite racing 5" T-Mount prop. Check out all our 20XX Motors and the rest of our BrotherHobby Products! Specifications:  KV: 2100Kv No. of Cells (Lipo): 4-6S Configuration: 12N14P Base casing: Al 7075 Stator: 0.15mm Nip

BrotherHobby TC 2004 3150Kv Ultralite Motor

Introducing the BrotherHobby TC 2004 Brushless Motor! This Ultralite motor is suitable for those who love to race and is perfect for the&nbspSub-250G Racing Drone. With aerospace-grade 7075 AL, titanium alloy shaft, and hard anodizing cover... this motor is wearproof with high crash tolerance.

Introducing the BrotherHobby TC 2004 Brushless Motor! This Ultralite motor is suitable for those who love to race and is perfect for the Sub-250G Racing Drone. With aerospace-grade 7075 AL, titanium alloy shaft, and hard anodizing cover... this

Brotherhobby TC 2004 Motor - 1700KV/1950KV/2100KV/3150KV

Brother Hobby


Introducing the BrotherHobby TC 2004 Brushless Motor! This Ultralite motor is suitable for those who love to race and is perfect for the Sub-250G Racing Drone. With aerospace-grade 7075 AL, titanium alloy shaft, and hard anodizing cover... this motor is wearproof with high crash tolerance.

Introducing the BrotherHobby TC 2004 Brushless Motor! This Ultralite motor is suitable for those who love to race and is perfect for the Sub-250G Racing Drone. With aerospace-grade 7075 AL, titanium alloy shaft, and hard anodizing cover... this motor is wearproof with high crash tolerance.
Features

Missile grade high purity electronic silver wire
Heat treatment Titanium alloy shaft
Aerospace-grade 7075 AL
Japanese NMB bearings
Wearproof



Specifications

Stator: 0.15mm Nippon silicon steel
Prop Adapter Shaft Thread: M 1.5
KV: 3150
Rotor: N52H arc magnets
AlBase casing: 7075 Al
Bolt Pattern: M2 12X12
Configuration: 12N14P
No.of Cells(Lipo): 4-6S
Bearings: NMB 7x3x3
Wire AWG: 24 AWG
Wire length:16cm
Model: TC 2004
Shaft: SUS 420
Bell cap: 7075

Includes

1 x Brotherhobby TC 2004 Motor
4 x M2x6 Base Screws
2 x M2x7 Prop Screws


Introducing the BrotherHobby TC 2004 Brushless Motor! This Ultralite motor is suitable for those who love to race and is perfect for the Sub-250G Racing Drone. With aerospace-grade 7075 AL, titanium alloy shaft, and hard anodizing cover... this motor is wearproof with high crash tolerance.   Introducing the BrotherHobb

Brotherhobby TC 2004 Motor - 3150KV

These motors are designed for sub 250g racing builds with T-Mount props, they work great as micro long-range motors as well.
Available in multiple KV options.
Check out our huge selection of motors and all our BrotherHobby gear!
Specifications

KV: 3150
Configuration: 12N14P
No.of Cells(Lipo): 4-6S
Rotor: N52H arc magnets
Stator: 0.15mm Nippon silicon steel
Shaft: SUS 420
Bearings: NMB 7x3x3
Wire AWG: 24 AWG wire 16cm length
Bell cap: 7075 Al
Base casing: 7075 Al
Prop Adapter Shaft Thread: M1.5
Bolt Pattern: M2 12X12
Weight: 14.9g w/ short wire

Includes

1x BrotherHobby TC 2004 3150Kv Micro Motor




These motors are designed for sub 250g racing builds with T-Mount props, they work great as micro long-range motors as well. Available in multiple KV options. Check out our huge selection of motors and all our BrotherHobby gear! Specifications KV: 3150 Configuration: 12N14P No.of Cells(Lipo): 4-6S Rotor: N52H arc magne

BrotherHobby TC 2004 3150Kv Micro Motor from WREKD Co.

BrotherHobby TC 2004 3150Kv Micro Motor

BROTHERHOBBY

These motors are designed for sub 250g racing builds with T-Mount props, they work great as micro long-range motors as well.

BrotherHobby TC 2004 3150Kv Micro Motor - For Sale at RaceDayQuads

GEPRC

GEPRC GR 1404 Motor - 4500Kv

Specification：

 	Item：GR1404
 	KV: 4500
 	Configuration: 9N12P
 	Stator Diamter：14mm
 	Stator Length：4mm
 	Shaft Diameter: 1.5mm
 	Motor Dimensions: Φ18.3 * 14.5mm
 	The hole position of motor：9mm
 	Weight: 9.8g
 	Idle current@8V(A) ≤0。51
 	No.of Cells(Lipo): 2~4S
 	Max Continuous Power(180S): 214
 	Internal Resistance: 0.213mΩ
 	Max Current(180S): 13.38A

Specification： Item：GR1404 KV: 4500 Configuration: 9N12P Stator Diamter：14mm Stator Length：4mm Shaft Diameter: 1.5mm Motor Dimensions: Φ18.3 * 14.5mm The hole position of motor：9mm Weight: 9.8g Idle current@8V(A) ≤0。51 No.of Cells(Lipo): 2~4S Max Continuous Power(180S): 214 Internal Resistance: 0.213mΩ Max Current(180S): 13.38A

GEPRC GR1404 4500KV Motor - GEPRC

GEPRC GR1404 4500KV Motor

A 1404 size motor from GEPRC. A powerful motor for micro drones looking for high speeds.

GEPRC GR1404 Motor - 4500KV

BetaFPV

BetaFPV 1404 Motor - 4500Kv

We are excited to introduce the 1404 4500KV brushless motor! It is designed for the Beta95X V3 Whoop Quadcopter and Beta95X V3 HD Digital VTX, which could offer pilots a more smooth and more powerful flight, and lead the Beta95X V3 series drones to the next level. In the meantime, this motor is also a great choice if y

BetaFPV 1404 4500KV Brushless Motors - 1PCS

BETAFPV

We are excited to introduce the 1404 4500KV brushless motor! It is designed for the Beta95X V3 Whoop Quadcopter and Beta95X V3 HD Digital VTX, which could offer pilots a more smooth and more powerful flight, and lead the Beta95X V3 series drones to the next level. In the meantime, this motor is also a great choice if you're building 2.5-4'' ultralight micro drones with Toothpick F405 AIO 20A FC V4.


Bullet Points

1404 4500KV brushless motor is designed for the Beta95X V3 Whoop Quadcopter and Beta95X V3 HD Digital VTX, which could offer pilots a more smooth and more powerful flight and lead the Beta95X V3 series drones to the next level.

Come with 4 specially designed motor clips in the package, pilots can use the clip to increase the height of the props, which could effectively reduce the shaking of drones.
Perfectly match with Toothpick F405 AIO 20A FC V4, this motor will bring pilots a powerful flight experience.
It is lightweight, durable and plenty of power! Combing with the perfect match of D63 3-blades props, pilots could get an amazing flight experience!
The plug of the BETAFPV 1404 4500KV motor is a micro JST-1.25 3-pin connector, with 28AWG cables. Just plug and play, no soldering required.

Recommended Parts

Flight Controller: Toothpick F405 AIO 20A FC V4

Compatible Propellers: Gemfan D63 3-Blades Props

Battery: 450mAh 4S 75C Lipo Battery

Frame: Beta95X V3 Frame Kit





Specification

Weight: 8.49g  (1 pcs)
Shaft length: 3mm
Shaft diameter: 2mm
Motor Mount Holes: 4-M2EQS-φ9
KV (rpm/V): 4500KV
Input Voltage: 3-4S LIPO
Cables: 40mm long, 28AWG cables



Package

1 or 4 * 1405 4500KV Brushless Motors
4 * Motor Clip
16 * M2 Screws




Rated at 5000kv, 1106 Brushless Motor hits the sweet spot for high-powered 4s power. This motor has been designed and built for your 4S 85-120mm racing or freestyle drone, resulting in incredible power and performance.

1404 4500KV Brushless Motors

BetaFPV 1404 4500KV Brushless Motors - 4PCS

A perfect set of motors for those 2.5-4" micro quads!
Check out all our micro motors and our BetaFPV selection!
Specifications

Shaft length: 3mm
Shaft diameter: 2mm
Motor Mount Holes: 9x9mm, M2
KV (rpm/V): 4500KV
Input Voltage: 3-4S LIPO
Cables: 40mm long, 28AWG cables
Weight: 8.49g each

Includes

4x BetaFPV 1404 4500Kv Micro Motor


A perfect set of motors for those 2.5-4" micro quads!

BetaFPV 1404 4500Kv Micro/Whoop Motor 4 Pack

BetaFPV 1404 4500Kv Micro Motor 4 Pack - For Sale at RaceDayQuads

A perfect set of motors for those 2.5-4&quot micro quads!
Check out all our micro motors and our BetaFPV selection!
Specifications

Shaft length: 3mm
Shaft diameter: 2mm
Motor Mount Holes: 9x9mm, M2
KV (rpm/V): 4500KV
Input Voltage: 3-4S LIPO
Cables: 40mm long, 28AWG cables
Weight: 8.49g each

Includes

4x BetaFPV 1404 4500Kv Micro Motor


A perfect set of motors for those 2.5-4" micro quads! Check out all our micro motors and our BetaFPV selection! Specifications Shaft length: 3mm Shaft diameter: 2mm Motor Mount Holes: 9x9mm, M2 KV (rpm/V): 4500KV Input Voltage: 3-4S LIPO Cables: 40mm long, 28AWG cables Weight: 8.49g each Includes 4x BetaFPV 1404 4500Kv

BetaFPV 1404 4500Kv Micro/Whoop Motor 4 Pack from WREKD Co.

BetaFPV is excited to introduce the 1404 4500KV brushless motor! It is designed for the&nbspBeta95X V3 Whoop Quadcopter&nbspand&nbspBeta95X V3 HD Digital VTX, which offers pilots a more smooth and more powerful flight that leads the Beta95X V3 series drones to the next level.

BetaFPV is excited to introduce the 1404 4500KV brushless motor! It is designed for the Beta95X V3 Whoop Quadcopter and Beta95X V3 HD Digital VTX, which offers pilots a more smooth and more powerful flight that leads the Beta95X V3 ser

BETAFPV 1404 Brushless Motor (1pc) - 4500KV

BetaFPV 1505 Motor - 3400Kv

BetaFPV is excited to introduce the 1505 3400KV brushless motor! It is designed for the&nbspBetaFPV Pavo30&nbspand&nbspBeta95X V3 HD Digital VTX, which offers pilots a more smooth and more powerful flight that leads the Beta95X V3 series drones to the next level.

BetaFPV is excited to introduce the 1505 3400KV brushless motor! It is designed for the BetaFPV Pavo30 and Beta95X V3 HD Digital VTX, which offers pilots a more smooth and more powerful flight that leads the Beta95X V3 series drones to

BetaFPV 1505 Brushless Motor (1pc) - 3400KV

1505 3400KV Brushless motor is designed for Pavo30 3-inch pusher cinewhoop Drone . Combined with Gemfan D76 5-Blades propellers, it offers the drone a powerful flight and less noise. In the meantime, we highly recommend this motor for building a 3-4S quadcopter with F722 AIO 35A Brushless flight controller.

Bullet Points

1505 3400KV brushless motor is designed for Pavo30 Whoop Drone, which could offer pilots a more smooth and more powerful flight and lead the Beta95X V3 series drones to the next level.
Gemfan D76 5-Blades props will be the best match with 1505 3400KV motor, this high efficient power system lays the foundation for powerful flight and less noise.
Perfectly match with F722 AIO 35A Brushless flight controller, this motor will bring pilots a powerful flight experience with 4S battery

Recommended Parts

Frame: Pavo30 frame kit

Flight Controller: F722 AIO 35A Brushless flight controller

Compatible Propellers: HQ 75 5-Blade 1.5 shaft hole propeller

Battery: 750mAh 4S battery/ 850mAh 4S battery/ 450mAh 4S battery




Specification

Weight: 12.52g/pc
Shaft length: 4mm
Shaft diameter: 1.5mm
Size: 21mm*21mm*18mm
Motor Mount Holes: 4-M2EQS-φ5
KV (rpm/V): 3400KV
Input Voltage: 3-4S lipo
Cables: 40mm long, 24AWG cables



Package

1 or 4 * 1505 3400KV Brushless Motors
16 * M2 Screws





1505 3400KV Brushless Motors

EMAX

EMAX ECO 1404 Motor - 3700Kv

Emax USA


Specifications

Framework: 9N12P
Length: 19.75mm
Diameter: 18.8mm
Propeller: 2.5&quot - 4&quot
Weight: 8.6g (W/O Silicone Wire)
Prop adapter shaft diameter: 1.5mm
Bearing Shaft: 2mm
Shaft Thread: CW

Features

Precision durable ball-bearings
Steel shaft for high strength
Anodizing for finish and corrosion resistance
9x9mm hole pattern
Multi-strand copper windings
100mm 26 AWG silicone wire



Specifications Framework: 9N12P Length: 19.75mm Diameter: 18.8mm Propeller: 2.5" - 4" Weight: 8.6g (W/O Silicone Wire) Prop adapter shaft diameter: 1.5mm Bearing Shaft: 2mm Shaft Thread: CW Features Precision durable ball-bearings Steel shaft for high strength Anodizing for finish and corrosion resistance 9x9mm hole pa

ECO Micro Series 1404 - 3700kv Brushless Motor from WREKD Co.

ECO Micro Series 1404 - 3700kv Brushless Motor

EMAX is taking their ECO series into the micro class! Arguably the best qualty and performance from any "economy" motor our there, ECOs will give anything a run for their money!Check out all our micro motors and our EMAX gear!
Features

Precision durable ball-bearings
Steel shaft for high strength
Anodizing for finish and corrosion resistance
9x9mm hole pattern
Multi-strand copper windings
100mm 26 AWG silicone wire

Specifications

Framework: 9N12P
Length: 19.75mm
Diameter: 18.8mm
Propeller: 2.5" - 4"
Weight: 8.6g (W/O Silicone Wire)
Prop adapter shaft diameter: 1.5mm
Bearing Shaft: 2mm
Shaft Thread: CW

Includes

1x EMAX ECO 1404 3700Kv Micro Motor


EMAX is taking their ECO series into the micro class! Arguably the best qualty and performance from any "economy" motor our there, ECOs will give anything a run for their money!Check out all our micro motors and our EMAX gear! Features Precision durable ball-bearings Steel shaft for high strength Anodizing for finish a

EMAX ECO 1404 3700Kv Micro Motor

SpecificationsFramework: 9N12PLength: 19.75mmDiameter: 18.8mmPropeller: 2.5&quot - 4&quotWeight: 8.6g (W/O Silicone Wire)Prop adapter shaft diameter: 1.5mmBearing Shaft: 2mmShaft Thread: CWFeaturesPrecision durable ball-bearingsSteel shaft for high strengthAnodizing for finish and corrosion resistance9x9mm hole patternMulti-strand copper windings100mm 26 AWG silicone wireSpecificationsFramework: 9N12PLength: 19.75mmDiameter: 18.8mmPropeller: 2.5&quot - 4&quotWeight: 8.6g (W/O Silicone Wire)Prop adapter shaft diameter: 1.5mmBearing Shaft: 2mmShaft Thread: CWFeaturesPrecision durable ball-bearingsSteel shaft for high strengthAnodizing for finish and corrosion resistance9x9mm hole patternMulti-strand copper windings100mm 26 AWG silicone wire

EMAX ECO Micro Series 1404 - 3700kv Brushless Motor shipped fast from the best source for all your FPV gear, RMRC! Free shipping for qualified orders using the shipping deal.

EMAX ECO Micro Series 1404 - 3700kv Brushless Motor - RMRC

EMAX ECO Micro Series 1404 - 3700kv Brushless Motor

Emax

EMAX is taking their ECO series into the micro class! Arguably the best qualty and performance from any &quoteconomy&quot motor our there, ECOs will give anything a run for their money!Check out all our micro motors and our EMAX gear!
Features

Precision durable ball-bearings
Steel shaft for high strength
Anodizing for finish and corrosion resistance
9x9mm hole pattern
Multi-strand copper windings
100mm 26 AWG silicone wire

Specifications

Framework: 9N12P
Length: 19.75mm
Diameter: 18.8mm
Propeller: 2.5&quot - 4&quot
Weight: 8.6g (W/O Silicone Wire)
Prop adapter shaft diameter: 1.5mm
Bearing Shaft: 2mm
Shaft Thread: CW

Includes

1x EMAX ECO 1404 3700Kv Micro Motor


EMAX ECO 1404 3700Kv Micro Motor from WREKD Co.

A spare or replacement&nbsp&nbspECO 1404 3700KV brushless motor for&nbspthe&nbspEMAX BabyHawk II HD Freestyle RTF&nbspor related drones.

A spare or replacement  ECO 1404 3700KV brushless motor for the EMAX BabyHawk II HD Freestyle RTF or related drones.

EMAX ECO 1404 3700KV Brushless Motor

The new EMAX Micro Series 1104 brushless motor features precision durable ball-bearings and steel shaft for high strengths. The motors resist corrosion and have an anodized finish. Check out all our 1404 motors and EMAX motors! Specifications Framework: 9N12P Length: 19.75mm Diameter: 18.8mm Propeller: 2.5" - 4" Weight

Emax ECO Micro Series Brushless Motor 1404-3700kv

NewBeeDrone

NewBeeDrone Flow 1202 Motor - 8420Kv

Specifications:
- 4.5g w/ wire
- Titanium Alloy TC4 Shaft
- NSK  Ball Bearing
- 0.2mm Silicon Steel Sheets Core
- 30AWG silicone wire with JST1.25 3Pin connector total length 60mm
- 7075 Aluminum Alloy
- 8420KV for 2S battery / 11420KV for 1S battery
- 1.5mm shaft
- 9mm X mounting screw pattern


Specifications: - 4.5g w/ wire - Titanium Alloy TC4 Shaft - NSK  Ball Bearing - 0.2mm Silicon Steel Sheets Core - 30AWG silicone wire with JST1.25 3Pin connector total length 60mm - 7075 Aluminum Alloy - 8420KV for 2S battery / 11420KV for 1S battery - 1.5mm shaft - 9mm X mounting screw pattern

NewBeeDrone FLOW 1202 Racing and Freestyle FPV Micro Motor (Set of 4) 8420KV/11420KV from WREKD Co.

NewBeeDrone FLOW 1202 Racing and Freestyle FPV Micro Motor (Set of 4) 8420KV/11420KV

Happymodel

The NewBeeDrone FLOW 1202 is a micro T-mount styled motor that comes in two KV options: 8420KV and 11420KV. This motor is suitable for racing and freestyle drones!

NewBeeDrone FLOW 1202 8420KV/11420KV Motor - T-Mount (Set of 4)

NewBeeDrone FLOW 1202 Racing and Freestyle FPV Micro Motor (Set of 4)

Hypershot

Hypershot 1507.5 Cinewhoop Motor - 3922Kv

With Cinewhoops becoming more and more useful each day, we decided to take the high end performance of the Hyperlite motor series and bring them into the cinematic world! Hypershot motors are designed to be smooth, light and providing all of the power needed to get the shot! We also offer this motor in 2922kv and T-Mou

Hypershot 1507.5 3922kv Cinewhoop FPV Motor - M5 Shaft

With Cinewhoops becoming more and more useful each day, we decided to take the high end performance of the Hyperlite motor series and bring them into the cinematic world! Hypershot motors are designed to be smooth, light and providing all of the power needed to get the shot! We also offer this motor in 2922kv and M5 Sh

Hypershot 1507.5 3922kv Cinewhoop FPV Motor - 1.5mm T-Mount

With Cinewhoops becoming more and more useful each day, we decided to take the high end performance of the Hyperlite motor series and bring them into the cinematic world! Hypershot motors are designed to be smooth, light and providing all of the power needed to get the shot!  This Bundle includes 4 Hypershot 1507.5 Mot

Hypershot 1507.5 Cinewhoop FPV Motor Bundle (4pcs)

Pyro-Drone

The new Hypershot 1507.5 Motor line is specially designed for cine-whoops!

Hypershot 1507.5 3922KV/ 2922KV Cinewhoop Motor - M5 Shaft

The new Hypershot 1507.5 Motor line is specially designed for cine-whoops!

Hypershot 1507.5 3922KV/ 2922KV Cinewhoop Motor - 1.5mm T-Mount

BrotherHobby VY 1504.5 Motor - 3950Kv

Introducing the VY 1504.5 Motor by BrotherHobby. This motor comes with a solid shape and features aerospace-grade 7075 AL and Japanese NSK bearings for smooth and quiet flying.

 BrotherHobby VY 1504.5 2650KV/2950KV/3950KV Motor

New BrotherHobby 1504.5 motors, great for ultralight builds!!!  Check out all our 15XX Motors, T-Mount Motors, and the rest of our BrotherHobby Collection! Features: Aerospace-grade 7075 AL Hard scratch resistant anodizing! Heat treated alloy steel shaft! Waterproof and shockproof! Japanese NSK bearings, silky smooth q

BrotherHobby VY 1504.5 3950KV Motor

BrotherHobby VY 1507 Motor - 3100Kv

Brotherhobby

Specifications

KV: 3100KV
Configuration: 12N14P
Wire AWG: 24AWG
Magnet: N52H arc magnets
Copper wire: Missile Grade Material( resistant to 260℃）
No.of Cells(Lipo): 4-6S
Base casing: Al 7075
Bell cap: Al 7075
Bearings: Japanese NSK 5x2x2.5 mm
Stator: 0.15mm Nippon stell silicon steel
Bolt Pattern: M2 (12mm 12 mm)
Weight: 16.3g with 16cm long wires

Includes

1x Brother Hobby VY 1507 3100Kv Micro Motor


Specifications KV: 3100KV Configuration: 12N14P Wire AWG: 24AWG Magnet: N52H arc magnets Copper wire: Missile Grade Material( resistant to 260℃） No.of Cells(Lipo): 4-6S Base casing: Al 7075 Bell cap: Al 7075 Bearings: Japanese NSK 5x2x2.5 mm Stator: 0.15mm Nippon stell silicon steel Bolt Pattern: M2 (12mm 12 mm) Weight: 16.3g with 16cm long wires Includes 1x Brother Hobby VY 1507 3100Kv Micro Motor

1507 3100KV Motor

The Brotherhobby VY  is a high-quality motor made with Japanese NSK bearings for silky smooth, free and quiet flying!

Brotherhobby VY 1507 1550KV/1900KV/3100KV/4150KV Motor

BetaFPV 1505 Motor - 3600Kv

Rated at 3600kv, 1505 motor hits the nice spot for high-powered 4s 4'' toothpick builds with the ability to swing up to 4" props with ease. Combined with 20A Toothpick F4 AIO FC, which will provide you enough output power, you can build a micro drone with incredible performance that is sure to please.

Project #MicroLR Build

Dave C FPV has released project Micro Long Range-  Scale down a 7" long range quad until it is sub 250g AUW. He makes a video present his concept, which allows you to easily fit an impressive amount of feature in your sub 250 setups. As far as Dave's presentation, Betafpv 1404/1505 motor, and 4025 props will be the best power system worth to build this fantastic drone. Learn more about at Thingiverse article.
1505 3600KV Motors / 1404 3800KV Motors / 4025 Props / Caddx Tarsier 4K Camera

Compatible 4'' Propellers
1505 Motors retains φ1.5mm shaft design instead of thread shaft for saving weight, which means it needs M2 screws to lock props, while most of 4'' props are locked with nuts in the market. These motors are best paired with 1.5mm shaft 4" props- 4025 props.

BULLET POINTS

Perfectly match with 20A Toothpick F4 AIO FC, it will bring you powerful flight experience
With BETA blue color and distinctive dart bell design, these motors will look slick on any quad

For offering pilots better cutting and soldering experience, it comes with 80mm long, 24AWG cable while no pre-solder plug






RECOMMENDED PARTS

Flight Controller: Toothpick F4 20A AIO FC

Compatible Propellers: HQ 4025 2-Blade Prop

Battery: 450mAh 3S 75C Lipo Battery / 450mAh 4S 75C Lipo Battery

Frame: TWIG Frame




SPECIFICATION

Weight: 13.08g  (1 pcs)
Shaft: φ1.5mm
Motor Mount Holes: M2
KV (rpm/V): 3600KV
Input Voltage: 3-4S LIPO
Cables: 80mm long, 24AWG cables



PACKAGE

1 or 4 * 1505 3600KV Brushless Motors
1 * Pack of M2 Screws



1505 3600KV Brushless Motors

Rated at 3600kv, the 1505 motor by BETAFPV fits perfectly in high-powered 4s 4'' toothpick builds.

BETAFPV 1505 3600KV Brushless Motors (4pcs)

BetaFPV 1404 Motor - 3800Kv

1404 motor is a perfect candidate for a lightweight 3S and 4S setup. It can be built with a regular carbon fiber frame to run 3-inch props on. This motor is great if you're building 3-4'' toothpick-style ultralight micro drones with 20A Toothpick F4 AIO FC.
Note: There are something changes in the new version of 1404 3800KV brushless motors. First, its appearance color is changed to black. The motor mounting hole size was modified from φ12 to φ9. The performance is still great as before. Please rest assured to purchase. Thank you!

Project #MicroLR Build

Dave C FPV has released project Micro Long Range-  Scale down a 7" long range quad until it is sub 250g AUW. He makes a video present his concept, which allows you to easily fit an impressive amount of feature in your sub 250 setups. As far as Dave's presentation, Betafpv 1404/1505 motor, and 4025 props will be the best power system worth to build this fantastic drone. Learn more about at Thingiverse article.
1505 3600KV Motors / 1404 3800KV Motors / 4025 Props / Caddx Tarsier 4K Camera

BULLET POINTS

Perfectly match with 20A Toothpick F4 AIO FC, it will bring you powerful flight experience
With black color and distinctive dart bell design, these motors will look slick on any quad

For offering pilots better cutting and soldering experience, it comes with 80mm long, 24AWG cable while no pre-solder plug






Compatible 4'' Propellers
1404 Motors retains φ1.5mm shaft design instead of thread shaft for saving weight, which means it needs M2 screws to lock props, while most of 4inch props are locked with nuts in the market. These motors are best paired with 1.5mm shaft 4" props- 4025 props.
RECOMMENDED PARTS

Flight Controller: Toothpick F4 20A AIO FC

Compatible Propellers: HQ 3020 2-Blade Prop / HQ 3030 3-Blade Prop / HQ 4025 2-Blade Prop

Battery: 450mAh 3S 75C Lipo Battery / 450mAh 4S 75C Lipo Battery

Frame: TWIG Frame
Motor: 1204 5000KV Motors / 1404 3800KV Motors





SPECIFICATION

Weight: 9.66g  (1 pcs)
Shaft: φ1.5mm
Motor Mount Holes: M2
KV (rpm/V): 3800KV
Input Voltage: 3-4S LIPO
Cables: 80mm long, 24AWG cables



PACKAGE

1 or 4 * 1404 3800KV Brushless Motors
1 * Pack of M2 Screws




1404 3800KV Brushless Motors

The BETAFPV 1404 motor is a perfect candidate for a lightweight 3S and 4S setup. It can be built with a regular carbon fiber frame to run 3-inch props on. This motor is great if you're building 3-4'' toothpick-style ultralight micro drones with 20A Toothpick F4 AIO FC. Note: There are something changes in the new versi

BetaFPV 1404 3800KV Brushless Motors 4 Pcs.

The BETAFPV 1404 motor is a perfect candidate for a lightweight 3S and 4S setup.

BETAFPV 1404 3800KV Brushless Motors (4pcs)

EMAX TH1103 Motor - 7000Kv

Spare replacement part for the EMAX Tinyhawk Freestyle.
Check out the rest of our TinyHawk Series Parts &ampamp Accessories and all our EMAX gear!
Specifications





Size: 1103 KV 7000kv






Mounting Hole: M2 8mm 3 hole pattern.






Center Hole clearing: 5mm






Prop Mount: T mount






Wire: Silicone Wire 26 AWG





Includes

1x EMAX TH1103 7000Kv Motor


Spare replacement part for the EMAX Tinyhawk Freestyle. Check out the rest of our TinyHawk Series Parts &amp; Accessories and all our EMAX gear! Specifications Size: 1103 KV 7000kv Mounting Hole: M2 8mm 3 hole pattern. Center Hole clearing: 5mm Prop Mount: T mount Wire: Silicone Wire 26 AWG Includes 1x EMAX TH1103 7000

EMAX TH1103 7000Kv Micro Motor from WREKD Co.

EMAX TH1103 7000Kv Micro Motor

Spare replacement part for the EMAX Tinyhawk Freestyle.
Check out the rest of our TinyHawk Series Parts &amp Accessories and all our EMAX gear!
Specifications





Size: 1103 KV 7000kv






Mounting Hole: M2 8mm 3 hole pattern.






Center Hole clearing: 5mm






Prop Mount: T mount






Wire: Silicone Wire 26 AWG





Includes

1x EMAX TH1103 7000Kv Motor


TH1103 - Genuine EMAX replacement part for the Tinyhawk Freestyle. Size: 1103 KV 7000kv Mounting Hole: M2 8mm 3 hole pattern. Center Hole clearing: 5mm Prop Mount: T mount Wire: Silicone Wire 26 AWG

EMAX TH1103 - Tinyhawk Freestyle Replacement Motor 7000kv

The stock motor on the EMAX TinyHawk Freestyle, now available separately. Use as a spare for your TinyHawk Freestyle or on another micro build!
