Diatone Mamba MK4 F740 3-6S AIO Flight Controller - 40A 32Bit 4in1 ESC, WIFI

Introducing the Diatone Mamba MK4 F740 AIO. This is a full featured all in one flight controller and ESC that is perfect for Sub 250g 3, 4, and 5 inch quads. It is equipped with an F7 processor, 40A ESC, Barometer, OSD Chip, 16M of Blackbox memory, and a connector to making connecting your video transmitter of choice a

Diatone MAMBA MK4 F740 40A 6S 32bit AIO Flight Controller/ESC - 25.5x25.5mm - WiFi Version

DiatoneUSA










Now this is something truly special for its size and capability - Introducing the Diatone Mamba MK4 F740 AIO. The Diatone Mamba MK4 F740 AIO is a powerful, all-in-one flight controller and ESC for sub 250g 3, 4, and 5 inch quads. It is equipped with an F7 processor, a 32bit 4in1 ESC of up to 40A, a barometer and OSD chip, and 16M of Blackbox memory. Connecting a video transmitter is easy and efficient, giving you a reliable and versatile system.









Check out all our Whoop/AIO Flight Controllers and our full Diatone collection!.


FC Specifications

Target: MAMBA F722_2022B
MCU: 216MHz STM32F722
GYRO: ICM-42688-P
Barometer: Yes
OSD: Yes
Blacbox: 16MB Flash

Uarts: 6 Set
Motor Signal: 4 Set
ESC Soft: Dshot300/600
ESC Telemetry: Yes
Power Led: Yes
LED Controller: BF LED
AIR UNIT Port: Yes
WIFI: No
F.Port: Yes
RSSI: No
Buzz: Yes
Input: 3~6S Lipo (12.6~25.2V)
BEC Protection: Yes
Receiver Protection: Yes
TVS Protection: Yes
BEC: 3.3V 0.5A &ampamp 5V 2A
Mounting size: 25.5 x 25.5mm/M2

ESC Specifications

Input: 3~6S Lipo (12.6~25.2V)
Continue Current: 40Ax4
Burst current: 45A (10 Seconds)
Target：BLHeli_32 MAMBA F40_128K
SOFT: Dshot300/600
PWM:24~128K

Include

1x Diatone Mamba MK4 F740 3-6S AIO Whoop/Toothpick Flight Controller w/ 40A 32bit 4in1 ESC - WIFI
1x High Frequency 470uF/35V
1x AIR UNIT sh1.0
1x 16AWG 60mm
1x AMASS Original XT60

Wiring Diagram


Now this is something truly special for its size and capability - Introducing the Diatone Mamba MK4 F740 AIO. The Diatone Mamba MK4 F740 AIO is a powerful, all-in-one flight controller and ESC for sub 250g 3, 4, and 5 inch quads. It is equipped with an F7 processor, a 32bit 4in1 ESC of up to 40A, a barometer and OSD ch

Diatone Mamba MK4 F740 3-6S AIO Whoop/Toothpick Flight Controller w/ 40A 32Bit 4in1 ESC - WIFI from WREKD Co.

Diatone Mamba MK4 F740 3-6S AIO Whoop/Toothpick Flight Controller w/ 40A 32Bit 4in1 ESC - WIFI

WREKD is a family-owned & operated, leading online FPV super-store based in the United States specializing in FPV racing / freestyle / tiny / micro whoop drones, parts, gear, and accessories. We offer fast, domestic, same-day shipping with the quickest delivery to anywhere in the U.S.A.

Diatone MAMBA MK4 F740 40A 6S 32bit AIO Flight Controller/ESC - 25.5x25.5mm - WiFi Version from WREKD Co.

DIATONE










Now this is something truly special for its size and capability - Introducing the Diatone Mamba MK4 F740 AIO. The Diatone Mamba MK4 F740 AIO is a powerful, all-in-one flight controller and ESC for sub 250g 3, 4, and 5 inch quads. It is equipped with an F7 processor, a 32bit 4in1 ESC of up to 40A, a barometer and OSD chip, and 16M of Blackbox memory. Connecting a video transmitter is easy and efficient, giving you a reliable and versatile system.









Check out all our Whoop/AIO Flight Controllers and our full Diatone collection!.


FC Specifications

Target: MAMBA F722_2022B
MCU: 216MHz STM32F722
GYRO: ICM-42688-P
Barometer: Yes
OSD: Yes
Blacbox: 16MB Flash

Uarts: 6 Set
Motor Signal: 4 Set
ESC Soft: Dshot300/600
ESC Telemetry: Yes
Power Led: Yes
LED Controller: BF LED
AIR UNIT Port: Yes
WIFI: No
F.Port: Yes
RSSI: No
Buzz: Yes
Input: 3~6S Lipo (12.6~25.2V)
BEC Protection: Yes
Receiver Protection: Yes
TVS Protection: Yes
BEC: 3.3V 0.5A &amp 5V 2A
Mounting size: 25.5 x 25.5mm/M2

ESC Specifications

Input: 3~6S Lipo (12.6~25.2V)
Continue Current: 40Ax4
Burst current: 45A (10 Seconds)
Target：BLHeli_32 MAMBA F40_128K
SOFT: Dshot300/600
PWM:24~128K

Include

1x Diatone Mamba MK4 F740 3-6S AIO Whoop/Toothpick Flight Controller w/ 40A 32bit 4in1 ESC - WIFI
1x High Frequency 470uF/35V
1x AIR UNIT sh1.0
1x 16AWG 60mm
1x AMASS Original XT60

Wiring Diagram


Diatone Mamba MK4 F740 3-6S AIO Whoop/Toothpick Flight Controller w/ 4

The MAMBA MK4 F740 features a powerful F7 processor, 40A ESC, Wifi configuration, Barometer, OSD Chip, 16M Blackbox memory, and an easy VTX connection. Ideal for Sub 250g, 3, 4, and 5 inch quads.
Specifications
Flight Controller

Target：MAMBA F722_2022B
MCU: 216MHz STM32F722
GYRO: ICM-42688-P
Barometer: Yes
OSD: Yes
Blacbox: 16 M Flash Memory
Uarts: 6 Set
Motor Signal:4 Set
ESC Soft: Dshot300/600
ESC Telemetry: Yes
Power Led: Yes
LED Controller: BF LED
AIR UNIT Port: Yes
WIFI: No（Basic）/SpeedyBee (WIFI) Optional
F.Port: Yes
RSSI: No
Buzz: Yes
Input: 3~6S Lipo (12.6~25.2V)
BEC Protection: Yes
Receiver Protection: Yes
TVS Protection: Yes
BEC: 3.3V 0.5A&amp 5V 2A
Mounting size: 25.5×25.5mm/M2

ESC

Input: 3~6S Lipo (12.6~25.2V)
Continue Current: 40A×4
Burst current: 45A (10S)
Target：BLHeli_32 MAMBA F40_128K
SOFT: Dshot300/600
PWM:24~128K

Includes

1x MAMBA MK4 F740 6S 25x25 AIO Flight Controller with 40A 32Bit ESC &amp WiFi
1x High Frequency 470uF/35V
1x AIR UNIT sh1.0 Cable
2x 16AWG 60mm

1x AMASS Original XT60

Wiring Diagram




The MAMBA MK4 F740 features a powerful F7 processor, 40A ESC, Wifi configuration, Barometer, OSD Chip, 16M Blackbox memory, and an easy VTX connection. Ideal for Sub 250g, 3, 4, and 5 inch quads. Specifications Flight Controller Target：MAMBA F722_2022B MCU: 216MHz STM32F722 GYRO: ICM-42688-P Barometer: Yes OSD: Yes Bla

MAMBA MK4 F740 6S 25x25 AIO Flight Controller with 40A 32Bit ESC & WiFi

The MAMBA MK4 F740 features a powerful F7 processor, 40A ESC, Wifi configuration, Barometer, OSD Chip, 16M Blackbox memory, and an easy VTX connection. Ideal for Sub 250g, 3, 4, and 5 inch quads. Specifications Flight Controller Target：MAMBA F722_2022B MCU: 216MHz STM32F722 GYRO: ICM-42688-P Barometer: Yes OSD: Yes Blacbox: 16 M Flash Memory Uarts: 6 Set Motor Signal:4 Set ESC Soft: Dshot300/600 ESC Telemetry: Yes Power Led: Yes LED Controller: BF LED AIR UNIT Port: Yes WIFI: No（Basic）/SpeedyBee (WIFI) Optional F.Port: Yes RSSI: No Buzz: Yes Input: 3~6S Lipo (12.6~25.2V) BEC Protection: Yes Receiver Protection: Yes TVS Protection: Yes BEC: 3.3V 0.5A&amp; 5V 2A Mounting size: 25.5×25.5mm/M2 ESC Input: 3~6S Lipo (12.6~25.2V) Continue Current: 40A×4 Burst current: 45A (10S) Target：BLHeli_32 MAMBA F40_128K SOFT: Dshot300/600 PWM:24~128K Includes 1x MAMBA MK4 F740 6S 25x25 AIO Flight Controller with 40A 32Bit ESC &amp;

Processor (MCU)

The FC is the brain or the CPU of your quad. It has a processor and other components that allow it to listen to your inputs and tells the quad what to do. FCs are commonly sold together with other components integrated or stacked (like ESCs and video transmitters). For beginners, choose a FC with a F4 or F7 processor that has a compatible mount with your frame.

Flight Controllers

FC Stack Mount

Built-in VTX

Built-in ESC

Foxeer

Foxeer H743 X8 4-8S 30x30 Flight Controller

The Foxeer H7 is an advanced and reliable 4-8S flight controller with dual built-in BECs and a barometer. It features a fast and powerful MPU6000 processor to provide accurate and consistent performance with less vibration in flight. Enjoy worry-free flying with this top-class controller.
Check out our 30x30 Flight Controllers as well as Foxeer Collection!
Features


5V/10V Dual BEC
MPU6000 32K Flash Rate
Plug &ampamp Play with Foxeer cameras


Specifications


Model: Foxeer H7
CPU: FOXEERH743
Gyro: MPU6000
Barometer: DPS310
Power Supply: 4-8S Lipo
BEC Output: 3.3V/0.5ADC5V/2ADC10V/2A
OSD: BF OSD
Black Box: 16M Flash Memory
UART: 6 Sets+Rx8
ESC Telemetry: RX8
Buzzer: Yes
Connector: DJI/HDZero
Smart Audio: Yes
LED: 1 Set 2812 LED
USB: Type-C
Servo: S1,S2
X8: Supported
Firmware(BetaFlight): FOXEERH743
Size: 37X37mm
Mounting Hole: 30.5 x 30.5mm, Φ4mm

Weight(g): 7.8g

Working Temperature: -20℃ ~ +55℃
Working Humidity: 20～95%

Storage Temperature: -20℃ ~ +70℃

X8 Setup CLI

X8 Setup CLI

Includes

1x Foxeer H743 X8 4-8S 30x30 Dual BEC Barometer Flight Controller - MPU6000
4x M3 Grommets

1x Cable



The Foxeer H7 is an advanced and reliable 4-8S flight controller with dual built-in BECs and a barometer. It features a fast and powerful MPU6000 processor to provide accurate and consistent performance with less vibration in flight. Enjoy worry-free flying with this top-class controller. Check out our 30x30 Flight Con

Foxeer H743 X8 4-8S 30x30 Dual BECs Barometer Flight Controller - MPU6000 from WREKD Co.

Foxeer H743 X8 4-8S 30x30 Dual BECs Barometer Flight Controller - MPU6000

The Foxeer H7 features 32KHz processing power, MPU6000 gyro, 6 sets of UARTs, 8 Motor channels, and is capable of running on 4-8S power!
Specifications

CPU: FOXEERH743
Gyro: MPU6000
Barometer: DPS310
Power Supply: 4~8S Lipo
BEC Output: 3.3V/0.5ADC5V/2ADC10V/2A
OSD: BF OSD
Black Box: 16M Flash Memory
UART: 6 Sets+Rx8
ESC Telemetry: RX8
Buzzer: YES
Connector: DJI/HDZero
Smart Audio: YES
LED: 1 Set 2812 LED
USB: Type-C
Servo: S1,S2
X8: Supported
Firmware: BetaFlight: FOXEERH743 ； Ardupilot
Working Temperature: -20℃ ~ +55℃
Working Humidity: 20～95%
Storage Temperature: -20℃ ~ +70℃
Size: 37X37mm
Mounting Hole: 30.5X30.5mm,Φ4mm
Weight: 7.8g


Includes

1x H7 4-8S 30x30 Flight Controller with MPU6000 and Barometer
4x Rubbers Columns
1x Cable

Wiring Diagram


The Foxeer H7 features 32KHz processing power, MPU6000 gyro, 6 sets of UARTs, 8 Motor channels, and is capable of running on 4-8S power! Specifications CPU: FOXEERH743 Gyro: MPU6000 Barometer: DPS310 Power Supply: 4~8S Lipo BEC Output: 3.3V/0.5A;DC5V/2A;DC10V/2A OSD: BF OSD Black Box: 16M Flash Memory UART: 6 Sets+Rx8

H7 4-8S 30x30 Flight Controller with MPU6000 and Barometer

The Foxeer H7 features 32KHz processing power, MPU6000 gyro, 6 sets of UARTs, 8 Motor channels, and is capable of running on 4-8S power!
Specifications

CPU: FOXEERH743
Gyro: MPU6000
Barometer: DPS310
Power Supply: 4~8S Lipo
BEC Output: 3.3V/0.5A;DC5V/2A;DC10V/2A
OSD: BF OSD
Black Box: 16M Flash Memory
UART: 6 Sets+Rx8
ESC Telemetry: RX8
Buzzer: YES
Connector: DJI/HDZero
Smart Audio: YES
LED: 1 Set 2812 LED
USB: Type-C
Servo: S1,S2
X8: Supported
Firmware: BetaFlight: FOXEERH743 ； Ardupilot
Working Temperature: -20℃ ~ +55℃
Working Humidity: 20～95%
Storage Temperature: -20℃ ~ +70℃
Size: 37X37mm
Mounting Hole: 30.5X30.5mm,Φ4mm
Weight: 7.8g


Includes

1x H7 4-8S 30x30 Flight Controller with MPU6000 and Barometer
4x Rubbers Columns
1x Cable

Wiring Diagram


FOXEER

The Foxeer H7 is an advanced and reliable 4-8S flight controller with dual built-in BECs and a barometer. It features a fast and powerful MPU6000 processor to provide accurate and consistent performance with less vibration in flight. Enjoy worry-free flying with this top-class controller.
Check out our 30x30 Flight Controllers as well as Foxeer Collection!
Features


5V/10V Dual BEC
MPU6000 32K Flash Rate
Plug &amp Play with Foxeer cameras


Specifications


Model: Foxeer H7
CPU: FOXEERH743
Gyro: MPU6000
Barometer: DPS310
Power Supply: 4-8S Lipo
BEC Output: 3.3V/0.5ADC5V/2ADC10V/2A
OSD: BF OSD
Black Box: 16M Flash Memory
UART: 6 Sets+Rx8
ESC Telemetry: RX8
Buzzer: Yes
Connector: DJI/HDZero
Smart Audio: Yes
LED: 1 Set 2812 LED
USB: Type-C
Servo: S1,S2
X8: Supported
Firmware(BetaFlight): FOXEERH743
Size: 37X37mm
Mounting Hole: 30.5 x 30.5mm, Φ4mm

Weight(g): 7.8g

Working Temperature: -20℃ ~ +55℃
Working Humidity: 20～95%

Storage Temperature: -20℃ ~ +70℃

X8 Setup CLI

X8 Setup CLI

Includes

1x Foxeer H743 X8 4-8S 30x30 Dual BEC Barometer Flight Controller - MPU6000
4x M3 Grommets

1x Cable



Foxeer H743 X8 4-8S 30x30 Dual BECs Barometer Flight Controller - MPU6

T-Motor

T-Motor F7 Pro Full Function 30x30 Flight Controller - Wifi, Bluetooth

TMOTOR

T-Motor has come out with one of the most advanced F7 flight controllers on the market. With 8 motor outputs, built-in Wi-Fi and Bluetooth, this FC is ready to take on even the most demanding of FPV tasks.
Browse our 30x30 Flight Controllers and all our T-Motor products!

Features

Wi-Fi
Bluetooth
Built-in blackbox for data logging
8 PWM outputs
DJI air unit plug

Specifications

MCU: STM32F722 RET6
IMU: ICM42688
Barometer: BMP280
Input Voltage: 3-8S
BEC: 10V/2A, 5V/3A
OSD: AT7456
Blackbox: 16MB Flash
Motor Outputs: 8
UARTS: 6
Target: TMOTOR F7 V2
Dimensions: 37x37x7.5mm
Mounting Pattern: 30x30mm
Weight: 8.1g

Includes

1x T-Motor F7 Pro Full Function 30x30 Flight Controller







The T-Motor F7 Pro Full Function 30x30 Flight Controller w/ Wifi & Bluetooth is a high performance FC packed with features and convenience. This powerful FC is ready for anything.

T-Motor F7 Pro Full Function 30x30 Flight Controller w/ Wifi & Bluetooth

T-Motor F7 Pro Full Function 30x30 Flight Controller w/ Wifi & Bluetooth for Sale

T-Motor's F7 Pro flight controller has arrived! This flight controller is full featured and designed with Cinelifter quads in mind. It has eight PWM outputs all on one convenient connector and is plug and play with the DJI Air Unit using the included cable. The flight controller has built in Wi-Fi and Bluetooth so you

T-Motor F7 Pro Flight Controller - 30x30mm

T-Motor Hobby

T-Motor F7 Pro Flight Controller - 30x30mm from WREKD Co.

T-Motor has come out with one of the most advanced F7 flight controllers on the market. With 8 motor outputs, built-in Wi-Fi and Bluetooth, this FC is ready to take on even the most demanding of FPV tasks.
Browse our 30x30 Flight Controllers and all our T-Motor products!

Features

Wi-Fi
Bluetooth
Built-in blackbox for data logging
8 PWM outputs
DJI air unit plug

Specifications

MCU: STM32F722 RET6
IMU: BMI270
Barometer: BMP280
Input Voltage: 3-8S
BEC: 10V/2A, 5V/3A
OSD: AT7456
Blackbox: 16MB Flash
Motor Outputs: 8
UARTS: 6
Target: TMOTOR F7 V2
Dimensions: 37x37x7.5mm
Mounting Pattern: 30x30mm
Weight: 8.1g

Includes

1x T-Motor F7 Pro Full Function 30x30 Flight Controller







T-Motor has come out with one of the most advanced F7 flight controllers on the market. With 8 motor outputs, built-in Wi-Fi and Bluetooth, this FC is ready to take on even the most demanding of FPV tasks. Browse our 30x30 Flight Controllers and all our T-Motor products! Features Wi-Fi Bluetooth Built-in blackbox for d

T-Motor F7 Pro Full Function 30x30 Flight Controller w/ Wifi & Bluetooth from WREKD Co.

T-Motor F7 Pro Full Function 30x30 Flight Controller w/ Wifi &amp Bluetooth

The best quality First Person View equipment. Free or discounted shipping on all orders.Drone Racing, RC Airplanes, FPV Cameras, FPV Goggles, Video Transmitters, RC Quads, Drone Antennas, Lipo Batteries, and Ground Station Equipment.All available for amateurs, schools, hobbyists, government, and wholesale buyers.

T-Motor F7 Pro Full Function 30x30 Flight Controller w/ Wifi - RMRC

Tiger Motors

T-Motor's F7 Pro Flight Controller has arrived! Enjoy full function in a wireless state! Great for cinematic professional use. This FC features 8 UARTS, WiFi and Bluetooth capabilites, and a 30.5x30.5 mounting pattern.Now with ICM42688 gyro.

T-Motor's F7 Pro Flight Controller has arrived! Enjoy full function in a wireless state! Great for cinematic professional use. This FC features 8 UARTS, WiFi and Bluetooth capabilites, and a 30.5x30.5 mounting pattern.
Now with ICM42688 gyro.

T-Motor F7 PRO Flight Controller w/ WiFi + Bluetooth

T-Motor's F7 Pro Flight Controller is here. Fully flashable and configurable over bluetooth/wifi! Great for cinematic professional use. This FC features 8 UARTS, WiFi and Bluetooth capabilities, MPU6000 gyro, BMP280 barometer, 16mb flash and 8 motor outputs!
Specifications

MCU: STMF722RET6
Gyro: MPU6000
Barometer: BMP280
Blackbox Memory: 16Mb
Input Voltage: 3-8S Lipo
BEC Output: 10V/2A, 5V/3A
OSD: AT7456
UARTS: 6 (1,2,3,4,5,6)
Dimensions: 37mm x 37mm x 7.5mm
Mounting Holes: 30.5mm x 30.5mm
Weight: 8.1g
Firmware Target: TMOTOR F7 V2

Includes

1 x T-Motor F7 Pro Flight Controller

1 x FC to ESC Cable (Wired for 4 Motor Output)
1 x FC to ESC Cable (Wired for 8 Motor Output)
1 x FC to DJI Air Unit Cable
5 x Vibration Dampeners

Wiring Diagram


T-Motor's F7 Pro Flight Controller is here. Fully flashable and configurable over bluetooth/wifi! Great for cinematic professional use. This FC features 8 UARTS, WiFi and Bluetooth capabilities, MPU6000 gyro, BMP280 barometer, 16mb flash and 8 motor outputs! Specifications MCU: STMF722RET6 Gyro: MPU6000 Barometer: BMP2

F7 Pro Full Function 30x30 Flight Controller with Wifi & Bluetooth

FETtec

FETtec KISS G4 Flight Controller

The FETtec FC G4 features the latest STM32G473 Processor. Providing unparalleled processing power to your aircraft. Along with an IIM-42652 SPI gyro, two 5v BECs, 6-27V (2-6S) power handling, and a host of other features, the G4 from FETtec is on the cutting edge of Flight Controller technology. This version includes analog OSD.
Specifications

Input Voltage: 2-6S LiPo

MCU: STM32G4

Gyro: IIM-42652 SPI

OSD: Graphic OSD (STM32)

UARTs: 5 Sets

ESC Connections: 8-Pin

Firmware: FETtec Alpha FC firmware (KISS FC firmware flashable)

BEC: 5V / 16V
Buzzer: Supported
Stack Size: 20x20 / 30x30

Dimensions: 37.19x37.19x7.9mm

Weight: 5.37g

Includes

1x G4 2-6S 20x20-30x30 FC
1x 8-Pin ESC Cable
1x 6-Pin Cable
1x 4-Pin Cable


The FETtec FC G4 features the latest STM32G473 Processor. Providing unparalleled processing power to your aircraft. Along with an IIM-42652 SPI gyro, two 5v BECs, 6-27V (2-6S) power handling, and a host of other features, the G4 from FETtec is on the cutting edge of Flight Controller technology. This version includes a

G4 2-6S 20x20-30x30 KISS Flight Controller


The FETtec FC G4 features the latest STM32G4 processor. Providing unparalleled processing power to your aircraft. Along with an MPU6000 gyro, two 5v BECs, 6-27V (2-6S) power handling, and a host of other features, the G4 from FETtec is on the cutting edge of Flight Controller technology.
Features:


Latest STM32G4 Processor


170Mhz + Math accelerator


MPU6000




Supply voltage 6-27V (2S-6S Lipo)


2x dedicated onboard BEC (max. 600mA each)


5V BEC for RX


5V/16V BEC for VTX (switchable and real Pit*)




2x 8 pin connector for solder free ESC connection


Connector 1: ESC signal 1-4, telemetry, VCC, GND


Connector 2: ESC signal 5-8 (depending on UAV type 1-4), telemetry, VCC, GND




1x 8 pin connector for solder free VTX, cam connection and OSD or digital systems


real Pit* VCC, GND, Video in, Video out, BEC 5V/16V, VCS/TX3, RX3




2x 6 pin connectors for serials


RX1, TX1, 3.3V, VCC, 5V, GND


RX3, VCS/TX3, RGB LED, VCC, 5V, GND




1x 4 pin connector for receiver


Signal, TLM, 5V, GND




5 UART serials


UART 1 free


UART 2 used for Receiver


UART 3 free


UART 4 used for onboard OSD, can be set free


UART 5 used for ESCs / TLM / Onewire




4 ESC solder pads (Signal/GND) in each corner


Buzzer pads


4 tiny RGB LEDs (selectable color)


Supported ESC protocols


PWM, Oneshot125, Oneshot42, Dshot150/300/600/1200/2400, FETtec Onewire




FETtec KISS firmware


Onboard OSD


Graphic OSD (STM32)


Full KISS Tuning





Filter (PIDs, Rates, Settings)
LED control (RGB LED, Racewire)
VTX
Live data graphs (Voltage, motor rpm, current, motor temp, gyro values, link quality)
KISS GPS support + live map
Custom graphic pilot logo
Stick overlay
Custom layout
can be deactivated for usage of digital systems



Connector type: JST-SH-1mm



*real Pit-Mode: A power supply pin which is remotely switchable

Dimensions:



Maximum outside dimensions: 37,2 x 37,2mm, without outside tips 30 x 30mm


Mounting hole arrangement:


20 x 20mm with M2 mounting hole (expandable to M3)


30 x 30mm with M3 mounting hole


30 x 30mm mounting hole tips are removable to reduce overall FC size




Overall height: 7,9mm


Weight: 5,37g



Firmware:

KISS Firmware
FETtec OSD Firmware


Scope of delivery:

1x FETtec FC G4
1x 8 pin cable (open on one side)
1x 6 pin cable (open on one side)


Related links to "FETtec FC G4"

 Do you have any questions concerning this product?
 Further products by FETtec

Available downloads:

 Download FETtec FC G4 manual


The FETtec FC G4 features the latest STM32G4 processor. Providing unparalleled processing power to your aircraft. Along with an MPU6000 gyro, two 5v BECs, 6-27V (2-6S) power handling, and a host of other features, the G4 from FETtec is on the cutting edge of Flight Controller technology. Features: Latest STM32G4 Proces

FETtec FC G4

BetaFPV

BetaFPV F405 V5 20A Toothpick AIO Flight Controller - F4 FC, 20A ESC

BETAFPV

Based on the F405 2-4S 20A Flight Controller V4, the F405 4S 20A Toothpick Flight Controller V5 applies a new ICM42688 gyro and ESC chip that comes with BLUEJAY ESC firmware so it supports bidirectional D-shot. In addition to plug-and-play ports for the receiver and HD Digitial VTX, the same as the V4 board, the V5 board is made with a more rational layout for easy solder and preventing solder from jumping to another pad and shorting components.
Check out all our whoop flight controllers, and all our BetaFPV gear!



Features

Not only is the flight controller board made with a rational layout, but it is also designed with larger solder pads. It is very easy for pilots to solder external electronics.
The flight controller is capable of handling 20A continuous current and reaching 25A peak current due to high-quality MOSFETs.
Soldering motor wires to the pad directly allows lower resistance for more current on motors. Besides, solder pads are reinforced by thick copper and edge plating processes, ensuring a solid value and durable use.
Reserving the UART ports layout, UART3 for RX, UART4 for HD digital VTX, UART6 for Analog VTX, and UART1 for spare use, it is more convenient for pilots to solder.
This board comes with a 25.5x25.5mm whoop mounting pattern this board can be added to both the toothpick drone and the cinematic whoop quadcopter



Note: F405 4S 20A FC V5 is available to flash both BLHeli_S and BLUEJAY ESC firmware and it comes with default BLUEJAY firmware. The main difference is that the BLUEJAY firmware supports bidirectional D-shot, while BLHeli_S does not support it.


Comparison to F405 2-4S 20A V4 FC
We upgraded the F405 2-4S 20A V4 board to V5 by adopting ICM42688 gyro instead of MPU6000 and adding some new features. ICM42688 gyro works great in most cases. Except for the gyro, the V5 board comes with a completely new ESC firmware that supports bidirectional D-shot. The way to connect motors changed and is solderable only on the V5 board. Besides the V5 FC board features high-quality material for stability and durability. The below pictures show the difference between the two flight controllers.

Note: The F405 2-4S 20A Flight Controller V4 with BMI270 gyro will be available for purchase for a period of time.
Diagram for Toothpick F405 20A AIO FC V5
The board integrates 2 LEDs, including the Power LED (Red) and the FC LED (Blue).







LED
Status
Description


Power LED (Red)
Solid
Power on


FC LED (Blue)
Solid
Motor Armed







Connecting External RX/HD Digital VTX

F405 4S 20A FC V5 integrates the Plug &ampamp Play port for the external RX and HD digital VTX, and there will be a 4-pin connector for RX and a 6-pin connector for HD digital VTX in the package. Thus, we highly recommend pilots use the port to save the solder work.












FC &ampamp ESC Firmware:
The default firmware is including CLI dump file. But if you flash firmware from the Betaflight configurator official site, please flash a CLI dump file for F405 4S 20A FC V5. We offer the default firmware and CLI dump file to download.

Download the FC default firmware betaflight_4.3.1_BETAFPVF405 and CLI dump file.

F405 4S 20A FC V5 is available to flash both BLHeli_S and BLUEJAY ESC firmware and it comes with default BLUEJAY firmware. The main difference is that the BLUEJAY firmware supports bidirectional D-shot, while BLHeli_S does not support it. Here are the download links for two firmware.
Here are the download links for ESC firmware. Please configure the BLUEJAY firmware through ESC - Configurator or Bluejay Configurator software.

Download the BLUEJAY ESC firmware
Download the ESC - Configurator
Download the Bluejay Configurator

We offer BLHeli_S ESC firmware for pilots. Please configure the BLHeli_S ESC firmware through BLheliSuite, BLHeli - Configurator, or ESC - Configurator software.

Download the BLHeli_S ESC firmware

Download the BLHeliSuite16714902a
Download the BLHeli - Configurator
Download the ESC - Configurator


frame like Pavo25 and X-knight 35.

Specifications:
Flight Controller

CPU: STM32F405RGT6
Six-Axis: ICM42688 (SPI connection)
Mounting Size: 25.5x25.5mm (M2 Anti-vibration rubber damper available)
FC Firmware: betaflight_4.3.1_BETAFPVF405
OSD: Built-in Betaflight OSD (OSD chip: AT7456E)
Receiver: SBUS/CRSF/DSMX Receiver
BEC: 5V 3A
Built-in current sensor
Weight: 8.35g

ESC

ESC Chip: SILABS EFM8BB21F16G-C
Support D-shot150, D-shot300, D-shot600, Oneshot125, Multishot, PWM
Input voltage: 2S-4S Lipo
Continuous current: 20A
Peak current: 25A
Firmware: G_H_20_48_v0.16.HEX (Default BLUEJAY), BLHeli_S (Optional)

Includes

1x BetaFPV F405 V5 2-4S AIO Whoop/Toothpick Flight Controller (w/ 20A 8Bit 4in1 ESC) - ICM42688
1x Cable Pigtail (XT30)
1x 6-Pin Connector for Digital VTX

1x4-Pin Connector for RX

4x M2x12 Screws
8x M2 Nuts
4x M2 Anti-vibration..

Based on the F405 2-4S 20A Flight Controller V4, the F405 4S 20A Toothpick Flight Controller V5 applies a new ICM42688 gyro and ESC chip that comes with BLUEJAY ESC firmware so it supports bidirectional D-shot. In addition to plug-and-play ports for the receiver and HD Digitial VTX, the same as the V4 board, the V5 boa

BetaFPV F405 V5 2-4S HD AIO Whoop/Toothpick Flight Controller (w/ 20A 8Bit 4in1 ESC) - ICM42688 from WREKD Co.

BetaFPV F405 V5 2-4S HD AIO Whoop/Toothpick Flight Controller (w/ 20A 8Bit 4in1 ESC) - ICM42688

Five33

Based on the F405 2-4S 20A Brushless Flight Controller V4, the F405 4S 20A Toothpick Brushless Flight Controller V5 applies a new ICM42688 gyro and ESC chip that comes with BLUEJAY ESC firmware so it supports bidirectional D-shot. In addition to plug&ampplay ports for the receiver and HD Digitial VTX the same as the V4 board, the V5 board is made with a rational layout for easy solder and preventing solder from jumping to another pad and shorting components.

Bullet Point

Not only is the flight controller board made with a rational layout but it is also designed with larger solder pads. It is very easy for pilots to solder external electronics.
The flight controller is capable of handling 20A continuous current and reaching 25A peak current due to high-quality MOSFETs.
Soldering motor wires to pad directly allows lower resistance for more current on motors. Besides, solder pads are reinforced by thick copper and edge plating process, ensuring a solid value and durable use.
Reserving the UART ports layout, UART3 for RX, UART4 for HD digital VTX, UART6 for Analog VTX and UART1 for spare use, it is more convenient for pilots to solder.
Come with a 25.5*25.5mm whoop mounting pattern, this board can be added to both the toothpick drone and the cinematic whoop quadcopter frame like Pavo25 and X-knight 35.




Specifications
Flight Controller

CPU: STM32F405RGT6
Six-Axis: ICM42688 (SPI connection)
Mounting Size: 25.5*25.5mm (M2 Anti-vibration rubber damper available)
FC Firmware: betaflight_4.3.1_BETAFPVF405
OSD: Built-in Betaflight OSD (OSD chip: AT7456E)
Receiver: SBUS/CRSF/DSMX Receiver
BEC: 5V 3A
Built-in current sensor
Weight: 8.35g

ESC

ESC Chip: SILABS EFM8BB21F16G-C
Support D-shot150, D-shot300, D-shot600, Oneshot125, Multishot, PWM
Input voltage: 2S-4S Lipo
Continuous current: 20A
Peak current: 25A
Firmware: G_H_20_48_v0.16.HEX (Default BLUEJAY), BLHeli_S (Optional)


Note: F405 4S 20A FC V5 is available to flash both BLHeli_S and BLUEJAY ESC firmware and it comes with default BLUEJAY firmware. The main difference is that the BLUEJAY firmware supports bidirectional D-shot, while BLHeli_S does not support it.

Comparison to F405 2-4S 20A V4 FC

We upgraded the F405 2-4S 20A V4 board to V5 by adopting ICM42688 gyro instead of MPU6000 and adding some new features. ICM42688 gyro works great in most cases. Except for the gyro, the V5 board comes with a completely new ESC firmware that supports bidirectional D-shot. The way to connect motors changed and is solderable only on the V5 board. Besides the V5 FC board features high-quality material for stability and durability. The below pictures show the difference between the two flight controllers.

Note: The F405 2-4S 20A Flight Controller V4 with BMI270 gyro will be available for purchase for a period of time.
Diagram for Toothpick F405 20A AIO FC V5
The board integrates 2 LEDs, including the Power LED (Red) and the FC LED (Blue).






LED
Status
Description


Power LED (Red)
Solid
Power on


FC LED (Blue)
Solid
Motor Armed





Connecting External RX/HD Digital VTX

F405 4S 20A FC V5 integrates the Plug &amp Play port for the external RX and HD digital VTX, and there will be a 4-pin connector for RX and a 6-pin connector for HD digital VTX in the package. Thus, we highly recommend pilots use the port to save the solder work.













FC &amp ESC Firmware
The default firmware is including CLI dump file. But if you flash firmware from the Betaflight configurator official site, please flash a CLI dump file for F405 4S 20A FC V5. We offer the default firmware and CLI dump file to download.

Download the FC default firmware betaflight_4.3.1_BETAFPVF405 and CLI dump file.

F405 4S 20A FC V5 is available to flash both BLHeli_S and BLUEJAY ESC firmware and it comes with default BLUEJAY firmware. The main difference is that the BLUEJAY firmware supports bidirectional D-shot, while BLHeli_S does not support it. Here are the download links for two firmware.
Here are the download links for ESC firmware. Please configure the BLUEJAY firmware through ESC - Configurator or Bluejay Configurator software.

Download the BLUEJAY ESC firmware
Download the ESC - Configurator
Download the Bluejay Configurator

We offer BLHeli_S ESC firmware for pilots. Please configure the BLHeli_S ESC firmware through BLheliSuite, BLHeli - Configurator, or ESC - Configurator software.

Download the BLHeli_S ESC firmware

Download the BLHeliSuite16714902a
Download the BLHeli - Configurator
Download the ESC - Configurator

Recommend Parts


Motors: 1404 Brushless Motors, 1506 Brushless Motors

Battery: 2S 600mAh, 3S/4S 850mAh, 4S 750mAh, or 4S 1000mAh

Frame: Pavo25 Frame, X-knight 35, or other frames with whoop mounting pattern.


Package

1 * F405 4S 20A Toothpick Brushless Flight Controller V5 BLHeli_S (ICM42688)
1 * Cable Pigtail (XT30)
1 * 6-Pin Connector for Digital VTX

1 * 4-Pin Connector for RX

4 * M2x12 Screws
8 * M2 Nuts
4 * M2 Anti-vibration Rubber Dampers



Based on the F405 2-4S 20A Brushless Flight Controller V4, the F405 4S 20A Toothpick Brushless Flight Controller V5 applies a new ICM42688 gyro and ESC chip that comes with BLUEJAY ESC firmware so it supports bidirectional D-shot. In addition to plug&amp;play ports for the receiver and HD Digitial VTX the same as the V

BETAFPV Toothpick F405 4S 20A Brushless Flight Controller V5 BLHELI_S(ICM42688)

Based on the F405 2-4S 20A Flight Controller V4, the F405 4S 20A Toothpick Flight Controller V5 applies a new ICM42688 gyro and ESC chip that comes with BLUEJAY ESC firmware so it supports bidirectional D-shot. In addition to plug-and-play ports for the receiver and HD Digitial VTX, the same as the V4 board, the V5 board is made with a more rational layout for easy solder and preventing solder from jumping to another pad and shorting components.
Check out all our whoop flight controllers, and all our BetaFPV gear!



Features

Not only is the flight controller board made with a rational layout, but it is also designed with larger solder pads. It is very easy for pilots to solder external electronics.
The flight controller is capable of handling 20A continuous current and reaching 25A peak current due to high-quality MOSFETs.
Soldering motor wires to the pad directly allows lower resistance for more current on motors. Besides, solder pads are reinforced by thick copper and edge plating processes, ensuring a solid value and durable use.
Reserving the UART ports layout, UART3 for RX, UART4 for HD digital VTX, UART6 for Analog VTX, and UART1 for spare use, it is more convenient for pilots to solder.
This board comes with a 25.5x25.5mm whoop mounting pattern this board can be added to both the toothpick drone and the cinematic whoop quadcopter



Note: F405 4S 20A FC V5 is available to flash both BLHeli_S and BLUEJAY ESC firmware and it comes with default BLUEJAY firmware. The main difference is that the BLUEJAY firmware supports bidirectional D-shot, while BLHeli_S does not support it.


Comparison to F405 2-4S 20A V4 FC
We upgraded the F405 2-4S 20A V4 board to V5 by adopting ICM42688 gyro instead of MPU6000 and adding some new features. ICM42688 gyro works great in most cases. Except for the gyro, the V5 board comes with a completely new ESC firmware that supports bidirectional D-shot. The way to connect motors changed and is solderable only on the V5 board. Besides the V5 FC board features high-quality material for stability and durability. The below pictures show the difference between the two flight controllers.

Note: The F405 2-4S 20A Flight Controller V4 with BMI270 gyro will be available for purchase for a period of time.
Diagram for Toothpick F405 20A AIO FC V5
The board integrates 2 LEDs, including the Power LED (Red) and the FC LED (Blue).







LED
Status
Description


Power LED (Red)
Solid
Power on


FC LED (Blue)
Solid
Motor Armed







Connecting External RX/HD Digital VTX

F405 4S 20A FC V5 integrates the Plug &amp Play port for the external RX and HD digital VTX, and there will be a 4-pin connector for RX and a 6-pin connector for HD digital VTX in the package. Thus, we highly recommend pilots use the port to save the solder work.












FC &amp ESC Firmware:
The default firmware is including CLI dump file. But if you flash firmware from the Betaflight configurator official site, please flash a CLI dump file for F405 4S 20A FC V5. We offer the default firmware and CLI dump file to download.

Download the FC default firmware betaflight_4.3.1_BETAFPVF405 and CLI dump file.

F405 4S 20A FC V5 is available to flash both BLHeli_S and BLUEJAY ESC firmware and it comes with default BLUEJAY firmware. The main difference is that the BLUEJAY firmware supports bidirectional D-shot, while BLHeli_S does not support it. Here are the download links for two firmware.
Here are the download links for ESC firmware. Please configure the BLUEJAY firmware through ESC - Configurator or Bluejay Configurator software.

Download the BLUEJAY ESC firmware
Download the ESC - Configurator
Download the Bluejay Configurator

We offer BLHeli_S ESC firmware for pilots. Please configure the BLHeli_S ESC firmware through BLheliSuite, BLHeli - Configurator, or ESC - Configurator software.

Download the BLHeli_S ESC firmware

Download the BLHeliSuite16714902a
Download the BLHeli - Configurator
Download the ESC - Configurator


frame like Pavo25 and X-knight 35.

Specifications:
Flight Controller

CPU: STM32F405RGT6
Six-Axis: ICM42688 (SPI connection)
Mounting Size: 25.5x25.5mm (M2 Anti-vibration rubber damper available)
FC Firmware: betaflight_4.3.1_BETAFPVF405
OSD: Built-in Betaflight OSD (OSD chip: AT7456E)
Receiver: SBUS/CRSF/DSMX Receiver
BEC: 5V 3A
Built-in current sensor
Weight: 8.35g

ESC

ESC Chip: SILABS EFM8BB21F16G-C
Support D-shot150, D-shot300, D-shot600, Oneshot125, Multishot, PWM
Input voltage: 2S-4S Lipo
Continuous current: 20A
Peak current: 25A
Firmware: G_H_20_48_v0.16.HEX (Default BLUEJAY), BLHeli_S (Optional)

Includes

1x BetaFPV F405 V5 2-4S AIO Whoop/Toothpick Flight Controller (w/ 20A 8Bit 4in1 ESC) - ICM42688
1x Cable Pigtail (XT30)
1x 6-Pin Connector for Digital VTX

1x4-Pin Connector for RX

4x M2x12 Screws
8x M2 Nuts
4x M2 Anti-vibration Rubber Dampers



BetaFPV F405 V5 2-4S HD AIO Whoop/Toothpick Flight Controller (w/ 20A

Based on the F405 2-4S 20A Brushless Flight Controller V4, the F405 4S 20A Toothpick Brushless Flight Controller V5 applies a new ICM42688 gyro and ESC chip that comes with BLUEJAY ESC firmware so it supports bidirectional D-shot. In addition to plug&ampplay ports for the receiver and HD Digitial VTX the same as the V4 board, the V5 board is made with a rational layout for easy solder and preventing solder from jumping to another pad and shorting components.

Bullet Point

Not only is the flight controller board made with a rational layout but it is also designed with larger solder pads. It is very easy for pilots to solder external electronics.
The flight controller is capable of handling 20A continuous current and reaching 25A peak current due to high-quality MOSFETs.
Soldering motor wires to pad directly allows lower resistance for more current on motors. Besides, solder pads are reinforced by thick copper and edge plating process, ensuring a solid value and durable use.
Reserving the UART ports layout, UART3 for RX, UART4 for HD digital VTX, UART6 for Analog VTX and UART1 for spare use, it is more convenient for pilots to solder.
Come with a 25.5*25.5mm whoop mounting pattern, this board can be added to both the toothpick drone and the cinematic whoop quadcopter frame like Pavo25 and X-knight 35.


Specifications
Flight Controller

CPU: STM32F405RGT6
Six-Axis: ICM42688 (SPI connection)
Mounting Size: 25.5*25.5mm (M2 Anti-vibration rubber damper available)
FC Firmware: betaflight_4.3.1_BETAFPVF405
OSD: Built-in Betaflight OSD (OSD chip: AT7456E)
Receiver: SBUS/CRSF/DSMX Receiver
BEC: 5V 3A
Built-in current sensor
Weight: 8.35g

ESC

ESC Chip: SILABS EFM8BB21F16G-C
Support D-shot150, D-shot300, D-shot600, Oneshot125, Multishot, PWM
Input voltage: 2S-4S Lipo
Continuous current: 20A
Peak current: 25A
Firmware: G_H_20_48_v0.16.HEX (Default BLUEJAY), BLHeli_S (Optional)


Note: F405 4S 20A FC V5 is available to flash both BLHeli_S and BLUEJAY ESC firmware and it comes with default BLUEJAY firmware. The main difference is that the BLUEJAY firmware supports bidirectional D-shot, while BLHeli_S does not support it.

Comparison to F405 2-4S 20A V4 FC

We upgraded the F405 2-4S 20A V4 board to V5 by adopting ICM42688 gyro instead of MPU6000 and adding some new features. ICM42688 gyro works great in most cases. Except for the gyro, the V5 board comes with a completely new ESC firmware that supports bidirectional D-shot. The way to connect motors changed and is solderable only on the V5 board. Besides the V5 FC board features high-quality material for stability and durability. The below pictures show the difference between the two flight controllers.

Note: The F405 2-4S 20A Flight Controller V4 with BMI270 gyro will be available for purchase for a period of time.
Diagram for Toothpick F405 20A AIO FC V5
The board integrates 2 LEDs, including the Power LED (Red) and the FC LED (Blue).





LED
Status
Description


Power LED (Red)
Solid
Power on


FC LED (Blue)
Solid
Motor Armed




Connecting External RX/HD Digital VTX

F405 4S 20A FC V5 integrates the Plug &amp Play port for the external RX and HD digital VTX, and there will be a 4-pin connector for RX and a 6-pin connector for HD digital VTX in the package. Thus, we highly recommend pilots use the port to save the solder work.













FC &amp ESC Firmware
The default firmware is including CLI dump file. But if you flash firmware from the Betaflight configurator official site, please flash a CLI dump file for F405 4S 20A FC V5. We offer the default firmware and CLI dump file to download.

Download the FC default firmware betaflight_4.3.1_BETAFPVF405 and CLI dump file.

F405 4S 20A FC V5 is available to flash both BLHeli_S and BLUEJAY ESC firmware and it comes with default BLUEJAY firmware. The main difference is that the BLUEJAY firmware supports bidirectional D-shot, while BLHeli_S does not support it. Here are the download links for two firmware.
Here are the download links for ESC firmware. Please configure the BLUEJAY firmware through ESC - Configurator or Bluejay Configurator software.

Download the BLUEJAY ESC firmware
Download the ESC - Configurator
Download the Bluejay Configurator

We offer BLHeli_S ESC firmware for pilots. Please configure the BLHeli_S ESC firmware through BLheliSuite, BLHeli - Configurator, or ESC - Configurator software.

Download the BLHeli_S ESC firmware

Download the BLHeliSuite16714902a
Download the BLHeli - Configurator
Download the ESC - Configurator

Recommend Parts


Motors: 1404 Brushless Motors, 1506 Brushless Motors

Battery: 2S 600mAh, 3S/4S 850mAh, 4S 750mAh, or 4S 1000mAh

Frame: Pavo25 Frame, X-knight 35, or other frames with whoop mounting pattern.


Package

1 * F405 4S 20A Toothpick Brushless Flight Controller V5 BLHeli_S (ICM42688)
1 * Cable Pigtail (XT30)
1 * 6-Pin Connector for Digital VTX

1 * 4-Pin Connector for RX

4 * M2x12 Screws
8 * M2 Nuts
4 * M2 Anti-vibration Rubber Dampers




F405 4S 20A Toothpick Brushless Flight Controller V5 BLHeli_S (ICM42688)

Based on the F405 2-4S 20A Brushless Flight Controller V4, the F405 4S 20A Toothpick Brushless Flight Controller V5 applies a new ICM42688 gyro and ESC chip that comes with BLUEJAY ESC firmware so it supports bidirectional D-shot. In addition to plug&ampplay ports for the receiver and HD Digitial VTX the same as the V4 board, the V5 board is made with a rational layout for easy solder and preventing solder from jumping to another pad and shorting components.

Features


Not only is the flight controller board made with a rational layout but it is also designed with larger solder pads. It is very easy for pilots to solder external electronics.
The flight controller is capable of handling 20A continuous current and reaching 25A peak current due to high-quality MOSFETs.
Soldering motor wires to pad directly allows lower resistance for more current on motors. Besides, solder pads are reinforced by thick copper and edge plating process, ensuring a solid value and durable use.
Reserving the UART ports layout, UART3 for RX, UART4 for HD digital VTX, UART6 for Analog VTX and UART1 for spare use, it is more convenient for pilots to solder.
Come with a 25.5*25.5mm whoop mounting pattern, this board can be added to both the toothpick drone and the cinematic whoop quadcopter frame.

Specifications
Flight Controller

CPU: STM32F405RGT6
Six-Axis: ICM42688 (SPI connection)
Mounting Size: 25.5*25.5mm (M2 Anti-vibration rubber damper available)
FC Firmware: betaflight_4.3.1_BETAFPVF405
OSD: Built-in Betaflight OSD (OSD chip: AT7456E)
Receiver: SBUS/CRSF/DSMX Receiver
BEC: 5V 3A
Built-in current sensor
Weight: 8.35g

ESC

ESC Chip: SILABS EFM8BB21F16G-C
Support D-shot150, D-shot300, D-shot600, Oneshot125, Multishot, PWM
Input voltage: 2S-4S Lipo
Continuous current: 20A
Peak current: 25A
Firmware: G_H_20_48_v0.16.HEX (Default BLUEJAY), BLHeli_S (Optional)

Includes


1 * F405 4S 20A Toothpick Brushless Flight Controller V5 BLHeli_S (ICM42688)
1 * Cable Pigtail (XT30)
1 * 6-Pin Connector for Digital VTX

1 * 4-Pin Connector for RX

4 * M2x12 Screws
8 * M2 Nuts
4 * M2 Anti-vibration Rubber Dampers

Wiring Diagram






LED
Status
Description


Power LED (Red)
Solid
Power on


FC LED (Blue)
Solid
Motor Armed





Connecting External RX/HD Digital VTX

F405 4S 20A FC V5 integrates the Plug &amp Play port for the external RX and HD digital VTX, and there will be a 4-pin connector for RX and a 6-pin connector for HD digital VTX in the package. Thus, we highly recommend pilots use the port to save the solder work.




F405 V5 2-4S 25x25 AIO Flight Controller with 8Bit 20A ESC

Based on the F405 2-4S 20A Brushless Flight Controller V4, the F405 4S 20A Toothpick Brushless Flight Controller V5 applies a new ICM42688 gyro and ESC chip that comes with BLUEJAY ESC firmware so it supports bidirectional D-shot. In addition to plug&amp;play ports for the receiver and HD Digitial VTX the same as the V4 board, the V5 board is made with a rational layout for easy solder and preventing solder from jumping to another pad and shorting components. Features Not only is the flight controller board made with a rational layout but it is also designed with larger solder pads. It is very easy for pilots to solder external electronics. The flight controller is capable of handling 20A continuous current and reaching 25A peak current due to high-quality MOSFETs. Soldering motor wires to pad directly allows lower resistance for

BetaFPV Toothpick F405 2-4S 20A AIO Brushless Flight Controller V5 (BLHeli_S/ICM42688)

BetaFPV F4 2-3S AIO Flight Controller V1 - 20A ESC, 2.4GHz ELRS












The BetaFPV V1 F4 2-3S AIO is the perfect choice for modern Whoop/Toothpick builds. Featuring an F4 AIO Flight Controller and 20A 4-in-1 ESC with ELRS serial, this setup guarantees smooth, consistent performance.  It features a dual BEC solution that delivers stable power outputs of 9V@2A for DJI O3 and 5V@3A for external devices. With a 20A ESC, it enables agile flight and increases dynamic. And connector for DJI O3 HD VTX and USB port for easy installation and maintenance. Ideal for HD VTX whoop enthusiasts, offering a heightened level of professionalism and convenience with this FC option.











Note: If you use the F4 2-3S 20A AIO FC V1, the serial port of the SBUS receiver is UART5Check out all our whoop flight controllers, and all our BetaFPV gear!
Features

Designed for HD VTX, it features a dual 9V@2A for DJI O3 and 5V@3A for external device BEC solution to prevent screen blackout on the DJI O3 due to low voltage during throttle increase.
It includes a new DJI O3 6-pin PMU for easy installation without soldering, reducing assembly complexity. Newbie friendly.
The power range of 2-3S provides increased thrust and improved control with a 20A ESC featuring a single NMOS for continuous current capability.
The upgraded onboard receiver allows selective power cutoff for saving power and offers additional UART TX3 and RX3 ports for connecting the external device.
The redesigned solder pad layout ensures larger, more secure pads for easy and reliable soldering, while the relocated USB port at the rear facilitates computer tuning.
It features an STM32F405RGT6 chip, Integrate Serial ELRS 2.4G receiver, 16M black box, barometer, current meter, reserve 3 complete serial ports and a standard SBUS, support GPS, HD VTX, external receiver, and other equipment.

F4 2-3S 20A AIO FC V1 also has extended the USB port to the end for easier parameter adjustment and wiring. And a new DJI O3 6-pin PMU has been added for convenient installation and maintenance.FAQPower cutoff: Removing the chip bead disconnects the power supply, and to reuse the onboard ELRS receiver, soldering the solder pads together restores power.UART3 release: Removing two resistors on the solder pads releases UART3. The left side is TX3, and the right side is RX3. To reconnect, solder the solder pads together when reusing the onboard ELRS receiver.Voltage Switch: The HD VTX connector defaults to 9V. The chip bead is soldered between the 9V pad and the middle pad. To use WalkSnail Avatar HD mini 1s and Lite, please ensure the power supply voltage is 5V. Remove the chip bead first from the 9V pad and solder it between the middle pad and the 5V pad. Alternatively, you can use solder instead the chip bead to switch between the 5V and 9V pads.Motor choice: Avoid selecting motors with excessively high KV ratings, as motors above 20,000KV are prone to burn.Betaflight Firmware and CLIFC firmware: Betaflight_4.4.1_BETAFVF405Download the firmware and CLI dump fileReference link:https://github.com/betaflight/betaflight/releases/tag/4.4.1ESC FirmwareWith BB51 ESC solution, F4 2-3S 20A AIO FC V1 is based on BLHeliSuite16714903 with Bluejay ESC firmware, it supports bidirectional D-shot and RPM filtering in Betaflight, offers 24KHz, 48KHz, and 96KHz fixed PWM frequency for options, and custom start-up melodies. F4 2-3S 20A AIO FC V1 default factory setting is 48KHz and it doesn’t recommend upgrading the 96KHz, or it might cause an error in the motor idle setting, not spinning when disarmed.DO NOT flash the firmware with a shorter interval, otherwise, there will be a certain chance of stalling and burning the flight controller.ESC-Configurator: https://preview.esc-configurator.com/Download BLHeliSuite16714903Download the Bluejay ESC firmware. Please choose C_X_70.HEXConnecting External DevicesPlease note that the board reserves two serial ports and a standard SBUS port, which is available for the external CRSF protocol receiver or GPS module, and SBUS protocol receiver. You can refer to the below picture.
Specifications

Weight: 5.58g (without motor connectors and power cable), 5.92g (with motor connectors)

Mounting Hole Size: 26mm x 26mm
CPU*: STM32F405RGT6 (168MHz)
Six-Axis: ICM42688P (SPI connection)
RX: Serial ELRS 2.4G Receiver
RX firmware version: BETAFPV AIO 2400 RX ELRS V2.5.2
Antenna: Enameled wire
Blackbox Memory: 16MB
Sensor: Barometer(BMP280),  Voltage&ampampCurrent
5V BEC*: 5V 3A@8V supply
9V BEC*: 9V 2A@8V supply

USB Port: SH1.0 4-Pin
Built-in ESC with 20A continuous and peak 25A current
ESC input voltage: 2-3S
FC firmfware version: Betaflight_4.4.1_BETAFPVF405
ESC firmware: C_X_70_48_V0.19.2.hex for BB51 Bluejay hardware
Signal support: D-shot300, D-shot600

Includes

1x BetaFPV V1 F4 2-3S AIO Whoop/Toothpick Flight Controller (w/ 20A 8Bit 4in1 ESC) - ELRS Serial

Wiring Diagram





The BetaFPV V1 F4 2-3S AIO is the perfect choice for modern Whoop/Toothpick builds. Featuring an F4 AIO Flight Controller and 20A 4-in-1 ESC with ELRS serial, this setup guarantees smooth, consistent performance.  It features a dual BEC solution that delivers stable power outputs of 9V@2A for DJI O3 and 5V@3A for exter

BetaFPV F4 20A V1 2-3S AIO Whoop/Toothpick Flight Controller (w/ 20A 8Bit 4in1 ESC) - ELRS 2.4GHz (UART) from WREKD Co.

BetaFPV F4 20A V1 2-3S AIO Whoop/Toothpick Flight Controller (w/ 20A 8Bit 4in1 ESC) - ELRS 2.4GHz (UART)












The BetaFPV V1 F4 2-3S AIO is the perfect choice for modern Whoop/Toothpick builds. Featuring an F4 AIO Flight Controller and 20A 4-in-1 ESC with ELRS serial, this setup guarantees smooth, consistent performance.  It features a dual BEC solution that delivers stable power outputs of 9V@2A for DJI O3 and 5V@3A for external devices. With a 20A ESC, it enables agile flight and increases dynamic. And connector for DJI O3 HD VTX and USB port for easy installation and maintenance. Ideal for HD VTX whoop enthusiasts, offering a heightened level of professionalism and convenience with this FC option.











Note: If you use the F4 2-3S 20A AIO FC V1, the serial port of the SBUS receiver is UART5Check out all our whoop flight controllers, and all our BetaFPV gear!
Features

Designed for HD VTX, it features a dual 9V@2A for DJI O3 and 5V@3A for external device BEC solution to prevent screen blackout on the DJI O3 due to low voltage during throttle increase.
It includes a new DJI O3 6-pin PMU for easy installation without soldering, reducing assembly complexity. Newbie friendly.
The power range of 2-3S provides increased thrust and improved control with a 20A ESC featuring a single NMOS for continuous current capability.
The upgraded onboard receiver allows selective power cutoff for saving power and offers additional UART TX3 and RX3 ports for connecting the external device.
The redesigned solder pad layout ensures larger, more secure pads for easy and reliable soldering, while the relocated USB port at the rear facilitates computer tuning.
It features an STM32F405RGT6 chip, Integrate Serial ELRS 2.4G receiver, 16M black box, barometer, current meter, reserve 3 complete serial ports and a standard SBUS, support GPS, HD VTX, external receiver, and other equipment.

F4 2-3S 20A AIO FC V1 also has extended the USB port to the end for easier parameter adjustment and wiring. And a new DJI O3 6-pin PMU has been added for convenient installation and maintenance.FAQPower cutoff: Removing the chip bead disconnects the power supply, and to reuse the onboard ELRS receiver, soldering the solder pads together restores power.UART3 release: Removing two resistors on the solder pads releases UART3. The left side is TX3, and the right side is RX3. To reconnect, solder the solder pads together when reusing the onboard ELRS receiver.Voltage Switch: The HD VTX connector defaults to 9V. The chip bead is soldered between the 9V pad and the middle pad. To use WalkSnail Avatar HD mini 1s and Lite, please ensure the power supply voltage is 5V. Remove the chip bead first from the 9V pad and solder it between the middle pad and the 5V pad. Alternatively, you can use solder instead the chip bead to switch between the 5V and 9V pads.Motor choice: Avoid selecting motors with excessively high KV ratings, as motors above 20,000KV are prone to burn.Betaflight Firmware and CLIFC firmware: Betaflight_4.4.1_BETAFVF405Download the firmware and CLI dump fileReference link:https://github.com/betaflight/betaflight/releases/tag/4.4.1ESC FirmwareWith BB51 ESC solution, F4 2-3S 20A AIO FC V1 is based on BLHeliSuite16714903 with Bluejay ESC firmware, it supports bidirectional D-shot and RPM filtering in Betaflight, offers 24KHz, 48KHz, and 96KHz fixed PWM frequency for options, and custom start-up melodies. F4 2-3S 20A AIO FC V1 default factory setting is 48KHz and it doesn’t recommend upgrading the 96KHz, or it might cause an error in the motor idle setting, not spinning when disarmed.DO NOT flash the firmware with a shorter interval, otherwise, there will be a certain chance of stalling and burning the flight controller.ESC-Configurator: https://preview.esc-configurator.com/Download BLHeliSuite16714903Download the Bluejay ESC firmware. Please choose C_X_70.HEXConnecting External DevicesPlease note that the board reserves two serial ports and a standard SBUS port, which is available for the external CRSF protocol receiver or GPS module, and SBUS protocol receiver. You can refer to the below picture.
Specifications

Weight: 5.58g (without motor connectors and power cable), 5.92g (with motor connectors)

Mounting Hole Size: 26mm x 26mm
CPU*: STM32F405RGT6 (168MHz)
Six-Axis: ICM42688P (SPI connection)
RX: Serial ELRS 2.4G Receiver
RX firmware version: BETAFPV AIO 2400 RX ELRS V2.5.2
Antenna: Enameled wire
Blackbox Memory: 16MB
Sensor: Barometer(BMP280),  Voltage&ampCurrent
5V BEC*: 5V 3A@8V supply
9V BEC*: 9V 2A@8V supply

USB Port: SH1.0 4-Pin
Built-in ESC with 20A continuous and peak 25A current
ESC input voltage: 2-3S
FC firmfware version: Betaflight_4.4.1_BETAFPVF405
ESC firmware: C_X_70_48_V0.19.2.hex for BB51 Bluejay hardware
Signal support: D-shot300, D-shot600

Includes

1x BetaFPV V1 F4 2-3S AIO Whoop/Toothpick Flight Controller (w/ 20A 8Bit 4in1 ESC) - ELRS Serial

Wiring Diagram





BetaFPV F4 20A V1 2-3S AIO Whoop/Toothpick Flight Controller (w/ 20A 8

F4 2-3S 20A AIO FC V1 is specifically designed for HD VTX, utilizing 2-3S batteries for enhancing the flight experience. It features a dual BEC solution that delivers stable power outputs of 9V@2A for DJI O3 and 5V@3A for external devices. With a 20A ESC, it enables agile flight and increases dynamic. And connector for

BetaFPV F4 2-3S 20A AIO FC V1 ELRS 2.4G Brushless Flight Controller

F4 2-3S 20A AIO FC V1 is specifically designed for HD VTX, utilizing 2-3S batteries for enhancing the flight experience. It features a dual BEC solution that delivers stable power outputs of 9V@2A for DJI O3 and 5V@3A for external devices. With a 20A ESC, it enables agile flight and increases dynamic. And connector for DJI O3 HD VTX and USB port for easy installation and maintenance. Ideal for HD VTX whoop enthusiasts, offering a heightened level of professionalism and convenience with this FC option.

Features

Designed for HD VTX, it features a dual 9V@2A for DJI O3 and 5V@3A for external device BEC solution to prevent screen blackout on the DJI O3 due to low voltage during throttle increase.
It includes a new DJI O3 6-pin PMU for easy installation without soldering, reducing assembly complexity. Newbie friendly.
The power range of 2-3S provides increased thrust and improved control with a 20A ESC featuring a single NMOS for continuous current capability.
The upgraded onboard receiver allows selective power cutoff for saving power and offers additional UART TX3 and RX3 ports for connecting the external device.
Redesigned solder pad layout ensures larger, more secure pads for easy and reliable soldering, while the relocated USB port at the rear facilitates computer tuning.
It features an STM32F405RGT6 chip, Integrate Serial ELRS 2.4G receiver, 16M black box, barometer, current meter, reserve 3 complete serial ports and a standard SBUS, support GPS, HD VTX, external receiver, and other equipment.

Specifications

Weight: 5.58g (without motor connectors and power cable),5.92g (with motor connectors)

Mounting Hole Size: 26mm x 26mm
CPU*: STM32F405RGT6 (168MHz)
Six-Axis: ICM42688P (SPI connection)
RX: Serial ELRS 2.4G Receiver
RX firmware version: BETAFPV AIO 2400 RX ELRS V2.5.2
Antenna: Enameled wire
Blackbox Memory: 16MB
Sensor: Barometer(BMP280),  Voltage&ampCurrent
5V BEC*: 5V 3A@8V supply
9V BEC*: 9V 2A@8V supply

USB Port: SH1.0 4-Pin
Built-in ESC with 20A continuous and peak 25A current
ESC input voltage: 2-3S
FC firmfware version: Betaflight_4.4.1_BETAFPVF405
ESC firmware: C_X_70_48_V0.19.2.hex for BB51 Bluejay hardware
Signal support: D-shot300, D-shot600

Includes

1 * F4 2-3S 20A AIO FC V1
4 * M2*10 Machine Screw
4 * M2*10 Nylon Screw
4 * M2 Nuts
4 * Shock Absorbing Ball
4 * JST1.25mm Angle Socket
4 * JST1.25mm Straight Socket
1 * SH1.0 4Pin Adapter Cable
1 * Type-C to SH1.0 Adapter
1 * XT30 Power Cord
1 * Filter Capacitor
1 * 30mm Double-head VTX connector wire
1 * 60mm Single-head VTX connector wire

Wiring Diagram
Below is the diagram for F4 2-3S 20A AIO FC V1.



F4 2-3S 20A AIO FC V1 is specifically designed for HD VTX, utilizing 2-3S batteries for enhancing the flight experience. It features a dual BEC solution that delivers stable power outputs of 9V@2A for DJI O3 and 5V@3A for external devices. With a 20A ESC, it enables agile flight and increases dynamic. And connector for

F4 V1 2-3S 25x25 AIO Flight Controller with 8Bit 20A ESC and ELRS

F4 2-3S 20A AIO FC V1 is specifically designed for HD VTX, utilizing 2-3S batteries for enhancing the flight experience. It features a dual BEC solution that delivers stable power outputs of 9V@2A for DJI O3 and 5V@3A for external devices. With a 20A ESC, it enables agile flight and increases dynamic. And connector for DJI O3 HD VTX and USB port for easy installation and maintenance. Ideal for HD VTX whoop enthusiasts, offering a heightened level of professionalism and convenience with this FC option. Features Designed for HD VTX, it features a dual 9V@2A for DJI O3 and 5V@3A for external device BEC solution to prevent screen blackout on the DJI O3 due to low voltage during throttle increase. It includes a new DJI O3 6-pin PMU for easy installation without soldering, reducing assembly complexity. Newbie friendly. The power

SpeedyBee

SpeedyBee F7 V3 30x30 Flight Controller Stack - F722 FC, 50A 32bit 128K ESC

The SpeedyBee F7 V3 Stack includes an F722 flight controller and a 50A 128K ESC. Featuring bluetooth configuration, barometer, OSD, Blackbox, a built-in FC LiPo monitoring system, and many more features, this stack is the perfect addition to your FPV build.
Features


1500uF Low ESR Capacitor with TVS Protective Diode
500MB Onboard Blackbox Flash memory
8 Motor output perfect for X8 Cinelifters
30.5 x 30.5mm Mounting Pattern
FC LiPo Monitoring System
SpeedyBee 50A 128K ESC
CNC Heatsink Shield
Built-in Barometer
128KHz PWM
4 LED Plugs
F722 FC
Buzzer

Specifications

SPEEDYBEE F7 V3 FLIGHT CONTROLLER



Power Output:
1) 10 groups of 5V output, three +5V pads and 1 BZ+ pad (used for Buzzer) on the front side, and 6 +5V output included in the connectors on the bottom side. The total current load is 2A.
2) 2 groups of 9V output, one +9V pad on the front side and the other included in a connector on the bottom side. The total current load is 4A.
3) Supported. Designed for receiver and GPS module even when the FC is powered through the USB port. Up to 1A current load Supported. Designed for 3.3V-input receivers. Up to 500mA current load.
WiFi Support, used for data transfer, e.g firmware flashing, and Blackbox analysis.
I2C: Supported. SDA &amp SCL pads on the front side. Used for magnetometer, sonar, etc.
Support Flight Controller Firmware: BetaFlight(Default), EMUFlight, INAV
ESC signal M1 - M4 on the bottom side and M5-M8 on the front side.
LED: Used for WS2812 LED controlled by Betaflight firmware.
UART: 5 sets (UART1, UART2, UART3, UART4, UART6)
DJI Air Unit plug: A full DJI Air Unit JST slot onboard
BLE Support, used for Flight Controller configuration
Buzzer: BZ+ and BZ- pad used for 5V Buzzer
Mounting: 30.5x30.5mm, 4mm hole size
Dimensions: 41(L) x 38(W) x 8.1(H)mm
OSD: BetaFlight OSD w/ AT7456E chip
BlackBox: 500MB onboard data flash
BetaFlight Camera Control Pad: Yes
ESC Telemetry: UART UART4 RX
Power input: 3S - 6S Lipo
Target: SPEEDYBEEF7V3
SmartPort: Supported
Baro: BMP280 (I2C)
MCU: STM32F722
Boot button: Yes
RSSI input: Yes
IMU: BMI270
USB: Type-C
Weight: 9G



SPEEDYBEE 50A BLHELI_32 128K ESC



Current Sensor: Supported (Scale=490 Offset=0)
Mounting: 30.5x0.5mm, 4mm hole size
Dimension: 45.6(L)x40(W)x8.8mm(H)
Firmware: SpeedyBee BL32 50A
Weight: 19.2g with heat sink
Continuous Current: 50Ax4
Power input: 3S - 6S LiPo
Burst Current: 55A(5S)
Power output: VBAT

Includes


1x Speedy Bee F7 V3 Flight Controller
1 4-Pin SH1.0 to SH1.0 Analog VTX Cable 60mm - Yellow and Blue
1x 6-Pin SH1.0 GPS module Cable without connector - 100mm
1x 4-Pin SH1.0 to 3+ 2-Pin JST1.25 FPV Camera Cable - 30mm
1x 4-Pin SH1.0 to 3+ 2-Pin JST1.25 FPV Camera Cable - 60mm
1x 4-Pin SH1.0 to 4-Pin JST1.25 FPV Camera Cable - 60mm
1x 6-Pin SH1.0 GPS module Cable with connector
1x 4-Pin SH1.0 Radio Receiver Cable - 100mm
1x SH 1.0mm 8-Pin Cable -30mm
5x M3 8mm Silicone Grommets
1x DJI 6-Pin Cable - 80mm
1x SpeedyBee 50A BLHeli_32 128K ESC
1x 35V 1500uF Low ESR Capacitor
1x SH 1.0mm 8-Pin Cable -30mm
5x M3 8.1mm Silicone Grommets
5x M3 Silicone O-Ring
1x XT60 Power Cable









































































































Wiring Diagram





































The SpeedyBee F7 V3 Stack includes an F722 flight controller and a 50A 128K ESC. Featuring bluetooth configuration, barometer, OSD, Blackbox, a built-in FC LiPo monitoring system, and many more features, this stack is the perfect addition to your FPV build. Features 1500uF Low ESR Capacitor with TVS Protective Diode 50

F7 Stack V3 3-6S 30x30 Stack with F7 FC and 32Bit 128K 50A ESC

The SpeedyBee F7 V3 Stack includes an F722 flight controller and a 50A 128K ESC. Featuring bluetooth configuration, barometer, OSD, Blackbox, a built-in FC LiPo monitoring system, and many more features, this stack is the perfect addition to your FPV build. Features 1500uF Low ESR Capacitor with TVS Protective Diode 500MB Onboard Blackbox Flash memory 8 Motor output perfect for X8 Cinelifters 30.5 x 30.5mm Mounting Pattern FC LiPo Monitoring System SpeedyBee 50A 128K ESC CNC Heatsink Shield Built-in Barometer 128KHz PWM 4 LED Plugs F722 FC Buzzer Specifications SPEEDYBEE F7 V3 FLIGHT CONTROLLER Power Output: 1) 10 groups of 5V output, three +5V pads and 1 BZ+ pad (used for Buzzer) on the front side, and 6 +5V output included in the connectors on the bottom side. The total current load is 2A. 2) 2 groups of 9V output,

The SpeedyBee F7 V3 Stack includes an F722 flight controller and a 50A 128K ESC.

SpeedyBee F7 V3 Stack - F722 FC + 50A BLHeli_32 128K ESC - 30x30

Foxeer F722 V4 30x30 Flight Controller

Foxeers's V4 F7 FC has a clean layout with some quality components. No more worrying about lifting pads during crashes, this FC has through holes for every solder point.This is a replacement Flight Controller for The Moxy Pro-Spec Built &amp Tuned.Pairs best with the Foxeer Reaper 128K 65A ESC.
Specifications

Model: F722 V4
CPU: STM32F722RET6
Gyro: ICM-42688
Power Supply: 3~6S Lipo (11V~30V)
BEC Output: DC5V/3A DC9V/3A
OSD: BF OSD
Black Box: 16M Flash Memory
UART: 6 Set
ESC Telemetry: RX4
Buzzer: YES
Smart Audio: YES
LED: 1 Set 2812 LED
USB: Type-C
X8: Supported Need CLI
Firmware: FOXEERF722V4
Size: 37X37mm
Mounting Hole: 30.5X30.5mm,Φ4mm
Weight: 8g
Working Temperature: -20℃ ~ +55℃
Working Humidity: 20～95%
Storage Temperature: -20℃ ~ +70℃

Includes

1x Foxeer F722 V4 Flight Controller
4x Silicone Grommets





Foxeers's V4 F7 FC has a clean layout with some quality components. No more worrying about lifting pads during crashes, this FC has through holes for every solder point.This is a replacement Flight Controller for The Moxy Pro-Spec Built &amp; Tuned.Pairs best with the Foxeer Reaper 128K 65A ESC. Specifications Model: F

F722 V4 3-6S 30x30 Flight Controller

Foxeers's V4 F7 FC has a clean layout with some quality components. No more worrying about lifting pads during crashes, this FC has through holes for every solder point.This is a replacement Flight Controller for The Moxy Pro-Spec Built &amp; Tuned.Pairs best with the Foxeer Reaper 128K 65A ESC.
Specifications

Model: F722 V4
CPU: STM32F722RET6
Gyro: ICM-42688
Power Supply: 3~6S Lipo (11V~30V)
BEC Output: DC5V/3A; DC9V/3A
OSD: BF OSD
Black Box: 16M Flash Memory
UART: 6 Set
ESC Telemetry: RX4
Buzzer: YES
Smart Audio: YES
LED: 1 Set 2812 LED
USB: Type-C
X8: Supported Need CLI
Firmware: FOXEERF722V4
Size: 37X37mm
Mounting Hole: 30.5X30.5mm,Φ4mm
Weight: 8g
Working Temperature: -20℃ ~ +55℃
Working Humidity: 20～95%
Storage Temperature: -20℃ ~ +70℃

Includes

1x Foxeer F722 V4 Flight Controller
4x Silicone Grommets





Foxeer has upgraded their top-shelf FC even further! Now, this absolute beast of a flight controller comes with dual BECs for even more peripheral usage, as well as a barometer built in!
Specifications

Processor: STM32F722RET6

Gyro: MPU6000

Barometer: DPS310

Input Voltage: 4~8S Lipo

Onboard BEC: DC5V/2A DC10V/2A

OSD: BF OSD

Black Box: 16M Flash Memory

UART: 5 Sets

ESC Telemetry: Yes
Buzzer: Yes
HD Video Connector: Yes
Smart Audio: Yes
LEDs: 1 Set 2812 LED

USB: Type-C
Firmware: BetaFlight - FOXEERF722V4

Dimensions: 37x37mm
Mounting Pattern: 30x30mm
Weight: 7.7g
Working temperature: -20℃ ~ +55℃
Working Humidity: 20～95%

Includes

1x F722 V4 F7 4-8S 30x30 FC with Dual BEC and Barometer
4X Rubber Spacers
1x Cable

Wiring Diagram


Foxeed has upgraded their top shelf FC even further! Now this absolute beast of a flight controller comes with dual BEDs for even more peripheral usage, as well as a barometer built in!

F722 V4 4-8S 30x30 Flight Controller with MPU6000 and Barometer

Foxeer has upgraded their top-shelf FC even further! Now, this absolute beast of a flight controller comes with dual BECs for even more peripheral usage, as well as a barometer built in!
Specifications

Processor: STM32F722RET6

Gyro: MPU6000

Barometer: DPS310

Input Voltage: 4~8S Lipo

Onboard BEC: DC5V/2A; DC10V/2A

OSD: BF OSD

Black Box: 16M Flash Memory

UART: 5 Sets

ESC Telemetry: Yes
Buzzer: Yes
HD Video Connector: Yes
Smart Audio: Yes
LEDs: 1 Set 2812 LED

USB: Type-C
Firmware: BetaFlight - FOXEERF722V4

Dimensions: 37x37mm
Mounting Pattern: 30x30mm
Weight: 7.7g
Working temperature: -20℃ ~ +55℃
Working Humidity: 20～95%

Includes

1x F722 V4 F7 4-8S 30x30 FC with Dual BEC and Barometer
4X Rubber Spacers
1x Cable

Wiring Diagram


SpeedyBee F405 V3 30x30 Flight Controller

RUNCAM

The new SpeedyBee F405 V3 FC. They now come with a whole new set of features like a built-in cell checker on the FC, a built-in barometer for long-range pilots, and of course seamless integration of the Speedybee Bluetooth app to be able to configure and adjust settings anywhere with your drone!
Check out all our 30x30 FCs and all our Speedy Bee products!
Specifications
F405 V3 Flight Controller

MCU: STM32F405
IMU: BMI270
USB: Type-C
Baro: built-in
OSD: BetaFlight OSD w/ AT7456E chip
BLE Support, used for Flight Controller configuration

WiFi Support, used for data transfer, e.g firmware flashing, and Blackbox analysis.
DJI Air Unit plug: A full DJI Air Unit JST slot onboard
BlackBox: Betaflight firmware requires the type of microSD card to be either Standard (SDSC) or High Capacity (SDHC), so extended capacity cards (SDXC) are not supported(Many high-speed U3 cards are SDXC). Also, the card MUST be formatted with the FAT16 or FAT32 (recommended) filesystems. So, you could use any SD card less than 32GB, but Betaflight can only recognize 4GB maximum.
BetaFlight Camera Control Pad: Yes
Power input: 3S - 6S Lipo
9 groups of 5V output, four +5V pads and 1 BZ+ pad( used for Buzzer) on the front side, and 4x LED 5V pads. The total current load is 2A.
2 groups of 9V output, one +9V pad on the front side and the other included in a connector on the bottom side. The total current load is 2A.
Supported. Designed for receiver and GPS module even when the FC is powered through the USB port. Up to 1A current load.
Supported. Designed for 3.3V-input receivers. Up to 500mA current load.
ESC signal M1 - M4 on the bottom side and M5-M8 on the front side.
UART: 5 sets (UART1, UART2, UART3, UART4, UART6)
ESC Telemetry: UART UART4 RX
I2C: Supported. SDA &amp SCL pads on the front side. Used for magnetometer, sonar, etc.
LED: Used for WS2812 LED controlled by Betaflight firmware.
Buzzer: BZ+ and BZ- pad used for 5V Buzzer
Boot button: Yes
RSSI input: Yes
SmartPort: Supported
Support Flight Controller Firmware: BetaFlight(Default), EMUFlight, INAV
Target: SPEEDYBEEF7V3
Mounting: 30.5x30.5mm, 4mm hole size
Dimension 41.6(L) x 39.4(W) x 7.8(H)mm
Weight 9.6g




Includes

1x SpeedyBee F405 V3 30x30 Flight Controller
1x SH1.0mm 8pin 30mm Cable

5x Silicone grommet M3 8.1mm
1x DJI 6pin Cable (80mm)

Manual
F405 V3 Manual

The new SpeedyBee F405 V3 FC. They now come with a whole new set of features like a built-in cell checker on the FC, a built-in barometer for long-range pilots, and of course seamless integration of the Speedybee Bluetooth app to be able to configure and adjust settings anywhere with your drone! Check out all our 30x30

SpeedyBee F405 V3 3-6S 30x30 Flight Controller

The new SpeedyBee F405 V3 FC. They now come with a whole new set of features like a built-in cell checker on the FC, a built-in barometer for long-range pilots, and of course seamless integration of the Speedybee Bluetooth app to be able to configure and adjust settings anywhere with your drone! We also carry the 50A S

SpeedyBee F405 V3 Flight Controller - 30x30mm

The new SpeedyBee F405 V3 FC. They now come with a whole new set of features like a built-in cell checker on the FC, a built-in barometer for long-range pilots, and of course seamless integration of the Speedybee Bluetooth app to be able to configure and adjust settings anywhere with your drone!
Check out all our 30x30 FCs and all our Speedy Bee products!
Specifications
F405 V3 Flight Controller

MCU: STM32F405
IMU: BMI270
USB: Type-C
Baro: built-in
OSD: BetaFlight OSD w/ AT7456E chip
BLE Support, used for Flight Controller configuration

WiFi Support, used for data transfer, e.g firmware flashing, and Blackbox analysis.
DJI Air Unit plug: A full DJI Air Unit JST slot onboard
BlackBox: Betaflight firmware requires the type of microSD card to be either Standard (SDSC) or High Capacity (SDHC), so extended capacity cards (SDXC) are not supported(Many high-speed U3 cards are SDXC). Also, the card MUST be formatted with the FAT16 or FAT32 (recommended) filesystems. So, you could use any SD card less than 32GB, but Betaflight can only recognize 4GB maximum.
BetaFlight Camera Control Pad: Yes
Power input: 3S - 6S Lipo
9 groups of 5V output, four +5V pads and 1 BZ+ pad( used for Buzzer) on the front side, and 4x LED 5V pads. The total current load is 2A.
2 groups of 9V output, one +9V pad on the front side and the other included in a connector on the bottom side. The total current load is 2A.
Supported. Designed for receiver and GPS module even when the FC is powered through the USB port. Up to 1A current load.
Supported. Designed for 3.3V-input receivers. Up to 500mA current load.
ESC signal M1 - M4 on the bottom side and M5-M8 on the front side.
UART: 5 sets (UART1, UART2, UART3, UART4, UART6)
ESC Telemetry: UART UART4 RX
I2C: Supported. SDA &ampamp SCL pads on the front side. Used for magnetometer, sonar, etc.
LED: Used for WS2812 LED controlled by Betaflight firmware.
Buzzer: BZ+ and BZ- pad used for 5V Buzzer
Boot button: Yes
RSSI input: Yes
SmartPort: Supported
Support Flight Controller Firmware: BetaFlight(Default), EMUFlight, INAV
Target: SPEEDYBEEF7V3
Mounting: 30.5x30.5mm, 4mm hole size
Dimension 41.6(L) x 39.4(W) x 7.8(H)mm
Weight 9.6g




Includes

1x SpeedyBee F405 V3 30x30 Flight Controller
1x SH1.0mm 8pin 30mm Cable

5x Silicone grommet M3 8.1mm
1x DJI 6pin Cable (80mm)

Manual
F405 V3 Manual

SpeedyBee F405 V3 3-6S 30x30 Flight Controller from WREKD Co.

RunCam

SpeedyBee F405 V3 Flight Controller - 30x30mm from WREKD Co.

The SpeedyBee F405 V3 Flight Controller - 30x30 features Bluetooth pairing!

SpeedyBee F405 V3 Flight Controller - 30x30

RaceDayQuads

The new SpeedyBee F405 V3 FC. They now come with a whole new set of features like a built-in cell checker on the FC, a built-in barometer for long-range pilots, and of course seamless integration of the Speedybee Bluetooth app to be able to configure and adjust settings anywhere with your drone!
Specifications
F405 V3 Flight Controller

MCU: STM32F405
IMU: BMI270
USB: Type-C
Baro: built-in
OSD: BetaFlight OSD w/ AT7456E chip
BLE Support, used for Flight Controller configuration

WiFi Support, used for data transfer, e.g firmware flashing, and Blackbox analysis.
DJI Air Unit plug: A full DJI Air Unit JST slot onboard
BlackBox: Betaflight firmware requires the type of microSD card to be either Standard (SDSC) or High Capacity (SDHC), so extended capacity cards (SDXC) are not supported(Many high-speed U3 cards are SDXC). Also, the card MUST be formatted with the FAT16 or FAT32 (recommended) filesystems. So, you could use any SD card less than 32GB, but Betaflight can only recognize 4GB maximum.
BetaFlight Camera Control Pad: Yes
Power input: 3S - 6S Lipo
9 groups of 5V output, four +5V pads and 1 BZ+ pad( used for Buzzer) on the front side, and 4x LED 5V pads. The total current load is 2A.
2 groups of 9V output, one +9V pad on the front side and the other included in a connector on the bottom side. The total current load is 2A.
Supported. Designed for receiver and GPS module even when the FC is powered through the USB port. Up to 1A current load.
Supported. Designed for 3.3V-input receivers. Up to 500mA current load.
ESC signal M1 - M4 on the bottom side and M5-M8 on the front side.
UART: 5 sets (UART1, UART2, UART3, UART4, UART6)
ESC Telemetry: UART UART4 RX
I2C: Supported. SDA &amp SCL pads on the front side. Used for magnetometer, sonar, etc.
LED: Used for WS2812 LED controlled by Betaflight firmware.
Buzzer: BZ+ and BZ- pad used for 5V Buzzer
Boot button: Yes
RSSI input: Yes
SmartPort: Supported
Support Flight Controller Firmware: BetaFlight(Default), EMUFlight, INAV
Target: SPEEDYBEEF7V3
Mounting: 30.5x30.5mm, 4mm hole size
Dimension 41.6(L) x 39.4(W) x 7.8(H)mm
Weight 9.6g




Includes

1x SpeedyBee F405 V3 30x30 Flight Controller
1x SH1.0mm 8pin 30mm Cable

5x Silicone grommet M3 8.1mm
1x DJI 6pin Cable (80mm)

Manual
F405 V3 Manual

The new SpeedyBee F405 V3 FC. They now come with a whole new set of features like a built-in cell checker on the FC, a built-in barometer for long-range pilots, and of course seamless integration of the Speedybee Bluetooth app to be able to configure and adjust settings anywhere with your drone! Specifications F405 V3

FETtec KISS G4-N 2-6S 30x30 / 20x20 Flight Controller

The FETtec FC G4 features the latest STM32G4 processor. Providing unparalleled processing power to your aircraft. Along with an IIM-42652 SPI gyro, two 5v BECs, 6-27V (2-6S) power handling, and a host of other features, the G4 from FETtec is on the cutting edge of Flight Controller technology.
Specifications

Input Voltage: 2-6S LiPo

MCU: STM32G4

Gyro: IIM-42652 SPI

OSD: HD MSP

UARTs: 5 Sets

ESC Connections: 8-Pin

Firmware: FETtec Alpha FC firmware (KISS FC firmware flashable)

BEC: 5V / 16V
Buzzer: Supported
Stack Size: 20x20 / 30x30

Dimensions: 37.19x37.19x7.9mm

Weight: 5.37g

Includes

1x G4-N G4 2-6S 20x20-30x30 FC
1x 8-Pin ESC Cable
1x 6-Pin Cable
1x 4-Pin Cable


The FETtec FC G4 features the latest STM32G4 processor. Providing unparalleled processing power to your aircraft. Along with an IIM-42652 SPI gyro, two 5v BECs, 6-27V (2-6S) power handling, and a host of other features, the G4 from FETtec is on the cutting edge of Flight Controller technology. Specifications Input Volt

G4-N G4 2-6S 20x20-30x30 KISS Flight Controller

The FETtec FC G4 - N v1.7 features the latest STM32G4 processor. Providing unparalleled processing power to your aircraft. Along with an IIM-42652 SPI gyro, two 5v BECs, 6-27V (2-6S) power handling, and a host of other features, the G4 from FETtec is on the cutting edge of Flight Controller technology. This version does not include the analog OSD. (Digital OSD supported)

The FETtec FC G4 - N v1.7 features the latest STM32G4 processor. Providing unparalleled processing power to your aircraft. Along with an IIM-42652 SPI gyro, two 5v BECs, 6-27V (2-6S) power handling, and a host of other features, the G4 from FETtec is

FETtec G4 - N v1.7 Flight Controller

FETTEC

The FETtec KISS G4-N 2-6S 30x30 / 20x20 Flight Controller features the latest STM32G4 processor. Providing unparalleled processing power to your aircraft.  Along with an IIM-42652 SPI gyro, two 5v BECs, 6-27V (2-6S) power handling, and a host of other features, the G4 from FETtec is on the cutting edge of Flight Controller technology.
Note: This G4-N is a variation on the original G4 and is optimized for digital use. If you are flying analog, you will need the original G4 with built-in OSD chip.
Check out our other flight controllers, as well as the rest of our FETtec selection!
Specifications


Input Voltage: 2-6S LiPo


MCU: STM32G4


Gyro: IIM-42652 SPI
OSD: No

UARTs: 5 Sets


ESC Connections: Yes

Firmware: KISS firmware


BEC: 3.3V, 5V, 16V


Current Sensor: Yes

Buzzer: Yes

Barometer: No

Black Box: No
DJI Compatible: Yes

Mounting Pattern: 30x30 / 20x20

Dimensions: 37.2x37.2mm


Weight: 5.37g


Includes

1x FETtec KISS G4-N 2-6S 30x30 / 20x20 Flight Controller
1x Capacitor
1x Wiring Harness



The processing power of our FETtec KISS G4-N 2-6S 30x30 / 20x20 Flight Controller can make the difference at your next race, or your casual day of flying. Take action now!

FETtec KISS G4-N V1.7 2-6S 30x30 / 20x20 Flight Controller

FETtec KISS G4-N 2-6S 30x30 / 20x20 Flight Controller For Sale

The FETtec KISS G4-N 2-6S 30x30 / 20x20 Flight Controller features the latest STM32G4 processor. Providing unparalleled processing power to your aircraft.  Along with an IIM-42652 SPI gyro, two 5v BECs, 6-27V (2-6S) power handling, and a host of other features, the G4 from FETtec is on the cutting edge of Flight Contro

FETtec KISS G4-N V1.7 2-6S 30x30 / 20x20 Flight Controller from WREKD Co.

Foxeer Reaper V4 AIO Flight Controller - F745 FC, 35A 2-4S ESC

Foxeers legendary performance and reliability of Reaper ESC’s now in an  AIO form factor, featuring an F7 processor and a 35A ESC in an under 9g package! This is V4 of this exceptional product.

Foxeer Reaper AIO V4 - F745 FC + 35A 2-4S BLHeli_S ESC (MPU6000)

The Foxeer Reaper F745 AIO V4 is an all-in-one board with an F7 flight controller and 35A ESC flashed with Bluejay firmware, featuring a MPU6000 gyro, 5 UARTS, and 16M BlackBox.
Specifications


Input Voltage: 2-6S LiPo


MCU: STM32F745

Gyro: MPU6000

OSD: yes

UARTs: 5 Sets


ESC Connections: yes

BEC: 5V 2A


Current Sensor: yes

Buzzer: yes

Barometer: yes
Black Box: 16Mb Onboard

Max. Continuous Current: 35A

Max Burst Current: 45A (10sec)


ESC Firmware: Bleujay (default) / BLheli_S

Stack Size: 25x25mm

Dimensions: 32.5x32.5xmm


Weight: 8.6g


Includes

1x Reaper F745 25x25 AIO Flight Controller with 45A ESC

Wiring Diagram


The Foxeer Reaper F745 AIO is an all-in-one board with an F7 flight controller and 45A ESC, featuring an STM32F745 High-performance processor and 16M BlackBox.

Reaper AIO V4 F745 25x25 Flight Controller with 8Bit 35A ESC

NDAA Compliant products include parts that adhere to the requirements outlined in Section 848 of the National Defense Authorization Act

NDAA Compliant Flight Controller (Beta)

T-Motor F7 Mini 3-6S 20x20 Flight Controller Stack for DJI - F7 FC, 45A ESC

T-Motor Mini F7 3-6S 20x20 Stack/Combo for DJI (F7 FC / 45A 4in1 ESC)

T-Motor Mini F7 3-6S 20x20 Stack/Combo for DJI (F7 FC / 45A  - RMRC

Get a better flying experience out of this 20*20mm stack, with 33% less weight, and a 41% smaller stack featuring 32bit High Performance! Capable of DUAL BEC Plug and Play, can provide power for DJI Digital HD Video Transmitter! Check out our other Flight Controllers and all our T-Motor Products!   Supports Various Thr

T-Motor MINI F45A+ MINI F7 STACK 20*20mm

Lightweight DJI plug and play ready 20x20 stack from T-Motor.
Features

Dual BEC, DJI Plug and Play Ready
45A ESC
F7 Flight Controller

Specifications
T-Motor F7 Mini Flight Controller

Input Voltage: 3-6S
Firmware: TMOTORF7 (STM32FX2)
BEC: 5V/2A, 10V/2A (For DJI HD VTX)
Main Control: STM32F722
Gyroscope: MPU6000
RAM: Onboard 16M
OSD: Support
Barometer: No
Mounting Pitch: 20*20mm
Weight: 5.1g

T-Motor Mini 45A ESC

Input Voltage: 3-6S
ESC Firmware: BLHeli32
Telemetry: Supported
Galvanometer: Supported
DSHOT 150/DSHOT 300/DSHOT 600/PROSHOT 1000
Backwards Compatible with Oneshot125/Oneshot42/Multishot
Betaflight Galvanometer Ratio: 200
Mounting Pitch: 20*20mm
Weight: 9.2g

Includes

1x T-Motor Mini F7 3-6S 20x20 Stack Combo (F7 FC / 45A ESC)

Wiring Diagram


Lightweight DJI plug and play ready 20x20 stack from T-Motor. Features Dual BEC, DJI Plug and Play Ready 45A ESC F7 Flight Controller Specifications T-Motor F7 Mini Flight Controller Input Voltage: 3-6S Firmware: TMOTORF7 (STM32FX2) BEC: 5V/2A, 10V/2A (For DJI HD VTX) Main Control: STM32F722 Gyroscope: MPU6000 RAM: Onb

Mini F7 3-6S 20x20 Stack with F7 FC and 32Bit 45A ESC

Lightweight DJI plug and play ready 20x20 stack from T-Motor.
Check out our 20x20 Flight Controllers, our DJI compatible gear, and all our T-Motor products!
Features

Dual BEC, DJI Plug and Play Ready
45A ESC
F7 Flight Controller

Specifications
T-Motor F7 Mini Flight Controller

Input Voltage: 3-6S
Firmware: TMOTORF7 (STM32FX2)
BEC: 5V/2A, 10V/2A (For DJI HD VTX)
Main Control: STM32F722
Gyroscope: BMI270
RAM: Onboard 16M
OSD: Support
Barometer: No
Mounting Pitch: 20*20mm
Weight: 5.1g

T-Motor Mini 45A ESC

Input Voltage: 3-6S
ESC Firmware: BLHeli32
Telemetry: Supported
Galvanometer: Supported
DSHOT 150/DSHOT 300/DSHOT 600/PROSHOT 1000
Backwards Compatible with Oneshot125/Oneshot42/Multishot
Betaflight Galvanometer Ratio: 200
Mounting Pitch: 20*20mm
Weight: 9.2g

Includes

1x T-Motor Mini F7 3-6S 20x20 Stack Combo (F7 FC / 45A ESC)


Lightweight DJI plug and play ready 20x20 stack from T-Motor. Check out our 20x20 Flight Controllers, our DJI compatible gear, and all our T-Motor products! Features Dual BEC, DJI Plug and Play Ready 45A ESC F7 Flight Controller Specifications T-Motor F7 Mini Flight Controller Input Voltage: 3-6S Firmware: TMOTORF7 (ST

T-Motor Mini F7 3-6S 20x20 Stack/Combo for DJI (F7 FC / 45A 4in1 ESC) from WREKD Co.

Get a better flying experience with the T-Motor Mini F45 + Mini F7 Stack! This stack brings lots of power all in a small package!

T-Motor Mini F7  Stack + F45A 3-6S BLHeli_32 4-in-1 ESC


Solder Free: Everything is 100% plug-n-play, the MR30 Quick Connection System makes assembly a breeze and removes the need for any soldering!
This stack is a perfect upgrade to the T-Motor Mini F7 Stack. This version is compatible will our solder-free motors, and will be a perfect match for our Skylite Frame.

Specifications
T-Motor F7 Mini Flight Controller V1.1

Input Voltage: 3-6S
Firmware: TMOTORF7 (STM32FX2)
BEC: 5V/2A, 10V/2A (For DJI HD VTX)
Main Control: STM32F722
Gyroscope: BMI270
RAM: Onboard 16M
OSD: Support
Barometer: No
Mounting Pitch: 20*20mm
Weight: 5.1g

T-Motor Mini 45A ESC

Input Voltage: 3-6S
ESC Firmware: BLHeli32
Telemetry: Supported
Galvanometer: Supported
DSHOT 150/DSHOT 300/DSHOT 600/PROSHOT 1000
Backward Compatible with Oneshot125/Oneshot42/Multishot
Betaflight Galvanometer Ratio: 200
Mounting Pitch: 20*20mm
Weight: 9.2g

Includes

1x T-Motor Mini F7 3-6S 20x20 Stack Combo (F7 FC / 45A ESC)

Wiring Diagram


Solder Free: Everything is 100% plug-n-play, the MR30 Quick Connection System makes assembly a breeze and removes the need for any soldering! ZERO Programming: No Betalight or ESC programming is required, all of the MR-30 T-motor Stacks will be pre-flashed with the latest version of Betaflight and BLheli and will also include a complete Betaflight Tune and Configuration Setup. Pre-programmed to work on either 4s or 6s batteries. This stack is a perfect upgrade to the T-Motor Mini F7 Stack. This version is compatible will our solder-free motors, and will be a perfect match for our Skylite Frame.

Mini F7 3-6S 20x20 Stack with F7 FC and 32Bit 45A ESC Solder-Free

T-Motor F7 HD 30x30 Flight Controller for DJI

The T-Motor F7 Flight Controller now comes in a version meant specifically for the DJI Digital FPV System! Including a plug for your Air Unit and a 10V 2A BEC to power it.
Check out all our 30x30 Flight Controllers, all our DJI compatible gear, and all our T-Motor products!

Specifications

Input Voltage: 3-6S
Gyro: BMI270
Master chip: STM32F722RET6
Flash: 16MB
BEC: 5V 2A, 10V 2A
Mounting hole: 30.5x30.5mm
Weight: 8.4g
Size: 37x37mm
Firmware: TMOTOR F7(Betaflight)

Includes

1x T-Motor F7 HD 30x30 Flight Controller for DJI

Wiring Diagram




The T-Motor F7 Flight Controller now comes in a version meant specifically for the DJI Digital FPV System! Including a plug for your Air Unit and a 10V 2A BEC to power it.  Check out all our 30x30 Flight Controllers, all our DJI compatible gear, and all our T-Motor products! Specifications Input Voltage: 3-6S Gyro: BMI

T-Motor F7 HD 30x30 Flight Controller from WREKD Co.

T-Motor F7 HD 30x30 Flight Controller





The T-Motor F7 Flight Controller now comes in a version meant specifically for the DJI Digital FPV System! Including a plug for your Air Unit and a 10V 2A BEC to power it.


Specifications

Input Voltage: 3-6S
Gyro: BMI270
Master chip: STM32F722RET6
Flash: 16MB
BEC: 5V 2A, 10V 2A
Mounting hole: 30.5x30.5mm
Weight: 8.4g
Size: 37x37mm
Firmware: TMOTOR F7(Betaflight)

Includes

1x T-Motor F7 HD 30x30 Flight Controller for DJI















The T-Motor F7 Flight Controller now comes in a version meant specifically for the DJI Digital FPV System! Including a plug for your Air Unit and a 10V 2A BEC to power it.    Specifications Input Voltage: 3-6S Gyro: BMI270 Master chip: STM32F722RET6 Flash: 16MB BEC: 5V 2A, 10V 2A Mounting hole: 30.5x30.5mm Weight: 8.4g

T-Motor F7 HD 30x30 Flight Controller for DJI from WREKD Co.

This is the HD version of the T-mtor F7 Flight controller with 10V output BEC that's plug and play with DJI Air UnitAlso available as a stack with the T-Motor F55 ESC See all our DJI Plug and Play Flight Controllers and Stacks! Specifications Input Voltage: 3-6S Gyro: BMI270 Master chip: STM32F722RET6 Flash: 16MB BEC:

T-Motor F7 HD 30x30 Flight Controller - RMRC

T-Motor flight controllers have been a staple of the drone industry for a long time, and this new flight controller shows off the years of experience. With DJI you can simply plug in the Air Unit and ESC and get flying with no soldering! If you're a racer who needs repairs to be lightning fast or a freestyler who wants a board that can keep up with them, this is the right choice for you.
Specifications

Input Voltage: 3-6S
Gyro: BMI270
Master chip: STM32F722RET6
UARTs: 5 Sets
Target: TMOTORF7 (Betaflight)
Current Sensor: Yes
BEC: 3.3V 2A / 5V 2A / 10V 2A
Black Box: 16MB Onboard
Mounting hole: 30x30mm
Weight: 8.4g
Dimensions: 37x37mm

Includes

1x T-Motor F7 HD 3-6S 30x30 Flight Controller
1x Air Unit Cable
1x 8 ESC Cable

Wiring Diagram



T-Motor flight controllers have been a staple of the drone industry for a long time, and this new flight controller shows off the years of experience. With DJI you can simply plug in the Air Unit and ESC and get flying with no soldering! If you're a racer who needs repairs to be lightning fast or a freestyler who wants

F7 HD 3-6S 30x30 Flight Controller

T-Motor F7 & F55A Pro II 3-6S 30x30 Flight Controller Stack - F7 FC, 55A 32Bit 55A ESC

T-Motor's powerful F7 Flight Controller combined with the T-Motor F55A Pro II ESC will give you optimized performance and seamless integration in your electronics stack.
The F55 Pro II updates the original F55 with a new heatsink design, LEDs, and increased the BEC current to 10V@2A.
Fully capable of pushing 6s with 75A burst and a sustained 55A current draw. Equipped with the latest in ESC technology such as 32-bit capability and BLHeli32 firmware.
Browse our 30x30 Flight Controllers and all our T-Motor products!
Specification
F7 FC

MCU: STMF722RET6
Gyro: BMI270
Memory: 16M
Input Voltage: 12v-25-2v (3-6S)
BEC: 5V/2A
Dimensions: 37mm x 37mm
Mounting Holes: 30.5mm x 30.5mm
Weight: 7.4g
Firmware Target: TMOTORF7 (Betaflight)

F55A Pro II 55A 3-6s BLHeli32 4-in-1 ESC w/ BEC

Continuous current: 4x55A
BLHeli_32 32bit
Burst current: 4x75A
BEC Output: 10V @2.0A
Size: 45x41x7.3mm
Weight: 17.5g (Including Heatsink)
Support DSHOT150/300/600/1200

Includes

1x T-Motor F7 Flight Controller
1x T-Motor F55A Pro II 55A 3-6s BLHeli32 4-in-1 ESC w/ BEC
1x XT-60 Pigtail
1x Insulation Board
4x Link Board
4x M3x30 Screw
2x FC to ESC Cable
4x Non-Slip Nut
1x Spacers
1x Capacitor


T-Motor's powerful F7 Flight Controller combined with the T-Motor F55A Pro II ESC will give you optimized performance and seamless integration in your electronics stack. The F55 Pro II updates the original F55 with a new heatsink design, LEDs, and increased the BEC current to 10V@2A. Fully capable of pushing 6s with 75
