Walksnail Avatar HD Moonlight VTX Kit - Micro Moonlight Camera, Dual Antenna

<h3 data-mce-fragment="1"><strong data-mce-fragment="1">features：</strong></h3>
<table width="100%">
<tbody>
<tr>
<td style="width: 31.983%" data-mce-style="width: 31.983%">●4k/60FPS</td>
<td style="width: 63.017%" data-mce-style="width: 63.017%">
<span data-mce-fragment="1">●</span>Startlight Camera</td>
</tr>
<tr>
<td style="width: 31.983%" data-mce-style="width: 31.983%"><span data-mce-fragment="1">●Built-in EIS</span></td>
<td style="width: 63.017%" data-mce-style="width: 63.017%">
<span data-mce-fragment="1">●</span>Support Gyroflow</td>
</tr>
<tr>
<td style="width: 31.983%" data-mce-style="width: 31.983%"><span data-mce-fragment="1">●Sd card</span></td>
<td style="width: 63.017%" data-mce-style="width: 63.017%"><span data-mce-fragment="1">●FOV 160°</span></td>
</tr>
<tr>
<td style="width: 31.983%" data-mce-style="width: 31.983%">
<span data-mce-fragment="1">●</span>Dual Antennas</td>
<td style="width: 63.017%" data-mce-style="width: 63.017%">
<span data-mce-fragment="1">●7.4</span>V-25.2V</td>
</tr>
</tbody>
</table>
<div style="text-align: start" data-mce-style="text-align: start"><img alt="" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/1._1d2b14fc-1c88-4697-bb29-cb18631e30aa.jpg?v=1705297573"></div>
<h3 data-mce-fragment="1">
<strong data-mce-fragment="1"></strong><br>
</h3>
<h3 data-mce-fragment="1"><strong data-mce-fragment="1">Bullet Points:</strong></h3>
<ul>
<li>Supports 4K/60fps, ensuring that FPV embraces true 4K. Shooting stable and HD videos without unnecessary latency, bring pilots a smoother FPV experience.</li>
</ul>
<div style="text-align: start" data-mce-style="text-align: start"><img alt="" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/3.4K60fps_4de32098-0f60-41b2-a657-8d87848b5bbc.jpg?v=1705902500"></div>
<div style="text-align: start" data-mce-style="text-align: start"><br></div>
<br>
<ul>
<li>Feature starlight sensor, to improve image quality and performance in low-light scene shooting, ensuring night vision shooting and eliminating frequent camera switching.</li>
</ul>
<div style="text-align: start" data-mce-style="text-align: start"><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/4._2b35b2a5-9429-4766-8c14-743612a26e29.jpg?v=1703821827" alt=""></div>
<br>
<ul>
<li><span data-mce-fragment="1">Built-in EIS and supports Gyroflow technology, taking you a smooth and stable video quality, to facilitate and enjoy freestyle fly. </span></li>
</ul>
<div style="text-align: start" data-mce-style="text-align: start"><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/4K_1_aefb6c25-b0cc-4ac0-b7e2-d2d60e0eb6ec.jpg?v=1705915604" alt=""></div>
<br>
<ul>
<li>Comes with silicone pads for mounting the camera, ensuring stability and minimizing camera shake for perfect captures.</li>
</ul>
<div style="text-align: start" data-mce-style="text-align: start"><img style="float: none" alt="" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/6..gif?v=1702627007" data-mce-style="float: none"></div>
<br>
<ul>
<li>Supports manual shutter and manual ISO settings, take perfect photos regardless of any lighting limits.</li>
</ul>
<div style="text-align: start" data-mce-style="text-align: start"><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/7._ISO_6de0a8f2-de29-41dc-bca6-24582ae40656.jpg?v=1705139859" alt=""></div>
<br>
<ul>
<li>The moonlight camera has a 160° FOV, providing you with a more natural and real picture for the ultimate flying experience.</li>
</ul>
<div style="text-align: start" data-mce-style="text-align: start"><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/8.FOV160.gif?v=1702627795" alt=""></div>
<br>
<ul>
<li>Come with ND8 filters to meet the needs of more different shooting scenes, to bring different effects to the shooting.</li>
</ul>
<div style="text-align: start" data-mce-style="text-align: start"><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/9._-1_2f3f87a8-971b-47f1-a99e-6389640386b1.jpg?v=1705139910" alt=""></div>
<p><img alt="" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/f7d7c897f798fc44c391847188c3ac79_c585c86b-ee7d-48bf-87bd-339f0cfccce3.jpg?v=1705133995"></p>
<p><img alt="" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/f4b3da9554de4e60ffd11b8edcb16ff8_752e4cb0-12df-486d-bb11-bc4d109fd0d0.jpg?v=1705025833"></p>
<p>Q: When will it be shipped?<br data-mce-fragment="1">A: In order to give pilots a better experience. Currently, each order will be shipped within 30 working days.</p>
<p>Q: Can moonlight vtx use other WS cameras?<br>A: No, but other vtx can use moonlight camera</p>
<table width="100%">
<tbody>
<tr>
<td><strong>Specification</strong></td>
<td></td>
</tr>
<tr>
<td>Model</td>
<td>Moonlight kit</td>
</tr>
<tr>
<td>Firmware name</td>
<td>Avatar<span data-mce-fragment="1">Moonlight</span>_Sky_X.X.X</td>
</tr>
<tr>
<td><span>Communication Frequency</span></td>
<td>5.725-5.850GHz</td>
</tr>
<tr>
<td><span>Transmitter Power (EIRP)</span></td>
<td><span>FCC:&lt30dBm CE:&lt14dBm SRRC:&lt20dBm MIC:&lt25dBm</span></td>
</tr>
<tr>
<td><span>1/O Interface</span></td>
<td><span>JST1.0*4(Power in)JST0.8*6(USB)，Micro SD card Slot；IPEX-1</span></td>
</tr>
<tr>
<td>Sensor</td>
<td>Starlight sensor<br>
</td>
</tr>
<tr>
<td>FOV</td>
<td>Max 160°</td>
</tr>
<tr>
<td>Aperture</td>
<td>F2.1</td>
</tr>
<tr>
<td>Shutter</td>
<td>Rolling shutter</td>
</tr>
<tr>
<td>ISO</td>
<td>100-25600</td>
</tr>
<tr>
<td>Recording resolution</td>
<td>4K@30/60fps,2.7K@30/60fps,1080p@100/60fps,720p@60fps</td>
</tr>
<tr>
<td>Max Mbps</td>
<td>150Mbps</td>
</tr>
<tr>
<td>Video format</td>
<td>MP4 (H.264)</td>
</tr>
<tr>
<td>3D DNR</td>
<td><span>Support</span></td>
</tr>
<tr>
<td>Gyroflow</td>
<td>Support</td>
</tr>
<tr>
<td>Built-in EIS</td>
<td>Support</td>
</tr>
<tr>
<td>Wide Power Input<br>
</td>
<td>7.4V-25.2V</td>
</tr>
<tr>
<td>Power consumption</td>
<td>12V@1.4A, 8V@2.2A</td>
</tr>
<tr>
<td>Memory card type</td>
<td>U3 MicroSD, Max 256G</td>
</tr>
<tr>
<td>Camera size</td>
<td>19.6mm*19mm*24mm</td>
</tr>
<tr>
<td>VTX size</td>
<td>15.3mm*34.5mm*34.5mm</td>
</tr>
<tr>
<td>VTX Installation hole distance</td>
<td>20*20mm/25*25mm (M2)</td>
</tr>
<tr>
<td>Weight <br>
</td>
<td>38.5g(Antenna not included)<br>
</td>
</tr>
<tr>
<td>OSD</td>
<td>Canvas mode</td>
</tr>
<tr>
<td>Latency</td>
<td>Average delay 22ms</td>
</tr>
<tr>
<td>Antenna</td>
<td>2 (IPEX)</td>
</tr>
<tr>
<td><span><strong>VTX Antenna</strong></span></td>
<td><span></span></td>
</tr>
<tr>
<td>model</td>
<td>avatar V2 antenna</td>
</tr>
<tr>
<td><span>Polarization</span></td>
<td><span>LHCP</span></td>
</tr>
<tr>
<td><span>Frequency range</span></td>
<td><span>5600MHz-6000MHz</span></td>
</tr>
<tr>
<td><span>Average Gain</span></td>
<td><span>1.9dBi</span></td>
</tr>
<tr>
<td><span>VSWR</span></td>
<td><span>＜1.5</span></td>
</tr>
<tr>
<td><span>Input Impedance</span></td>
<td><span>50Ω</span></td>
</tr>
<tr>
<td><span>Interface</span></td>
<td><span>IPEX-1</span></td>
</tr>
<tr>
<td>Dimension</td>
<td><span>R15 X 45mm （without cable）</span></td>
</tr>
<tr>
<td><span>Weight</span></td>
<td><span>2g</span></td>
</tr>
</tbody>
</table>
<p><br></p>
<p><strong data-mce-fragment="1">Packing List：</strong></p>
<p> <img alt="" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/890d4ec9e2d52117c77f8b22b701f9e1.jpg?v=1705132112" data-mce-fragment="1" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/890d4ec9e2d52117c77f8b22b701f9e1.jpg?v=1705132112"></p>
<p><br></p>
<ul></ul>
<ul></ul>
<ul></ul>
<ul></ul>

features： ●4k/60FPS ●Startlight Camera ●Built-in EIS ●Support Gyroflow ●Sd card ●FOV 160° ●Dual Antennas ●7.4V-25.2V Bullet Points: Supports 4K/60fps, ensuring that FPV embraces true 4K. Shooting stable and HD videos without unnecessary latency, bring pilots a smoother FPV experience. Feature starlight sensor, to impro

Walksnail Moonlight kit (Pre-order) – CADDX FPV

features：



●4k/60FPS

●Startlight Camera


●Built-in EIS

●Support Gyroflow


●Sd card
●FOV 160°



●Dual Antennas

●7.4V-25.2V







Bullet Points:

Supports 4K/60fps, ensuring that FPV embraces t

Walksnail Moonlight kit (Pre-order)

Boasting 4k/60fps, amazing low light detail, EIS and Gyroflow technology, and a host of other features - the Walksnail Moonlight aims to be the HD system on all your frames!

Walksnail Moonlight Kit - 4K FPV System

About this product The Moonlight is a brand new HD FPV system from Walksnail that won&#x27t break the bank. Boasting 4k/60fps, amazing low light detail, EIS and Gyroflow technology, and a host of other features to make this the HD system on all your frames! Walksnail Moonlight 4K - Cinematic FPV Features Starlight Camera f

About this product The Moonlight is a brand new HD FPV system from Walksnail that won't break the bank. Boasting 4k/60fps, amazing low light detail, EIS and Gyroflow technology, and a host of other features to make this the HD system on all your frames! Walksnail Moonlight 4K - Cinematic FPV Features Starlight Camera f

Pre-Orders shipping ASAP!
Experience unparalleled performance with the Walksnail Avatar Moonlight 4K Starlight Kit. Featuring 4k 60fps with built-in EIS and support for Gyroflow, capture true 4k footage in ultra-low light conditions. Enjoy FPV and HD video quality, along with DVR recording capabilities for stunning visuals. Elevate your content with this industry-leading kit.
Check out all our Walksnail HD products and check out all our Walksnail compatible products!
Features

4k/60FPS

Startlight Camera
Built-in EIS
Support Gyroflow
Sd card
4km range
22ms low latency
FOV 160°
Dual Antennas
7.4V-25.2V






Supports 4K/60fps, ensuring that FPV embraces true 4K. Shooting stable and HD videos without unnecessary latency, bringing pilots a smoother FPV experience.

Featuring the starlight sensor, to improve image quality and performance in low-light scene shooting, ensuring night vision shooting and eliminating frequent camera switching.

Built-in EIS and supports Gyroflow technology, giving you smooth and stable video quality, to facilitate and enjoy freestyle fly.

Comes with silicone pads for mounting the camera, ensuring stability and minimizing camera shake for perfect captures.

Supports manual shutter and manual ISO settings, take perfect photos regardless of any lighting limits.

The moonlight camera has a 160° FOV, providing you with a more natural and real picture for the ultimate flying experience.

It comes with ND8 filters to meet the needs of many different shooting scenes.

Specifications


Model: Moonlight kit
Firmware Name: AvatarMoonlight_Sky_X.X.X
Communication Frequency: 5.725-5.850GHz
Transmitter Power (EIRP) FCC:&amplt30dBm CE:&amplt14dBm SRRC:&amplt20dBm MIC:&amplt25dBm

1/O Interface JST1.0 x 4(Power in) JST0.8 x 6(USB)，Micro SD card Slot；IPEX-1
Sensor: Starlight sensor
FOV: Max 160°
Aperture: F2.1
Shutter: Rolling shutter
ISO: 100-25600
Recording resolution: 4K@30/60fps, 2.7K@30/60fps, 1080p@100/60fps, 720p@60fps
Max Mbps: 150Mbps
Video format: MP4 (H.264)
3D DNR: Support
Gyroflow: Support
Built-in EIS: Support
Wide Power Input: 7.4V-25.2V
Power consumption: 12V@1.4A, 8V@2.2A
Memory card type: U3 MicroSD, Max 256G
VTX size: 15.3mm x 34.5mm x 34.5mm
VTX Installation hole distance: 20 x 20mm/25 x 25mm (M2)
Weight: 38.5g (Antenna not included)
OSD: Canvas mode
Latency: Average delay 22ms
Antenna: 2 (IPEX)

Avatar V2 Antenna

Polarization: LHCP
Frequency range: 5600MHz-6000MHz
Gain: 1.9dBi
VSWR: ≤1.5
Input Impedance: 50Ω
Interface: IPEX-1
Size: R15 X 45mm (without cable)
Weight: 2g


Includes

1x Walksnail Moonlight Kit (VTX &ampamp Camera)
1x Hardware &ampamp Cable kit
1x ND Filter
2x Avatar v2 LHCP u.FL Antennas






Pre-Orders shipping ASAP! Experience unparalleled performance with the Walksnail Avatar Moonlight 4K Starlight Kit. Featuring 4k 60fps with built-in EIS and support for Gyroflow, capture true 4k footage in ultra-low light conditions. Enjoy FPV and HD video quality, along with DVR recording capabilities for stunning vis

Walksnail Avatar HD Moonlight Kit 20x20 / 25x25 VTX Kit w/ Micro Moonlight Camera - (Dual Antenna) from WREKD Co.

(PRE-ORDER) Walksnail Avatar HD Moonlight Kit 20x20 / 25x25 VTX Kit w/ Micro Moonlight Camera - (Dual Antenna)

The New Walksnail Moonlight Kit Supports 4K/60fps, ensuring that FPV embraces true 4K. Shooting stable and HD videos without unnecessary latency to give the pilots a smoother FPV experience. It features a starlight sensor, built-in EIS and supports Gyroflow technology to improve image quality and performance in low-lig

Walksnail Moonlight Kit 4K/60FPS HD FPV System

VTX Frequency

The VTX processes the image from your FPV camera and sends it to your goggle’s video receiver (VRX). If you chose as digital video system, you need a VTX that matches the system. Most analog VTXs and VRXs are compatible with each other, and your biggest consideration will be how much output power you need. The more output power, the more range and better signal you’ll get. Learn more about VTXs.

Video Transmitters

VTX Stack Mount

VTX Antenna Connector

Max Transmission Power

Digital / Analog VTX

FPV Camera Included

Walksnail Avatar HD V2 VTX Kit - Micro HD Camera V2, Single Antenna

This Walksnail Avatar HD Kit V2 features built-in 32GB storage and Gyroflow support.&nbsp

This Walksnail Avatar HD Kit V2 features built-in 32GB storage and Gyroflow support.

Walksnail Avatar HD Kit V2 - 32GB w/ Gyro

This Walksnail Avatar HD Kit V2 features built-in 8GB storage and gyro.

Walksnail Avatar HD Kit V2 - 8GB - w/ Gyro

This Walksnail Digital HD VTX / Micro Camera Kit V2 is designed for use with Walksnail Avatar/Fatshark Dominator HD FPV systems. It features H.265 encoding to provide 1080p FPV image quality with ultra-low latency and 2K pixels, 4:3 native sensor for improved image quality. The kit also supports Gyroflow for smoother,

Walksnail Avatar Digital HD Kit V2 with Camera V2+Gyroflow for Walksnail Avatar/Fatshark Dominator HD FPV System - Choose Memory Size

WALKSNAIL

Introducing the Walksnail Avatar HD Kit V2 - 32GB w/ Gyro, an unparalleled advancement in aerial imaging technology. Elevate your drone flying experience with this cutting-edge kit designed for enthusiasts and professionals alike.Featuring a built-in 32GB storage capacity and Gyroflow support, this Avatar HD Kit V2 is engineered to redefine your perspective. The 2K/120fps/4:3 native sensor camera captures breathtaking views, expanding your creativity by enabling you to capture more of the surrounding environment during flight, resulting in stunning and immersive views.The Avatar HD system employs industry-leading H.265 coding technology, delivering unparalleled 1080p FPV image quality with ultra-low latency, a mere 22ms. This ensures seamless, real-time visuals while flying. With an impressive 4Km range, enjoy an extensive exploration radius without compromising on image quality or connection stability.Crafted with precision, this kit boasts optimized antenna base design...

The best quality First Person View equipment. Free or discounted shipping on all orders.Drone Racing, RC Airplanes, FPV Cameras, FPV Goggles, Video Transmitters, RC Quads, Drone Antennas, Lipo Batteries, and Ground Station Equipment.All available for amateurs, schools, hobbyists, government, and wholesale buyers.

Walksnail Avatar HD Kit V2 - 32GB w/ Gyro - RMRC

Walksnail Avatar HD Kit V2 32GB with Gyro

The Micro Camera and VTX Combo for Fat Shark Dominator HDO3 are provided by WalkSnail.
The video transmitter for the Fat Shark Dominator HD Goggles and Walksnail Goggles has arrived! The Walksnail Avatar HD Pro Kit features a VTX with enhanced TVS protection and support for up to 6S.  The VTX is resistant to GPS interference with a wide input voltage range of 6V to 25.2V. This kit also features 1080P compatibility, high frame starlight, a 4KM range, and an 8GB and 32GB built-in storage option. The 32GB VTX delivers unmatched stability due to the aid of being equipped with Gyroflow technology. This allows super smooth and stabilized video from your FPV system. Enjoy the unparalleled performance and take your FPV adventures to new heights with this cutting-edge technology!
Check out all our Walksnail HD products!




Features

Compatible with FatShark Dominator HD FPV Goggles
Canvas mode and distance detection with the dual-antenna system
Reliable digital HD video transmission (1080P – H.265 encoding)
Ultra low-latency (22ms)

2K pixel, 120fps, 4:3 native sensor
Support Gyroflow
1080P HD FPV
F/2.0 Large Aperture
160° wide-angle FOV


VTX Specifications

Communication Frequency 5.725-5.850GHz

Transmitter Power (EIRP) FCC:&amplt30dBmCE:&amplt14dBmSRRC:&amplt20dBm

MIC:&amplt25dBm

1/O Interface JST1.0x4(Power in)JST0.8x6(USB)

Mounting Holes 25.5x25.5mm 20x20mm

Dimensions 33.5x33.5x10.5mm

Storage 8G/32G

Recording 1080p/720p

Weight 17.6g

Operating Temperature -20-40℃

Channels 8

Wide Power Input 6V-25.2V

Supported FC System Betaflight Inav Fettec ArduPilot Kiss

OSD Canvas mode

Latency Average delay 22ms

Antenna 1(IPEX)

Camera Specifications

Model Avatar V2 camera
Image Sensor 1/3.2-Inch 4Mp 4:3sensor
Resolution 1080P/60fps 720P/100fps 720P/60fps1080P/120fps compatibility 1080P/100fps compatibility
Ratio 4:3 native /16:9
Lens 2.1mm
FOV 160°

Aperture F2.0

Shutter Rolling shutter

Min.Illumination 0.001Lux

Weight 7.2g

Dimensions 19x19x22mm

Coaxial Cable 140mm

Gyroflow supported/ non-supported, two version

Antenna Specifications

Polarization LHCP

Bandwidth 5600MHz-6000MHz.

Gain 1.9dBi

VSWR ≤1.5

Input Impedance 50Ω

Interface IPEX-1

Size R15x45mm (without cable）

Weight 2g

Includes

USB transfer extension cable X1

4 Pin silicone cable X1

M2x4mm screws X8

M2x5mm screws X4

M2x6mm screws X4

M2x14mm screws X4

M2x5x0.5mm gasket X4



The Micro Camera and VTX Combo for Fat Shark Dominator HDO3 are provided by WalkSnail.  The video transmitter for the Fat Shark Dominator HD Goggles and Walksnail Goggles has arrived! The Walksnail Avatar HD Pro Kit features a VTX with enhanced TVS protection and support for up to 6S.  The VTX is resistant to GPS inter

Walksnail Avatar HD Micro Camera & VTX Kit V2 - Choose Version from WREKD Co.

Walksnail Avatar HD Micro Camera & VTX Kit V2 - Choose Version

CADDX

The Micro Camera and VTX Combo for Fat Shark Dominator HDO3 are provided by WalkSnail.
The video transmitter for the Fat Shark Dominator HD Goggles and Walksnail Goggles has arrived! The Walksnail Avatar HD Pro Kit features a VTX with enhanced TVS protection and support for up to 6S.  The VTX is resistant to GPS interference with a wide input voltage range of 6V to 25.2V. This kit also features 1080P compatibility, high frame starlight, a 4KM range, and an 8GB and 32GB built-in storage option. The 32GB VTX delivers unmatched stability due to the aid of being equipped with Gyroflow technology. This allows super smooth and stabilized video from your FPV system. Enjoy the unparalleled performance and take your FPV adventures to new heights with this cutting-edge technology!
Check out all our Walksnail HD products!




Features

Compatible with FatShark Dominator HD FPV Goggles
Canvas mode and distance detection with the dual-antenna system
Reliable digital HD video transmission (1080P – H.265 encoding)
Ultra low-latency (22ms)

2K pixel, 120fps, 4:3 native sensor
Support Gyroflow
1080P HD FPV
F/2.0 Large Aperture
160° wide-angle FOV


VTX Specifications

Communication Frequency 5.725-5.850GHz

Transmitter Power (EIRP) FCC:&lt30dBmCE:&lt14dBmSRRC:&lt20dBm

MIC:&lt25dBm

1/O Interface JST1.0x4(Power in)JST0.8x6(USB)

Mounting Holes 25.5x25.5mm 20x20mm

Dimensions 33.5x33.5x10.5mm

Storage 8G/32G

Recording 1080p/720p

Weight 17.6g

Operating Temperature -20-40℃

Channels 8

Wide Power Input 6V-25.2V

Supported FC System Betaflight Inav Fettec ArduPilot Kiss

OSD Canvas mode

Latency Average delay 22ms

Antenna 1(IPEX)

Camera Specifications

Model Avatar V2 camera
Image Sensor 1/3.2-Inch 4Mp 4:3sensor
Resolution 1080P/60fps 720P/100fps 720P/60fps1080P/120fps compatibility 1080P/100fps compatibility
Ratio 4:3 native /16:9
Lens 2.1mm
FOV 160°

Aperture F2.0

Shutter Rolling shutter

Min.Illumination 0.001Lux

Weight 7.2g

Dimensions 19x19x22mm

Coaxial Cable 140mm

Gyroflow supported/ non-supported, two version

Antenna Specifications

Polarization LHCP

Bandwidth 5600MHz-6000MHz.

Gain 1.9dBi

VSWR ≤1.5

Input Impedance 50Ω

Interface IPEX-1

Size R15x45mm (without cable）

Weight 2g

Includes

USB transfer extension cable X1

4 Pin silicone cable X1

M2x4mm screws X8

M2x5mm screws X4

M2x6mm screws X4

M2x14mm screws X4

M2x5x0.5mm gasket X4



Walksnail HD Micro Camera & VTX Combo (Compatible w/ Fat Shark Dominator HD) For Sale

About this product ThisWalksnail Avatar HD Kit V2features built-in 32GB storage and Gyroflow support. The 2K/120fps/4:3 native sensor camera allows you to capture more of the surrounding scenery while flying the drone, resulting in more comprehensive and visually appealing images. The Avatar HD system uses H.265 code,

Walksnail Avatar HD V2 VTX Module - Dual Antenna Version

<div style="text-align: center" data-mce-fragment="1" data-mce-style="text-align: center">
<h3 style="text-align: left" data-mce-style="text-align: left">Bullet Points：<br>
</h3>
</div>
<div data-mce-fragment="1" data-mce-style="text-align: center">
<ul>
<li>The kit includes 20mm x 20mm and 25mm x 25mm mounting holes for greater compatibility with a wider range of FPV drone models.</li>
<li>Updated the design of PCB board and shell, improved the quality of VTX, more durable.</li>
<li>Optimized the installation place of the antenna, it's better to protect the VTX.</li>
<li>The position of the frequency binding button has been changed, to make the frequency binding operation more convenient.</li>
<li>The kit includes a spare power pad, providing an extra opportunity for welding.</li>
</ul>
</div>
<div data-mce-fragment="1" data-mce-style="text-align: center">
<div style="text-align: left" data-mce-style="text-align: left"><img alt="" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/5_a74bf4a9-87aa-4ca8-bc05-0c352e5b4676.jpg?v=1697782652"></div>
</div>
<div style="text-align: center" data-mce-fragment="1" data-mce-style="text-align: center">
<div style="text-align: left" data-mce-style="text-align: left">
<div style="text-align: left" data-mce-fragment="1" data-mce-style="text-align: left">
<ul>
<li>The Avatar VTX comes with 32g built-in storage it can record 1080P or 720P HD fly videos without interference. 32G built-in storage, recording video time increased by 4 times.</li>
</ul>
<p><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/7_a3368129-fde3-4c9c-9bea-7832b77c11f7.jpg?v=1695276608" style="float: none" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/7_a3368129-fde3-4c9c-9bea-7832b77c11f7.jpg?v=1695276608" data-mce-style="float: none"></p>
</div>
</div>
<div style="text-align: center" data-mce-style="text-align: center">
<div style="text-align: center" data-mce-style="text-align: center">
<div style="text-align: left" data-mce-style="text-align: left">
<article data-identifier-application__slash__x-doc-key="v1GXn4x3DLeonDQ4" data-identifier-application__slash__x-cangjie-fragment="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" data-clipboard-cangjie='["root",{"copyFrom":1329378339},["p",{"uuid":"lei4y6iyyt3vq4ejxk","ind":{"left":0},"list":{"listId":"y6t50qxp2xn","level":0,"isOrdered":false,"isTaskList":false,"isChecked":false,"listStyleType":"SCIR_ECIR_SREC","symbolStyle":{"shd":"#FFFFFF"},"listStyle":{"format":"bullet","text":"●","align":"left"},"hideSymbol":false,"extraData":{}}},["span",{"data-type":"text"},["span",{"highlight":"#FFFFFF","data-type":"leaf"},"TVS added, up to 8S"]]]]'>
<ul>
<li>New VTX with enhanced TVS protection and support for up to 6S. With a wide input voltage the range of 6V to 25.2V, our VTX delivers unmatched stability. Enjoy unparalleled performance and take your FPV adventures to new heights with our cutting-edge technology.</li>
</ul>
</article>
<article data-identifier-application__slash__x-doc-key="v1GXn4x3DLeonDQ4" data-identifier-application__slash__x-cangjie-fragment="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" data-clipboard-cangjie='["root",{"copyFrom":1329378339},["p",{"uuid":"lei4y6iyyt3vq4ejxk","ind":{"left":0},"list":{"listId":"y6t50qxp2xn","level":0,"isOrdered":false,"isTaskList":false,"isChecked":false,"listStyleType":"SCIR_ECIR_SREC","symbolStyle":{"shd":"#FFFFFF"},"listStyle":{"format":"bullet","text":"●","align":"left"},"hideSymbol":false,"extraData":{}}},["span",{"data-type":"text"},["span",{"highlight":"#FFFFFF","data-type":"leaf"},"TVS added, up to 8S"]]]]'><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/6_290966f5-24c6-4f62-a7be-716aaca90ffd.jpg?v=1695276215" style="margin-bottom: 16px float: none" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/6_290966f5-24c6-4f62-a7be-716aaca90ffd.jpg?v=1695276215" data-mce-style="margin-bottom: 16px float: none"></article>
<article data-identifier-application__slash__x-doc-key="v1GXn4x3DLeonDQ4" data-identifier-application__slash__x-cangjie-fragment="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" data-clipboard-cangjie='["root",{"copyFrom":1329378339},["p",{"uuid":"lei4y6iyyt3vq4ejxk","ind":{"left":0},"list":{"listId":"y6t50qxp2xn","level":0,"isOrdered":false,"isTaskList":false,"isChecked":false,"listStyleType":"SCIR_ECIR_SREC","symbolStyle":{"shd":"#FFFFFF"},"listStyle":{"format":"bullet","text":"●","align":"left"},"hideSymbol":false,"extraData":{}}},["span",{"data-type":"text"},["span",{"highlight":"#FFFFFF","data-type":"leaf"},"TVS added, up to 8S"]]]]'></article>
</div>
<div style="text-align: center" data-mce-style="text-align: center">
<table width="100%">
<tbody>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left"><strong>Specification</strong></td>
<td style="text-align: left" data-mce-style="text-align: left"></td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left"><strong>VTX</strong></td>
<td style="text-align: left" data-mce-style="text-align: left"> </td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Model</td>
<td style="text-align: left" data-mce-style="text-align: left">Avatar V2 module(Dual Antenna)</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Communication Frequency</td>
<td style="text-align: left" data-mce-style="text-align: left">5.725-5.850GHz</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Transmitter Power (EIRP)</td>
<td style="text-align: left" data-mce-style="text-align: left">FCC:&lt30dBm CE:&lt14dBm SRRC:&lt20dBm MIC:&lt25dBm</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">1/O Interface</td>
<td style="text-align: left" data-mce-style="text-align: left">JST1.0*4(Power in)JST0.8*6(USB)</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Mounting Holes</td>
<td style="text-align: left" data-mce-style="text-align: left">25.5*25.5mm 20*20mm</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Dimensions</td>
<td style="text-align: left" data-mce-style="text-align: left">33*33*<span style="color: #000000" data-mce-style="color: #000000">10.5</span>mm</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Storage</td>
<td style="text-align: left" data-mce-style="text-align: left">32G</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Recording</td>
<td style="text-align: left" data-mce-style="text-align: left">1080P/720P</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Weight</td>
<td style="text-align: left" data-mce-style="text-align: left">15.4g<br>
</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Operating Temperature</td>
<td style="text-align: left" data-mce-style="text-align: left">-20-40℃</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Channels</td>
<td style="text-align: left" data-mce-style="text-align: left">8</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Wide Power Input</td>
<td style="text-align: left" data-mce-style="text-align: left">6V-<span style="color: #000000" data-mce-style="color: #000000">25.2</span>V</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Supported FC System</td>
<td style="text-align: left" data-mce-style="text-align: left">Betaflight Inav Fettec ArduPilotKiss</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">OSD</td>
<td style="text-align: left" data-mce-style="text-align: left">Canvas mode</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Latency</td>
<td style="text-align: left" data-mce-style="text-align: left">Average delay 22ms</td>
</tr>
<tr>
<td style="text-align: left" data-mce-style="text-align: left">Antenna</td>
<td style="text-align: left" data-mce-style="text-align: left">2(IPEX)</td>
</tr>
</tbody>
</table>
</div>
</div>
</div>
</div>

Bullet Points： The kit includes 20mm x 20mm and 25mm x 25mm mounting holes for greater compatibility with a wider range of FPV drone models. Updated the design of PCB board and shell, improved the quality of VTX, more durable. Optimized the installation place of the antenna, it's better to protect the VTX. The position

Walksnail Avatar HD VTX V2 Module (Dual Antennas Version) – CADDX FPV


Bullet Points：




The kit includes 20mm x 20mm and 25mm x 25mm mounting holes for greater compatibility with a wider range of FPV drone models.
Updated the design of PCB board and shell, improved th

Walksnail Avatar HD VTX V2 Module (Dual Antennas Version)

The VTX has a new higher quality casing and is equipped with 20mm x 20mm and 25mm x 25mm mounting holes, allowing compatibility with a vast array of FPV drone models. The PCB board and shell design is more advanced, and the antenna-optimized installation place offers greater protection to the VTX. Dual antennas provide more stable and powerful signals. Using H.265 encoding for industry-leading 1080p images with low latency.
Check out all our Walksnail HD products and check out all our Walksnail compatible products!
Features

The module includes 20mm x 20mm and 25mm x 25mm mounting holes for greater compatibility with a wider range of FPV drone models.
Updated the design of PCB board and shell, improved the quality of VTX, more durable.
Optimized the installation place of the antenna, it&#39s better to protect the VTX.
The position of the frequency binding button has been changed, to make the frequency binding operation more convenient.
The module includes a spare power pad, providing an extra opportunity for welding.


A spare pad is added to provide two power connection modes.



New VTX with enhanced TVS protection and support for up to 6S. With a wide input voltage the range of 6V to 25.2V, our VTX delivers unmatched stability. Enjoy unparalleled performance and take your FPV adventures to new heights with our cutting-edge technology.




The Avatar VTX comes with 32g built-in storage it can record 1080p or 720p HD flight videos without interference. 32G built-in storage, recording video time increased by 4 times.




It supports high frame rate and standard frame rate at the same time. Under high frame rate, the average delay is 22ms.





Specifications

Model: Avatar V2 module(Dual Antenna)

Communication Frequency: 725-5.850GHz

Transmitter Power (EIRP): FCC:&amplt30dBmCE:&amplt14dBmSRRC:&amplt20dBm MIC:&amplt25dBm

1/O Interface: JST1.0x4(Power in)JST0.8x6(USB)

Mounting Holes: 25.5x25.5mm 20x20mm

Dimensions: 33.5x33.5x10.5mm

Storage: 32G

Recording: 1080p/720p

Weight: 15.4g

Operating Temperature: -20-40℃

Channels: 8

Wide Power Input: 6V-25.2V

Supported FC System: Betaflight Inav Fettec ArduPilot Kiss

OSD: Canvas mode

Latency: Average delay 22ms

Antenna: 2(IPEX)

Includes

1x Walksnail Avatar HD V2 20x20 / 25x25 VTX Module - (Dual Antenna Version)


The VTX has a new higher quality casing and is equipped with 20mm x 20mm and 25mm x 25mm mounting holes, allowing compatibility with a vast array of FPV drone models. The PCB board and shell design is more advanced, and the antenna-optimized installation place offers greater protection to the VTX. Dual antennas provide

Walksnail Avatar HD V2 20x20 / 25x25 VTX Module - (Dual Antenna Version) from WREKD Co.

Walksnail Avatar HD V2 20x20 / 25x25 VTX Module - (Dual Antenna Version)

The Walksnail Avatar HD VTX V2 is a versatile VTX module compatible with dual antennas.

Walksnail Avatar HD VTX V2 Module - 32GB Dual Antennas Version

The Walksnail Avatar HD VTX Module V2 provides superior performance with a range of features, including 25*25mm and 20*20mm mounting holes, optimized antenna installation, frequency binding button, spare power pad and 32GB built-in storage for 1080P or 720P HD fly videos. Increased TVS protection and support for up to

Walksnail Avatar HD VTX V2 Module Dual Antennas Version 32G (VTX ONLY) for Walksnail Avatar/Fatshark Dominator HD FPV System

The VTX has a new higher quality casing and is equipped with 20mm x 20mm and 25mm x 25mm mounting holes, allowing compatibility with a vast array of FPV drone models. The PCB board and shell design is more advanced, and the antenna-optimized installation place offers greater protection to the VTX. Dual antennas provide more stable and powerful signals. Using H.265 encoding for industry-leading 1080p images with low latency.
Check out all our Walksnail HD products and check out all our Walksnail compatible products!
Features

The module includes 20mm x 20mm and 25mm x 25mm mounting holes for greater compatibility with a wider range of FPV drone models.
Updated the design of PCB board and shell, improved the quality of VTX, more durable.
Optimized the installation place of the antenna, it's better to protect the VTX.
The position of the frequency binding button has been changed, to make the frequency binding operation more convenient.
The module includes a spare power pad, providing an extra opportunity for welding.


A spare pad is added to provide two power connection modes.



New VTX with enhanced TVS protection and support for up to 6S. With a wide input voltage the range of 6V to 25.2V, our VTX delivers unmatched stability. Enjoy unparalleled performance and take your FPV adventures to new heights with our cutting-edge technology.




The Avatar VTX comes with 32g built-in storage it can record 1080p or 720p HD flight videos without interference. 32G built-in storage, recording video time increased by 4 times.




It supports high frame rate and standard frame rate at the same time. Under high frame rate, the average delay is 22ms.





Specifications

Model: Avatar V2 module(Dual Antenna)

Communication Frequency: 725-5.850GHz

Transmitter Power (EIRP): FCC:&lt30dBmCE:&lt14dBmSRRC:&lt20dBm MIC:&lt25dBm

1/O Interface: JST1.0x4(Power in)JST0.8x6(USB)

Mounting Holes: 25.5x25.5mm 20x20mm

Dimensions: 33.5x33.5x10.5mm

Storage: 32G

Recording: 1080p/720p

Weight: 15.4g

Operating Temperature: -20-40℃

Channels: 8

Wide Power Input: 6V-25.2V

Supported FC System: Betaflight Inav Fettec ArduPilot Kiss

OSD: Canvas mode

Latency: Average delay 22ms

Antenna: 2(IPEX)

Includes

1x Walksnail Avatar HD V2 20x20 / 25x25 VTX Module - (Dual Antenna Version)


Walksnail Avatar HD V2 20x20 / 25x25 VTX Module - (Dual Antenna Versio

Walksnail Avatar HD Kit V2 VTX Kit - Micro Camera V2, Dual Antenna Version

Experience FPV like never before with the Walksnail Avatar HD Kit V2 with dual antennas.

Walksnail Avatar HD Kit V2 - 32GB + Gyro w/ Dual Antennas

Lightweight design, ultra-thin experience
The Walksnail Avatar VRX Kit Combo is only 83g and comes with 114x55x22mm a size easy to carry.


Walksnail VRX adopts a 4-antenna design. 2 directional antennas and the maximum transmission distance is 4km

1080P/60FPSWalksnail VRX adopts industry-leading H.265 encoding technology,which can provide a minimum delay of 22ms and a maximum resolution of 1080p.The HD picture quality takes you to experience the fun of flying a drone.

HDMI output ensures you enjoy uncompressed audio and video signals from the Walksnail HD system

Canvas ModeSupports Betaflight, INAV, and KISS with full OSD. You can easily adjust the parameters you want by remote control.

Specification

Camera:

Model Avatar nano/Avatar camera
Image Sensor: 1/2.7”1nch
Resolution: 1080P/60fps,720P/120fps,720P/60fps
Ratio: 16/9 4/3
Lens: 2.1mm
FOV: 170°
Aperture: F2.0
Shutter: Rolling shutter
Min.Illumination: 0.001Lux
Weight: 3.5g/6g
Dimensions: 14x14x17mm/19x19x22mm
Coaxial Cable: 90mm/140mm

VTX:

Model: Avatar V2 module(Dual Antenna)
Communication Frequency: 725-5.850GHz
Transmitter Power (EIRP): FCC:&lt30dBmCE:&lt14dBmSRRC:&lt20dBm MIC:&lt25dBm
1/O Interface: JST1.0x4(Power in)JST0.8x6(USB)
Mounting Holes: 25.5x25.5mm 20x20mm
Dimensions: 33.5x33.5x10.5mm
Storage: 32G
Recording: 1080p/720p
Weight: 15.4g
Operating Temperature: -20-40℃
Channels: 8
Wide Power Input: 6V-25.2V
Supported FC System: Betaflight Inav Fettec ArduPilot Kiss
OSD: Canvas mode
Latency: Average delay 22ms
Antenna: 2(IPEX)

Avatar HD VRX

Model Avatar HD VRX
CommunicationFrequency: 5.725-5.850GHz
TransmitterPower: (EIRP) FCC:&lt30dBmCE:&lt14dBmSRRC:&lt20dBmMIC:&lt25dBm
I/O Interface: HDMI, micro SD card slot, DC5.5x2.1mm
HDMI output: 1080p/60fps, 720p/100fps, 720p/60fps
Power Input: 7-21V(2S-5S)
SD Card Support:256G
System: Avatar HD system


Includes:

 Avatar VRX: (or buy alone)

RedBirdAntenna x2
HDMI cable x1
2-in-1 DCPowerCable x1

Avatar Micro V2 HD Kit (Dual Antenna Version): (or buy alone)

1x Walksnail Avatar HD Kit V2 20x20 / 25x25 VTX Kit w/ Micro Camera V2 - (Dual Antenna Version)
1x USB transfer extension cable
1x 4 Pin silicone cable
8x M2x4mm screws
4x M2x5mm screws
4x M2x6mm screws
4x M2x14mm screws
4x M2x5x0.5mm gasket


Lightweight design, ultra-thin experience  The Walksnail Avatar VRX Kit Combo is only 83g and comes with 114x55x22mm; a size easy to carry. Walksnail VRX adopts a 4-antenna design. 2 directional antennas and the maximum transmission distance is 4km 1080P/60FPSWalksnail VRX adopts industry-leading H.265 encoding technol

Walksnail Avatar HD V2 VTX Micro Kit Combo - (Dual Antenna Version)

Walksnail Avatar HD Kit V2 (Dual Antennas Version) Features Dual antennas Compatible 4K 1080P 120fps compatibility 22ms low latency Ranging Mode 4KM range Light weight design FOV160° Built-in 32G storage,  Support Gyroflow 6V-25.2V The only native 4:3 high-definition sensor in the FPV industry Bullet Points for Walksna

Walksnail Avatar HD Kit V2 (Dual Antennas Version) – CADDX FPV

Walksnail Avatar HD Kit V2 (Dual Antennas Version)

Features


Dual antennas
Compatible 4K
1080P 120fps compatibility
22ms low latency
Ranging Mode
4KM range
Light weight design
FOV160°
Built-in 32G s

Walksnail Avatar HD Kit V2 (Dual Antennas Version)

Walksnail Avatar HD Kit V2 Dual Antennas Version 32G with Camera V2+Gyroflow for Walksnail Avatar/Fatshark Dominator HD FPV System

Introducing the Walksnail Avatar HD Kit V2 (Dual Antenna Version)! This kit offers improved VTX with a new higher quality casing and is equipped with 20mm x 20mm and 25mm x 25mm mounting holes, allowing compatibility with a vast array of FPV drone models. The PCB board and shell design is more advanced, and the antenna-optimized installation place offers greater protection to the VTX. Dual antennas provide more stable and powerful signals. Using H.265 encoding for industry-leading 1080p images with low latency. Camera V2 delivers 2K pixels, a 4:3 native sensor for enhanced visuals, and a native 4:3 mode ratio so you can capture more of your surroundings in stunning detail. This kit includes the new VTX and camera, coming with 2 antennas.

Check out all our Walksnail HD products and check out all our Walksnail compatible products!
Features

Dual antennas
Compatible 4K
1080P 120fps compatibility
22ms low latency
Ranging Mode
4KM range
Lightweight design
FOV160°
Built-in 32G storage,
Support Gyroflow
6V-25.2V
The only native 4:3 high-definition sensor in the FPV industry







The Avatar HD system uses H.265 code, an industry-leading technology, to provide 1080p FPV image quality with low latency.
Camera V2 with 2K pixels, 4:3 native sensor for better image quality and native 4:3 mode image ratio allows you to capture more of the surrounding scenery while flying the drone, resulting in more comprehensive and visually appealing images. Meanwhile, it's a better fit for regular FPV races as well.



The camera ( 32G VTX KIT) supports Gyroflow, take you a smooth and stable video quality.



The kit includes 20mm x 20mm and 25mm x 25mm mounting holes for greater compatibility with a wider range of FPV drone models.
Updated the design of PCB board and shell, improved the quality of VTX, more durable.
Optimized the installation place of the antenna, so as to better protect the VTX.
The position of the frequency binding button has been changed to make the frequency binding operation more convenient.
A spare pad is added to provide two power connection modes.




New VTX with enhanced TVS protection and support for up to 6S. With a wide input voltage the range of 6V to 25.2V, our VTX delivers unmatched stability. Enjoy unparalleled performance and take your FPV adventures to new heights with our cutting-edge technology.




Supports both high frame rate and standard frame rate, it has an average latency of 22ms with the high frame rate.



Designed to carry dual antennas to achieve more stable and powerful signals. The quality of the antenna is upgraded, and the working performance of the whole frequency band is more stable.


Specification
Camera

Model: Avatar V2 camera

Image Sensor: 1/3.2-Inch 4Mp 4:3sensor

Resolution: 1080P/60fps 720P/100fps 720P/60fps1080P/120fps compatibility
1080P/100fps compatibility

Ratio: 4:3 native /16:9

Lens: 2.1mm

FOV: 160°

Aperture: F2.0

Shutter: Rolling shutter

Min.Illumination: 0.001Lux

Weight: 7.2g

Dimensions: 19x19x22mm

Coaxial Cable: 140mm

Gyroflow: Only 32G VTX Supported

VTX



Model: Avatar V2 module(Dual Antenna)
Communication Frequency: 725-5.850GHz
Transmitter Power (EIRP): FCC:&lt30dBmCE:&lt14dBmSRRC:&lt20dBm MIC:&lt25dBm
1/O Interface: JST1.0x4(Power in)JST0.8x6(USB)
Mounting Holes: 25.5x25.5mm 20x20mm
Dimensions: 33.5x33.5x10.5mm
Storage: 32G
Recording: 1080p/720p
Weight: 15.4g
Operating Temperature: -20-40℃
Channels: 8
Wide Power Input: 6V-25.2V
Supported FC System: Betaflight Inav Fettec ArduPilot Kiss
OSD: Canvas mode
Latency: Average delay 22ms
Antenna: 2(IPEX)

Avatar V2 antenna

Polarization: LHCP
Bandwidth: 5600MHz-6000MHz
Gain: 1.9dBi
VSWR: ≤1.5
Input Impedance: 50Ω
Interface: IPEX-1
Size: R15 X 45mm （without cable）
Weight: 2g

Includes

1x Walksnail Avatar HD Kit V2 20x20 / 25x25 VTX Kit w/ Micro Camera V2 - (Dual Antenna Version)
1x USB transfer extension cable
1x 4 Pin silicone cable
8x M2x4mm screws
4x M2x5mm screws
4x M2x6mm screws
4x M2x14mm screws
4x M2x5x0.5mm gasket






Introducing the Walksnail Avatar HD Kit V2 (Dual Antenna Version)! This kit offers improved VTX with a new higher quality casing and is equipped with 20mm x 20mm and 25mm x 25mm mounting holes, allowing compatibility with a vast array of FPV drone models. The PCB board and shell design is more advanced, and the antenna

Walksnail Avatar HD Kit V2 20x20 / 25x25 VTX Kit w/ Micro Camera V2 - (Dual Antenna Version)

Walksnail Avatar HD Kit V2 20x20 / 25x25 VTX Kit w/ Micro Camera V2 -

Introducing the Walksnail Avatar HD Kit V2 (Dual Antenna Version)! This kit offers improved VTX with a new higher quality casing and is equipped with 20mm x 20mm and 25mm x 25mm mounting holes, allowing compatibility with a vast array of FPV drone models. The PCB board and shell design is more advanced, and the antenna-optimized installation place offers greater protection to the VTX. Dual antennas provide more stable and powerful signals. Using H.265 encoding for industry-leading 1080p images with low latency. Camera V2 delivers 2K pixels, a 4:3 native sensor for enhanced visuals, and a native 4:3 mode ratio so you can capture more of your surroundings in stunning detail. This kit includes the new VTX and camera, coming with 2 antennas.

Check out all our Walksnail HD products and check out all our Walksnail compatible products!
Features

Dual antennas
Compatible 4K
1080P 120fps compatibility
22ms low latency
Ranging Mode
4KM range
Lightweight design
FOV160°
Built-in 32G storage,
Support Gyroflow
6V-25.2V
The only native 4:3 high-definition sensor in the FPV industry







The Avatar HD system uses H.265 code, an industry-leading technology, to provide 1080p FPV image quality with low latency.
Camera V2 with 2K pixels, 4:3 native sensor for better image quality and native 4:3 mode image ratio allows you to capture more of the surrounding scenery while flying the drone, resulting in more comprehensive and visually appealing images. Meanwhile, it&#39s a better fit for regular FPV races as well.



The camera ( 32G VTX KIT) supports Gyroflow, take you a smooth and stable video quality.



The kit includes 20mm x 20mm and 25mm x 25mm mounting holes for greater compatibility with a wider range of FPV drone models.
Updated the design of PCB board and shell, improved the quality of VTX, more durable.
Optimized the installation place of the antenna, so as to better protect the VTX.
The position of the frequency binding button has been changed to make the frequency binding operation more convenient.
A spare pad is added to provide two power connection modes.




New VTX with enhanced TVS protection and support for up to 6S. With a wide input voltage the range of 6V to 25.2V, our VTX delivers unmatched stability. Enjoy unparalleled performance and take your FPV adventures to new heights with our cutting-edge technology.




Supports both high frame rate and standard frame rate, it has an average latency of 22ms with the high frame rate.



Designed to carry dual antennas to achieve more stable and powerful signals. The quality of the antenna is upgraded, and the working performance of the whole frequency band is more stable.


Specification
Camera

Model: Avatar V2 camera

Image Sensor: 1/3.2-Inch 4Mp 4:3sensor

Resolution: 1080P/60fps 720P/100fps 720P/60fps1080P/120fps compatibility
1080P/100fps compatibility

Ratio: 4:3 native /16:9

Lens: 2.1mm

FOV: 160°

Aperture: F2.0

Shutter: Rolling shutter

Min.Illumination: 0.001Lux

Weight: 7.2g

Dimensions: 19x19x22mm

Coaxial Cable: 140mm

Gyroflow: Only 32G VTX Supported

VTX



Model: Avatar V2 module(Dual Antenna)
Communication Frequency: 725-5.850GHz
Transmitter Power (EIRP): FCC:&amplt30dBmCE:&amplt14dBmSRRC:&amplt20dBm MIC:&amplt25dBm
1/O Interface: JST1.0x4(Power in)JST0.8x6(USB)
Mounting Holes: 25.5x25.5mm 20x20mm
Dimensions: 33.5x33.5x10.5mm
Storage: 32G
Recording: 1080p/720p
Weight: 15.4g
Operating Temperature: -20-40℃
Channels: 8
Wide Power Input: 6V-25.2V
Supported FC System: Betaflight Inav Fettec ArduPilot Kiss
OSD: Canvas mode
Latency: Average delay 22ms
Antenna: 2(IPEX)

Avatar V2 antenna

Polarization: LHCP
Bandwidth: 5600MHz-6000MHz
Gain: 1.9dBi
VSWR: ≤1.5
Input Impedance: 50Ω
Interface: IPEX-1
Size: R15 X 45mm （without cable）
Weight: 2g

Includes

1x Walksnail Avatar HD Kit V2 20x20 / 25x25 VTX Kit w/ Micro Camera V2 - (Dual Antenna Version)
1x USB transfer extension cable
1x 4 Pin silicone cable
8x M2x4mm screws
4x M2x5mm screws
4x M2x6mm screws
4x M2x14mm screws
4x M2x5x0.5mm gasket






Walksnail Avatar HD Kit V2 20x20 / 25x25 VTX Kit w/ Micro Camera V2 - (Dual Antenna Version) from WREKD Co.

Walksnail Avatar HD Kit V2 (Dual Antennas Version) - RMRC

Walksnail Avatar HD V2 Pro VTX Kit - Micro Camera Pro, Dual Antenna Version

<h3 style="text-align: left" data-mce-style="text-align: left">
<strong>Walksnail Avatar HD Pro kit (Dual Antennas Version)</strong><br>
</h3>
<div style="text-align: left" data-mce-style="text-align: left"><img alt="" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/1_6693b86b-9816-40fe-9110-90a3a60f89f4.jpg?v=1697782631"></div>
<div style="text-align: left" data-mce-style="text-align: left">
<h3 data-mce-fragment="1"><strong data-mce-fragment="1">features：</strong></h3>
<ul>
<li>Dual Antennas</li>
<li><span>Compatible 4K</span></li>
<li>FOV160°</li>
<li>6V-25.2V</li>
<li>4km range</li>
<li>22ms low latency</li>
<li>Built-in 32G storage</li>
<li>High frame starlight</li>
<li>1080P 120fps compatibility</li>
<li>Sony Starvis Ⅱ Technology</li>
</ul>
</div>
<div style="text-align: left" data-mce-style="text-align: left"><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/2_a80ae180-77a5-4803-8dbb-531f11776930.jpg?v=1697799663" alt=""></div>
<h3 data-mce-fragment="1"><strong data-mce-fragment="1">Bullet Points for Avatar HD Pro kit (Dual Antennas)</strong></h3>
<ul>
<li>The Avatar HD system uses H.265 code, an industry-leading technology, to provide 1080p FPV image quality with low latency. Support 1080P/60FPS, 720P/120FPS.</li>
<li>Featuring a 1/1.8 inch Sony Starvis <meta charset="utf-8"> <span data-mce-fragment="1">Ⅱ </span>sensor, this camera delivers excellent night vision that's just as clear as day.</li>
</ul>
<div style="text-align: left" data-mce-style="text-align: left"><img alt="" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/3_db239c08-d489-41ff-9fd3-cd1a35bb05e0.jpg?v=1697792677"></div>
<div style="text-align: left" data-mce-style="text-align: left">
<ul>
<li>The camera supports Gyroflow, take you smooth and stable video quality.</li>
</ul>
<img data-mce-fragment="1" style="margin-bottom: 16px float: none" alt="supports Gyroflow" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/GIF16fps.gif?v=1679280057" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/GIF16fps_480x480.gif?v=1679280057" data-mce-style="float: none"><br>
</div>
<div style="text-align: left" data-mce-style="text-align: left">
<ul>
<li style="text-align: left" data-mce-style="text-align: left">The kit includes 20mm x 20mm and 25mm x 25mm mounting holes for greater compatibility with a wider range of FPV drone models.  </li>
<li style="text-align: left" data-mce-style="text-align: left">Updated the design of PCB board and shell, improved the quality of VTX, more durable.</li>
<li style="text-align: left" data-mce-style="text-align: left">Optimized the installation place of the antenna, so as to better protect the VTX.</li>
<li style="text-align: left" data-mce-style="text-align: left">The position of the frequency binding button has been changed to make the frequency binding operation more convenient.</li>
<li style="text-align: left" data-mce-style="text-align: left">A spare pad is added to provide two power connection modes. </li>
</ul>
<span style="font-size: 0.875rem"> <img data-mce-fragment="1" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/5_a74bf4a9-87aa-4ca8-bc05-0c352e5b4676.jpg?v=1697782652" alt="" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/5_a74bf4a9-87aa-4ca8-bc05-0c352e5b4676.jpg?v=1697782652"></span><br>
<article data-identifier-application__slash__x-doc-key="v1GXn4x3DLeonDQ4" data-identifier-application__slash__x-cangjie-fragment="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" data-clipboard-cangjie='["root",{"copyFrom":1329378339},["p",{"uuid":"lei4y6iyyt3vq4ejxk","ind":{"left":0},"list":{"listId":"y6t50qxp2xn","level":0,"isOrdered":false,"isTaskList":false,"isChecked":false,"listStyleType":"SCIR_ECIR_SREC","symbolStyle":{"shd":"#FFFFFF"},"listStyle":{"format":"bullet","text":"●","align":"left"},"hideSymbol":false,"extraData":{}}},["span",{"data-type":"text"},["span",{"highlight":"#FFFFFF","data-type":"leaf"},"TVS added, up to 8S"]]]]'>
<ul>
<li>New VTX with enhanced TVS protection and support for up to 6S. With a wide input voltage the range of 6V to 25.2V, our VTX delivers unmatched stability. Enjoy unparalleled performance and take your FPV adventures to new heights with our cutting-edge technology.</li>
</ul>
</article>
<article data-identifier-application__slash__x-doc-key="v1GXn4x3DLeonDQ4" data-identifier-application__slash__x-cangjie-fragment="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" data-clipboard-cangjie='["root",{"copyFrom":1329378339},["p",{"uuid":"lei4y6iyyt3vq4ejxk","ind":{"left":0},"list":{"listId":"y6t50qxp2xn","level":0,"isOrdered":false,"isTaskList":false,"isChecked":false,"listStyleType":"SCIR_ECIR_SREC","symbolStyle":{"shd":"#FFFFFF"},"listStyle":{"format":"bullet","text":"●","align":"left"},"hideSymbol":false,"extraData":{}}},["span",{"data-type":"text"},["span",{"highlight":"#FFFFFF","data-type":"leaf"},"TVS added, up to 8S"]]]]'><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/6_290966f5-24c6-4f62-a7be-716aaca90ffd.jpg?v=1695276215" style="margin-bottom: 16px float: none"></article>
</div>
<div style="text-align: center" data-mce-style="text-align: center">
<div data-mce-fragment="1" style="text-align: left" data-mce-style="text-align: left">
<ul>
<li>The Avatar VTX comes with 32g built-in storage it can record 1080p or 720p HD flight videos without interference. 32G built-in storage, recording video time increased by 4 times.</li>
</ul>
</div>
<div data-mce-fragment="1" style="text-align: left" data-mce-style="text-align: left"><img alt="" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/7_07adb9a2-5388-4344-9a8b-77be62e090d6.jpg?v=1697792703"></div>
<div data-mce-fragment="1" style="text-align: left" data-mce-style="text-align: left">
<div data-mce-fragment="1" style="text-align: left" data-mce-style="text-align: left">
<ul data-mce-fragment="1">
<li>It supports high frame rate and standard frame rate at the same time. Under high frame rate, the average delay is 22ms.</li>
</ul>
</div>
<div data-mce-fragment="1" style="text-align: left" data-mce-style="text-align: left"><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/GIF301.gif?v=1697622391" alt=""></div>
</div>
</div>
<ul>
<li>Designed to carry dual antennas to achieve more stable and powerful signals. The quality of the antenna is upgraded, and the working performance of the whole frequency band is more stable.</li>
</ul>
<div style="text-align: center" data-mce-style="text-align: center"><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/9_414bb70a-f9d8-499f-963d-2bd927b3ecd3.jpg?v=1695276321" style="margin-bottom: 16px float: none"></div>
<div style="text-align: center" data-mce-style="text-align: center"><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/10_7a7205eb-1872-426b-b1c5-e5ebcdf2fd5e.jpg?v=1695276654" style="margin-bottom: 16px float: none"></div>
<div style="text-align: center" data-mce-style="text-align: center"><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/11_dc4419c0-6b01-4579-91dd-d77ed17cb7e8.jpg?v=1695276668" style="margin-bottom: 16px float: none"></div>
<div data-mce-fragment="1" style="text-align: start" data-mce-style="text-align: start">
<table width="100%">
<tbody>
<tr>
<td><strong data-mce-fragment="1">Specification</strong></td>
<td></td>
</tr>
<tr>
<td><strong data-mce-fragment="1">Camera</strong></td>
<td> </td>
</tr>
<tr>
<td><span>Model</span></td>
<td><span>Avatar HD Pro Camera</span></td>
</tr>
<tr>
<td><span>Image Sensor</span></td>
<td>
<span>1/1.8-Inch Sony Starvis </span><span data-mce-fragment="1">Ⅱ</span><span> Sensor</span>
</td>
</tr>
<tr>
<td><span>Resolution</span></td>
<td><span>1080P/60fps720P/120fps,720P/60fps1080P/120fps compatibility</span></td>
</tr>
<tr>
<td><span>Ratio</span></td>
<td><span>16/9 4/3</span></td>
</tr>
<tr>
<td><span>Lens</span></td>
<td><span>8Mp</span></td>
</tr>
<tr>
<td><span>FOV</span></td>
<td><span>160°</span></td>
</tr>
<tr>
<td><span>Aperture</span></td>
<td><span>F1.6</span></td>
</tr>
<tr>
<td><span>Shutter</span></td>
<td><span>Rolling shutter</span></td>
</tr>
<tr>
<td><span>Min.Illumination</span></td>
<td><span>0.00001Lux</span></td>
</tr>
<tr>
<td><span>Weight</span></td>
<td><span>9.5g</span></td>
</tr>
<tr>
<td><span>Dimensions</span></td>
<td><span>19*19*24mm</span></td>
</tr>
<tr>
<td><span>Coaxial Cable</span></td>
<td><span>140mm</span></td>
</tr>
<tr>
<td><strong>VTX</strong></td>
<td></td>
</tr>
<tr>
<td><span>Model</span></td>
<td><span>Avatar V2 Pro Module(Dual Antenna)</span></td>
</tr>
<tr>
<td><span>Communication Frequency</span></td>
<td><span>5.725-5.850GHz</span></td>
</tr>
<tr>
<td><span>Transmitter Power (EIRP)</span></td>
<td>
<span>FCC:&lt30dBm CE:&lt14dBm SRRC:&lt20dBm </span><span>MIC:&lt25dBm</span>
</td>
</tr>
<tr>
<td><span>1/O Interface</span></td>
<td><span>JST1.0*4(Power in)JST0.8*6(USB)</span></td>
</tr>
<tr>
<td><span>Mounting Holes</span></td>
<td><span>25.5*25.5mm 20*20mm</span></td>
</tr>
<tr>
<td><span>Dimensions</span></td>
<td><span>33.5*33.5*10.5mm</span></td>
</tr>
<tr>
<td><span>Storage</span></td>
<td><span>32G</span></td>
</tr>
<tr>
<td><span>Recording</span></td>
<td><span>1080p/720p</span></td>
</tr>
<tr>
<td><span>Weight</span></td>
<td><span mce-data-marked="1">15.4g</span></td>
</tr>
<tr>
<td><span>Operating Temperature</span></td>
<td><span>-20-40℃</span></td>
</tr>
<tr>
<td><span>Channels</span></td>
<td><span>8</span></td>
</tr>
<tr>
<td><span>Wide Power Input</span></td>
<td><span>6V-25.2V</span></td>
</tr>
<tr>
<td><span>Supported FC System</span></td>
<td><span>Betaflight Inav Fettec ArduPilotKiss</span></td>
</tr>
<tr>
<td><span>OSD</span></td>
<td><span>Canvas mode</span></td>
</tr>
<tr>
<td><span>Latency</span></td>
<td><span>Average delay 22ms</span></td>
</tr>
<tr>
<td><span>Antenna</span></td>
<td><span>2(IPEX)</span></td>
</tr>
<tr>
<td><span><strong>Avatar V2 Antenna</strong></span></td>
<td><span></span></td>
</tr>
<tr>
<td><span>Polarization</span></td>
<td><span>LHCP</span></td>
</tr>
<tr>
<td><span>Frequency range</span></td>
<td><span>5600MHz-6000MHz</span></td>
</tr>
<tr>
<td><span>Gain</span></td>
<td><span>1.9dBi</span></td>
</tr>
<tr>
<td><span>VSWR</span></td>
<td><span>≤1.5</span></td>
</tr>
<tr>
<td><span>Input Impedance</span></td>
<td><span>50Ω</span></td>
</tr>
<tr>
<td><span>Interface</span></td>
<td><span>IPEX-1</span></td>
</tr>
<tr>
<td><span>Size</span></td>
<td><span>R15 X 45mm(without cable)</span></td>
</tr>
<tr>
<td><span>Weight</span></td>
<td><span>2g</span></td>
</tr>
<tr>
<td><span><strong>Packing List</strong></span></td>
<td><span></span></td>
</tr>
<tr>
<td><span>USB transfer extension cable</span></td>
<td><span>X1</span></td>
</tr>
<tr>
<td><span>4 Pin silicone cable</span></td>
<td><span>X1</span></td>
</tr>
<tr>
<td><span>M2*4mm screws</span></td>
<td><span>X8</span></td>
</tr>
<tr>
<td><span>M2*5mm screws</span></td>
<td><span>X4</span></td>
</tr>
<tr>
<td><span>M2*6mm screws</span></td>
<td><span>X4</span></td>
</tr>
<tr>
<td><span>M2*14mm screws</span></td>
<td><span>X4</span></td>
</tr>
<tr>
<td><span>M2*5*0.5mm gasket</span></td>
<td><span>X4</span></td>
</tr>
</tbody>
</table>
<br>
</div>

Walksnail Avatar HD Pro kit (Dual Antennas Version) features： Dual Antennas Compatible 4K FOV160° 6V-25.2V 4km range 22ms low latency Built-in 32G storage High frame starlight 1080P 120fps compatibility Sony Starvis Ⅱ Technology Bullet Points for Avatar HD Pro kit (Dual Antennas) The Avatar HD system uses H.265 code, a

Walksnail Avatar HD Pro Kit (Dual Antennas Version) – CADDX FPV


Walksnail Avatar HD Pro kit (Dual Antennas Version)



features：

Dual Antennas
Compatible 4K
FOV160°
6V-25.2V
4km range
22ms low latency
Built-in 32G storage
High frame starlight
1080P 120fps compat

Walksnail Avatar HD Pro Kit (Dual Antennas Version)

WALKSNAIL Avatar HD Pro Kit (Dual Antenna)

WALKSNAIL Avatar HD Pro Kit (Dual Antenna) - RMRC

This kit offers improved VTX with a new higher quality casing and is equipped with 20mm x 20mm and 25mm x 25mm mounting holes, allowing compatibility with a vast array of FPV drone models. The PCB board and shell design is more advanced, and the antenna-optimized installation place offers greater protection to the VTX. Dual antennas provide more stable and powerful signals. Using H.265 encoding for industry-leading 1080p images with low latency.  This kit includes the new VTX and camera, coming with 2 antennas. The micro camera comes with a 1/1.8 inch Sony Starvis Ⅱ sensor, come with extremely clear night vision. Supports 1080P/120fps high frame, the first high frame night vision HD camera in the FPV market. Walksnail Avatar camera has 160° wide-angle FOV, send you a more natural and real picture. This kit includes the new VTX and camera, coming with 2 antennas.
Check out all our Walksnail HD products and check out all our Walksnail compatible products!
Features

Dual Antennas
Compatible 4K
FOV160°
6V-25.2V
4km range
22ms low latency
Built-in 32G storage
High frame starlight
1080P 120fps compatibility
Sony Starvis Ⅱ Technology






The Avatar HD system uses H.265 code, an industry-leading technology, to provide 1080p FPV image quality with low latency. Support 1080P/60FPS, 720P/120FPS.
Featuring a 1/1.8 inch Sony Starvis Ⅱ sensor, this camera delivers excellent night vision that's just as clear as day.



The camera supports Gyroflow, take you smooth and stable video quality.



The kit includes 20mm x 20mm and 25mm x 25mm mounting holes for greater compatibility with a wider range of FPV drone models.
Updated the design of PCB board and shell, improved the quality of VTX, more durable.
Optimized the installation place of the antenna, so as to better protect the VTX.
The position of the frequency binding button has been changed to make the frequency binding operation more convenient.
A spare pad is added to provide two power connection modes.



New VTX with enhanced TVS protection and support for up to 6S. With a wide input voltage the range of 6V to 25.2V, our VTX delivers unmatched stability. Enjoy unparalleled performance and take your FPV adventures to new heights with our cutting-edge technology.




The Avatar VTX comes with 32g built-in storage it can record 1080p or 720p HD flight videos without interference. 32G built-in storage, recording video time increased by 4 times.




It supports high frame rate and standard frame rate at the same time. Under high frame rate, the average delay is 22ms.



Designed to carry dual antennas to achieve more stable and powerful signals. The quality of the antenna is upgraded, and the working performance of the whole frequency band is more stable.





Specifications
Camera

Model: Avatar HD Pro Camera
Image Sensor: 1/1.8-Inch Sony Starvis Ⅱ Sensor
Resolution: 1080P/60fps720P/120fps,720P/60fps1080P/120fps compatibility
Ratio: 16/9 4/3
Lens: 8Mp
FOV: 160°
Aperture: F1.6
Shutter: Rolling shutter
Min.Illumination: 0.00001Lux
Weight: 9.5g
Dimensions: 19x19x24mm
Coaxial Cable: 140mm

VTX

Model: Avatar V2 Pro Module(Dual Antenna)
Communication Frequency: 5.725-5.850GHz
Transmitter Power (EIRP): FCC:&lt30dBm CE:&lt14dBm SRRC:&lt20dBm MIC:&lt25dBm
1/O Interface: JST1.0x4(Power in)JST0.8x6(USB)
Mounting Holes: 25.5x25.5mm 20x20mm
Dimensions: 33.5x33.5x10.5mm
Storage: 32G
Recording: 1080p/720p
Weight: 15.4g
Operating Temperature: -20-40℃
Channels: 8
Wide Power Input: 6V-25.2V
Supported FC System:Betaflight Inav Fettec ArduPilotKiss
OSD: Canvas mode
Latency: Average delay 22ms
Antenna: 2(IPEX)

Avatar V2 Antenna

Polarization: LHCP
Frequency range: 5600MHz-6000MHz
Gain: 1.9dBi
VSWR: ≤1.5
Input Impedance: 50Ω
Interface: IPEX-1
Size: R15 X 45mm(without cable)
Weight: 2g

Includes

1x Walksnail Avatar HD Pro Kit 20x20 / 25x25 VTX Kit w/ Micro Camera Pro - (Dual Antenna Version)
1x USB transfer extension cable
1x 4 Pin silicone cable
8x M2x4mm screws
4x M2x5mm screws
4x M2x6mm screws
4x Mx14mm screws
4x M2x5x0.5mm gasket





This kit offers improved VTX with a new higher quality casing and is equipped with 20mm x 20mm and 25mm x 25mm mounting holes, allowing compatibility with a vast array of FPV drone models. The PCB board and shell design is more advanced, and the antenna-optimized installation place offers greater protection to the VTX.

Walksnail Avatar HD Pro Kit 20x20 / 25x25 VTX Kit w/ Micro Camera Pro - (Dual Antenna Version)

Walksnail Avatar HD Pro Kit 20x20 / 25x25 VTX Kit w/ Micro Camera Pro

The Walksnail Avatar HD Pro Kit utilizes cutting-edge H.265 coding, ensuring top-tier 1080p FPV visuals while maintaining minimal latency.&nbsp

The Walksnail Avatar HD Pro Kit utilizes cutting-edge H.265 coding, ensuring top-tier 1080p FPV visuals while maintaining minimal latency.

Walksnail Avatar HD Pro Kit - 32GB w/ Dual Antennas

This Walksnail Avatar Digital HD Pro Kit is designed for use with Walksnail Avatar/Fatshark Dominator HD FPV systems. It features H.265 encoding to provide 1080p FPV image quality with ultra-low latency and 1/1.8 inch Sony Starvis Ⅱ sensor, come with extremely clear night vision as long as day vision. The kit also supp

Walksnail Avatar HD Pro Kit Dual Antennas Version 32G with Pro Camera+Gyroflow for Walksnail Avatar/Fatshark Dominator HD FPV System

ESC Stack Mount

The ESC(s) controls your motors’ speed. It draws power from the battery to spin the motors based on what the FC tells it to do. Each motor needs an ESC. It’s common today to see 4-in-1 ESCs so you only need to buy a single part. For beginners, choose a 4-in-1 ESC that has a compatible mount with your frame and FC. The biggest consideration is amperage limit. We show you ESCs with appropriate amperage limits based on your frame size. You can calculate how much amperage you need based on your motor and prop choice.

ESCs

HDZero

HDZero Freestyle V2 1W Digital HD VTX Kit

HDZero Freestyle V2 VTX is the second generation 5.8GHz digital video transmitter, perfect for most 3.5-inch and 5-inch drones. It comes in a CNC case that guarantees durable RF shielding with improved signal integrity. A wire harness is included for solderless connection for power and MSP UART port. Moreover, the ante

HDZero Freestyle V2 20x20 25-1000mW HD VTX Kit W/u.FL

Divimath


HDZero Freestyle V2 VTX is the second generation 5.8GHz digital video transmitter, perfect for most 3.5-inch and 5-inch drones. It comes in a CNC case that guarantees durable RF shielding with improved signal integrity. A wire harness is included for solderless connection for power and MSP UART port. Moreover, the antenna and MIPI cable are secured with a retention bar and screws. This VTX supports 720p60, 1080p30, 540p60, and 540p90 video modes.























This VTX can fit most frames that can accommodate the Caddx Vista/Runcam Link VTX.
The kit includes a Runcam HDZero Nano 90, HDZero RHCP Antenna, and a 120mm MIPI Cable.
The RunCam HDZero Nano 90 HD Camera is the first 90fps camera for HDZero VTX. This camera enables HDZero to be 5ms faster than analog 60i video to show a full field/frame.











Check out all our VTXs and our HDZero selection.
















Specification
Freestyle V2 VTX

Manufacturer:  Divimath, Inc
Model:  HDZero Freestyle V2 VTX
Weight:  22.3g
Dimensions:  29x30x14mm
Operating Frequency:  5.725-5.850GHz
Transmitter Power:  25mW, 200mW, XXXXmW
Mounting Pattern:  20x20mm M2 Holes
Antenna Interface:  Secured u.FL
Video In:  Secured MIPI
SmartAudio:  YES
MSP Canvas Mode:  YES
Input Power:  7-25V
Operating Temperature:  32F-104F (0-40C)
Power Consumption:  6-15W

Runcam HDZero Nano 90

Resolution: 540P@90fps 4:3 | 720P@60fps 4:3
Dimensions: L18mmxW14mmxH18mm
Lens: FOV D:160° H:127° V:92°
Net Weight: 5.2g(without cable)
Shutter: Rolling Shutter
Image Sensor: 1/3&quot

Includes

1x  HDZero Freestyle V2 20x20 25-1000mW Digital HD VTX - U.FL

1x Nano 90 Camera (with 19 x 19 Mount)


1x HDZero RHCP Antenna


1x 120mm MIPI Cable


1x Power Cable


1x SA Cable


1x Plastic bar for MIPI Cable with 3x Screws (M1.4 x 2mm)


1x Plastic bar for U.FL with 3x Screws (M1.4 x 8mm)

1x Double Sided Tape (29 x 30 x 1mm)

Wiring Diagram


HDZero Freestyle V2 20x20 25-1000mW Digital HD VTX Kit - U.FL from WREKD Co.

HDZero Freestyle V2 20x20 25-1000mW Digital HD VTX Kit - U.FL

The HDZero Freestyle V2 VTX Kit is a 2nd generation 5.8GHz digital video transmitter kit with a camera, VTX, and antenna that can fit most of the 3.5-inch and 5-inch drones.&nbsp

The HDZero Freestyle V2 VTX Kit is a 2nd generation 5.8GHz digital video transmitter kit with a camera, VTX, and antenna that can fit most of the 3.5-inch and 5-inch drones.

HDZero Freestyle V2 VTX Kit

Description The HDZero Freestyle V2 VTX is our 2nd generation 5.8GHz digital video transmitter which can be fitted into most 3-5-inch HD drones. All sockets are well protected by the CNC case that provides durability, RF shielding and improved signal integrity. A wire harness is included for solderless connection for power and MSP UART port. The antenna and MIPI cable are secured by the included retention bar and screws. The VTX supports 720p60 ,1080p30, 540p60 and 540p90 video modes. The VTX is capable of maximum 1W RF output at R1 channel if unlocked with license or approval from the local authorities. Specifications  &#009&#009&#009&#009&#009&#009&#009&#009&#009Manufacturer &#009&#009&#009&#009&#009&#009&#009&#009&#009    Divimath, Inc&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Model&#009&#009&#009&#009&#009&#009&#009&#009&#009    HDZero Freestyle V2 VTX&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Weight&#009&#009&#009&#009&#009&#009&#009&#009&#009    22.3 g&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Dimensions&#009&#009&#009&#009&#009&#009&#009&#009&#009    29x30x14mm&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Operating Frequency &#009&#009&#009&#009&#009&#009&#009&#009&#009    5.725-5.850GHz&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Transmitter Power&#009&#009&#009&#009&#009&#009&#009&#009&#009    25mW,200mW&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Mounting Pattern&#009&#009&#009&#009&#009&#009&#009&#009&#009    20x20mm M2 holes&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Antenna Interface&#009&#009&#009&#009&#009&#009&#009&#009&#009    Secured U.FL &#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Video In&#009&#009&#009&#009&#009&#009&#009&#009&#009    Secured MIPI&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009SmartAudio&#009&#009&#009&#009&#009&#009&#009&#009&#009    Yes&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009MSP Canvas Mode&#009&#009&#009&#009&#009&#009&#009&#009&#009    Yes&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Input Power&#009&#009&#009&#009&#009&#009&#009&#009&#009    7-25V&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Operating Temperature&#009&#009&#009&#009&#009&#009&#009&#009&#009    32˚F-104 ˚F (0˚-40˚C)&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Power Consumption&#009&#009&#009&#009&#009&#009&#009&#009&#009    6-15W&#009&#009&#009&#009&#009&#009  Includes &#0091x Freestyle V2 VTX&#0091x Nano 90 Camera (with 19 x 19 Mount)&#0091x HDZero RHCP antenna&#0091x 120mm Mipi Cable&#0091x Power Cable&#0091x SA Cable&#0091x Plastic bar for Mipi Cable with 3 x screws (M1.4 x 2mm).&#0091x Plastic bar for U.FL with 3 x screws (M1.4 x 8mm)&#0091x Double Sided Tape (29 x 30 x 1mm )

Description The HDZero Freestyle V2 VTX is our 2nd generation 5.8GHz digital video transmitter which can be fitted into most 3-5-inch HD drones. All sockets are well protected by the CNC case that provides durability, RF shielding and improved signal integrity. A wire harness is included for solderless connection for power and MSP UART port. The antenna and MIPI cable are secured by the included retention bar and screws. The VTX supports 720p60 ,1080p30, 540p60 and 540p90 video modes. The VTX is capable of maximum 1W RF output at R1 channel if unlocked with license or approval from the local authorities. Specifications  									Manufacturer 									    Divimath, Inc													Model									    HDZero Freestyle V2 VTX													Weight									    22.3 g													Dimensions									    29x30x14mm													Operating Frequency 									    5.725-5.850GHz													Transmitter Power									    25mW,200mW													Mounting Pattern									    20x20mm M2 holes													Antenna Interface									    Secured U.FL 													Video In									    Secured MIPI													SmartAudio									    Yes													MSP Canvas Mode									    Yes													Input Power									    7-25V													Operating Temperature									    32˚F-104 ˚F (0˚-40˚C)													Power Consumption									    6-15W						  Includes 	1x Freestyle V2 VTX	1x Nano 90 Camera (with 19 x 19 Mount)	1x HDZero RHCP antenna	1x 120mm Mipi Cable	1x Power Cable	1x SA Cable	1x Plastic bar for Mipi Cable with 3 x screws (M1.4 x 2mm).	1x Plastic bar for U.FL with 3 x screws (M1.4 x 8mm)	1x Double Sided Tape (29 x 30 x 1mm )

HDZero Freestyle V2 Kit | HDZERO

HDZero Freestyle V2 Kit

HDZERO


HDZero Freestyle V2 VTX is the second generation 5.8GHz digital video transmitter, perfect for most 3.5-inch and 5-inch drones. It comes in a CNC case that guarantees durable RF shielding with improved signal integrity. A wire harness is included for solderless connection for power and MSP UART port. Moreover, the antenna and MIPI cable are secured with a retention bar and screws. This VTX supports 720p60, 1080p30, 540p60, and 540p90 video modes.























This VTX can fit most frames that can accommodate the Caddx Vista/Runcam Link VTX.
The kit includes a Runcam HDZero Nano 90, HDZero RHCP Antenna, and a 120mm MIPI Cable.
The RunCam HDZero Nano 90 HD Camera is the first 90fps camera for HDZero VTX. This camera enables HDZero to be 5ms faster than analog 60i video to show a full field/frame.











Check out all our VTXs and our HDZero selection.
















Specification
Freestyle V2 VTX

Manufacturer:  Divimath, Inc
Model:  HDZero Freestyle V2 VTX
Weight:  22.3g
Dimensions:  29x30x14mm
Operating Frequency:  5.725-5.850GHz
Transmitter Power:  25mW, 200mW, XXXXmW
Mounting Pattern:  20x20mm M2 Holes
Antenna Interface:  Secured u.FL
Video In:  Secured MIPI
SmartAudio:  YES
MSP Canvas Mode:  YES
Input Power:  7-25V
Operating Temperature:  32F-104F (0-40C)
Power Consumption:  6-15W

Runcam HDZero Nano 90

Resolution: 540P@90fps 4:3 | 720P@60fps 4:3
Dimensions: L18mmxW14mmxH18mm
Lens: FOV D:160° H:127° V:92°
Net Weight: 5.2g(without cable)
Shutter: Rolling Shutter
Image Sensor: 1/3"

Includes

1x  HDZero Freestyle V2 20x20 25-1000mW Digital HD VTX - U.FL

1x Nano 90 Camera (with 19 x 19 Mount)


1x HDZero RHCP Antenna


1x 120mm MIPI Cable


1x Power Cable


1x SA Cable


1x Plastic bar for MIPI Cable with 3x Screws (M1.4 x 2mm)


1x Plastic bar for U.FL with 3x Screws (M1.4 x 8mm)

1x Double Sided Tape (29 x 30 x 1mm)

Wiring Diagram


HDZero Freestyle V2 20x20 25-1000mW Digital HD VTX - U.FL

HDZero Freestyle V2 1W Digital HD VTX

HDZero Freestyle V2 VTX is the second generation 5.8GHz digital video transmitter, perfect for most 3.5-inch and 5-inch drones. It comes in a CNC case that guarantees protection and durable RF shielding with improved signal integrity. A wire harness is included for solderless connection for power and MSP UART port. Mor

HDZero Freestyle V2 20x20 25-1000mW HD VTX - U.FL

Description The HDZero Freestyle V2 VTX is our 2nd generation 5.8GHz digital video transmitter which can be fitted into most 3-5-inch HD drones. All sockets are well protected by the CNC case that provides durability, RF shielding and improved signal integrity. A wire harness is included for solderless connection for power and MSP UART port. The antenna and MIPI cable are secured by the included retention bar and screws. The VTX supports 720p60 ,1080p30, 540p60 and 540p90 video modes. The VTX is capable of maximum 1W RF output at R1 channel if unlocked with license or approval from the local authorities. Specifications  &#009&#009&#009&#009&#009&#009&#009&#009&#009Manufacturer &#009&#009&#009&#009&#009&#009&#009&#009&#009    Divimath, Inc&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Model&#009&#009&#009&#009&#009&#009&#009&#009&#009    HDZero Freestyle V2 VTX&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Weight&#009&#009&#009&#009&#009&#009&#009&#009&#009    22.3 g&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Dimensions&#009&#009&#009&#009&#009&#009&#009&#009&#009    29x30x14mm&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Operating Frequency &#009&#009&#009&#009&#009&#009&#009&#009&#009    5.725-5.850GHz&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Transmitter Power&#009&#009&#009&#009&#009&#009&#009&#009&#009    25mW,200mW&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Mounting Pattern&#009&#009&#009&#009&#009&#009&#009&#009&#009    20x20mm M2 holes&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Antenna Interface&#009&#009&#009&#009&#009&#009&#009&#009&#009    Secured U.FL &#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Video In&#009&#009&#009&#009&#009&#009&#009&#009&#009    Secured MIPI&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009SmartAudio&#009&#009&#009&#009&#009&#009&#009&#009&#009    Yes&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009MSP Canvas Mode&#009&#009&#009&#009&#009&#009&#009&#009&#009    Yes&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Input Power&#009&#009&#009&#009&#009&#009&#009&#009&#009    7-25V&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Operating Temperature&#009&#009&#009&#009&#009&#009&#009&#009&#009    32˚F-104 ˚F (0˚-40˚C)&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Power Consumption&#009&#009&#009&#009&#009&#009&#009&#009&#009    6-15W&#009&#009&#009&#009&#009&#009  Includes &#0091x Freestyle V2 VTX&#0091x Power Cable&#0091x SA Cable&#0091x Plastic bar for Mipi Cable with 3 x screws (M1.4 x 2mm).&#0091x Plastic bar for U.FL with 3 x screws (M1.4 x 8mm)&#0091x Double Sided Tape (29 x 30 x 1mm)

Description The HDZero Freestyle V2 VTX is our 2nd generation 5.8GHz digital video transmitter which can be fitted into most 3-5-inch HD drones. All sockets are well protected by the CNC case that provides durability, RF shielding and improved signal integrity. A wire harness is included for solderless connection for power and MSP UART port. The antenna and MIPI cable are secured by the included retention bar and screws. The VTX supports 720p60 ,1080p30, 540p60 and 540p90 video modes. The VTX is capable of maximum 1W RF output at R1 channel if unlocked with license or approval from the local authorities. Specifications  									Manufacturer 									    Divimath, Inc													Model									    HDZero Freestyle V2 VTX													Weight									    22.3 g													Dimensions									    29x30x14mm													Operating Frequency 									    5.725-5.850GHz													Transmitter Power									    25mW,200mW													Mounting Pattern									    20x20mm M2 holes													Antenna Interface									    Secured U.FL 													Video In									    Secured MIPI													SmartAudio									    Yes													MSP Canvas Mode									    Yes													Input Power									    7-25V													Operating Temperature									    32˚F-104 ˚F (0˚-40˚C)													Power Consumption									    6-15W						  Includes 	1x Freestyle V2 VTX	1x Power Cable	1x SA Cable	1x Plastic bar for Mipi Cable with 3 x screws (M1.4 x 2mm).	1x Plastic bar for U.FL with 3 x screws (M1.4 x 8mm)	1x Double Sided Tape (29 x 30 x 1mm)

HDZero Freestyle V2 VTX | HDZERO

HDZero Freestyle V2 VTX


HDZero Freestyle V2 VTX is the second generation 5.8GHz digital video transmitter, perfect for most 3.5-inch and 5-inch drones. It comes in a CNC case that guarantees protection and durable RF shielding with improved signal integrity. A wire harness is included for solderless connection for power and MSP UART port. Moreover, the antenna and MIPI cable are secured with a retention bar and screws. This VTX supports 720p60, 1080p30, 540p60, and 540p90 video modes.












This VTX can fit most frames that can accommodate the Caddx Vista/Runcam Link VTX.











Check out all our VTXs and our HDZero selection.

Specification

Manufacturer:  Divimath, Inc
Model:  HDZero Freestyle V2 VTX
Weight:  22.3g
Dimensions:  29x30x14mm
Operating Frequency:  5.725-5.850GHz
Transmitter Power:  25mW, 200mW, XXXXmW
Mounting Pattern:  20x20mm M2 Holes
Antenna Interface:  Secured u.FL
Video In:  Secured MIPI
SmartAudio:  YES
MSP Canvas Mode:  YES
Input Power:  7-25V
Operating Temperature:  32F-104F (0-40C)
Power Consumption:  6-15W

Includes

1x  HDZero Freestyle V2 20x20 25-1000mW Digital HD VTX - U.FL

1x Power Cable


1x SA Cable


1x Plastic bar for MIPI Cable with 3x Screws (M1.4 x 2mm)


1x Plastic bar for U.FL with 3x Screws (M1.4 x 8mm)

1x Double Sided Tape (29 x 30 x 1mm)

Wiring Diagram



HDZero Freestyle V2 20x20 25-1000mW Digital HD VTX - U.FL from WREKD Co.

The HDZero Freestyle V2 VTX is a 2nd generation 5.8GHz digital video transmitter that can fit most of the 3.5-inch and 5-inch drones.&nbsp

The HDZero Freestyle V2 VTX is a 2nd generation 5.8GHz digital video transmitter that can fit most of the 3.5-inch and 5-inch drones.

Walksnail Avatar HD V2 Pro VTX Kit - Micro HD Camera V2, Single Antenna

The Micro Camera and VTX Combo for Fat Shark Dominator HDO3 are provided by WalkSnail.
The video transmitter for the Fat Shark Dominator HD Goggles and Walksnail Goggles has arrived! The Walksnail Avatar HD Pro Kit features a VTX with enhanced TVS protection and support for up to 6S. This VTX delivers unmatched stability due to the aid of being equipped with Gyroflow technology. This allows super smooth and stabilized video from your FPV system. The VTX is resistant to GPS interference with a wide input voltage range of 6V to 25.2V. This kit also features 1080P compatibility, high frame starlight, a 4KM range, and 32GB built-in storage option.  Enjoy the unparalleled performance and take your FPV adventures to new heights with this cutting-edge technology!
Check out all our Walksnail HD products!




Features

Compatible with FatShark Dominator HD FPV Goggles
Canvas mode and distance detection with the dual-antenna system
Reliable digital HD video transmission (1080P – H.265 encoding)
1080P 120fps compatibility
Sony Starvis Ⅱ Technology
Built-in 32GB storage
High frame starlight
Lightweight design
22ms low latency
Ranging Mode
4km range
6V-25.2V
FOV 160°





VTX Specifications

Communication Frequency: 5.725-5.850GHz

Transmitter Power (EIRP) FCC:&lt30dBmCE:&lt14dBmSRRC:&lt20dBm

MIC:&lt25dBm

1/O Interface: JST1.0x4(Power in)JST0.8x6(USB)

Mounting Holes: 25.5x25.5mm 20x20mm

Dimensions: 33.5x33.5x10.5mm

Storage: 8G/32G

Recording: 1080p/720p

Weight: 17.6g

Operating Temperature: -20-40℃

Channels 8

Wide Power Input: 6V-25.2V

Supported FC System Betaflight Inav Fettec ArduPilot Kiss

OSD Canvas mode

Latency: Average delay 22ms

Antenna: 1(IPEX)

Camera Specifications

Resolution: 1080P/60fps720P/120fps,720P/60fps1080P/120fps compatibility

Image Sensor: 1/1.8-Inch Sony Starvis Ⅱ Sensor

Model: Avatar HD Pro camera

Min.Illumination: 0.00001Lux

Dimensions: 19x19x24mm

Shutter: Rolling shutter

Coaxial Cable: 140mm

Ratio: 16/9 4/3

Aperture: F1.6

Weight: 9.5g

Lens: 8Mp

FOV: 160°

Antenna Specifications

Polarization: LHCP

Bandwidth: 5600MHz-6000MHz.

Gain: 1.9dBi

VSWR: ≤1.5

Input Impedance: 50Ω

Interface: IPEX-1

Size: R15x45mm (without cable）

Weight: 2g

Includes

USB transfer extension cable X1

4 Pin silicone cable X1

M2x4mm screws X8

M2x5mm screws X4

M2x6mm screws X4

M2x14mm screws X4

M2x5x0.5mm gasket X4



The Micro Camera and VTX Combo for Fat Shark Dominator HDO3 are provided by WalkSnail.  The video transmitter for the Fat Shark Dominator HD Goggles and Walksnail Goggles has arrived! The Walksnail Avatar HD Pro Kit features a VTX with enhanced TVS protection and support for up to 6S. This VTX delivers unmatched stabil

Walksnail Avatar PRO HD V2 VTX Kit - 32GB with Gyroflow

<div style="text-align: left" data-mce-style="text-align: left"><img alt="Walksnail Avatar HD Pro Camera" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/1.Pro_-1.jpg?v=1679018571" style="margin-bottom: 16px float: none"></div>
<div style="text-align: start" data-mce-style="text-align: start">
<h3>Bullet Point :<br>
</h3>
<ul>
<li>
<span data-mce-fragment="1">1/1.8 inch Sony Starvis Ⅱ sensor,</span> come with extremely clear night vision as long as day vision. </li>
<li>Support 1080P/120fps high frame, also the first high frame night vision HD camera in FPV market. </li>
<li>Supporting Gyroflow for more stable and smoother footage. </li>
</ul>
<ol></ol>
<div style="text-align: left" data-mce-style="text-align: left">
<p style="text-align: left" data-mce-style="text-align: left"><img alt="Walksnail Avatar HD VTX V2 Only" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/2.VTX-2.jpg?v=1679018518" style="float: none" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/2.VTX-2_480x480.jpg?v=1679018518" data-mce-style="float: none"></p>
<h3 style="text-align: left" data-mce-style="text-align: left">Bullet Point:<br>
</h3>
<ul>
<li>Add 20*20mm mounting holes for easy installation.</li>
<li>Add 32g built-in storage option.</li>
<li>Updated the design of PCB board and outer shell, more durable.</li>
<li>A spare pad is added to provide two power connection modes.</li>
<li>Optimized antenna base design and frequency button position for greater convenience.</li>
</ul>
</div>
</div>
<h3>Bullet Point for Avatar HD Pro kit</h3>
<div style="text-align: left" data-mce-style="text-align: left"><img alt="Walksnail Avatar HD Pro Kit" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/3-1_9b60d6f3-b32f-4c50-bed6-4099534195ee.jpg?v=1679044228" style="margin-bottom: 16px float: none"></div>
<div style="text-align: left" data-mce-style="text-align: left">
<h3 data-mce-fragment="1"><strong data-mce-fragment="1">features：</strong></h3>
<ul>
<li>1080P 120fps compatibility</li>
<li>High frame starlight</li>
<li>22ms low latency</li>
<li>Ranging Mode</li>
<li>4km range</li>
<li>Light weight design</li>
<li>FOV160°</li>
<li>Built-in 32G storage</li>
<li>6V-25.2V</li>
<li>Sony Starvis Ⅱ Technology</li>
</ul>
</div>
<div style="text-align: left" data-mce-style="text-align: left"><img alt="Walksnail Avatar HD Pro Kit Features" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/4._657cb900-0063-4675-9bf4-6989ea187d91.jpg?v=1679034554" style="margin-bottom: 16px float: none" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/4._657cb900-0063-4675-9bf4-6989ea187d91_480x480.jpg?v=1679034554" data-mce-style="float: none"></div>
<ul>
<li>The Avatar HD system uses H.265 code, an industry-leading technology, to provide 1080p FPV image quality with ultra-low latency. Support 1080P/60FPS, 720P/120FPS.</li>
<li>Featuring a 1/1.8 inch Sony Starvis <meta charset="utf-8"> <span data-mce-fragment="1">Ⅱ </span>sensor, this camera delivers excellent night vision that's just as clear as day.</li>
</ul>
<div style="text-align: left" data-mce-style="text-align: left"><img alt="1080P/60FPS, 720P/120FPS" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/5.1080P.jpg?v=1679280922" style="margin-bottom: 16px float: none"></div>
<div style="text-align: left" data-mce-style="text-align: center">
<ul>
<li style="text-align: left" data-mce-style="text-align: left">The camera ( 32G VTX KIT)<span data-mce-fragment="1"> supports </span><span data-mce-fragment="1">Gyroflow</span>, take you smooth and stable video quality.</li>
</ul>
<img alt="supports Gyroflow" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/GIF16fps.gif?v=1679280057" style="margin-bottom: 16px float: none" data-mce-fragment="1" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/GIF16fps_480x480.gif?v=1679280057" data-mce-style="float: none"><br>
</div>
<div style="text-align: left" data-mce-style="text-align: center">
<ul>
<li style="text-align: left" data-mce-style="text-align: left">In addition to the original 25mm x 25mm mounting holes, the kit now includes 20mm x 20mm holes for greater compatibility with a wider range of FPV drone models.</li>
<li style="text-align: left" data-mce-style="text-align: left">Updated the design of PCB board and shell, improved the quality of VTX, more durable.</li>
<li style="text-align: left" data-mce-style="text-align: left">Optimized the installation place of the antenna, so as to better protect the VTX.</li>
<li style="text-align: left" data-mce-style="text-align: left">The position of the frequency binding button has been changed to make the frequency binding operation more convenient.</li>
<li style="text-align: left" data-mce-style="text-align: left">A spare pad is added to provide two power connection modes. </li>
</ul>
<p><img alt="Partial upgrade display of Walksnail Avatar HD VTX V2" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/7._97925926-45f0-4fdc-b7c5-e60d8829aca4.jpg?v=1679018255" style="float: none" data-mce-fragment="1" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/7._97925926-45f0-4fdc-b7c5-e60d8829aca4_480x480.jpg?v=1679018255" data-mce-style="float: none">    </p>
<article data-identifier-application__slash__x-doc-key="v1GXn4x3DLeonDQ4" data-identifier-application__slash__x-cangjie-fragment="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" data-clipboard-cangjie='["root",{"copyFrom":1329378339},["p",{"uuid":"lei4y6iyyt3vq4ejxk","ind":{"left":0},"list":{"listId":"y6t50qxp2xn","level":0,"isOrdered":false,"isTaskList":false,"isChecked":false,"listStyleType":"SCIR_ECIR_SREC","symbolStyle":{"shd":"#FFFFFF"},"listStyle":{"format":"bullet","text":"●","align":"left"},"hideSymbol":false,"extraData":{}}},["span",{"data-type":"text"},["span",{"highlight":"#FFFFFF","data-type":"leaf"},"TVS added, up to 8S"]]]]'>
<ul>
<li style="text-align: left" data-mce-style="text-align: left">New VTX with enhanced TVS protection and support for up to 6S. With a wide input voltage the range of 6V to 25.2V, our VTX delivers unmatched stability and resistance to GPS interference. Enjoy unparalleled performance and take your FPV adventures to new heights with our cutting-edge technology.</li>
</ul>
</article>
<article data-identifier-application__slash__x-doc-key="v1GXn4x3DLeonDQ4" data-identifier-application__slash__x-cangjie-fragment="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" data-clipboard-cangjie='["root",{"copyFrom":1329378339},["p",{"uuid":"lei4y6iyyt3vq4ejxk","ind":{"left":0},"list":{"listId":"y6t50qxp2xn","level":0,"isOrdered":false,"isTaskList":false,"isChecked":false,"listStyleType":"SCIR_ECIR_SREC","symbolStyle":{"shd":"#FFFFFF"},"listStyle":{"format":"bullet","text":"●","align":"left"},"hideSymbol":false,"extraData":{}}},["span",{"data-type":"text"},["span",{"highlight":"#FFFFFF","data-type":"leaf"},"TVS added, up to 8S"]]]]'><img alt="Walksnail Avatar HD VTX V2 Only" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/6._1.jpg?v=1678776194" style="margin-bottom: 16px float: none" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/6._1_480x480.jpg?v=1678776194" data-mce-style="float: none"></article>
</div>
<div style="text-align: center" data-mce-style="text-align: center">
<div style="text-align: left" data-mce-fragment="1" data-mce-style="text-align: left">
<ul>
<li>The Avatar VTX comes with 8g/32g built-in storage it can record 1080p or 720p HD flight videos without interference.32G built-in storage, recording video time increased by 4 times. </li>
</ul>
</div>
<div style="text-align: left" data-mce-fragment="1" data-mce-style="text-align: left"><img alt="32G built-in storage" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/9..jpg?v=1678506942" style="margin-bottom: 16px float: none" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/9._480x480.jpg?v=1678506942" data-mce-style="float: none"></div>
<div style="text-align: left" data-mce-fragment="1" data-mce-style="text-align: left">
<div style="text-align: left" data-mce-fragment="1" data-mce-style="text-align: left">
<ul data-mce-fragment="1">
<li data-mce-fragment="1">It supports high frame rate and standard frame rate at the same time. Under high frame rate, the average delay is 22ms.</li>
</ul>
</div>
<div style="text-align: left" data-mce-fragment="1" data-mce-style="text-align: left"><img alt="The brightness of Pro Camera is improved at night, and the picture is clear" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/GIF30.gif?v=1679283331" style="margin-bottom: 16px float: none"></div>
</div>
</div>
<ul>
<li>The compact and convenient single-antenna design makes it easier to assemble your FPV drone. The quality of the antenna is upgraded, and the working performance of the whole frequency band is more stable.</li>
</ul>
<div style="text-align: left" data-mce-style="text-align: center"><img alt="The quality of the antenna is upgraded, and the working performance of the whole frequency band is more stable." src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/10._5f084f2f-d7f0-48f6-9d82-2134495a0ff2.jpg?v=1679017504" style="margin-bottom: 16px float: none" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/10._5f084f2f-d7f0-48f6-9d82-2134495a0ff2_480x480.jpg?v=1679017504" data-mce-style="float: none"></div>
<ul>
<li>HD 1080p OLED Dual Micro Displays</li>
</ul>
<div style="text-align: left" data-mce-style="text-align: center">
<img alt="HD 1080p OLED Dual Micro Displays" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/12..jpg?v=1678507057" style="margin-bottom: 16px float: none" data-mce-fragment="1" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/12._480x480.jpg?v=1678507057" data-mce-style="float: none">  <span style="font-size: 1.4em" data-mce-style="font-size: 1.4em"> </span>
</div>
<ul>
<li>The Avatar goggles are designed to be lightweight, mini, small and have a 46° field of view, making them more comfortable for pilots while giving them a more immersive FPV experience. </li>
</ul>
<div style="text-align: left" data-mce-style="text-align: center"><img alt="The Avatar goggles are designed to be lightweight, mini, small and have a 46° field of view" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/13..jpg?v=1678507099" style="margin-bottom: 16px float: none" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/13._480x480.jpg?v=1678507099" data-mce-style="float: none"></div>
<div style="text-align: left" data-mce-style="text-align: left">
<ul>
<li>The goggles have the feature of adjusting the focus without the need to install,corrective lenses.</li>
</ul>
</div>
<div style="text-align: left" data-mce-style="text-align: start">
<img alt="Walksnail Avatar HD Goggles with adjustable focus." src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/13._b721df2d-fe75-45e5-be05-0772048c5c90.jpg?v=1678776265" style="margin-bottom: 16px float: none" data-mce-fragment="1" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/13._b721df2d-fe75-45e5-be05-0772048c5c90_480x480.jpg?v=1678776265" data-mce-style="float: none">  </div>
<ul>
<li>HDMI Output</li>
</ul>
<div style="text-align: left" data-mce-style="text-align: center"><img alt="HDMI Output" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/14.HDMI.jpg?v=1678776276" style="margin-bottom: 16px float: none" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/14.HDMI_480x480.jpg?v=1678776276" data-mce-style="float: none"></div>
<ul>
<li><span>Turn on the ranging mode to display the distance between the drone and goggles in real time, in case the drone is lost due to long distance flight.</span></li>
</ul>
<div style="text-align: left" data-mce-style="text-align: center"><img alt="ranging mode" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/15..jpg?v=1678775178" style="margin-bottom: 16px float: none" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/15._480x480.jpg?v=1678775178" data-mce-style="float: none"></div>
<div style="text-align: left" data-mce-style="text-align: center"><img alt="Walksnail Avatar HD Pro Kit Dimensions" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/17._48447fa0-d29e-46d6-a751-c2a5070a63ef.jpg?v=1678524063" style="margin-bottom: 16px float: none" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/17._48447fa0-d29e-46d6-a751-c2a5070a63ef_480x480.jpg?v=1678524063" data-mce-style="float: none"></div>
<div style="text-align: left" data-mce-style="text-align: center"><img alt="Walksnail Avatar HD VTX V2 Line Installation Instructions" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/18..jpg?v=1678519325" style="margin-bottom: 16px float: none" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/18._480x480.jpg?v=1678519325" data-mce-style="float: none"></div>
<div style="text-align: start" data-mce-fragment="1" data-mce-style="text-align: start">
<li>
<strong>Q: </strong>Do we support 1080P 120FPS?</li>
<li>
<strong>A: </strong>Our VTX products all support 1080P/120FPS, and can reach <span data-mce-fragment="1">1080P/</span>120FPS through firmware upgrade <strong>is around the corner.</strong>
</li>
</div>
<p> </p>
<div style="text-align: start" data-mce-fragment="1" data-mce-style="text-align: start">
<table width="100%">
<tbody>
<tr>
<td><strong data-mce-fragment="1">Specification</strong></td>
<td></td>
</tr>
<tr>
<td><strong data-mce-fragment="1">Camera</strong></td>
<td> </td>
</tr>
<tr>
<td><span>Model</span></td>
<td><span>Avatar HD Pro Camera</span></td>
</tr>
<tr>
<td><span>Image Sensor</span></td>
<td>
<span>1/1.8-Inch Sony Starvis </span><span data-mce-fragment="1">Ⅱ</span><span> Sensor</span>
</td>
</tr>
<tr>
<td><span>Resolution</span></td>
<td><span>1080P/60fps720P/120fps,720P/60fps1080P/120fps compatibility</span></td>
</tr>
<tr>
<td><span>Ratio</span></td>
<td><span>16/9 4/3</span></td>
</tr>
<tr>
<td><span>Lens</span></td>
<td><span>8Mp</span></td>
</tr>
<tr>
<td><span>FOV</span></td>
<td><span>160°</span></td>
</tr>
<tr>
<td><span>Aperture</span></td>
<td><span>F1.6</span></td>
</tr>
<tr>
<td><span>Shutter</span></td>
<td><span>Rolling shutter</span></td>
</tr>
<tr>
<td><span>Min.Illumination</span></td>
<td><span>0.00001Lux</span></td>
</tr>
<tr>
<td><span>Weight</span></td>
<td><span>9.5g</span></td>
</tr>
<tr>
<td><span>Dimensions</span></td>
<td><span>19*19*24mm</span></td>
</tr>
<tr>
<td><span>Coaxial Cable</span></td>
<td><span>140mm</span></td>
</tr>
<tr>
<td><strong>VTX</strong></td>
<td></td>
</tr>
<tr>
<td><span>Model</span></td>
<td><span>Avatar V2 Module</span></td>
</tr>
<tr>
<td><span>Communication Frequency</span></td>
<td><span>5.725-5.850GHz</span></td>
</tr>
<tr>
<td><span>Transmitter Power (EIRP)</span></td>
<td>
<span>FCC:&lt30dBmCE:&lt14dBmSRRC:&lt20dBm</span><br><span>MIC:&lt25dBm</span>
</td>
</tr>
<tr>
<td><span>1/O Interface</span></td>
<td><span>JST1.0*4(Power in)JST0.8*6(USB)</span></td>
</tr>
<tr>
<td><span>Mounting Holes</span></td>
<td><span>25.5*25.5mm 20*20mm</span></td>
</tr>
<tr>
<td><span>Dimensions</span></td>
<td><span>33.5*33.5*10.5mm</span></td>
</tr>
<tr>
<td><span>Storage</span></td>
<td><span>8G/32G</span></td>
</tr>
<tr>
<td><span>Recording</span></td>
<td><span>1080p/720p</span></td>
</tr>
<tr>
<td><span>Weight</span></td>
<td><span>17.6g</span></td>
</tr>
<tr>
<td><span>Operating Temperature</span></td>
<td><span>-20-40℃</span></td>
</tr>
<tr>
<td><span>Channels</span></td>
<td><span>8</span></td>
</tr>
<tr>
<td><span>Wide Power Input</span></td>
<td><span>6V-25.2V</span></td>
</tr>
<tr>
<td><span>Supported FC System</span></td>
<td><span>Betaflight Inav Fettec ArduPilotKiss</span></td>
</tr>
<tr>
<td><span>OSD</span></td>
<td><span>Canvas mode</span></td>
</tr>
<tr>
<td><span>Latency</span></td>
<td><span>Average delay 22ms</span></td>
</tr>
<tr>
<td><span>Antenna</span></td>
<td><span>1(IPEX)</span></td>
</tr>
<tr>
<td><span><strong>Avatar V2 Antenna</strong></span></td>
<td><span></span></td>
</tr>
<tr>
<td><span>Polarization</span></td>
<td><span>LHCP</span></td>
</tr>
<tr>
<td><span>Frequency range</span></td>
<td><span>5600MHz-6000MHz</span></td>
</tr>
<tr>
<td><span>Gain</span></td>
<td><span>1.9dBi</span></td>
</tr>
<tr>
<td><span>VSWR</span></td>
<td><span>≤1.5</span></td>
</tr>
<tr>
<td><span>Input Impedance</span></td>
<td><span>50Ω</span></td>
</tr>
<tr>
<td><span>Interface</span></td>
<td><span>IPEX-1</span></td>
</tr>
<tr>
<td><span>Size</span></td>
<td><span>R15 X 45mm(without cable)</span></td>
</tr>
<tr>
<td><span>Weight</span></td>
<td><span>2g</span></td>
</tr>
<tr>
<td><span><strong>Packing List</strong></span></td>
<td><span></span></td>
</tr>
<tr>
<td><span>USB transfer extension cable</span></td>
<td><span>X1</span></td>
</tr>
<tr>
<td><span>4 Pin silicone cable</span></td>
<td><span>X1</span></td>
</tr>
<tr>
<td><span>M2*4mm screws</span></td>
<td><span>X8</span></td>
</tr>
<tr>
<td><span>M2*5mm screws</span></td>
<td><span>X4</span></td>
</tr>
<tr>
<td><span>M2*6mm screws</span></td>
<td><span>X4</span></td>
</tr>
<tr>
<td><span>M2*14mm screws</span></td>
<td><span>X4</span></td>
</tr>
<tr>
<td><span>M2*5*0.5mm gasket</span></td>
<td><span>X4</span></td>
</tr>
</tbody>
</table>
<br>
</div>

Bullet Point : 1/1.8 inch Sony Starvis Ⅱ sensor, come with extremely clear night vision as long as day vision.  Support 1080P/120fps high frame, also the first high frame night vision HD camera in FPV market.  Supporting Gyroflow for more stable and smoother footage.  Bullet Point: Add 20*20mm mounting holes for easy i

Walksnail Avatar HD Pro Kit – CADDX FPV



Bullet Point :



1/1.8 inch Sony Starvis Ⅱ sensor, come with extremely clear night vision as long as day vision.
Support 1080P/120fps high frame, also the first high frame night vision HD camera i

Walksnail Avatar HD Pro Kit

The Walksnail Avatar HD Pro Kit features 1080P compatibility, high frame starlight, a 4KM range, and 32GB built-in storage.&nbsp

The Walksnail Avatar HD Pro Kit features 1080P compatibility, high frame starlight, a 4KM range, and 32GB built-in storage.

The Micro Camera and VTX Combo for Fat Shark Dominator HDO3 are provided by WalkSnail.
The video transmitter for the Fat Shark Dominator HD Goggles and Walksnail Goggles has arrived! The Walksnail Avatar HD Pro Kit features a VTX with enhanced TVS protection and support for up to 6S. This VTX delivers unmatched stability due to the aid of being equipped with Gyroflow technology. This allows super smooth and stabilized video from your FPV system. The VTX is resistant to GPS interference with a wide input voltage range of 6V to 25.2V. This kit also features 1080P compatibility, high frame starlight, a 4KM range, and 32GB built-in storage option.  Enjoy the unparalleled performance and take your FPV adventures to new heights with this cutting-edge technology!
Check out all our Walksnail HD products!




Features

Compatible with FatShark Dominator HD FPV Goggles
Canvas mode and distance detection with the dual-antenna system
Reliable digital HD video transmission (1080P – H.265 encoding)
1080P 120fps compatibility
Sony Starvis Ⅱ Technology
Built-in 32GB storage
High frame starlight
Lightweight design
22ms low latency
Ranging Mode
4km range
6V-25.2V
FOV 160°





VTX Specifications

Communication Frequency: 5.725-5.850GHz

Transmitter Power (EIRP) FCC:&amplt30dBmCE:&amplt14dBmSRRC:&amplt20dBm

MIC:&amplt25dBm

1/O Interface: JST1.0x4(Power in)JST0.8x6(USB)

Mounting Holes: 25.5x25.5mm 20x20mm

Dimensions: 33.5x33.5x10.5mm

Storage: 8G/32G

Recording: 1080p/720p

Weight: 17.6g

Operating Temperature: -20-40℃

Channels 8

Wide Power Input: 6V-25.2V

Supported FC System Betaflight Inav Fettec ArduPilot Kiss

OSD Canvas mode

Latency: Average delay 22ms

Antenna: 1(IPEX)

Camera Specifications

Resolution: 1080P/60fps720P/120fps,720P/60fps1080P/120fps compatibility

Image Sensor: 1/1.8-Inch Sony Starvis Ⅱ Sensor

Model: Avatar HD Pro camera

Min.Illumination: 0.00001Lux

Dimensions: 19x19x24mm

Shutter: Rolling shutter

Coaxial Cable: 140mm

Ratio: 16/9 4/3

Aperture: F1.6

Weight: 9.5g

Lens: 8Mp

FOV: 160°

Antenna Specifications

Polarization: LHCP

Bandwidth: 5600MHz-6000MHz.

Gain: 1.9dBi

VSWR: ≤1.5

Input Impedance: 50Ω

Interface: IPEX-1

Size: R15x45mm (without cable）

Weight: 2g

Includes

USB transfer extension cable X1

4 Pin silicone cable X1

M2x4mm screws X8

M2x5mm screws X4

M2x6mm screws X4

M2x14mm screws X4

M2x5x0.5mm gasket X4



Walksnail Avatar PRO HD V2 VTX Kit - 32GB with Gyroflow from WREKD Co.

Walksnail Avatar Digital HD Pro Kit 32GB with Gyroflow for Walksnail Avatar/Fatshark Dominator HD FPV System

ImmersionRC

ImmersionRC Ghost Ultimate Hybrid 2.4GHz Rx and 5.8GHz VTX

The Immersion RC Ghost Ultimate Hybrid 5.8GHz VTX &amp 2.4GHz takes the innovative Ghost Hybrid concept to a new level, with the traditional long-range/low latency Ghost uplink, and a high-power Tramp video transmitter, packaged in a beautiful anodized heatsink.

The Immersion RC Ghost Ultimate Hybrid 5.8GHz VTX & 2.4GHz takes the innovative Ghost Hybrid concept to a new level, with the traditional long-range/low latency Ghost uplink, and a high-power Tramp video transmitter, packaged in a beautiful anodi

Immersion RC Ghost Ultimate Hybrid 5.8GHz VTX & 2.4GHz Rx

Immersion RC Ghost Ultimate Hybrid 5.8GHz VTX &amp 2.4GHz Rx

In the FPV wold, we are conditioned… conditioned to cringe when leaving LOS, conditioned to fear concrete structures… until now.
The Ultimate Hybrid takes the innovative Ghost Hybrid concept to a new level, with the traditional long range/low latency Ghost uplink, and a high power Tramp video transmitter, packaged in a beautiful anodized heatsink.
Designed by pilots, built by pilots, supported by pilots.
Check out all our IRC Ghost Products and the rest of our ImmersionRC Products!
FEATURES:

 	Standard mounting pattern for digital vTx’s (Caddx Vista™)
 	2s-6s HV operation, no need for a 5V supply
 	5.8GHz 10-1500mW Video Transmitter *
 	Onboard Ghost Uno Receiver
 	Only 10.3g with heatsink, 3.1g without
 	Long range AND low latency
 	500Hz updates *
 	2.4GHz LoRa and FLRC Control
 	All 37 Standard Channels
 	Thermally regulated, Factory calibrated

* 1kHz ready for when OpenTx can supply quality data at this rate
* Available vTx channels and power may vary from region to region to comply with local regulations

INTELLIGENT VTX CONTROL
Intelligent, and direct control of the video transmitter from the Ghost ecosystem. Use either the OLED menus on the Ghost Transmitter module, or the responsive OpenTx tools menu.
Tx remains silent on power-up, shuts down immediately in an (unlikely) failsafe.

MANUAL:

 	Ghost Users Manual v2.5 (Firmware v1.0.6.5) (23.0 MB)
 	Ghost Quick Start Guide (159.5 KB)
 	Ghost Users Manual v1.9 (Firmware v1.0.2.1) (18.5 MB)

PACKAGE INCLUDES:

 	1x qTee Antenna
 	1x U.FL to SMA
 	Wire Harness

ATTN.
VTX is set to 25mW by default! Power levels above 25mW require a HAM license or have to be approved by local authorities! Please ensure you're flying legal frequencies and use our prepared Betaflight VTX tables according to your region.

ImmersionRC Ghost Ultimate Hybrid | Five33

ImmersionRC Ghost Ultimate Hybrid

In the FPV wold, we are conditioned… conditioned to cringe when leaving LOS, conditioned to fear concrete structures… until now. The Ultimate Hybrid takes the innovative Ghost Hybrid concept to a new level, with the traditional long range/low latency Ghost uplink, and a high power Tramp video transmitter, packaged in a

ImmersionRC Ghost Ultimate Hybrid 5.8GHz vTx/2.4GHz Rx

HDZero Freestyle 1W Video Transmitter

The HDZero Freestyle VTX is a digital HD 720p 60fps 5.8GHz made for freestyle drones. The large heatsink surrounding the VTX helps maintain a stable temperature from the increased transmission power potential. Mounts on standard 30x30mm spaced holes. The VTX includes a BEC that converts 2S-6S to fixed 5.8V with a maximum 5A output current. The VTX also includes a U.FL RHCP antenna.
The power input range is now 2S –6S. Though the VTX integrates a surge protection circuit, a large capacitor (450+uF) parallel with battery leads is mandatory to smooth the power supply of the whole quad.
Check out the rest of our HDZero gear!

Specifications

Input Voltage: 2-6S

Operating Frequency: 5.725-5.850GHz
Transmitter Power: 25mW, 200mW (Out of the box)
Antenna Interface: Secured U.FL
Video In Secured: MIPI
SmartAudio: Yes
MSP Canvas Mode: Yes
Operating Temperature: 32˚F-104 ˚F (0˚-40˚C)
Power Consumption: 6-15W
Mounting Pattern: 30x30mm M3 holes

Dimensions: 40x42x10mm
Weight: 28g

Important Notes:

The Freestyle VTX consumes up to 15W. If it is connected with FC that has built-in BEC output, make sure the BEC has enough current. For example, the BEC has 10V, it needs a minimum of 1.5A current output.
Removing the heat sink is not recommended because it is part of the design.

Includes

1x HDZero Freestyle VTX
1x U.FL Antenna
1x BEC


You're going to love the U.FL HDZero Freestyle 30x30 25-1000mW Digital HD VTX on your freestyle build. Lightweight and reliable, you don't want to miss this.

HDZero Freestyle 30x30 25-1000mW Digital HD VTX - U.FL

U.FL HDZero Freestyle 30x30 25-1000mW Digital HD VTX for Sale

The HDZero Freestyle VTX is a digital HD 720p 60fps 5.8GHz made for freestyle drones. The large heatsink surrounding the VTX helps maintain a stable temperature from the increased transmission power potential. Mounts on standard 30x30mm spaced holes.

HDZero Freestyle VTX - RMRC

HDZero Freestyle VTX

Description The HDZero Freestyle VTX is a digital HD 720p 60fps video transmitter capable of delivering up to 1000mw on 5.8GHz. It works with the HDZero/Shark Byte goggle module to transmit video, and with a remote controller to wirelessly control the parameters for the transmitter and camera. The VTX includes an U.FL RHCP antenna. The power input range is 2S –6S. Though the VTX integrates a surge protection circuit, a large capacitor (450+uF) parallel with battery leads is mandatory to smooth the power supply of the whole quad.  Specifications Manual download &#009&#009&#009&#009&#009&#009&#009&#009&#009Model:&#009&#009&#009&#009&#009&#009&#009&#009&#009HDZero Freestyle&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009SKU：&#009&#009&#009&#009&#009&#009&#009&#009&#009HDZ3130&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Frequency: &#009&#009&#009&#009&#009&#009&#009&#009&#0095.725-5.850GHz&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Resolution Default:&#009&#009&#009&#009&#009&#009&#009&#009&#0091280*720@60fps&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009RF power：&#009&#009&#009&#009&#009&#009&#009&#009&#00925mw/200mw/500mw/1000mw&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009RF Connector:&#009&#009&#009&#009&#009&#009&#009&#009&#009Secured U.FL&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Video Connector:&#009&#009&#009&#009&#009&#009&#009&#009&#009Secured MIPI&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009FC protocol&#009&#009&#009&#009&#009&#009&#009&#009&#009MSP Canvas Mode/SmartAudio&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Size: &#009&#009&#009&#009&#009&#009&#009&#009&#00940mm x 42mm x 10mm&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Weight:&#009&#009&#009&#009&#009&#009&#009&#009&#00928g&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Power:  &#009&#009&#009&#009&#009&#009&#009&#009&#0096-15W&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Power input：&#009&#009&#009&#009&#009&#009&#009&#009&#0097V-26V(2S-6S)&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009&#009Mounting：&#009&#009&#009&#009&#009&#009&#009&#009&#00930.5mm x 30.5mm M3 holes&#009&#009&#009&#009&#009&#009 Includes HDZero Freestyle VTX * 1HDZero RHCP Antenna * 1Power/ Uart Cables * 1；u.FL Antenna Retention Screws * 2/Plate * 1MIPI Retention Screws * 2/Plate * 1  Important Notes: &#009The Freestyle VTX consumes up to 15W. If it is connected with FC, make sure the FC has enough current. For example, the FC has 10V, it needs minimum 1.5A current output.&#009Removing the heat sink is not recommended because it is part of the design. HDZero Range Testing - Putting the HDZero Freestyle VTX to the test---------Wezley VartyHDZero is (almost) ready to replace analog FPV // 1W FREESTYLE VTX---------Joshua Bardwell

Description The HDZero Freestyle VTX is a digital HD 720p 60fps video transmitter capable of delivering up to 1000mw on 5.8GHz. It works with the HDZero/Shark Byte goggle module to transmit video, and with a remote controller to wirelessly control the parameters for the transmitter and camera. The VTX includes an U.FL RHCP antenna. The power input range is 2S –6S. Though the VTX integrates a surge protection circuit, a large capacitor (450+uF) parallel with battery leads is mandatory to smooth the power supply of the whole quad.  Specifications Manual download 									Model:									HDZero Freestyle													SKU：									HDZ3130													Frequency: 									5.725-5.850GHz													Resolution Default:									1280*720@60fps													RF power：									25mw/200mw/500mw/1000mw													RF Connector:									Secured U.FL													Video Connector:									Secured MIPI													FC protocol									MSP Canvas Mode/SmartAudio													Size: 									40mm x 42mm x 10mm													Weight:									28g													Power:  									6-15W													Power input：									7V-26V(2S-6S)													Mounting：									30.5mm x 30.5mm M3 holes						 Includes HDZero Freestyle VTX * 1;HDZero RHCP Antenna * 1;Power/ Uart Cables * 1；u.FL Antenna Retention Screws * 2/Plate * 1MIPI Retention Screws * 2/Plate * 1  Important Notes: 	The Freestyle VTX consumes up to 15W. If it is connected with FC, make sure the FC has enough current. For example, the FC has 10V, it needs minimum 1.5A current output.	Removing the heat sink is not recommended because it is part of the design. HDZero Range Testing - Putting the HDZero Freestyle VTX to the test---------Wezley VartyHDZero is (almost) ready to replace analog FPV // 1W FREESTYLE VTX---------Joshua Bardwell

HDZero Freestyle VTX | HDZERO

The HDZero Freestyle VTX is a digital HD 720p 60fps 5.8GHz made for freestyle drones. The large heatsink surrounding the VTX helps maintain a stable temperature from the increased transmission power. Mounts on standard 30x30mm spaced holes.&nbsp

The HDZero Freestyle VTX is a digital HD 720p 60fps 5.8GHz made for freestyle drones. The large heatsink surrounding the VTX helps maintain a stable temperature from the increased transmission power. Mounts on standard 30x30mm spaced holes.


HDZero Freestyle Digital HD Video Transmitter (1W Capable)

TBS Unify Pro32 HV 5.8GHz Video Transmitter - MMCX

With the TBS UNIFY PRO32 HV (MMCX) we have boosted the output power, improved the robustness, decreased the power consumption, added capability for insane features and perfected the way it is installed in your multirotor. In a nutshell, it’s the most comprehensive, future proof, highest quality and overall best HV VTx

TBS Unify Pro32 HV (MMCX) VTx Video Transmitter

Team BlackSheep

With the TBS UNIFY PRO32 HV we have boosted the output power, improved the robustness, decreased the power consumption, added capability for insane features and perfected the way it is installed in your multirotor.

TBS Unify Pro32 HV 5.8GHz Video Transmitter (MMCX)

Walksnail Avatar HD V2 VTX Module - Single Antenna

<div style="text-align: center" data-mce-fragment="1" data-mce-style="text-align: center">
<h3 style="text-align: left" data-mce-style="text-align: left">Bullet Point<br>
</h3>
</div>
<div data-mce-fragment="1" data-mce-style="text-align: center">
<ul>
<li>Except the original 25*25mm mounting holes, now added 20*20mm holes for greater compatibility with a wider range of FPV drone models.</li>
<li>Updated the design of PCB board and shell, improved the quality of VTX, more durable.</li>
<li>Optimized the installation place of the antenna, it's better to protect the VTX.</li>
<li>The position of the frequency binding button has been changed, to make the frequency binding operation more convenient.</li>
<li>The kit includes a spare power pad, providing an extra opportunity for welding.</li>
</ul>
</div>
<div data-mce-fragment="1" data-mce-style="text-align: center">
<div style="text-align: left" data-mce-style="text-align: left"><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/7._97925926-45f0-4fdc-b7c5-e60d8829aca4.jpg?v=1679018255" style="float: none"></div>
</div>
<div style="text-align: center" data-mce-fragment="1" data-mce-style="text-align: center">
<div style="text-align: left" data-mce-style="text-align: left">
<div style="text-align: left" data-mce-fragment="1" data-mce-style="text-align: left">
<ul>
<li>The Avatar VTX comes with 8g/32g built-in storage it can record 1080P or 720P HD fly videos without interference. 32G built-in storage, recording video time increased by 4 times.</li>
</ul>
</div>
<div style="text-align: left" data-mce-fragment="1" data-mce-style="text-align: left"><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/9..jpg?v=1678506942" style="float: none" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/9._480x480.jpg?v=1678506942"></div>
</div>
<div style="text-align: center" data-mce-style="text-align: center">
<div style="text-align: center" data-mce-style="text-align: center">
<div style="text-align: left" data-mce-style="text-align: left">
<article data-identifier-application__slash__x-doc-key="v1GXn4x3DLeonDQ4" data-identifier-application__slash__x-cangjie-fragment="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" data-clipboard-cangjie='["root",{"copyFrom":1329378339},["p",{"uuid":"lei4y6iyyt3vq4ejxk","ind":{"left":0},"list":{"listId":"y6t50qxp2xn","level":0,"isOrdered":false,"isTaskList":false,"isChecked":false,"listStyleType":"SCIR_ECIR_SREC","symbolStyle":{"shd":"#FFFFFF"},"listStyle":{"format":"bullet","text":"●","align":"left"},"hideSymbol":false,"extraData":{}}},["span",{"data-type":"text"},["span",{"highlight":"#FFFFFF","data-type":"leaf"},"TVS added, up to 8S"]]]]'>
<ul>
<li>New VTX with enhanced TVS protection and support for up to 6S. With a wide input voltage the range of 6V to25.2V, our VTX delivers unmatched stability and resistance to GPS interference. Enjoy unparalleled performance and take your FPV adventures to new heights with our cutting-edge technology.</li>
</ul>
</article>
<article data-identifier-application__slash__x-doc-key="v1GXn4x3DLeonDQ4" data-identifier-application__slash__x-cangjie-fragment="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" data-clipboard-cangjie='["root",{"copyFrom":1329378339},["p",{"uuid":"lei4y6iyyt3vq4ejxk","ind":{"left":0},"list":{"listId":"y6t50qxp2xn","level":0,"isOrdered":false,"isTaskList":false,"isChecked":false,"listStyleType":"SCIR_ECIR_SREC","symbolStyle":{"shd":"#FFFFFF"},"listStyle":{"format":"bullet","text":"●","align":"left"},"hideSymbol":false,"extraData":{}}},["span",{"data-type":"text"},["span",{"highlight":"#FFFFFF","data-type":"leaf"},"TVS added, up to 8S"]]]]'><img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/6._1.jpg?v=1678776194" style="float: none" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/6._1_480x480.jpg?v=1678776194"></article>
<article data-identifier-application__slash__x-doc-key="v1GXn4x3DLeonDQ4" data-identifier-application__slash__x-cangjie-fragment="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" data-clipboard-cangjie='["root",{"copyFrom":1329378339},["p",{"uuid":"lei4y6iyyt3vq4ejxk","ind":{"left":0},"list":{"listId":"y6t50qxp2xn","level":0,"isOrdered":false,"isTaskList":false,"isChecked":false,"listStyleType":"SCIR_ECIR_SREC","symbolStyle":{"shd":"#FFFFFF"},"listStyle":{"format":"bullet","text":"●","align":"left"},"hideSymbol":false,"extraData":{}}},["span",{"data-type":"text"},["span",{"highlight":"#FFFFFF","data-type":"leaf"},"TVS added, up to 8S"]]]]'></article>
</div>
<div style="text-align: center" data-mce-style="text-align: center">
<table width="100%">
<tbody>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left"><strong>Specification</strong></td>
<td style="text-align: left" data-mce-style="text-align: left"></td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left"><strong>VTX</strong></td>
<td style="text-align: left" data-mce-style="text-align: left"> </td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Model</td>
<td style="text-align: left" data-mce-style="text-align: left">Avatar V2 module</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Communication Frequency</td>
<td style="text-align: left" data-mce-style="text-align: left">5.725-5.850GHz</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Transmitter Power (EIRP)</td>
<td style="text-align: left" data-mce-style="text-align: left">FCC:&lt30dBmCE:&lt14dBmSRRC:&lt20dBm<br>MIC:&lt25dBm</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">1/O Interface</td>
<td style="text-align: left" data-mce-style="text-align: left">JST1.0*4(Power in)JST0.8*6(USB)</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Mounting Holes</td>
<td style="text-align: left" data-mce-style="text-align: left">25.5*25.5mm；20*20mm</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Dimensions</td>
<td style="text-align: left" data-mce-style="text-align: left">33*33*<span style="color: #000000" data-mce-style="color: #000000">10.5</span>mm</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Storage</td>
<td style="text-align: left" data-mce-style="text-align: left">8G/ 32G</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Recording</td>
<td style="text-align: left" data-mce-style="text-align: left">1080P/720P</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Weight</td>
<td style="text-align: left" data-mce-style="text-align: left">17.6g<br>
</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Operating Temperature</td>
<td style="text-align: left" data-mce-style="text-align: left">-20-40℃</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Channels</td>
<td style="text-align: left" data-mce-style="text-align: left">8</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Wide Power Input</td>
<td style="text-align: left" data-mce-style="text-align: left">6V-<span style="color: #000000" data-mce-style="color: #000000">25.2</span>V</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Supported FC System</td>
<td style="text-align: left" data-mce-style="text-align: left">Betaflight Inav Fettec ArduPilotKiss</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">OSD</td>
<td style="text-align: left" data-mce-style="text-align: left">Canvas mode</td>
</tr>
<tr style="text-align: left" data-mce-style="text-align: left">
<td style="text-align: left" data-mce-style="text-align: left">Latency</td>
<td style="text-align: left" data-mce-style="text-align: left">Average delay 22ms</td>
</tr>
<tr>
<td style="text-align: left" data-mce-style="text-align: left">Antenna</td>
<td style="text-align: left" data-mce-style="text-align: left">1(IPEX)</td>
</tr>
</tbody>
</table>
</div>
</div>
</div>
</div>

Bullet Point Except the original 25*25mm mounting holes, now added 20*20mm holes for greater compatibility with a wider range of FPV drone models. Updated the design of PCB board and shell, improved the quality of VTX, more durable. Optimized the installation place of the antenna, it's better to protect the VTX. The po

Walksnail Avatar HD VTX V2 Module – CADDX FPV


Bullet Point




Except the original 25*25mm mounting holes, now added 20*20mm holes for greater compatibility with a wider range of FPV drone models.
Updated the design of PCB board and shell, impro

Walksnail Avatar HD VTX V2 Module

The Walksnail Avatar HD VTX Module V2 provides superior performance with a range of features, including 25*25mm and 20*20mm mounting holes, optimized antenna installation, frequency binding button, spare power pad and up to 8 or 32GB built-in storage for 1080P or 720P HD fly videos. Increased TVS protection and support

Walksnail Avatar HD VTX Module V2 (VTX ONLY) for Walksnail Avatar/Fatshark Dominator HD FPV System - Choose Memory Size

Spare replacement VTX module for Walksnail HD V2 VTX Combos.
Check out all our Walksnail HD products!

Includes

1x Walksnail Avatar HD V2 VTX Module


Spare replacement VTX module for Walksnail HD V2 VTX Combos.  Check out all our Walksnail HD products! Includes 1x Walksnail Avatar HD V2 VTX Module

Walksnail Avatar HD V2 VTX Module - Choose Version from WREKD Co.

Walksnail Avatar HD V2 VTX Module - Choose Version

Caddx

Bullet Point Exceptthe original 25*25mm mounting holes, now added 20*20mm holes for greater compatibility with a wider range of FPV drone models. Updated the design of PCB board and shell, improved the quality of VTX, more durable. Optimized the installation place of the antenna, it&#x27s better to protect the VTX. The pos

Bullet Point Exceptthe original 25*25mm mounting holes, now added 20*20mm holes for greater compatibility with a wider range of FPV drone models. Updated the design of PCB board and shell, improved the quality of VTX, more durable. Optimized the installation place of the antenna, it's better to protect the VTX. The pos
