NewBeeDrone x Team BlackSheep BeeBrain BLV4 AIO Flight Controller - 12A ESC, Crossfire Rx

The NewBeeDrone BeeBrain BLV4 F411 1-2S AIO Whoop/Toothpick Flight Controller provides optimal performance for pilots who want a compact build. This single board is equipped with a flight controller, 12A 32Bit 4in1 ESC, 5.8GHz VTX, and a TBS Crossfire receiver, all on a 29x29mm platform. Enjoy advanced features and excellent performance for your compact setup!
The new &quotSmart Max&quot technology uses the MCU to read the board temperature on the back of the VTEC chip and uses PID control to control the output power of the VTX amplifier. When the board temperature rises, the VTX power will be automatically reduced. When the temperature is low, the maximum output power can be up to 400mW. If
Check out all our Whoop/AIO Flight Controllers and the rest of our NewBeeDrone products.
Features

Built-In TBS Crossfire Nano Receiver
SmartMAX (SmartMax up to 400mw)
25x25 Mounting Pattern
5w/25w Switchable VTX
F411 Flight Controller
12A BLHeli_S ESC
1-2S Voltage
BMI270 Gyro

Specifications

MCU: STM32F411
GYRO：BMI270
VTX: Switchable output power from 5mw- 25mw(for Racing) - SmartMAX(SmartMax up to 400mw) with BeeTX 5.8Ghz Antenna
ESC: 12A BLHeliS Pre-Flash with Bluejay 0.18 target: S-H-40 48kHz
ESC Connector: JST-1.0 3Pin
OSD: NBD7456 Graphical OSD compatible with Betaflight OSD
Receiver: Crossfire Nano receiver with MINIMORTAL T ANTENNA
Flight Controller Weight: 6.5g(Include antennas and battery connector)
Flight Controller Size: Outer dimensions: 29x29x7.6mm
Flight Controller Holes: 25.5x25.5mm
Battery input: 1-2S (For 2S you will need to set throttle cap at less 50%)
Uart2: Crossfire Nano receiver
Power Connector: NBD-PH2.0 connector

Additional Information

UART2 TX and RX for onboard Crossfire (CRSF)

UART1 TX and RX free

VTX Adjustable power 5mW-25mW-SmartMAX. SmartMAX will automatically adjust the VTX power according to the board temperature. When the board temperature rises, the VTX power will be automatically reduced. When the temperature is low, the maximum output power can be up to 400mW.

Firmware

Download: BeeBrain BLV4 CRSF Betaflight 4.4 firmware


Includes

1x NewBeeDrone BeeBrain BLV4 F411 1-2S AIO Whoop/Toothpick Flight Controller w/ 12A 8Bit 4in1 ESC &ampamp 400mW VTX - CRSF
4x Grommet
4x Screw

1x Receiver T-Antennas


1x Receiver Mono Pole Antenna


1x VTX Antenna


Wiring Diagram


The NewBeeDrone BeeBrain BLV4 F411 1-2S AIO Whoop/Toothpick Flight Controller provides optimal performance for pilots who want a compact build. This single board is equipped with a flight controller, 12A 32Bit 4in1 ESC, 5.8GHz VTX, and a TBS Crossfire receiver, all on a 29x29mm platform. Enjoy advanced features and exc

NewBeeDrone BeeBrain BLV4 F411 1-2S AIO Whoop/Toothpick Flight Controller w/ 12A 8Bit 4in1 ESC & 400mW VTX - CRSF from WREKD Co.

NewBeeDrone BeeBrain BLV4 F411 1-2S AIO Whoop/Toothpick Flight Controller w/ 12A 8Bit 4in1 ESC & 400mW VTX - CRSF

NewBeeDrone x Team BlackSheep BeeBrain BLV4 Built in Crossfire Rx
Warning:

We would like to remind you that our flight controller product is designed to work with our own product line. While we have taken every possible measure to ensure the quality and compatibility of our product line, using third party components may result in incompatibility or improper functioning of the product. such as Camere with different voltage signal will mass up the OSD function, frame from other company that is not fitting well with our FC, Motor plug are not compatible with the JST1.0 on the FC. etc.
We strongly recommend that you verify the compatibility and functioning before any soldering or modification.

Please be aware, drone flight controller will break due to crash, any physical damage or crash will have posibility to destory the hardware. This is also not cover by our warranty.  If you find that the product is Dead On Arrival (DOA), we will replace it for you free of charge.
However, we cannot take responsibility for any issues that may arise due to modifications made to the product or the use 3rd party components. In such cases, we will not be able to provide support or warranty coverage.

Thank you for your understanding and for choosing our product. If you have any questions or concerns, please don't hesitate to contact our customer support team.
This product is designed mainly to be a replacement part for the NewBeeDrone x Team BlackSheep AcroBee65 BLV4 Crossfire.

BeeBrain BLV4 CRSF Spec:
MCU: STM32F411GYRO：BMI270VTX: Switchable output power from 5mw- 25mw(for Racing) - SmartMAX(SmartMax up to 400mw)  with BeeTX 5.8Ghz AntennaESC: 12A BLHeliS Pre-Flash with Bluejay 0.18 target: S-H-40 48kHzESC Connector: JST-1.0 3PinOSD: NBD7456 Graphical OSD compatible with Betaflight OSDReceiver: Crossfire Nano receiver with MINIMORTAL T ANTENNAFlight Controller Weight: 6.5g(Include antennas and battery connector)Flight Controller Size: Outer dimensions: 29x29x7.6mmFlight Controller Holes: 25.5x25.5mmBattery input: 1SUart2: Crossfire Nano receiver
Power Connector: NBD-PH2.0 connector
Includes


1 x BeeBrain BLV4 CRSF Flight Controller
4 x Grommet
4 x Screw

1 x MINIMORTAL T Antenna
1 x VTX Antenna




Firmware: 1. BeeBrain BLV4 CRSF Betaflight 4.4  firmware
All New firmware can be found on our Github Page

All firmware can be found on our Github PageWire Diagram:


NewBeeDrone x Team BlackSheep BeeBrain BLV4 Built in Crossfire Rx Warning: We would like to remind you that our flight controller product is designed to work with our own product line. While we have taken every possible measure to ensure the quality and compatibility of our product line, using third party components ma

NewBeeDrone x Team BlackSheep BeeBrain BLV4 Built-in Crossfire Rx AIO Flight Controller

NewBeeDrone x Team BlackSheep BeeBrain BLV4 Built-in Crossfire Rx AIO

NewBeeDrone x Team BlackSheep BeeBrain BLV4 Built in Crossfire Rx
Warning:

We would like to remind you that our flight controller product is designed to work with our own product line. While we have taken every possible measure to ensure the quality and compatibility of our product line, using third party components may result in incompatibility or improper functioning of the product. such as Camere with different voltage signal will mass up the OSD function, frame from other company that is not fitting well with our FC, Motor plug are not compatible with the JST1.0 on the FC. etc.
We strongly recommend that you verify the compatibility and functioning before any soldering or modification.

Please be aware, drone flight controller will break due to crash, any physical damage or crash will have posibility to destory the hardware. This is also not cover by our warranty.  If you find that the product is Dead On Arrival (DOA), we will replace it for you free of charge.
However, we cannot take responsibility for any issues that may arise due to modifications made to the product or the use 3rd party components. In such cases, we will not be able to provide support or warranty coverage.

Thank you for your understanding and for choosing our product. If you have any questions or concerns, please don&#39t hesitate to contact our customer support team.
This product is designed mainly to be a replacement part for the NewBeeDrone x Team BlackSheep AcroBee65 BLV4 Crossfire.

BeeBrain BLV4 CRSF Spec:
MCU: STM32F411GYRO：BMI270VTX: Switchable output power from 5mw- 25mw(for Racing) - SmartMAX(SmartMax up to 400mw)  with BeeTX 5.8Ghz AntennaESC: 12A BLHeliS Pre-Flash with Bluejay 0.18 target: S-H-40 48kHzESC Connector: JST-1.0 3PinOSD: NBD7456 Graphical OSD compatible with Betaflight OSDReceiver: Crossfire Nano receiver with MINIMORTAL T ANTENNAFlight Controller Weight: 6.5g(Include antennas and battery connector)Flight Controller Size: Outer dimensions: 29x29x7.6mmFlight Controller Holes: 25.5x25.5mmBattery input: 1SUart2: Crossfire Nano receiver
Power Connector: NBD-PH2.0 connector
Includes


1 x BeeBrain BLV4 CRSF Flight Controller
4 x Grommet
4 x Screw

1 x MINIMORTAL T Antenna
1 x VTX Antenna




Firmware: 1. BeeBrain BLV4 CRSF Betaflight 4.4  firmware
All New firmware can be found on our Github Page

All firmware can be found on our Github PageWire Diagram:


NewBeeDrone x Team BlackSheep BeeBrain BLV4 Built-in Crossfire Rx AIO Flight Controller from WREKD Co.

NEWBEEDRONE

The NewBeeDrone BeeBrain BLV4 F411 1-2S AIO Whoop/Toothpick Flight Controller provides optimal performance for pilots who want a compact build. This single board is equipped with a flight controller, 12A 32Bit 4in1 ESC, 5.8GHz VTX, and a TBS Crossfire receiver, all on a 29x29mm platform. Enjoy advanced features and excellent performance for your compact setup!
The new "Smart Max" technology uses the MCU to read the board temperature on the back of the VTEC chip and uses PID control to control the output power of the VTX amplifier. When the board temperature rises, the VTX power will be automatically reduced. When the temperature is low, the maximum output power can be up to 400mW. If
Check out all our Whoop/AIO Flight Controllers and the rest of our NewBeeDrone products.
Features

Built-In TBS Crossfire Nano Receiver
SmartMAX (SmartMax up to 400mw)
25x25 Mounting Pattern
5w/25w Switchable VTX
F411 Flight Controller
12A BLHeli_S ESC
1-2S Voltage
BMI270 Gyro

Specifications

MCU: STM32F411
GYRO：BMI270
VTX: Switchable output power from 5mw- 25mw(for Racing) - SmartMAX(SmartMax up to 400mw) with BeeTX 5.8Ghz Antenna
ESC: 12A BLHeliS Pre-Flash with Bluejay 0.18 target: S-H-40 48kHz
ESC Connector: JST-1.0 3Pin
OSD: NBD7456 Graphical OSD compatible with Betaflight OSD
Receiver: Crossfire Nano receiver with MINIMORTAL T ANTENNA
Flight Controller Weight: 6.5g(Include antennas and battery connector)
Flight Controller Size: Outer dimensions: 29x29x7.6mm
Flight Controller Holes: 25.5x25.5mm
Battery input: 1-2S (For 2S you will need to set throttle cap at less 50%)
Uart2: Crossfire Nano receiver
Power Connector: NBD-PH2.0 connector

Additional Information

UART2 TX and RX for onboard Crossfire (CRSF)

UART1 TX and RX free

VTX Adjustable power 5mW-25mW-SmartMAX. SmartMAX will automatically adjust the VTX power according to the board temperature. When the board temperature rises, the VTX power will be automatically reduced. When the temperature is low, the maximum output power can be up to 400mW.

Firmware

Download: BeeBrain BLV4 CRSF Betaflight 4.4 firmware


Includes

1x NewBeeDrone BeeBrain BLV4 F411 1-2S AIO Whoop/Toothpick Flight Controller w/ 12A 8Bit 4in1 ESC &amp 400mW VTX - CRSF
4x Grommet
4x Screw

1x Receiver T-Antennas


1x Receiver Mono Pole Antenna


1x VTX Antenna


Wiring Diagram


NewBeeDrone BeeBrain BLV4 F411 1-2S AIO Whoop/Toothpick Flight Control

The BeeBrain BLV4 AIO Flight Controller integrates an F411 flight controller, a 12AMP 4-In-1 BLHeli_S ESC, a 5.8GHz VTX, and a TBS Crossfire receiver onto a compact 29x29mm platform.

NewBeeDrone BeeBrain BLV4 AIO - F411 FC + 12A 1-2S BLHeli_S ESC + Built-In TBS Crossfire

Processor (MCU)

The FC is the brain or the CPU of your quad. It has a processor and other components that allow it to listen to your inputs and tells the quad what to do. FCs are commonly sold together with other components integrated or stacked (like ESCs and video transmitters). For beginners, choose a FC with a F4 or F7 processor that has a compatible mount with your frame.

Flight Controllers

FC Stack Mount

Built-in VTX

Built-in ESC

Happymodel

Happymodel DiamondF4 1S AIO Whoop Flight Controller - F4 FC, 5A ESC, 25-200mW VTX

Happymodel DiamondF4 AIO 5-IN-1 Flight controller built-in VTX ESC OSD Receiver with Frsky Receiver For Moblite 6/7 Check out all our Flight Controllers! Specification: Flight controller: (Frsky SPI RX version) DiamondF4 FR FC Firmware target: CrazybeeF4FR MCU:STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000(SPI con

Happymodel DiamondF4 AIO 5-IN-1 Flight controller built-in VTX ESC OSD Receiver with Frsky Receiver For Moblite 6/7

The Happymodel Diamond F4 AIO 5-IN-1 Flight Controller has a built-in VTX, ESC, OSD, and receiver - all on one triangle-shaped whoop board!

Happymodel Diamond F4 ELRS 5-in-1 AIO Flight Controller - SPI ELRS 2.4GHz

Happymodel X12 5in1 AIO Flight Controller - F4 FC, 12A ESC, 400mW VTX, RX

The Happymodel X12&nbspis a&nbsp5-in-1&nbspAIO board featuring an F4 Flight Controller, onbard 12A 4-in-1 ESC, 5.8GHz OpenVTX, and three different receiver options:&nbspPNP, FrSky, or ELRS. This AIO is great for brushless whoops with its great RX an VTX range!

The Happymodel X12 is a 5-in-1 AIO board featuring an F4 Flight Controller, onbard 12A 4-in-1 ESC, 5.8GHz OpenVTX, and three different receiver options: PNP, FrSky, or ELRS. This AIO is great for brushless whoops with its great RX

Happymodel X12 AIO 5-in-1 Board - F4 FC + 12A ESC

The HappyModel X12 2S AIO Whoop Flight Controller (F4 FC / 12A 4in1 ESC / 25-400mW VTX) AIO board featuring an F4 Flight Controller, onboard 12A 4-in-1 ESC, 5.8GHz OpenVTX and built-in receiver of your choice! Happymodel continues to impress with yet another fantastic AIO for whoop applications!
Browse the rest of our Whoop AIO boards and all our Happymodel products!
Specifications

Input Voltage: 1-2S
MCU: STM32F411CEU6 (100MHZ, 512K FLASH)
Gyro: MPU6000 or ICM20689 or BMI270
Max Continuous Current: 12A
VTX Output Power: 25-400mW
Antenna Connector: U.FL
OSD: Yes
Betaflight Target: ELRS Version: CRAZYBEEF4SX1280, PNP Version: CRAZYBEEF4DX
ESC Firmware: Z_H_30_REV16_7
Mounting Pattern: 25x25mm
Weight: 5.1g

ELRS Version

Packet Rate: 50Hz/150Hz/250Hz/500Hz
ELRS Firmware Version: V2.0
RF Frequency: 2.4GHz
Antenna: SMD antenna
Telemetry output Power: &amplt12dBm

Includes

1x HappyModel X12 2S AIO Whoop Flight Controller (F4 FC / 12A 4in1 ESC / 25-400mW VTX)
1x Connecting Wires Set
1x Hardware Set
1x Antenna



The HappyModel X12 2S AIO Whoop Flight Controller (F4 FC / 12A 4in1 ESC / 25-400mW VTX) AIO board featuring an F4 Flight Controller, onboard 12A 4-in-1 ESC, 5.8GHz OpenVTX and built-in receiver of your choice! Happymodel continues to impress with yet another fantastic AIO for whoop applications! Browse the rest of our

HappyModel X12 2S AIO Whoop Flight Controller (F4 FC / 12A 4in1 ESC / 25-400mW VTX) - Choose Version from WREKD Co.

HappyModel X12 2S AIO Whoop Flight Controller (F4 FC / 12A 4in1 ESC / 25-400mW VTX) - Choose Version

HAPPYMODEL

The HappyModel X12 2S AIO Whoop Flight Controller (F4 FC / 12A 4in1 ESC / 25-400mW VTX) AIO board featuring an F4 Flight Controller, onboard 12A 4-in-1 ESC, 5.8GHz OpenVTX and built-in receiver of your choice! Happymodel continues to impress with yet another fantastic AIO for whoop applications!
Browse the rest of our Whoop AIO boards and all our Happymodel products!
Specifications

Input Voltage: 1-2S
MCU: STM32F411CEU6 (100MHZ, 512K FLASH)
Gyro: MPU6000 or ICM20689 or BMI270
Max Continuous Current: 12A
VTX Output Power: 25-400mW
Antenna Connector: U.FL
OSD: Yes
Betaflight Target: ELRS Version: CRAZYBEEF4SX1280, PNP Version: CRAZYBEEF4DX
ESC Firmware: Z_H_30_REV16_7
Mounting Pattern: 25x25mm
Weight: 5.1g

ELRS Version

Packet Rate: 50Hz/150Hz/250Hz/500Hz
ELRS Firmware Version: V2.0
RF Frequency: 2.4GHz
Antenna: SMD antenna
Telemetry output Power: &lt12dBm

Includes

1x HappyModel X12 2S AIO Whoop Flight Controller (F4 FC / 12A 4in1 ESC / 25-400mW VTX)
1x Connecting Wires Set
1x Hardware Set
1x Antenna



Increase your range with the impressive HappyModel X12 2S AIO Whoop Flight Controller. Optimize your flight today!

HappyModel X12 2S AIO Whoop Flight Controller (F4 FC / 12A 4in1 ESC / 25-400mW VTX) - For Sale

Happymodel Crazybee F4 Lite 1S Whoop Flight Controller for Mobula 6

Replacement flight controller for the popular Happymodel Mobula 6 or any 1S build Checkout our Mobula 6 parts and our full collection of Happymodel Products! Specifications Flight Controller (Frsky SPI RX version) CRAZYBEE F4 Lite Frsky version Firmware target: CrazybeeF4FR (Flysky SPI RX version) CRAZYBEE F4 Lite Flys

HappyModel Crazybee F4 Lite 1S Whoop Flight Controller for Mobula 6 - Frsky

The Happymodel CrazyBee F4 Lite Flight Controller brings lots of power in a small package. This 4-in-1 FC comes with an integrated receiver (FrSky), ESC, and an onboard 5.8GHz VTX!

Happymodel Crazybee F4 Lite 1S Whoop Flight Controller - Frsky

The Happymodel CrazyBee F4 Lite Flight Controller brings lots of power in a small package. This 4-in-1 FC comes with an integrated receiver (Flysky), ESC, and an onboard 5.8GHz VTX!

Happymodel Crazybee F4 Lite 1S Whoop Flight Controller - Flysky

EMAX

EMAX Mini Magnum 2 Flight Controller Stack - F4 32Bit 35A 2-6S VTX Stack

Emax USA

UPDATE: New batch has additional Uart pads for different setups of receiver or third party applications that require additional Uart.
Stack Height, from lowest componant on ESC board to highest point on VTX board: 22mm
UPC Code: 723668085485
OmnibusF4 Target



INSTRUCTION MANUAL







UPDATE: New batch has additional Uart pads for different setups of receiver or third party applications that require additional Uart. Stack Height, from lowest componant on ESC board to highest point on VTX board: 22mm UPC Code: 723668085485 OmnibusF4 Target INSTRUCTION MANUAL

Mini Magnum 2.5 - F4 BLHELI32 35amp 6S MMCX from WREKD Co.

Mini Magnum 2.5 - F4 BLHELI32 35amp 6S MMCX

Introducing the next generation of the famed Magnum line, the Mini Magnum 2.

Emax Mini Magnum 2 - F4 BLHeli32 35A 2-6s VTX Stack

Mini Magnum 2 - F4 BLHELI32 35amp 6S MMCX Version

Mini Magnum 2 - F4 BLHELI32 35amp 6S MMCX Version - 20x20mm

CLRacing

CLRacing F4S V1.6 AIO 30x30 Flight Controller

This board is designed to fully embrace all the features of Betaflight. In fact, this design is ahead of Betaflight, in this case, because it is designed to be fully functional when Betaflight 3.2 will be released. Everything works, except the buzzer, which will work when betaflight 3.2 is ready. It's a programmable mi

CL Racing F4S Flight Controller PDB OSD AIO V1.6 - 30x30mm

CLRACING

The latest version of the CLF4S is here!
Version 1.6 will have voltage scale change from 110 to 160 in the battery tab, and user selectable BEC is now 7.2V or 5V.
V1.5 added some small changes to improve how the board handled larger motors. The F4S version, this CLF4 FC is packed full of the latest features and technology in the industry, like camera control. Loved because of its dependability and affordability, the CL Racing F4S is a fan favorite!
Check out all our 30x30 Flight Controllers!
Features

Build in 5V BEC 2A
Build-in User selectable 7.2V or 5v 2A Filtered BEC For camera and VTX
Dedicated hardware inverted connect to  UART3 for smartport telemetry
6 layer 2oz Copper PCB
Dedicated Camera setting control pads along with camera power signal pads
4 in 1 esc socket with external current sensor input
Added TX1 and TX6 pads
Support External Current sensor from 4 in 1 ESC.

Specifications

LiPo Input: 2-6S (5V-30V)
Power rail: 3.3v,5v,9v,vbat
132A ( MAX display ) Current sensor with 160A PDB build in
6 layer 2oz Copper PCB
Size: 36x36mm
Mount Holes: 30.5 x 30.5 mm
CPU - STM32F405RGT6 (F4 chip)
MPU-6000
Full SD Card socket
Built-in 5V BEC 2A
Built-in User selectable 7.2V or 5V 2A Filtered BEC For camera and VTX
Dedicated Camera setting control pads along with camera power signal pads
Dedicated VTX connection with along with TX4 for easy connect and control VTX
Built-in Betaflight OSD
4 UARTS + USB (UART1 , UART3 ,UART4, UART6 ) (Pinout TX1, TX4,RX4, TX6,RX6 )
5V LED strip output
4 motors on each corner for a better layout.
Support RX : Dedicated Sbus hardware inverted, Satellite RX, Ibus, TBS Crossfire
Dedicated hardware inverted connect to  UART3 for smartport telemetry
4 in 1 esc socket with external current sensor input
Support TP and Smartaudio VTX
Buzzer pads for external buzzer

Includes

1x CLRacing F4S V1.6 Flight Controller
1x 4in1 ESC Cable
6x Anti Vibration Soft Mounts

Build Tips

1. Solder the main battery lead to the board first.
2.check on the bottom label  :UART 1- &gtsBus. UART 3 -&gt telemetry
3. use TX4 for the smart audio if you use it.
4.if you solder on the buzzer, go to CLI paste " set beeper_frequency = 0" enter and "save"

5. For use telemetry. select the uart3 as smart port. and go to CLI do " set tlm_halfduplex = off " you have to use this command to make it work.
6. for use 4 IN 1 esc. you can use the cable comes with the FC. but you may have to shift the pin around to get the correct motor layout. if you esc has the current sensor, you can use the solder pads label as (EXT) for the external Current sensor ( INT ) for internal current sensor
7.after soldering everything on the board. check continuity on all 4 motor signal wire to battery positive and battery negative. very important. if those have continuity. you will have a big problem. smoke stopper won't stop this.





The latest CLRacing F4S "S" AIO Flight Controller brings the features you expect from an AIO FC at a great price! Get affordable, easy to use performance today!

CLRacing F4S "S" AIO Flight Controller for Sale - RaceDayQuads

CL_Racing

This board is designed to fully embrace all the features of Betaflight. In fact, this design is ahead of Betaflight, in this case, because it is designed to be fully functional with Betaflight 3.2. Version 1.5.

CL Racing F4S Flight Controller PDB OSD AIO

CL Racing

The latest version of the CLF4S is here!
Version 1.6 will have voltage scale change from 110 to 160 in the battery tab, and user selectable BEC is now 7.2V or 5V.
V1.5 added some small changes to improve how the board handled larger motors. The F4S version, this CLF4 FC is packed full of the latest features and technology in the industry, like camera control. Loved because of its dependability and affordability, the CL Racing F4S is a fan favorite!
Check out all our 30x30 Flight Controllers!
Features

Build in 5V BEC 2A
Build-in User selectable 7.2V or 5v 2A Filtered BEC For camera and VTX
Dedicated hardware inverted connect to  UART3 for smartport telemetry
6 layer 2oz Copper PCB
Dedicated Camera setting control pads along with camera power signal pads
4 in 1 esc socket with external current sensor input
Added TX1 and TX6 pads
Support External Current sensor from 4 in 1 ESC.

Specifications

LiPo Input: 2-6S (5V-30V)
Power rail: 3.3v,5v,9v,vbat
132A ( MAX display ) Current sensor with 160A PDB build in
6 layer 2oz Copper PCB
Size: 36x36mm
Mount Holes: 30.5 x 30.5 mm
CPU - STM32F405RGT6 (F4 chip)
MPU-6000
Full SD Card socket
Built-in 5V BEC 2A
Built-in User selectable 7.2V or 5V 2A Filtered BEC For camera and VTX
Dedicated Camera setting control pads along with camera power signal pads
Dedicated VTX connection with along with TX4 for easy connect and control VTX
Built-in Betaflight OSD
4 UARTS + USB (UART1 , UART3 ,UART4, UART6 ) (Pinout TX1, TX4,RX4, TX6,RX6 )
5V LED strip output
4 motors on each corner for a better layout.
Support RX : Dedicated Sbus hardware inverted, Satellite RX, Ibus, TBS Crossfire
Dedicated hardware inverted connect to  UART3 for smartport telemetry
4 in 1 esc socket with external current sensor input
Support TP and Smartaudio VTX
Buzzer pads for external buzzer

Includes

1x CLRacing F4S V1.6 Flight Controller
1x 4in1 ESC Cable
6x Anti Vibration Soft Mounts

Build Tips

1. Solder the main battery lead to the board first.
2.check on the bottom label  :UART 1- &ampgtsBus. UART 3 -&ampgt telemetry
3. use TX4 for the smart audio if you use it.
4.if you solder on the buzzer, go to CLI paste &quot set beeper_frequency = 0&quot enter and &quotsave&quot

5. For use telemetry. select the uart3 as smart port. and go to CLI do &quot set tlm_halfduplex = off &quot you have to use this command to make it work.
6. for use 4 IN 1 esc. you can use the cable comes with the FC. but you may have to shift the pin around to get the correct motor layout. if you esc has the current sensor, you can use the solder pads label as (EXT) for the external Current sensor ( INT ) for internal current sensor
7.after soldering everything on the board. check continuity on all 4 motor signal wire to battery positive and battery negative. very important. if those have continuity. you will have a big problem. smoke stopper won&#39t stop this.





The latest version of the CLF4S is here! Version 1.6 will have voltage scale change from 110 to 160 in the battery tab, and user selectable BEC is now 7.2V or 5V. V1.5 added some small changes to improve how the board handled larger motors. The F4S version, this CLF4 FC is packed full of the latest features and technol

CLRacing F4S V1.6 AIO 30x30 Flight Controller from WREKD Co.

NewBeeDrone x ImmersionRC BeeBrain BLV4 AIO Flight Controller - Ghost Rx


NewBeeDrone x ImmersionRC BeeBrain BLV4 Built in Ghost Rx

Warning! The BeeBrainBLV4 OSD might not compatible with third party camera. If you are planning to use it for customized build, Please be aware it only support the camera below:
NewBeeDrone BeeEye CameraRuncam Nano4
BeeBrain BLV4 GHOST Spec:MCU: STM32F411GYRO：BMI270VTX: Switchable output power from 5mw- 25mw(for Racing) - SmartMAX(SmartMax up to 400mw)  with BeeTX 5.8Ghz AntennaESC: 12A BLHeliS Pre-Flash with Bluejay 0.18 target: S-H-40 48kHzESC Connector: JST-1.0 3PinOSD: NBD7456 Graphical OSD compatible with Betaflight OSDReceiver: GHOST 2.4G receiver with GHOST 2.4G qT AntennaFlight Controller Weight: 6.5g(Include antennas and battery connector)Flight Controller Size: Outer dimensions: 29x29x7.6mmFlight Controller Holes: 25.5x25.5mmBattery input: 1SUart2: Tx for GHOST 2.4G ReceiverUart1:  Tx&ampampRx freePower Connector:

NBD-PH2.0 connector

Includes

1 x BeeBrain BLV4 GHOST Flight Controller
4 x Grommet
4 x Screw
1 x qT Antenna

1 x VTX Antenna



Firmware: 1. BeeBrain BLV4 GHOST Betaflight 4.4  firmware
All New firmware can be found on our Github Page

Terms and Condition:
We would like to remind you that our flight controller product is designed to work with our own product line. While we have taken every possible measure to ensure the quality and compatibility of our product line, using third party components may result in incompatibility or improper functioning of the product. such as Camere with different voltage signal will mass up the OSD function, frame from other company that is not fitting well with our FC, Motor plug are not compatible with the JST1.0 on the FC. etc.
We strongly recommend that you verify the compatibility and functioning before any soldering or modification.
Please be aware, drone flight controller will break due to crash, any physical damage or crash will have posibility to destory the hardware. This is also not cover by our warranty.  If you find that the product is Dead On Arrival (DOA), we will replace it for you free of charge.
However, we cannot take responsibility for any issues that may arise due to modifications made to the product or the use 3rd party components. In such cases, we will not be able to provide support or warranty coverage.
Wire Diagram:

NewBeeDrone x ImmersionRC BeeBrain BLV4 Built in Ghost Rx Warning! The BeeBrainBLV4 OSD might not compatible with third party camera. If you are planning to use it for customized build, Please be aware it only support the camera below:  NewBeeDrone BeeEye CameraRuncam Nano4  BeeBrain BLV4 GHOST Spec:MCU: STM32F411GYRO：

NewBeeDrone x ImmersionRC BeeBrain BLV4 Built-in Ghost Rx AIO Flight Controller from WREKD Co.

NewBeeDrone x ImmersionRC BeeBrain BLV4 Built-in Ghost Rx AIO Flight Controller


NewBeeDrone x ImmersionRC BeeBrain BLV4 Built in Ghost Rx

Warning! The BeeBrainBLV4 OSD might not compatible with third party camera. If you are planning to use it for customized build, Please be aware it only support the camera below:
NewBeeDrone BeeEye CameraRuncam Nano4
BeeBrain BLV4 GHOST Spec:MCU: STM32F411GYRO：BMI270VTX: Switchable output power from 5mw- 25mw(for Racing) - SmartMAX(SmartMax up to 400mw)  with BeeTX 5.8Ghz AntennaESC: 12A BLHeliS Pre-Flash with Bluejay 0.18 target: S-H-40 48kHzESC Connector: JST-1.0 3PinOSD: NBD7456 Graphical OSD compatible with Betaflight OSDReceiver: GHOST 2.4G receiver with GHOST 2.4G qT AntennaFlight Controller Weight: 6.5g(Include antennas and battery connector)Flight Controller Size: Outer dimensions: 29x29x7.6mmFlight Controller Holes: 25.5x25.5mmBattery input: 1SUart2: Tx for GHOST 2.4G ReceiverUart1:  Tx&ampRx freePower Connector:

NBD-PH2.0 connector

Includes

1 x BeeBrain BLV4 GHOST Flight Controller
4 x Grommet
4 x Screw

1 x qT Antenna
1 x VTX Antenna



Firmware: 1. BeeBrain BLV4 GHOST Betaflight 4.4  firmware
All New firmware can be found on our Github Page

Terms and Condition:
We would like to remind you that our flight controller product is designed to work with our own product line. While we have taken every possible measure to ensure the quality and compatibility of our product line, using third party components may result in incompatibility or improper functioning of the product. such as Camere with different voltage signal will mass up the OSD function, frame from other company that is not fitting well with our FC, Motor plug are not compatible with the JST1.0 on the FC. etc.
We strongly recommend that you verify the compatibility and functioning before any soldering or modification.
Please be aware, drone flight controller will break due to crash, any physical damage or crash will have posibility to destory the hardware. This is also not cover by our warranty.  If you find that the product is Dead On Arrival (DOA), we will replace it for you free of charge.
However, we cannot take responsibility for any issues that may arise due to modifications made to the product or the use 3rd party components. In such cases, we will not be able to provide support or warranty coverage.
Wire Diagram:

NewBeeDrone x ImmersionRC BeeBrain BLV4 Built-in Ghost Rx AIO Flight C

Flywoo

Flywoo GOKU Versatile F411 V2 1S AIO Whoop/Toothpick Flight Controller - 5A 8Bit 4in1 ESC, 250mW VTX

GOKU Versatile F411 1S 5A AIO V2.0 is another versatile and highly integrated circuit board in the GOKU Versatile series!1S 5A ESC， OSD, 3 serial ports， I2C functionality and 2XWS2812 LEDs . Reasonable layout makes it easier for you to build .You only need to choose the motor, frame, camera, propeller ， everything else

GOKU Versatile F411 1S 5A AIO V2.0 , 25.5X25.5

FLYWOO

Check out the GOKU Versatile F411 1S 5A AIO V2.0 for a versatile and highly integrated circuit board. Built-in ELRS 2.4g RX , 1S 5A ESC, OSD, 3 serial ports, I2C functionality  and 2XWS2812 LEDs.  This 25.5x25.5mm board comes with a reasonable layout making it easier for you to build. You only need to choose the motor, frame, camera, propeller for your build. Where as everything else you need is all packed into this compact whoop board.
Features

Built-in ELRS 2.4g RX (UART2) , 1S, 5A ESC, OSD

Opened 3 serial ports and 12C functionality
Mounting Pattern: 25x25mm, M2
Ultra light weight 3.7g

Built-in 2XWS2812 LEDs
Reasonable layout, easy to build
Can work with different RX at the same time

Specifications
Flywoo Versatile F411 1S V2 AIO Whoop/Toothpick Flight Controller

Size: 25.5x25.5mm
Mounting: 25x25mm (M2)

Weight: 3.7g
MCU: STM32F411CEU6

UARTS: 1/2
Soft serial port：1
MOTOR: M1-M4 OUTPUT
I2C: SCL/SDA
GYRO: ICM42688
LED: 2xWS2812

BEC: 5V

Firmware Target: FLYWOOF411_5IN1_AIO
Onboard 4in1 ESC

Onboard 4in1 ESC

Built-in 1S LiPo/LiPo HVCurrent: 5A
MCU: EFM8BB21
Supports Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600
Input Voltage: 1S Lipo
Firmware: BLHELI_S
Firmware Target: O_H_5_REV16_8.HEX

Default protocol: DSHOT 150/300/600
ELRS 2.4G RX (UART2)

Includes

1x Flywoo GOKU Versatile F411 1S V2 AIO Flight Controller w/ 5A 4in1 ESC
1x PH2.0 Connector
1x  Capacitor
1x Connecting Wire
1x Receiver Antenna


Check out the GOKU Versatile F411 1S 5A AIO V2.0 for a versatile and highly integrated circuit board. Built-in ELRS 2.4g RX , 1S 5A ESC, OSD, 3 serial ports, I2C functionality  and 2XWS2812 LEDs.  This 25.5x25.5mm board comes with a reasonable layout making it easier for you to build. You only need to choose the motor,

Flywoo GOKU Versatile F411 1S V2 AIO Whoop/Toothpick Flight Controller w/ 5A 4in1 ESC

Flywoo GOKU Versatile F411 1S V2 AIO Whoop/Toothpick Flight Controller

    GOKU Versatile F411 1S 5A AIO V2.0 is another versatile and highly integrated circuit board in the GOKU Versatile series!  Built-in 250mw VTX ，1S 5A ESC， OSD 3 serial ports， I2C functionality  and 2XWS2812 LEDs .   Reasonable layout makes it easier for you to build . You only need to choose the motor frame camera p

GOKU Versatile F411 VTX 1S 5A AIO V2.0 w/ 250mw vtx , 25.5X25.5

GOKU Versatile F411 VTX 1S 5A AIO V2.0  w/ 250mw vtx , 25.5X25.5

Flywoo GOKU Versatile F411 1S V2 AIO Whoop/Toothpick Flight Controller w/ 5A 4in1 ESC from WREKD Co.











The Flywoo GOKU Versatile F411 1S V2 AIO Whoop/Toothpick Flight Controller is a highly integrated circuit board that makes building your dream quadcopter easier than ever! It includes a 250mW VTX, 1S 5A ESC, OSD, 3 serial ports, I2C functionality, and 2XWS2812 LEDs – all in a compact whoop board. Get ready to fly! You only need to choose the motor, frame, camera, propeller, everything else all packed into a compact whoop board.
Check out all our Whoop/AIO Flight Controllers and our other great products from Flywoo!
Features

Built-in 250mw VTX, 1S 5A ESC, OSD .

Opened 3 serial ports and I2C functionality

Mounting Pattern: 25x25mm, M2

Ultra light weight 4g

Built-in 2XWS2812 LEDs

Reasonable layout, easy to build



SpecificationsFlight Controller


MCU: STM32F411CEU6
GYRO: ICM42688
UARTS: 1/2
Soft serial port：1
I2C: SCL/SDA
BEC: 5V
Input Voltage: 1S ( &amplt4.35v)
Firmware: FLYWOOF411_5IN1_AIO

Mounting:  25x25mm, M2

Onboard 4in1 ESC

MCU: EFM8BB21
Power supply: 1S LiPo/LiPo HVCurrent: 5A
Firmware: BLHeli_S
Factory firmware: O_H_5_REV16_8.HEX
Default protocol: DSHOT 150/300/600

Onboard 5.8g VTX

Output power: 25mw~250mw switchable
Frequency: 40CH
Frequency: 5.8GHz 5 bands 40 channels(include Race band) IRC ready

Includes

1x Flywoo GOKU Versatile F411 1S V2 AIO Whoop/Toothpick Flight Controller w/ 5A 4in1 ESC &ampamp 250mW VTX

Wiring Diagram












The Flywoo GOKU Versatile F411 1S V2 AIO Whoop/Toothpick Flight Controller is a highly integrated circuit board that makes building your dream quadcopter easier than ever! It includes a 250mW VTX, 1S 5A ESC, OSD, 3 serial ports, I2C functionality, and 2XWS2812 LEDs – all in a compact whoop board. Get ready to fly! You

Flywoo GOKU Versatile F411 1S V2 AIO Whoop/Toothpick Flight Controller w/ 5A 8Bit 4in1 ESC & 250mW VTX from WREKD Co.

Flywoo GOKU Versatile F411 1S V2 AIO Whoop/Toothpick Flight Controller w/ 5A 8Bit 4in1 ESC & 250mW VTX











The Flywoo GOKU Versatile F411 1S V2 AIO Whoop/Toothpick Flight Controller is a highly integrated circuit board that makes building your dream quadcopter easier than ever! It includes a 250mW VTX, 1S 5A ESC, OSD, 3 serial ports, I2C functionality, and 2XWS2812 LEDs – all in a compact whoop board. Get ready to fly! You only need to choose the motor, frame, camera, propeller, everything else all packed into a compact whoop board.
Check out all our Whoop/AIO Flight Controllers and our other great products from Flywoo!
Features

Built-in 250mw VTX, 1S 5A ESC, OSD .

Opened 3 serial ports and I2C functionality

Mounting Pattern: 25x25mm, M2

Ultra light weight 4g

Built-in 2XWS2812 LEDs

Reasonable layout, easy to build



SpecificationsFlight Controller


MCU: STM32F411CEU6
GYRO: ICM42688
UARTS: 1/2
Soft serial port：1
I2C: SCL/SDA
BEC: 5V
Input Voltage: 1S ( &lt4.35v)
Firmware: FLYWOOF411_5IN1_AIO

Mounting:  25x25mm, M2

Onboard 4in1 ESC

MCU: EFM8BB21
Power supply: 1S LiPo/LiPo HVCurrent: 5A
Firmware: BLHeli_S
Factory firmware: O_H_5_REV16_8.HEX
Default protocol: DSHOT 150/300/600

Onboard 5.8g VTX

Output power: 25mw~250mw switchable
Frequency: 40CH
Frequency: 5.8GHz 5 bands 40 channels(include Race band) IRC ready

Includes

1x Flywoo GOKU Versatile F411 1S V2 AIO Whoop/Toothpick Flight Controller w/ 5A 4in1 ESC &amp 250mW VTX

Wiring Diagram












EMAX Tinyhawk 3 1-2S F4 AIO Flight Controller 5A ESC 25/100/200mW VTX

Replacement AIO Flight Controller for the Tinyhawk 3.  Check out all Tinyhawk 3 Related Collection and the rest of our Emax Gear! Package Includes: 1 x Emax Tinyhawk 3 Spare Parts - 1-2S 5A F4 AIO Flight Controller ESC with 25/100/200mw VTX

Emax Tinyhawk 3 Spare Parts - 1-2S 5A F4 AIO Flight Controller ESC with 25/100/200mw VTX

Replacement all-in-one flight controller and ESC for the Tinyhawk 3. Standard 26x26 whoop mounting pattern for DIY builds.
Check out the rest of the Tinyhawk line and all our EMAX gear!
Includes

1x EMAX Tinyhawk III 1-2S F4 AIO Flight Controller 5A ESC 25/100/200mW VTX



Replacement all-in-one flight controller and ESC for the Tinyhawk 3. Standard 26x26 whoop mounting pattern for DIY builds. Check out the rest of the Tinyhawk line and all our EMAX gear! Includes 1x EMAX Tinyhawk III 1-2S F4 AIO Flight Controller 5A ESC 25/100/200mW VTX

EMAX TinyHawk II AIO Flight Controller ESC/VTX/RX

AIO FC/ESC/VTX F4 5A for the EMAX Tinyhawk II Race. View other Tinyhawk II Race products. View all our EMAX products.

EMAX Tinyhawk II Parts - All-In-One FC/ESC/VTX F4 5A 25/100/200mw

Emax

Spare replacement EMAX TinyHawk II AIO.Check out all our TinyHawk parts, and EMAX gear!
Includes


1x EMAX TinyHawk II AIO Flight Controller ESC/VTX/RX


Spare replacement EMAX TinyHawk II AIO.Check out all our TinyHawk parts, and EMAX gear! Includes 1x EMAX TinyHawk II AIO Flight Controller ESC/VTX/RX

EMAX TinyHawk II AIO Flight Controller ESC/VTX/RX from WREKD Co.

ESC Stack Mount

The ESC(s) controls your motors’ speed. It draws power from the battery to spin the motors based on what the FC tells it to do. Each motor needs an ESC. It’s common today to see 4-in-1 ESCs so you only need to buy a single part. For beginners, choose a 4-in-1 ESC that has a compatible mount with your frame and FC. The biggest consideration is amperage limit. We show you ESCs with appropriate amperage limits based on your frame size. You can calculate how much amperage you need based on your motor and prop choice.

ESCs

Frame Stack Mount

The frame is typically the first part to pick because it determines what kind of flying you’ll be doing the most. Start by picking a frame type, and narrow down the options by propeller size. The frame holds your quad parts together and heavily impacts what the quad can do.

Frames

The VTX processes the image from your FPV camera and sends it to your goggle’s video receiver (VRX). If you chose as digital video system, you need a VTX that matches the system. Most analog VTXs and VRXs are compatible with each other, and your biggest consideration will be how much output power you need. The more output power, the more range and better signal you’ll get. Learn more about VTXs.
