Caddx

Caddx Air Unit Micro Kit for DJI

DJI revolutionized FPV with the development of their digital HD technology. This resulted in a huge upgrade from the original analog resolution to a fully digital 720p signal right in your goggles.
The DJI FPV Air Unit provides ultra-low latency HD digital image transmission, built-in 1080p/60fps DVR recording, and eight frequency channels to allow up to eight pilots to fly simultaneously.






Specifications

WeightAir Unit (Camera included): 45.8 g3.9 g (MMCX elbow each)
DimensionsAir Unit: 44 × 37.8 × 14.4 mmCamera: 27.4 × 21.1 × 20.1 mmCoaxial Cable: 100 mm
Operating Frequency: 5.725-5.850 GHzTransmitter Power (EIRP): FCC/SRRC: &lt30 dBm CE: &lt14 dBm
Min. Latency (end-to-end)Low Latency Mode (720p/120fps): &lt28 msHigh-Quality Mode (720p/60fps): &lt40 ms
Max. Transmission Distance: FCC/SRRC: &lt4 km CE: &lt0.7 kmVideo Format: MP4 (Video format: H.264 Audio format: ACC-LC)I/O Interface: USB-C, MMCX, 3-in-1 port, microSD card slotOperating Temperature Range: 32° to 104°F (0° to 40°C)Input Power: 7.4-17.6 V, about 4-9 WSensor: 1/3.2'' CMOS Effective Pixels: 4 MLens: 2.1 mm, f/2.1Shutter: Rolling shutterISO: 100-25600FOV: 150°(D) 122°(H) 93°(V)Dimension: 22.1 × 21.1 × 20.1 mmWeight: 8.2 g
Channels: 8Channels InfoFCCChannel 1: 5660Channel 2: 5695Channel 3: 5735Channel 4: 5770Channel 5: 5805Channel 6: 5878Channel 7: 5914Channel 8: 5839
Compatibility

DJI FPV Goggles
DJI FPV Remote Controller

Tips
The air unit may become hot during or after operation.DO NOT touch the air unit before it cools down.DO NOT use the air unit for an extended period when there is no external cooling equipment. Otherwise, the air unit may overheat and enter overheat protection mode. Keep the antennas of the air unit at least 40 mm apart.Keep the air unit away from metal objects or carbon fiber frames. Make sure to choose a position where the transmission will not be blocked during flight.
Includes

DJI FPV Air Unit (with camera and four M2 screws) × 1
Three-in-one cable × 1
Antenna (MMCX elbow) × 2



DJI revolutionized FPV with the development of their digital HD technology. This resulted in a huge upgrade from the original analog resolution to a fully digital 720p signal right in your goggles.  The DJI FPV Air Unit provides ultra-low latency HD digital image transmission, built-in 1080p/60fps DVR recording, and ei

Caddx DJI FPV Air Unit

FPV through the DJI Digital HD Air Unit. The way FPV is meant to be.&nbspThis is the Caddx DJI air unit with 120fps HD camera.

FPV through the DJI Digital HD Air Unit. The way FPV is meant to be. This is the Caddx DJI air unit with 120fps HD camera.

Caddx DJI Digital HD FPV Air Unit Kit

The CaddxFPV Air Unit Micro Version is a 19x19 micro-sized camera with low-latency digital video transmission. The Air Unit Transmission technology utilizes a two-way communication system to stabilize signal connections, granting pilots more flexibility when flying through challenging areas.Also see the&nbspCaddx Polar Micro Digital FPV Air Unit Camera Kit here.

The CaddxFPV Air Unit Micro Version is a 19x19 micro-sized camera with low-latency digital video transmission. The Air Unit Transmission technology utilizes a two-way communication system to stabilize signal connections, granting pilots more flexibil

Caddx Air Unit Micro Version for DJI Digital HD FPV System

The Original DJI Digital HD FPV Air Unit Kit is back - Limited Quantities Available! This is&nbspthe original DJI Air Unit with 120fps HD camera.

The Original DJI Digital HD FPV Air Unit Kit is back - Limited Quantities Available! This is the original DJI Air Unit with 120fps HD camera.

DJI Digital HD FPV Air Unit Kit - Original Version

CADDXFPV

<div style="text-align: left"><span style="color: #000000">Only <a href="https://caddxfpv.com/collections/digital-cameras-1/products/air-unit-micro-camera" target="_blank" rel="noopener noreferrer">Caddx air unit micro camera</a> + cable left in stock (excluding Air Unit)</span></div>
<div style="text-align: left"><span style="color: #000000">Note: The camera will be packed in a static bag.</span></div>
<div style="text-align: left">
<div class="YQaNob" data-cp="1" data-is-ver="false" data-nnttsvi="1" data-sm="1" data-sugg-time="500" data-sugg-url="https://clients1.google.com/complete/search" data-uilc="zh-CN" id="tw-container">
<div jsname="gI9xcc" jsslot="1">
<div jscontroller="geqCid" jsdata="SANFE_B8xgqs" jsaction="uQxhTd:d4hecblWUBqb:TO5MWbIcWBXe:hLaFAeKFlBO:UuREqbM2HAEc:eNrnOdrcuQ6b:npT2md">
<div class="tw-src-ltr" id="tw-ob">
<div class="oSioSc">
<div id="tw-target">
<div id="kAz1tf" class="g9WsWb">
<h1 class="tw-ta-container hide-focus-ring tw-nfl" id="tw-target-text-container" tabindex="0">
<span style="color: #362121"></span><br>
</h1>
<br>
</div>
</div>
</div>
</div>
<h1 class="dURPtb"><br></h1>
<div jsname="gI9xcc" jsslot="1"><br></div>
</div>
</div>
</div>
<div class="KFFQ0c"><br></div>
<br>
</div>
<div style="text-align: left">
<img src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/CaddxFPV_Air_Unit_Micro_Version_Pre-order1_7c954fb1-6449-435b-93fc-8449b19a648e.jpg?v=1619604267" alt=""><img data-mce-fragment="1" src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/CaddxFPV_Air_Unit_Micro_Version_Pre-order2_6c5fb1fe-b49f-4d65-8023-7dbad644f266.jpg?v=1619604291" style="float: none" data-mce-src="https://cdn.shopify.com/s/files/1/0036/3921/4169/files/CaddxFPV_Air_Unit_Micro_Version_Pre-order2_6c5fb1fe-b49f-4d65-8023-7dbad644f266.jpg?v=1619604291">
</div>

The Caddx Air Unit Micro Version is a 19*19mm micro sized camera. Which is with 28ms Low-Latency, 720p/120fps Video Transmission. Anti- Interference Digital Transmission.

CaddxFPV Air Unit Micro Version for DJI Digital HD FPV System – CADDX FPV

Only Caddx air unit micro camera + cable left in stock (excluding Air Unit)
Note: The camera will be packed in a static bag.




























CADDXFPV Air Unit Micro Version

The CaddxFPV Air Unit Micro Version is a 19x19 micro-sized camera with low-latency digital video transmission. The Air Unit Transmission technology utilizes a two-way communication system to stabilize signal connections, granting pilots more flexibility when flying through challenging areas. Modern innovations, like a strong transmission system embedded remote controller receiver, and multi-antenna technology, is why the Air Unit can perform remarkably.

The best quality First Person View equipment. Free or discounted shipping on all orders.Drone Racing, RC Airplanes, FPV Cameras, FPV Goggles, Video Transmitters, RC Quads, Drone Antennas, Lipo Batteries, and Ground Station Equipment.All available for amateurs, schools, hobbyists, government, and wholesale buyers.

Caddx Air Unit Micro Version For DJI Digital HD FPV System - www.readymaderc.com

VTX Frequency

The VTX processes the image from your FPV camera and sends it to your goggle’s video receiver (VRX). If you chose as digital video system, you need a VTX that matches the system. Most analog VTXs and VRXs are compatible with each other, and your biggest consideration will be how much output power you need. The more output power, the more range and better signal you’ll get. Learn more about VTXs.

Video Transmitters

VTX Stack Mount

VTX Antenna Connector

Max Transmission Power

Digital / Analog VTX

FPV Camera Included

Caddx Polar Micro Digital FPV Air Unit Camera Kit

Caddx Polar Micro Digital FPV Air Unit Camera Kit - Silver

The Caddx Air Unit Polar Starlight supports brightness and saturation adjustment. 1/1.8-Inch HD Digital Starlight Sensor. Excellent Image Quality and Brilliant True Colors.

CADDXFPV Polar Starlight Digital Camera | HD FPV Drones Camera System – CADDX FPV

CADDXFPV Polar Starlight Air Unit

Caddx Air Unit Polar Starlight Digital HD DJI FPV System

Caddx Air Unit Polar Starlight Digital HD DJI FPV System - RMRC

Caddx Polar Micro Digital FPV Air Unit Camera Kit - Coffee

TBS Unify Pro32 HV 5.8GHz Video Transmitter - MMCX

With the TBS UNIFY PRO32 HV (MMCX) we have boosted the output power, improved the robustness, decreased the power consumption, added capability for insane features and perfected the way it is installed in your multirotor. In a nutshell, it’s the most comprehensive, future proof, highest quality and overall best HV VTx

TBS Unify Pro32 HV (MMCX) VTx Video Transmitter

Team BlackSheep

With the TBS UNIFY PRO32 HV we have boosted the output power, improved the robustness, decreased the power consumption, added capability for insane features and perfected the way it is installed in your multirotor.

TBS Unify Pro32 HV 5.8GHz Video Transmitter (MMCX)

TBS Unify EVO 5.8GHz Video Transmitter

Introducing the latest technology in TBS video transmitters! It comes with a built-in graphical OSD and microphone, talks all the protocols and transmits all the power levels! This makes it a perfect companion for any situation where you don't have any OSD, or want to benefit from the simplicity and clarity that the TB

TBS Unify Evo VTX

The EVO comes with a built-in graphical OSD and microphone, talks all the protocols and transmits all the power levels! This makes it a perfect companion for any situation where you don't have any OSD, or want to benefit from the simplicity and clarity that the TBS OSD is known for.
Check out the rest of out TBS Products and all our VTXs!
Features
THE SWISS ARMY KNIFE OF VIDEO TRANSMITTERSWe packed all the features that we could into the smallest form factor possible. When we set out to make this video transmitter we were looking to make something that would fit all use cases for analog video transmitters ever envisioned. Long range, racing, freestyle, wings, cars. You name it, the VTx will shine in this application! More features are still under development and they can be loaded via the TBS AgentX with the onboard USB port.BARCODES? BARCODES!! (PATENT PENDING)The VTx is capable of processing the camera image. So we taught it to read barcodes! This means the VTx no longer needs to be transmitting to set channels, and setting channels can be done in the pits. It also means no more guesswork what channel the VTx is on, simply point it at the barcode of your choice and it will move to that channel or power level! There are many more exciting features coming with this technology, stay tuned and barcode on!CRSF, SMARTAUDIO 2.1, PWM, PITMODECRSF is the defacto standard in FPV and racing drones, so it makes sense that this video transmitter can both understand as well as speak CRSF. For compatibility, the VTx also speaks SA 2.1 and has the teamrace-friendly pitmode feature. PWM controls allow you to use the VTx with any radio and product. For example, you may have it on your R/C cars, R/C motorcycles or other devices that don't have flight controllers or Crossfire and control the VTx button with a switch or button you have on the radio.

Specifications

Operating Voltage: 6V - 26V (2S - 6S)
Supply current: (25mW) ~ 0.11A | (100mW) ~ 0.13A | (400mW) ~ 0.18A | (full power) ~ 0.24A
Operating Temperature: watch for normal airflow
Video Input Impedance: 75 Ohm
Weight: 7g
Dimensions: 30 x 23 x 5.5mm
Antenna Connector: u.FL socket
Video Format: NTSC/PAL
Audio: Microphone included
Output Power: 14dBm (25mW), 20dBm (100mW), 26dBm (400mW), 29dBm (800mW)

Includes

1x TBS UNIFY EVO 5G8 Video transmitter
1x u.FL pigtail SMA
1x Power, Camera and CRSF cables

Wiring Diagram


The EVO comes with a built-in graphical OSD and microphone, talks all the protocols and transmits all the power levels! This makes it a perfect companion for any situation where you don't have any OSD, or want to benefit from the simplicity and clarity that the TBS OSD is known for. Check out the rest of out TBS Produc

TBS Unify EVO 25-800mW 5.8GHz VTX - SMA

TBS knows video transmitters, and their latest creation merges the best qualities of multiple VTX's into one. The Unify EVO aims to satisfy the video needs of every pilot!

TBS Unify Pro32 Nano 5G8 V1.1 500mW Video Transmitter

With the TBS UNIFY PRO32 Nano we have boosted the output power, improved the robustness, decreased the power consumption, added capability for insane features and perfected the way it is installed in your multirotor. In a nutshell, it’s the most comprehensive, future proof, highest quality and overall best nano VTx ever made.
MAIN FEATURES

 	Smallest, lightest video transmitter on the market
 	Barcodes reading
 	Up to 500mw+ of output power
 	Ultra-clean transmission (up to 16 pilots at once!)
 	PitMode - power up your quad during a race. Now with team-race capability!
 	Easy OSD, FC and RC channel changes, with fallback button menu
 	Robust RF amplifier allows powering up without antenna for hours!
 	Clean powerup and video switching
 	CE certified

BARCODES? BARCODES!! (PATENT PENDING)
The VTx is capable of processing the camera image. So we taught it to read barcodes! This means the VTx no longer needs to be transmitting to set channels, and setting channels can be done in the pits. It also means no more guesswork what channel the VTx is on, simply point it at the barcode of your choice and it will move to that channel or power level! There are many more exciting features coming with this technology, stay tuned and barcode on!
PITMODE - MADE TO RACE
Zero interference even while powered up, it's now a possibility! If you've ever repaired a quad during a race, you'll know the frustrations of not being able to power on and test your system. With PitMode, we will reduce the output power to a bare minimum (way below single digit mW's) to allow you to power up your quad and still see the image! You've got less than one meter of range to put your quad through its paces before placing it on that starting grid. Using SmartAudio or CRSF, you can power up the VTx using your remote!
SMARTAUDIO V2.1 &ampamp CRSF - TEAM RACE READY
SmartAudio technology provides UART control for your entire video transmitter. Parameters such as output power, bands, channels and frequency can be freely controlled. This enables remote channel control directly from a smart device (TBS Crossfire, external bluetooth or wifi module required), from your radio (TBS Crossfire with TBS Tango or OpenTX compatible remote required), or from the OSD (e.g. Betaflight OSD, TBS CORE PRO).

With all these options available, you ought to find something that fits your bill. Together with CleanSwitch, the sky is the limit ... jump between channels without interfering fellow pilots in air, create backup-/emergency-frequencies, global VTx power adjustments by race organizers or other clever systems aimed at streamlining and improving race management are now a possibility!
CLEANSWITCH - NEIGHBOR FRIENDLY
CleanSwitch is a technology developed at TBS that will ensure that your video transmitter is interference-free while powering on, or while changing channels. All current video transmitters swipe across the entire band while being powered on, often resulting in flickering and heavy interference to anyone in the air, regardless of video channel chosen. TBS CleanSwitch will allow you to power on and change channels while your buddies are in the air, without any external interference. CleanSwitch is race friendly, and pilot friendly ... that's how we like it at TBS :)
SPECIFICATIONS

 	Operating Voltage: 3-13V
 	Operating Temperature: watch for normal airflow
 	Video Input Impedance: 75 Ohm
 	Weight: 1g
 	Dimensions: 15 x 13 x 2mm
 	Antenna Connector: u.FL socket
 	Video Format: NTSC/PAL
 	Output Power: 14dBm (25mW), 20dBm (100mW), 26dBm (400mW), 28dBm (500+mw)

INCLUDED

 	1x TBS UNIFY PRO32 5G8 Video transmitter
 	1x Silicone cable set (pre-tinned)
 	1x Linear whip antenna
 	1x Shrink Tube

DOWNLOADS

 	TBS UNIFY Pro32 Manual
 	TBS UNIFY Pro32 Manual (German)
 	Declaration of Conformity
 	OTA Firmware Update
 	VTX Table for Betaflight

* HAM license is required for operation on HAM channels, and HAM power levels! The VTx ships with only legal channels enabled, please consult the manual on unlocking procedure.

TBS UNIFY PRO32 NANO 5G8 V1.1 | Five33

TBS UNIFY PRO32 NANO 5G8 V1.1

TBS Avionics Co. Ltd.

TBS UNIFY PRO32 NANO 5G8 V1.1
With the TBS UNIFY PRO32 Nano we have boosted the output power, improved the robustness, decreased the power consumption, added capability for insane features and perfected the way it is installed in your multirotor. In a nutshell, it’s the most comprehensive, future proof, highest quality and overall best nano VTx ever made.

MAIN FEATURES

Smallest, lightest video transmitter on the market
Barcodes reading
Up to 500mw+ of output power
Ultra-clean transmission (up to 16 pilots at once!)
PitMode - power up your quad during a race. Now with team-race capability!
Easy OSD, FC and RC channel changes, with fallback button menu
Robust RF amplifier allows powering up without antenna for hours!
Clean powerup and video switching
CE certified

BARCODES? BARCODES!! (PATENT PENDING)
The VTx is capable of processing the camera image. So we taught it to read barcodes! This means the VTx no longer needs to be transmitting to set channels, and setting channels can be done in the pits. It also means no more guesswork what channel the VTx is on, simply point it at the barcode of your choice and it will move to that channel or power level! There are many more exciting features coming with this technology, stay tuned and barcode on!
PITMODE - MADE TO RACE
Zero interference even while powered up, it's now a possibility! If you've ever repaired a quad during a race, you'll know the frustrations of not being able to power on and test your system. With PitMode, we will reduce the output power to a bare minimum (way below single digit mW's) to allow you to power up your quad and still see the image! You've got less than one meter of range to put your quad through its paces before placing it on that starting grid. Using SmartAudio or CRSF, you can power up the VTx using your remote!
SMARTAUDIO V2.1 &amp CRSF - TEAM RACE READY
SmartAudio technology provides UART control for your entire video transmitter. Parameters such as output power, bands, channels and frequency can be freely controlled. This enables remote channel control directly from a smart device (TBS Crossfire, external bluetooth or wifi module required), from your radio (TBS Crossfire with TBS Tango or OpenTX compatible remote required), or from the OSD (e.g. Betaflight OSD, TBS CORE PRO).
With all these options available, you ought to find something that fits your bill. Together with CleanSwitch, the sky is the limit ... jump between channels without interfering fellow pilots in air, create backup-/emergency-frequencies, global VTx power adjustments by race organizers or other clever systems aimed at streamlining and improving race management are now a possibility!
CLEANSWITCH - NEIGHBOR FRIENDLY
CleanSwitch is a technology developed at TBS that will ensure that your video transmitter is interference-free while powering on, or while changing channels. All current video transmitters swipe across the entire band while being powered on, often resulting in flickering and heavy interference to anyone in the air, regardless of video channel chosen. TBS CleanSwitch will allow you to power on and change channels while your buddies are in the air, without any external interference. CleanSwitch is race friendly, and pilot friendly ... that's how we like it at TBS :)
SPECIFICATIONS



Operating Voltage
3-13V


Operating Temperature
Watch for normal airflow


Video Input Impedance
75 Ohm


Weight
1g


Dimensions
15 x 13 x 2mm


Antenna Connector
u.FL socket


Video Format
NTSC/PAL


Output Power
14dBm (25mW), 20dBm (100mW), 26dBm (400mW), 28dBm (500+mw)



INCLUDED

1x TBS UNIFY PRO32 5G8 Video transmitter
1x Silicone cable set (pre-tinned)
1x Linear whip antenna
1x Shrink Tube

DOWNLOADS

TBS UNIFY Pro32 Manual
TBS UNIFY Pro32 Manual (German)
Declaration of Conformity
OTA Firmware Update
VTX Table for Betaflight

* HAM license is required for operation on HAM channels, and HAM power levels! The VTx ships with only legal channels enabled, please consult the manual on unlocking procedure.

TBS UNIFY PRO32 NANO 5G8 V1.1 With the TBS UNIFY PRO32 Nano we have boosted the output power, improved the robustness, decreased the power consumption, added capability for insane features and perfected the way it is installed in your multirotor. In a nutshell, it’s the most comprehensive, future proof, highest quality

With the TBS UNIFY PRO32 Nano we have boosted the output power, improved the robustness, decreased the power consumption, added capability for insane features and perfected the way it is installed in your multirotor. In a nutshell, it’s the most comprehensive, future proof, highest quality and overall best nano VTx ever made. V1.1

With the TBS UNIFY PRO32 Nano we have boosted the output power, improved the robustness, decreased the power consumption, added capability for insane features and perfected the way it is installed in your multirotor. In a nutshell, it’s the most co

TBS Unify Pro Nano 5G8

The world's smallest FPV video transmitter with 25mW / 50mW power levels, Smart Audio and u.FL

TBS UNIFY PRO NANO 5G8 | Five33

TBS UNIFY PRO NANO 5G8


TBS UNIFY PRO NANO 5G8


The world's smallest FPV video transmitter with 25mW / 50mW power levels, Smart Audio and u.FL

SIZE MATTERS!
As builds become smaller and the innovation surrounding brushed and brushless micro quads accelerates, the need for a high-quality VTx increases. TBS has built the smallest VTx possible, focusing purely on size! Sporting the usual Unify Pro pedigree, a newly-revised u.FL connector and the industry-standard Smart Audio support. You will be blown away with the performance in terms of range, signal clarity and signal spacing.

SPECIFICATIONS



Input Voltage
4.5V - 5V ONLY


Power levels
25mW / 50mW


Interface
SmartAudio and capacitive button (or solder external tactile button separately - included!)


Weight
1.4g (incl. antenna)


Size
13.2mm x 14.6mm


Antenna connector
u.FL (upgraded)


Antenna length
45.6mm (end to end)


TBS Tech

Smart Audio, Clean Switch





INCLUDES

1x Unify Pro nano 5G8 VTX
1x button switch
1x TBS UNIFY PRO 5G8 Linear Antenna
6x 30awg silicon connection wires (2 black, 2 red, 1 white, 1 yellow)


DOWNLOADS

VTX Table for Betaflight

MANUAL

TBS UNIFY Pro Manual



TBS UNIFY PRO NANO 5G8 The world's smallest FPV video transmitter with 25mW / 50mW power levels, Smart Audio and u.FL   SIZE MATTERS! As builds become smaller and the innovation surrounding brushed and brushless micro quads accelerates, the need for a high-quality VTx increases. TBS has built the smallest VTx possible,

SIZE MATTERS! As builds become smaller and the innovation surrounding brushed and brushless micro quads accelerates, the need for a high-quality VTx increases. TBS has built the smallest VTx possible, focusing purely on size! Sporting the usual Unify Pro pedigree, a newly-revised u.FL connector and the industry-standar

TBS Unify Pro Nano 5G8 VTx Video Transmitter

The world's smallest FPV video transmitter with 25mW / 50mW power levels, Smart Audio and u.FL.

TBS Unify Pro 5G8 V3 - SMA






This is the TBS Unify PRO 5G8 V3 SMA video transmitter for FPV. The smallest and most powerful (800mW!) video transmitter the world has ever seen! It's race ready with PitMode, a super-clean and interference free power levels, and connectivity to flight controllers and other means of quickly changing channels. It runs off a filtered 5V power supply, so it's perfect when being connected to a TBS CORE PRO or TBS PowerCube (*)
New in V3:

Improved Voltage spikes acceptance from 6.5Vmax. on V2 to 13Vmax. on V3

Main features

Smallest, lightest video transmitter on the market
Up to 800mW of output power
Ultra-clean transmission (up to 16 pilots at once!)
PitMode - power up your quad during a race
Easy OSD, FC and RC channel changes, with fallback button menu
Robust RF amplifier allows powering up without antenna for hours!
Clean powerup and video switching
CE certified

PitMode - Made to race
Zero interference even while powered up, it's now a possibility! If you've ever repaired a quad during a race, you'll know the frustrations of not being able to power on and test your system. With PitMode, we will reduce the output power to a bare minimum (way below single digit mW's), and move to frequencies unused by race organizers, to allow you to power up your quad and still see the image! You've got a few meters of range to put your quad through its paces before placing it on that starting grid, and in combination with CleanSwitch you can power on as soon as your channel is available without interrupting any of the active channels.
SmartAudio V2 - Full control
SmartAudio technology provides UART and I2C control for your entire video transmitter. Parameters such as output power, bands, channels and frequency can be freely controlled. This enables remote channel control directly from a smart device (TBS Crossfire, external bluetooth or wifi module required), from your radio (TBS Crossfire with TBS Tango or OpenTX compatible remote required), or from the OSD (e.g. TBS CORE PRO). With all these options available, you ought to find something that fits your bill. Together with CleanSwitch, the sky is the limit ... jump between channels without interfering fellow pilots in air, create backup-/emergency-frequencies, global VTx power adjustments by race organizers or other clever systems aimed at streamlining and improving race management are now a possibility!
CleanSwitch - Neighbor friendly
CleanSwitch is a technology developed at TBS that will ensure that your video transmitter is interference-free while powering on, or while changing channels. All current video transmitters swipe across the entire band while being powered on, often resulting in flickering and heavy interference to anyone in the air, regardless of video channel chosen. TBS CleanSwitch will allow you to power on and change channels while your buddies are in the air, without any external interference. CleanSwitch is race friendly, and pilot friendly ... that's how we like it at TBS :)
Say NO! to Dipswitches
Even though learning binary was a fun mind-game, in practice a single-push-button or OSD-controlled video transmitter is just much easier to operate. Gone are the days of video transmitter cards, stepping on people's channels by mistake, or a mismatch between your goggle and video transmitter frequencies.
Specifications

Operating Voltage: 4.5 - 5.5V
Supply current: 600mA
Operating Temperature: watch for normal airflow
Audio carrier Frequency: 6.5 MHz
Video Input Impedance: 75 Ohm
Weight: 5g (with SMA, without antenna)
Antenna Connector: SMA Female Socket with screw mounting holes
Video Format: NTSC/PAL
Output Power: 13dBm (25mW), 23dBm (200mW), 27dBm (500mW), 29dBm (800mW*)

Included

TBS UNIFY 5G8 Video transmitter
5V Video Transmitter pigtail cable
TBS UNIFY Pro Manual
CE Certification
Declaration of Conformity

* HAM license is required for operation on HAM channels, and HAM power levels! The VTx ships with only legal channels enabled, please consult the manual on unlocking procedure.






FPV Regulatory Notice
The use and operation of this type of product in the USA and many other countries may require a license and some countries may forbid its use entirely. In the USA, you will need a "HAM" amateur radio license. Learn more about HAM licenses. It is your responsibility to ensure that the use of this product meets the requirements imposed by your government’s rules and regulations for RF devices. Do not purchase this product if you are unsure of the government requirements or are not able to comply with them. GetFPV cannot be held responsible for your actions if you purchase and/or use this product in violation of your government's regulations. By agreeing to our terms and conditions during the check-out process, you also agree to have read and to understand this notice.

TBS Unify Pro 5G8 V3 (SMA) This is the TBS Unify PRO 5G8 V3 SMA video transmitter for FPV. The smallest and most powerful (800mW!) video transmitter the world has ever seen! It's race ready with PitMode, a super-clean and interference free power levels, and connectivity to flight controllers and other me

TBS Unify Pro 5G8 V3 (SMA)

TBS Unify Pro 5G8 V3 (SMA) DroneRacingParts.com

This is the TBS Unify PRO 5G8 V3 SMA video transmitter for FPV. The smallest and most powerful (800mW!) video transmitter the world has ever seen! It's race ready with PitMode, a super-clean and interference free power levels, and connectivity to flight controllers and other means of quickly changing channels. It runs off a filtered 5V power supply, so it's perfect when being connected to a TBS CORE PRO or TBS PowerCube.
New in V3: Improved Voltage spikes acceptance from 6.5Vmax. on V2 to 13Vmax.
Check out the rest of out TBS Products and all our VTXs!
Features

Smallest, lightest video transmitter on the market
Up to 800mW of output power
Ultra-clean transmission (up to 16 pilots at once!)
PitMode - power up your quad during a race
Easy OSD, FC and RC channel changes, with fallback button menu
Robust RF amplifier allows powering up without antenna for hours!
Clean powerup and video switching
CE certified

PitMode - Made to raceZero interference even while powered up, it's now a possibility! If you've ever repaired a quad during a race, you'll know the frustrations of not being able to power on and test your system. With PitMode, we will reduce the output power to a bare minimum (way below single digit mW's), and move to frequencies unused by race organizers, to allow you to power up your quad and still see the image! You've got a few meters of range to put your quad through its paces before placing it on that starting grid, and in combination with CleanSwitch you can power on as soon as your channel is available without interrupting any of the active channels. SmartAudio V2 - Full controlSmartAudio technology provides UART and I2C control for your entire video transmitter. Parameters such as output power, bands, channels and frequency can be freely controlled. This enables remote channel control directly from a smart device (TBS Crossfire, external bluetooth or wifi module required), from your radio (TBS Crossfire with TBS Tango or OpenTX compatible remote required), or from the OSD (e.g. TBS CORE PRO). With all these options available, you ought to find something that fits your bill. Together with CleanSwitch, the sky is the limit ... jump between channels without interfering fellow pilots in air, create backup-/emergency-frequencies, global VTx power adjustments by race organizers or other clever systems aimed at streamlining and improving race management are now a possibility!CleanSwitch - Neighbor friendlyCleanSwitch is a technology developed at TBS that will ensure that your video transmitter is interference-free while powering on, or while changing channels. All current video transmitters swipe across the entire band while being powered on, often resulting in flickering and heavy interference to anyone in the air, regardless of video channel chosen. TBS CleanSwitch will allow you to power on and change channels while your buddies are in the air, without any external interference. CleanSwitch is race friendly, and pilot friendly ... that's how we like it at TBS :)Say NO! to DipswitchesEven though learning binary was a fun mind-game, in practice a single-push-button or OSD-controlled video transmitter is just much easier to operate. Gone are the days of video transmitter cards, stepping on people's channels by mistake, or a mismatch between your goggle and video transmitter frequencies.
Specifications

Operating Voltage: 4.5 - 5.5V
Supply current: 600mA
Operating Temperature: watch for normal airflow
Audio carrier Frequency: 6.5 MHz
Video Input Impedance: 75 Ohm
Weight: 5g (with SMA, without antenna)
Antenna Connector: SMA Female Socket with screw mounting holes
Video Format: NTSC/PAL
Output Power: 13dBm (25mW), 23dBm (200mW), 27dBm (500mW), 29dBm (800mW)

Includes

1x TBS Unify Pro V3 25-800mW 5.8GHz VTX - SMA
1x 5V Video Transmitter pigtail cable


This is the TBS Unify PRO 5G8 V3 SMA video transmitter for FPV. The smallest and most powerful (800mW!) video transmitter the world has ever seen! It's race ready with PitMode, a super-clean and interference free power levels, and connectivity to flight controllers and other means of quickly changing channels. It runs

TBS Unify Pro V3 25-800mW 5.8GHz VTX - SMA

A video transmitter just for racers. 5g weight, 25 - 800mW output power (user adjustable). Cutting weight and flying far has never been this easy and affordable.Antenna Connector: SMA Female Socket

TBS Unify Pro 5G8 HV - SMA

A Unify Pro 5G8 HV transmitter from Team Black Sheep.

TBS Unify Pro 5G8 HV (SMA)

TBS Unify Pro 5G8 HV - Race SMA

Distilling the smallest, lightest and most powerful video transmitters (aka "the golden standard" :) ) down to a bare minimum for FPV racing, at a very attractive price! MAIN FEATURES Smallest, lightest video transmitter on the market 2-6S input power supported 25mW / 200mW power settings Ultra-clean transmission (up t

TBS Unify PRO 5G8 HV Race (SMA)

The smallest, lightest 40ch video transmitter on the market, down to a bare minimum for FPV racing, at a very attractive price!

TBS Unify Pro HV 5G8 - Race (SMA)

TBS Unify Pro 5G8 HV - RP-SMA

TBS Unify Pro 5G8 HV (RP-SMA)

TBS Unify Pro 5G8 V3 - RP-SMA

The smallest, lightest 40ch video transmitter on the market!

TBS Unify Pro 5G8 V3 (RP-SMA)

TBS Unify Pro HV 25-800mW 5.8GHz VTX - SMA

The most popular, most powerful video transmitter on the market just got a "bigger" brother. It can be connected directly to up to 6S of battery-juice and do 5V output for your camera. It will filter the power and make sure you get clean video, even without being connected to a TBS CORE or TBS PowerCube. With a brand new active output power monitor, we ensure that you'll always meet the race requirements while giving you the best possible picture. With only 7g and a 31x22x6mm form factor, your quad will barely notice it's there. The 25mW - 800mW adjustable output power allows you to race with friends and penetrate serious concrete with just a few pushes of a button. The 40CH coverage gives you the freedom to fly at any race without having to resort to video transmitter swapping practices.
Check out the rest of out TBS Products and all our VTXs!
Features
Pitmode - Made to RaceZero interference even while powered up, it's now a possibility! If you've ever repaired a quad during a race, you'll know the frustrations of not being able to power on and test your system. With PitMode, we will reduce the output power to a bare minimum (way below single digit mW's), and move to frequencies unused by race organizers, to allow you to power up your quad and still see the image! You've got a few meters of range to put your quad through its paces before placing it on that starting grid, and in combination with CleanSwitch you can power on as soon as your channel is available without interrupting any of the active channels. SmartAudio - Full ControlSmartAudio technology provides UART and I2C control for your entire video transmitter. Parameters such as output power, bands, channels, and frequency can be freely controlled. This enables remote channel control directly from a smart device (TBS Crossfire, external Bluetooth or wifi module required), from your radio (TBS Crossfire with TBS Tango or OpenTX compatible remote required), or from the OSD (e.g. TBS CORE PRO). With all these options available, you ought to find something that fits your bill. Together with CleanSwitch, the sky is the limit ... jump between channels without interfering fellow pilots in the air, create backup-/emergency-frequencies, global VTx power adjustments by race organizers or other clever systems aimed at streamlining and improving race management are now a possibility!CleanSwitch - Neighbor FriendlyCleanSwitch is a technology developed at TBS that will ensure that your video transmitter is interference-free while powering on, or while changing channels. All current video transmitters swipe across the entire band while being powered on, often resulting in flickering and heavy interference to anyone in the air, regardless of video channel chosen. TBS CleanSwitch will allow you to power on and change channels while your buddies are in the air, without any external interference. CleanSwitch is race friendly, and pilot friendly ... that's how we like it at TBS :)Say no! to DipswitchesEven though learning binary was a fun mind-game, in practice a single-push-button or OSD-controlled video transmitter is just much easier to operate. Gone are the days of video transmitter cards, stepping on people's channels by mistake, or a mismatch between your goggle and video transmitter frequencies.
Specifications

Operating Voltage: 2S - 6S
Supply current: up to 600mA
Operating Temperature: watch for normal airflow
Audio carrier Frequency: 6.5 MHz
Video Input Impedance: 75 Ohm
Weight: 7g (with SMA, without antenna)
Input Connector: JST GH 7pin (after July 2018)
Antenna Connector: SMA Female Socket with screw mounting holes
Video Format: NTSC/PAL
Output Power: 13dBm (25mW), 23dBm (200mW), 27dBm (500mW), 29dBm (800mW)

Includes
1x TBS Unify Pro HV 25-800mW 5.8GHz VTX - SMA1x 7Pin Video Transmitter pigtail cable1x TBS UNIFY Pro Manual

The most popular, most powerful video transmitter on the market just got a "bigger" brother. It can be connected directly to up to 6S of battery-juice and do 5V output for your camera. It will filter the power and make sure you get clean video, even without being connected to a TBS CORE or TBS PowerCube. With a brand n

TBS Unify Pro HV Race 25-200mW 5.8GHz VTX - SMA

he newly refreshed Unify is here! The U.FL connector now has screws over a tiny plate to hold it in place. The connections have changed to add an additional ground and data pin to allow you to wire audio and SmartAudio separately.Distilling the smallest, lightest and most powerful video transmitters (aka "the golden standard") down to a bare minimum for FPV racing, at a very attractive price.
Check out the rest of out TBS Products and all our RC transmitters, modules, and accessories.
Features

Smallest, lightest video transmitter on the market
2-6S input power supported
25mW / 200mW power settings
Ultra-clean transmission (up to 16 pilots at once!)
PitMode - power up your quad during a race
Easy OSD, FC and RC channel changes, with fallback button menu
Robust RF amplifier allows powering up without an antenna for hours!
Clean powerup and video switching
CE certified
SmartAudio is now split into Audio = Audio and Data = SmartAudio

PITMODE - MADE TO RACEZero interference even while powered up, it's now a possibility! If you've ever repaired a quad during a race, you'll know the frustrations of not being able to power on and test your system. With PitMode, we will reduce the output power to a bare minimum (way below single digit mW's), and move to frequencies unused by race organizers, to allow you to power up your quad and still see the image! You've got a few meters of range to put your quad through its paces before placing it on that starting grid, and in combination with CleanSwitch you can power on as soon as your channel is available without interrupting any of the active channels. SMARTAUDIO V2 - FULL CONTROLSmartAudio technology provides UART and I2C control for your entire video transmitter. Parameters such as output power, bands, channels, and frequency can be freely controlled. This enables remote channel control directly from a smart device (TBS Crossfire, external Bluetooth or wifi module required), from your radio (TBS Crossfire with TBS Tango or OpenTX compatible remote required), or from the OSD (e.g. TBS CORE PRO). With all these options available, you ought to find something that fits your bill. Together with CleanSwitch, the sky is the limit ... jump between channels without interfering fellow pilots in the air, create backup-/emergency-frequencies, global VTx power adjustments by race organizers or other clever systems aimed at streamlining and improving race management are now a possibility.CLEANSWITCH - NEIGHBOR FRIENDLYCleanSwitch is a technology developed at TBS that will ensure that your video transmitter is interference-free while powering on, or while changing channels. All current video transmitters swipe across the entire band while being powered on, often resulting in flickering and heavy interference to anyone in the air, regardless of video channel chosen. TBS CleanSwitch will allow you to power on and change channels while your buddies are in the air, without any external interference. CleanSwitch is race friendly, and pilot friendly ... that's how we like it at TBS.SAY NO! TO DIPSWITCHESEven though learning binary was a fun mind-game, in practice a single-push-button or OSD-controlled video transmitter is just much easier to operate. Gone are the days of video transmitter cards, stepping on people's channels by mistake, or a mismatch between your goggle and video transmitter frequencies.
Specifications

Operating Voltage: 2S - 6S
Supply current: 600mA
Operating Temperature: watch for normal airflow
Audio carrier Frequency: 6.5 MHz
Video Input Impedance: 75 Ohm
Weight: 7g (with SMA, without antenna)
Antenna Connector: SMA Female Socket with screw mounting holes, U.FL to VTx
Video Format: NTSC/PAL
Output Power: 13dBm (25mW), 23dBm (200mW)

TBS UNIFY Pro Manual
Includes

1x TBS Unify Pro HV Race 25-200mW 5.8GHz VTX - SMA


he newly refreshed Unify is here! The U.FL connector now has screws over a tiny plate to hold it in place. The connections have changed to add an additional ground and data pin to allow you to wire audio and SmartAudio separately.Distilling the smallest, lightest and most powerful video transmitters (aka "the golden st

BetaFPV

BetaFPV M03 25-350mW 5.8GHz VTX

BETAFPV

M03 VTX, a ultralight and high output power 5.8GHz analog VTX, is designed for 65-85mm whoop drone for longer range flying. Combining this VTX and the excellent radio link ExpressLRS 2.4G, pilots can fly whoop drones longer to explore more possibilities and fun.

Note: The current version for M03 VTX is V1.1.
Bullet Point

With the 25-350mW output power, M03 VTX provides a stable image and strong transmission.
Only 1.1g and tiny size for drones like 65-85mm whoop drones. The screw mounting holes pattern is suitable with BETAFPV micro canopy. The camera connector JST-0.8 is suitable with BETAFPV C02 and C03 camera.
Comes with IPX type of antenna, just plug and play, no extra solder work needed.
M03 VTX is perfectly suitable for the 65-85mm whoop drone. We highly recommend to use it with ELRS 2.4G FC board, like F4 1S 5A FC (ELRS 2.4G) or F4 1S 12A FC (ELRS 2.4G).




Specification

Item: M03 5.8G VTX

Output power: PIT/25/100/200/400mW (V1.1, adjustable)
Supply voltage range: 4.5-5.5V
Weight: 1.1g (antenna not included)
VTX internal size: 18X14mm
Frequency: 5.8GHz 48 channels, with Raceband: 5658~5917MHz
Channel SEL: SmartAudio
Modulation type: FM
Frequency control: PLL

All harmonic: Max -50dBm
Frequency stability: ±100KHz (Typ.)
Frequency precision: ±200KHz (Typ.)
Channel carrier error: ±1.5dB
Antenna port: 50 Ω
Operating temperature: -10℃~+80℃
Camera connector: JST-0.8, compatible with camera like BETAFPV C01, BETAFPV C02 and NewBeeDrone BeeEye.



Diagram
Below is the diagram of the M03 VTX. The camera connector is JST-0.8 and it is compatible with cameras like BETAFPV C01, BETAFPV C02, C03 and NewBeeDrone BeeEye.


How to Connect with FC
Here is the diagram about how to connect the M03 VTX with F4 1S 5A FC (ELRS 2.4G) board.


Here is the diagram about how to connect the M03 VTX with F4 1S 12A FC (ELRS 2.4G) board.

Change Band &amp Channel &amp Power
M03 VTX could only use the Smart Audio port to change the band and channel.  Enter the OSD menu by radio transmitter sticks ( Pitch Stick UP and Yaw Stick Left). Then FEATURES -&gt VTX SA to change the frequency point and power.

Switchable power includes 25mW, 100mW, 200mW and 350mW. Except the method via OSD menu as show above, the output power could be changed via the power button.

Below is the frequency table of M03 VTX V1.0 and V1.1.

FAQ


The newest version of M03 VTX is V1.1, which has a different VTX configuration. Pilots should flash the relevant VTX file for V1.0 and V1.1 versions. Click here to download the VTX table file for M03 VTX V1.0 and V1.1.


Package

1 * BETAFPV M03 5.8G VTX (antenna assembled)
5 * 30AWG silicone wire (30mm)



M03 VTX, a ultralight and high output power 5.8GHz analog VTX, is designed for 65-85mm whoop drone for longer range flying. Combining this VTX and the excellent radio link ExpressLRS 2.4G, pilots can fly whoop drones longer to explore more possibilities and fun.  Note: The current version for M03 VTX is V1.1. Bullet Po

M03 5.8G VTX

M03 VTX, an ultralight and high output power 5.8GHz analog VTX, is designed for 65-85mm whoop drone for longer-range flying.
Check out all our Micro/Nano VTXs and all our BetaFPV gear!

Features

With the 25-350mW output power, the M03 VTX provides a stable image and strong transmission.
Only 1.1g and a tiny size for drones like 65-85mm whoop drones. The screw mounting holes pattern is suitable with BETAFPV micro canopy. The camera connector JST-0.8 is suitable for the BETAFPV C02 camera.
Comes with IPX type of antenna, just plug and play, no extra solder work needed.
M03 VTX is perfectly suitable for the 65-85mm whoop drone. We highly recommend using it with ELRS 2.4G FC board, like F4 1S 5A FC (ELRS 2.4G) or F4 1S 12A FC (ELRS 2.4G).

Diagram
Below is the diagram of the M03 VTX. The camera connector is JST-0.8 and it is compatible with cameras like BETAFPV C01, BETAFPV C02, and NewBeeDrone BeeEye.


How to connect with the Flight Controller
Here is the diagram about how to connect the M03 VTX with F4 1S 5A FC (ELRS 2.4G) board.


Here is the diagram about how to connect the M03 VTX with F4 1S 12A FC (ELRS 2.4G) board.


Change Band &ampamp Band &ampamp Chnanel &ampamp Power

M03 VTX could only use the Smart Audio port to change the band and channel.  Enter the OSD menu by radio transmitter sticks ( Pitch Stick UP and Yaw Stick Left). Then FEATURES -&ampgt VTX SA to change the frequency point and power.

Switchable power includes 25mW, 100mW, 200mW and 350mW. Except for the method via OSD menu as show above, the output power could be changed via the power button.

Specifications

Item: M03 5.8G VTX

Output power: 25/100/200/350mW (adjustable)
Supply voltage range: 4.5-5.5V
Weight: 1.1g (antenna not included)
VTX internal size: 18X14mm
Frequency: 5.8GHz 48 channels, with Raceband: 5658~5917MHz
Channel SEL: SmartAudio
Modulation type: FM
Frequency control: PLL

All harmonic: Max -50dBm
Frequency stability: ±100KHz (Typ.)
Frequency precision: ±200KHz (Typ.)
Channel carrier error: ±1.5dB
Antenna port: 50 Ω
Operating temperature: -10℃~+80℃
Camera connector: JST-0.8, compatible with cameras like BETAFPV C01, BETAFPV C02 and NewBeeDrone BeeEye.

Includes


1x BetaFPV M03 25-350mW 5.8G Micro VTX - U.FL
5x 30AWG silicone wire (30mm)


M03 VTX, an ultralight and high output power 5.8GHz analog VTX, is designed for 65-85mm whoop drone for longer-range flying. Check out all our Micro/Nano VTXs and all our BetaFPV gear! Features With the 25-350mW output power, the M03 VTX provides a stable image and strong transmission. Only 1.1g and a tiny size for dro

BetaFPV M03 25-350mW 5.8G Micro VTX - U.FL from WREKD Co.

BetaFPV M03 25-350mW 5.8G Micro VTX - U.FL

M03 VTX, an ultralight and high output power 5.8GHz analog VTX, is designed for 65-85mm whoop drone for longer-range flying.
Check out all our Micro/Nano VTXs and all our BetaFPV gear!

Features

With the 25-350mW output power, the M03 VTX provides a stable image and strong transmission.
Only 1.1g and a tiny size for drones like 65-85mm whoop drones. The screw mounting holes pattern is suitable with BETAFPV micro canopy. The camera connector JST-0.8 is suitable for the BETAFPV C02 camera.
Comes with IPX type of antenna, just plug and play, no extra solder work needed.
M03 VTX is perfectly suitable for the 65-85mm whoop drone. We highly recommend using it with ELRS 2.4G FC board, like F4 1S 5A FC (ELRS 2.4G) or F4 1S 12A FC (ELRS 2.4G).

Diagram
Below is the diagram of the M03 VTX. The camera connector is JST-0.8 and it is compatible with cameras like BETAFPV C01, BETAFPV C02, and NewBeeDrone BeeEye.


How to connect with the Flight Controller
Here is the diagram about how to connect the M03 VTX with F4 1S 5A FC (ELRS 2.4G) board.


Here is the diagram about how to connect the M03 VTX with F4 1S 12A FC (ELRS 2.4G) board.


Change Band &amp Band &amp Chnanel &amp Power

M03 VTX could only use the Smart Audio port to change the band and channel.  Enter the OSD menu by radio transmitter sticks ( Pitch Stick UP and Yaw Stick Left). Then FEATURES -&gt VTX SA to change the frequency point and power.

Switchable power includes 25mW, 100mW, 200mW and 350mW. Except for the method via OSD menu as show above, the output power could be changed via the power button.

Specifications

Item: M03 5.8G VTX

Output power: 25/100/200/350mW (adjustable)
Supply voltage range: 4.5-5.5V
Weight: 1.1g (antenna not included)
VTX internal size: 18X14mm
Frequency: 5.8GHz 48 channels, with Raceband: 5658~5917MHz
Channel SEL: SmartAudio
Modulation type: FM
Frequency control: PLL

All harmonic: Max -50dBm
Frequency stability: ±100KHz (Typ.)
Frequency precision: ±200KHz (Typ.)
Channel carrier error: ±1.5dB
Antenna port: 50 Ω
Operating temperature: -10℃~+80℃
Camera connector: JST-0.8, compatible with cameras like BETAFPV C01, BETAFPV C02 and NewBeeDrone BeeEye.

Includes


1x BetaFPV M03 25-350mW 5.8G Micro VTX - U.FL
5x 30AWG silicone wire (30mm)


Foxeer

Foxeer Reaper Nano 25-350mW 5.8GHz VTX w/ IRC Tramp - U.FL


Me Caveman, me love FPV and Foxeer! Foxeer Reaper Nano VTX made for serious racing, perfect for me! Me love to race and need every advantage me can get. This little guy deliver the power and performance me need to win!
Don&#39t forget to check all our other awesome Analog Video Transmitters and the rest of our Foxeer products!
Specifications (me think important things!):

Input Voltage: 5V DC (need power!)
Output Voltage: 5V (me make sure me not go over this when soldering to pad)
Power: 25mW/100mW/200mW/350mW (more power = more range = more responsibility)
Installation hole: No pins (me think makes look slimmer)
Weight: &amplt1g (lighter than tiny rock)
Channels: 40CH (lots of channels for clear signal!)
Consumption: 340mA @ 350mW

Includes:

1x Foxeer Reaper Nano 5.8G 40CH 350mW VTx (me love this little guy!)
1x Power wire (need this to make it work!)



The Foxeer Reaper Nano is a lightweight 5.8G VTx with 40CH and 350mW power output, perfect for FPV enthusiasts.

Foxeer Reaper Nano 5.8G 40CH 350mW 1g Tramp VTx from WREKD Co.

Foxeer Reaper Nano 5.8G 40CH 350mW 1g Tramp VTx

Foxeer Reaper Nano 5.8G 40CH 350mW 1g Tramp VTx



Name
Reaper Nano


Input Voltage
5V


Output Voltage
5V



Channels


40CH




Power


25mW/100mW/200mW/350mW




Weight

&lt1g



Size

12*16mm



Consumption

340mA @ 350mW






Band
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH8




Band A
5865
5845
5825
5805
5785
5765
5745
5725


Band B
5733
5752
5771
5790
5809
5828
5847
5866


Band E
5705
5685
5665
5645
5885
5905
5925
5945


Band F
5740
5760
5780
5800
5820
5840
5860
5880


Band R
5658
5695
5732
5769
5806
5843
5880
5917






Foxeer Reaper Nano 5.8G 40CH 350mW 1g Tramp VTx Name Reaper Nano Input Voltage 5V Output Voltage 5V Channels 40CH Power 25mW/100mW/200mW/350mW Weight &lt;1g Size 12*16mm Consumption 340mA @ 350mW Band CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 Band A 5865 5845 5825 5805 5785 5765 5745 5725 Band B 5733 5752 5771 5790 5809 5828 584

Foxeer Reaper Nano Video Transmitter
At less than 1 gram in weight, the Reaper Nano is one of the smallest video transmitters around while still outputting 350mW of power!
Specifications

 	Weight: &amplt1 gram
 	Dimensions: 12x16mm
 	Power Levels: 25, 100, 200, 350 mW
 	Smart Audio Protocol: Tramp
 	Input Voltage: 5V
 	Power Consumption: 340mA at 350mW

Package Includes

 	1x Reaper Nano Video Transmitter

Downloads


 	Manual
 	Frequency Table

Foxeer Reaper Nano 5.8G 350mW Video Transmitter | Five33

Foxeer Reaper Nano 5.8G 350mW Video Transmitter

FOXEER

The Foxeer Reaper Nano VTX is made for speed and performance. With its lightweight design and adjustable 25-350mW power output, you can race with confidence. Get ready to take flight.
Check out all our Micro/Nano VTXs as well as the rest of our Foxeer Collection!

Features


&lt1g
12x16mm
350mW
Tramp


Specifications

Input Voltage: 5V DC
Output Voltage: 5V
Power: 25mW/100mW/200mW/350mW
Installation hole: No pins
Weight: &lt1g
Channels: 40CH
Consumption: 340mA @ 350mW

Includes

1x Foxeer Reaper Nano 25-350mW 5.8G Micro VTX - U.FL


The Foxeer Reaper Nano VTX is made for speed and performance. With its lightweight design and adjustable 25-350mW power output, you can race with confidence. Get ready to take flight. Check out all our Micro/Nano VTXs as well as the rest of our Foxeer Collection! Features &lt;1g 12x16mm 350mW Tramp Specifications Input

Foxeer Reaper Nano 25-350mW 5.8G Micro VTX - U.FL

This Foxeer Reaper Nano VTX was designed for serious racing where every gram and performance matters. Check out all our Analog Video Transmitters and the rest of our Foxeer Collection!   Specifications: Input Voltage: 5V DC Output Voltage: 5V Power: 25mW/100mW/200mW/350mW Installation hole: No pins Weight: &lt;1g Chann

Foxeer Reaper Nano 5.8G 350mW VTx

AKK AIO-SA Whoop/Micro AIO FPV Camera w/ 25-200mW VTX

Featuring a whoop camera with Smart Audio! Take your Whoop tech to the next level.
Check out all our Camera/VTX AIOs &amp Combos

 Features

Super light weight: 4.3g, all in one vtx + camera + antenna
One button frequency and power setup
Support 0.01mW parameter-adjusting mode
0.01/25mW/50mW/100mW/200mW power switchable
OSD configuration using FC Uart (F3/F4/F7 with OSD)

Notice: 5645,5925,5945(E4,E7,E8) channels are not available due to FCC regulation.

Specifications

Input voltage: 3.2-5.5V
Weight: 4.3g(exclude antenna)
Frequency: 5.8GHz 5 bands 40 channels

Includes

1x AKK AIO-SA Whoop/Micro AIO FPV Camera &amp 25-200mW VTX w/ Smart Audio




Featuring a whoop camera with Smart Audio! Take your Whoop tech to the next level.Super light weight: 4.3g, all in one vtx + camera + antennaOne button...

AKK AIO-SA Whoop/Micro AIO FPV Camera & 25-200mW VTX w/ Smart Audio

AKK AIO-SA Whoop/Micro AIO FPV Camera for Sale - RaceDayQuads

Featuring a whoop camera with Smart Audio! Take your Whoop tech to the next level.
Check out all our Camera/VTX AIOs &ampamp Combos

 Features

Super light weight: 4.3g, all in one vtx + camera + antenna
One button frequency and power setup
Support 0.01mW parameter-adjusting mode
0.01/25mW/50mW/100mW/200mW power switchable
OSD configuration using FC Uart (F3/F4/F7 with OSD)

Notice: 5645,5925,5945(E4,E7,E8) channels are not available due to FCC regulation.

Specifications

Input voltage: 3.2-5.5V
Weight: 4.3g(exclude antenna)
Frequency: 5.8GHz 5 bands 40 channels

Includes

1x AKK AIO-SA Whoop/Micro AIO FPV Camera &ampamp 25-200mW VTX w/ Smart Audio




Featuring a whoop camera with Smart Audio! Take your Whoop tech to the next level. Check out all our Camera/VTX AIOs &amp; Combos  Features Super light weight: 4.3g, all in one vtx + camera + antenna One button frequency and power setup Support 0.01mW parameter-adjusting mode 0.01/25mW/50mW/100mW/200mW power switchable

AKK AIO-SA Whoop/Micro AIO FPV Camera & 25-200mW VTX w/ Smart Audio from WREKD Co.

iFlight

iFlight Succex Whoop 25/100/200mW Adjustable VTX

PRODUCT DESCRIPTION SucceX Whoop VTX  25/100/200mW Adjustable -Power: PIT/25/100/200mW -Antenna interface: IPEX (UFL) -Telemetry: IRC Tramp -Size: triangle 26mm*19mm -Mounting holes: none -Weight: 2g Package included: 1pc x SucceX Whoop VTX  25/100/200mW Adjustable NOTE: IT FITS FOR SucceX F4 Whoop Flight Controller 2-

SucceX Whoop VTX 25/100/200mW Adjustable

Antenna Connector

Antennas send signals to and from your VRX/VTX and RX/TX. Many video transmitters and radio receivers come with antennas. Ensure if you need them. Or choose upgrades to increase range and penetration. Select appropriate antennas based on connector, radio frequency, and polarization (if circularly polarized).

Antennas

The FPV camera captures the image you see through the goggles. An FPV camera may be included with the VTX, particularly with digital VTXs.
