iFlight

iFlight BOB57 O3 6" Frame Kit

Introducing the iFlight BOB57 O3 Frame Kit, an innovative long-range HD drone conceptualized in a collaborative effort between iFlight and renowned pilot &amp videographer, Ellis van Jason.

Introducing the iFlight BOB57 O3 Frame Kit, an innovative long-range HD drone conceptualized in a collaborative effort between iFlight and renowned pilot & videographer, Ellis van Jason.

iFlight BOB57 O3 Ellis Van Jason Frame Kit

IFLIGHT

The iFlight BOB57 is a long-range HD drone that was designed in collaboration with pilot &amp videographer Ellis van Jason. The team crafted this cinematic 6-inch drone that ensures agility and flight time while combining the advantages of both 5-inch and 7-inch drones for both cinematic and freestyle flights.
Be sure to browse the rest of our iFlight products and DJI compatible frames, electronics and accessories.
Don't feel like building it but one one now!? We also carry the BNF!
Features

Hybrid motor design optimized for  that can be used with both bi-blade and tri-blade 6" propellers
Solid antenna mount for less ocillations when using long antennas

H-shaped frame with robust middle section for less props in view
Gladiator shell protects from dust and water droplets
Front-mounting XT-60
Compatible with DJI O3 Air Unit and Vista

Specifications

Product Name: BOB57 O3 Frame Kit
Frame wheelbase: 278mm
Frame Dimension: L165 x W225 x H34 mm
Weight: 305g
Frame Body Dimension: 34mm
Arm Thickness: 6mm
Bottom Plate Thickness: 1.5mm
Top Plate Thickness: 2mm
Upper Plate Thickness: 2.5mm
Motor Mounting: 16 x 16mm
VTX Mounting: 25.5 x 25.5/Φ1.6mm, 20 x 20/Φ2mm



Includes

1 x BOB57 O3 Frame Kit
1 x BOB57 TPU Parts
1 x 215mm MIPI Video Cable for DJI O3 Air Unit
4 x Motor Wire Shield Tube
1 x Battery Anti-Slip Pad
2 x Battery Strap
1 x Screw Bag


The iFlight BOB57 is a long-range HD drone that was designed in collaboration with pilot &amp; videographer Ellis van Jason. The team crafted this cinematic 6-inch drone that ensures agility and flight time while combining the advantages of both 5-inch and 7-inch drones for both cinematic and freestyle flights. Be sure

iFlight BOB57 O3 LR & Freestyle Cinematic 6" Frame Kit

Frame Size

The frame is typically the first part to pick because it determines what kind of flying you’ll be doing the most. Start by picking a frame type, and narrow down the options by propeller size. The frame holds your quad parts together and heavily impacts what the quad can do.

Frames

Frame Kit

Frame Stack Mount

FPV Camera Mount

Frame Type

Rekon FPV

Rekon FPV Rekon10 Pro Long Range 10" Frame Kit

The Rekon FPV Rekon10 Pro Long Range Frame Kit is a beast designed for the most challenging long-range missions!

Rekon FPV Rekon10 Pro Long Range Frame Kit  - 10"

Rekon FPV Rekon10 Pro Long Range Frame Kit  - 10&quot

NewBeeDrone

NewBeeDrone M-367 True-X 7" Frame

NewBeeDrone M-367 7inch True-X FPV Frame

Design Idea:



Simplicity in Construction: Designed for effortless assembly and minimal maintenance.

Versatile Hardware Mounting Solutions: Offers flexibility in mounting configurations, allowing for personalized setups tailored to your needs.

Strategic Tactic Mounting Points: Featuring mounting points on both top and bottom plates, enabling users to securely fasten any accessory using straps.

Innovative Motor Arm Protection: Inspired by the Air Max concept, our motor arm protectors are crafted with a lightweight, hollow design, using durable TPU material. This not only reduces weight but also offers enhanced protection for the arm edges and motor. The snap-on installation eliminates the need for screws, ensuring the motor remains firmly attached to the frame, optimizing system performance.


Spec:

FC Mount: 20X20, 25.5X25.5, 30.5X30.5 mm
VTX Mount: 20X20
Camera Mount: 19mm wide
Motor Mount:19x19 M3 screw mount


What's include: Carbon Fiber Parts:

Top plate 2mm x1

Mid plate 2.5mm x1
 Bottom plate 2.5m x1
Front arm 6mm x2
Rear arm 6mm x2

3D Printed Parts:

Motor arm protector TPU
TBS Crossfire nano receiver mount TPU
VTX Antenna Mount (two antenna) TPU
FPV Camera mount TPU

Hardware:

M3  High Tensile Carbon Steel 8mm x13
M3 High Tensile Carbon Steel 10mm x18
M3 High Tensile Carbon Steel 14mm x9
M3 High Tensile Carbon Steel 16mm x5
M3 High Tensile Carbon Steel 25mm x5
M3 Nylon Lock Nut x9
M3  7075 Aluminum Standoff 28mm x9

Accessory:

PU Battery mount sticker x1
Strap 20mm x 300mm x3
Nylon Zipties 3*100mm x5




NewBeeDrone M-367 7inch True-X FPV Frame   Design Idea:  Simplicity in Construction: Designed for effortless assembly and minimal maintenance. Versatile Hardware Mounting Solutions: Offers flexibility in mounting configurations, allowing for personalized setups tailored to your needs. Strategic Tactic Mounting Points:

NewBeeDrone M-367 7inch True-X FPV Frame

NewBeeDrone M-367 7inch True-X FPV Frame

Design Idea:



Simplicity in Construction: Designed for effortless assembly and minimal maintenance.

Versatile Hardware Mounting Solutions: Offers flexibility in mounting configurations, allowing for personalized setups tailored to your needs.

Strategic Tactic Mounting Points: Featuring mounting points on both top and bottom plates, enabling users to securely fasten any accessory using straps.

Innovative Motor Arm Protection: Inspired by the Air Max concept, our motor arm protectors are crafted with a lightweight, hollow design, using durable TPU material. This not only reduces weight but also offers enhanced protection for the arm edges and motor. The snap-on installation eliminates the need for screws, ensuring the motor remains firmly attached to the frame, optimizing system performance.


Spec:

FC Mount: 20X20, 25.5X25.5, 30.5X30.5 mm
VTX Mount: 20X20
Camera Mount: 19mm wide
Motor Mount:19x19 M3 screw mount


What&#39s include: Carbon Fiber Parts:

Top plate 2mm x1

Mid plate 2.5mm x1
 Bottom plate 2.5m x1
Front arm 6mm x2
Rear arm 6mm x2

3D Printed Parts:

Motor arm protector TPU
TBS Crossfire nano receiver mount TPU
VTX Antenna Mount (two antenna) TPU
FPV Camera mount TPU

Hardware:

M3  High Tensile Carbon Steel 8mm x13
M3 High Tensile Carbon Steel 10mm x18
M3 High Tensile Carbon Steel 14mm x9
M3 High Tensile Carbon Steel 16mm x5
M3 High Tensile Carbon Steel 25mm x5
M3 Nylon Lock Nut x9
M3  7075 Aluminum Standoff 28mm x9

Accessory:

PU Battery mount sticker x1
Strap 20mm x 300mm x3
Nylon Zipties 3*100mm x5




NewBeeDrone M-367 7inch True-X FPV Frame from WREKD Co.

NewBeeDrone M-323 DC 7" Frame

NewBeeDrone M-323 7inch DC (Dead Cat) FPV Frame
Design Idea:



Simplicity in Construction: Designed for effortless assembly and minimal maintenance.

Versatile Hardware Mounting Solutions: Offers flexibility in mounting configurations, allowing for personalized setups tailored to your needs.

Strategic Tactic Mounting Points: Featuring mounting points on both top and bottom plates, enabling users to securely fasten any accessory using straps.

Innovative Motor Arm Protection: Inspired by the Air Max concept, our motor arm protectors are crafted with a lightweight, hollow design, using durable TPU material. This not only reduces weight but also offers enhanced protection for the arm edges and motor. The snap-on installation eliminates the need for screws, ensuring the motor remains firmly attached to the frame, optimizing system performance.


Spec:

FC Mount: 20X20, 25.5X25.5, 30.5X30.5 mm
VTX Mount: 20X20
Camera Mount: 19mm wide
Motor Mount:19x19 M3 screw mount


What&#39s include: Carbon Fiber Parts:

Top plate 2mm x1

Mid plate 2.5mm x1
 Bottom plate 2.5m x1
Front arm 6mm x2
Rear arm 6mm x2

3D Printed Parts:

Motor arm protector TPU
TBS Crossfire nano receiver mount TPU
VTX Antenna Mount (two antenna) TPU
FPV Camera mount TPU

Hardware:

 M3  High Tensile Carbon Steel 8mm x13
M3 High Tensile Carbon Steel 10mm x18
M3 High Tensile Carbon Steel 14mm x9
M3 High Tensile Carbon Steel 16mm x5
M3 High Tensile Carbon Steel 25mm x5
M3 Nylon Lock Nut x9
 M3  7075 Aluminum Standoff 28mm x9

Accessory:

PU Battery mount sticker x1
Strap 20mm x 300mm x3
Nylon Zipties 3*100mm x5




NewBeeDrone M-323 7inch DC (Dead Cat) FPV Frame Design Idea:  Simplicity in Construction: Designed for effortless assembly and minimal maintenance. Versatile Hardware Mounting Solutions: Offers flexibility in mounting configurations, allowing for personalized setups tailored to your needs. Strategic Tactic Mounting Poi

NewBeeDrone M-323 7inch DC (Dead Cat) FPV Frame from WREKD Co.

NewBeeDrone M-323 7inch DC (Dead Cat) FPV Frame

NewBeeDrone M-323 7inch DC (Dead Cat) FPV Frame
Design Idea:



Simplicity in Construction: Designed for effortless assembly and minimal maintenance.

Versatile Hardware Mounting Solutions: Offers flexibility in mounting configurations, allowing for personalized setups tailored to your needs.

Strategic Tactic Mounting Points: Featuring mounting points on both top and bottom plates, enabling users to securely fasten any accessory using straps.

Innovative Motor Arm Protection: Inspired by the Air Max concept, our motor arm protectors are crafted with a lightweight, hollow design, using durable TPU material. This not only reduces weight but also offers enhanced protection for the arm edges and motor. The snap-on installation eliminates the need for screws, ensuring the motor remains firmly attached to the frame, optimizing system performance.


Spec:

FC Mount: 20X20, 25.5X25.5, 30.5X30.5 mm
VTX Mount: 20X20
Camera Mount: 19mm wide
Motor Mount:19x19 M3 screw mount


What's include: Carbon Fiber Parts:

Top plate 2mm x1

Mid plate 2.5mm x1
 Bottom plate 2.5m x1
Front arm 6mm x2
Rear arm 6mm x2

3D Printed Parts:

Motor arm protector TPU
TBS Crossfire nano receiver mount TPU
VTX Antenna Mount (two antenna) TPU
FPV Camera mount TPU

Hardware:

 M3  High Tensile Carbon Steel 8mm x13
M3 High Tensile Carbon Steel 10mm x18
M3 High Tensile Carbon Steel 14mm x9
M3 High Tensile Carbon Steel 16mm x5
M3 High Tensile Carbon Steel 25mm x5
M3 Nylon Lock Nut x9
 M3  7075 Aluminum Standoff 28mm x9

Accessory:

PU Battery mount sticker x1
Strap 20mm x 300mm x3
Nylon Zipties 3*100mm x5




Axis Flying

AxisFlying Kolas 6" Long Range Folding Frame

AXIS FLYING

The Axisflying Kolas 6 is a 6" long-range FPV frame with up to 15 minutes of flight time. Axisflying has adopted an innovative folding design with the Kolas 6, allowing for easier storage and transport! This unique frame kit also includes all 3D printed parts.
Check out all our DJI-compatible frames, electronics, and accessories and all our Axis Flying Products!

Features

XT60 plug on the left side of the frame for flight safety
25MM top to bottom distance for Caddx Vista
Open right side design for quick tuning
20MM/25MM/26.5MM Mounting Holes
Independent receiver compartment
High-strength T700 carbon plate
Foldable drone for easy storage
Ability to carry GoPro Camera
16x16 motor mounting holes
Underslung navigation light
15 Minute flight time
6" Foldable arms

Specifications

Wheelbase: 245mm
Top plate: 2.5mm
Bottom plate: 32.5mm
Arm: 7.0mm
FC mounting holes: 25.5mm x 25.5mm M2 / 20mm x 20mm M3
VTX mounting holes: 25.5mm x 25.5mm / 20mm x 20mm
Motor mounting holes: 16mm x 16mm
Camera installation space: 19-20mm
Suitable propeller size: 6″propeller
Weight: 138g (without TPU)



Includes


4x Axisflying Kolas 6 Foldable 6" Arms
1x Battery Ant-Slip Pad
1x 3D Printed Parts Set
2x Camera Side Plates
1x Hardware Set
1x Main Plate
2x LiPo Strap
1x Top Plate




The Axisflying Kolas 6 is a 6" long-range FPV frame with up to 15 minutes of flight time. Axisflying has adopted an innovative folding design with the Kolas 6, allowing for easier storage and transport! This unique frame kit also includes all 3D printed parts. Check out all our DJI-compatible frames, electronics, and a

AxisFlying Kolas 6 Long Range Foldable 6" Frame Kit

AxisFlying

The Axisflying Kolas 6 is a 6&quot long-range FPV frame with up to 15 minutes of flight time. Axisflying has adopted an innovative folding design with the Kolas 6, allowing for easier storage and transport! This unique frame kit also includes all 3D printed parts.
Check out all our DJI-compatible frames, electronics, and accessories and all our Axis Flying Products!

Features

XT60 plug on the left side of the frame for flight safety
25MM top to bottom distance for Caddx Vista
Open right side design for quick tuning
20MM/25MM/26.5MM Mounting Holes
Independent receiver compartment
High-strength T700 carbon plate
Foldable drone for easy storage
Ability to carry GoPro Camera
16x16 motor mounting holes
Underslung navigation light
15 Minute flight time
6&quot Foldable arms

Specifications

Wheelbase: 245mm
Top plate: 2.5mm
Bottom plate: 32.5mm
Arm: 7.0mm
FC mounting holes: 25.5mm x 25.5mm M2 / 20mm x 20mm M3
VTX mounting holes: 25.5mm x 25.5mm / 20mm x 20mm
Motor mounting holes: 16mm x 16mm
Camera installation space: 19-20mm
Suitable propeller size: 6″propeller
Weight: 138g (without TPU)



Includes


4x Axisflying Kolas 6 Foldable 6&quot Arms
1x Battery Ant-Slip Pad
1x 3D Printed Parts Set
2x Camera Side Plates
1x Hardware Set
1x Main Plate
2x LiPo Strap
1x Top Plate




AxisFlying Kolas 6 Long Range Foldable 6" Frame Kit from WREKD Co.

AxisFlying Kolas 6 Long Range Foldable 6

iFlight AOS 7 EVO (v1.2) 7" Frame Kit












The iFlight AOS 7 EVO 7" Frame Kit is perfect for freestyle drone racing. Constructed with 8mm arm thickness for superior durability and reliability, the kit features 25.5x25.5 or 20x20mm stack mountings in the front, center, and rear. It fits the DJI O3 Air Unit, Caddx Vista, or HDZero Freestyle VTX and both 20mm (DJI and O3 camera) and 19mm (micro-sized) cameras. Standoffs, frame, and screws are included.









The AOS 7 builds on the scientific approach used to design the AOS 5 and AOS 5.5, extending the benefits of those designs to the 7" class. Until now, 7" quads have been primarily used for long-range cruising and have never been able to match the performance of 5" quads for aggressive freestyle flying. The AOS 7 EVO 7" frame kit is here to break that conception.
The latest version of this frame is the AOS 7 EVO. It has an updated camera, top and bottom plates to support the DJI O3 Air Unit, and all other 19-20mm FPV cameras.
With the V1.2 updated side plates and silicone dampers.  Frame kit upgrade to the top plate with two antenna cutouts. Making this frame more ideal and suited for the DJI O3 Air Unit.
Check out all of our 7" frames and our selection of iFlight gear!
Make sure to check out our other O3 compatible frames!
Features

25.5x25.5 or 20x20mm stack mountings in the front, center and rear.

Fits the DJI O3 Air Unit, Caddx Vista or HDZero Freestyle VTX perfectly

Fits both 20mm (DJI and O3 camera) and 19mm (Micro sized) cameras

Standoffs, frame and screws included




Specifications

Product Name: AOS 7 EVO V1.2 Frame Kit

Frame wheelbase: 293mm

Frame Dimension: L228xW284xH34.5 mm

Arm Thickness: 8mm

Top Plate Thickness: 2mm

Bottom Plate Thickness: 2mm

Upper Plate Thickness: 2.5mm

Motor Mounting: 19x19mm

VTX Mounting: 20x20/Φ2mm / 25.5x25.5/Φ2mm

Weight: 290±5 grams (Included TPU Parts)

Includes

1x iFlight AOS 7 EVO 7" V1.2 Frame Kit
1x TPU Parts
4x Motor Wire Shield Tube

1x Screw Bag

2x Battery Strap


The iFlight AOS 7 EVO 7" Frame Kit is perfect for freestyle drone racing. Constructed with 8mm arm thickness for superior durability and reliability, the kit features 25.5x25.5 or 20x20mm stack mountings in the front, center, and rear. It fits the DJI O3 Air Unit, Caddx Vista, or HDZero Freestyle VTX and both 20mm (DJI












The iFlight AOS 7 EVO 7&quot Frame Kit is perfect for freestyle drone racing. Constructed with 8mm arm thickness for superior durability and reliability, the kit features 25.5x25.5 or 20x20mm stack mountings in the front, center, and rear. It fits the DJI O3 Air Unit, Caddx Vista, or HDZero Freestyle VTX and both 20mm (DJI and O3 camera) and 19mm (micro-sized) cameras. Standoffs, frame, and screws are included.









The AOS 7 builds on the scientific approach used to design the AOS 5 and AOS 5.5, extending the benefits of those designs to the 7&quot class. Until now, 7&quot quads have been primarily used for long-range cruising and have never been able to match the performance of 5&quot quads for aggressive freestyle flying. The AOS 7 EVO 7&quot frame kit is here to break that conception.
The latest version of this frame is the AOS 7 EVO. It has an updated camera, top and bottom plates to support the DJI O3 Air Unit, and all other 19-20mm FPV cameras.
With the V1.2 updated side plates and silicone dampers.  Frame kit upgrade to the top plate with two antenna cutouts. Making this frame more ideal and suited for the DJI O3 Air Unit.
Check out all of our 7&quot frames and our selection of iFlight gear!
Make sure to check out our other O3 compatible frames!
Features

25.5x25.5 or 20x20mm stack mountings in the front, center and rear.

Fits the DJI O3 Air Unit, Caddx Vista or HDZero Freestyle VTX perfectly

Fits both 20mm (DJI and O3 camera) and 19mm (Micro sized) cameras

Standoffs, frame and screws included




Specifications

Product Name: AOS 7 EVO V1.2 Frame Kit

Frame wheelbase: 293mm

Frame Dimension: L228xW284xH34.5 mm

Arm Thickness: 8mm

Top Plate Thickness: 2mm

Bottom Plate Thickness: 2mm

Upper Plate Thickness: 2.5mm

Motor Mounting: 19x19mm

VTX Mounting: 20x20/Φ2mm / 25.5x25.5/Φ2mm

Weight: 290±5 grams (Included TPU Parts)

Includes

1x iFlight AOS 7 EVO 7&quot V1.2 Frame Kit
1x TPU Parts
4x Motor Wire Shield Tube

1x Screw Bag

2x Battery Strap


iFlight AOS 7 EVO (v1.2) 7" Frame Kit from WREKD Co.

iFlight AOS 7 EVO (v1.2) 7

ImpulseRC

ImpulseRC ApexLR EVO HD O3 Deadcat Long Range 7" Frame Kit

IMPULSE RC

The ApexLR EVO  7&quot Frame is the ideal companion for exploration and videography that demands extra range. It has special arm geometry for motors not usually found in deadcat-style frames, and a special design that keeps the DJI O3 Air Unit and HD Camera electrically isolated. This EVO version boasts an aluminum camera mount, video isolation, and TPU inserts to fit many HD and analog cameras.
Be sure to check out our 7&quot frame selection and all our ImpulseRC products!


TENSION BRACES

As prop size increases, the longer arms required cause vibration issues which negatively impact flight performance and video stability. The ApexLR EVO uses a unique tension brace design between the arms to increase stiffness and shift the resonant frequency of the assembly.
Pre-loading the arms in this way allows us to keep vibration to a manageable level while still using 5.5mm thick arms for a 7&quot prop. The new approach saves 20g in carbon weight alone compared to equivalent 8mm thick arms.
The ApexLR EVO is a variation on the typical &#39dead cat&#39 frame which have been modified to keep the front and rear motors aligned, allowing them to maintain the much loved compressed-x geometry in the motor layout.
This ensures the frame remains balanced and flight characteristics are not compromised, unlike the classic &#39dead cat&#39 design which moves the rear motors closer to the body and severely impacts handling.


CAMERA MOUNT

Included with the ApexLR EVO is a newly redesigned aluminium camera mount and 3D printed insulation inserts. This keeps the camera firmly locked in place and reduces vibrations, whilst ensuring it is electrically isolated from the frame.
With the many different HD and analog cameras on the market there is a large variation between models in the distance from the front of the lens to the mounting bolts. To give the camera the best possible protection, whilst also keeping the frame out of shot, it is critical to be able to adjust the position of the camera forwards and backwards within the frame.
By rotating the TPU inserts 180 degrees, as well as alternating between using the upper or lower bolt as the pivot point, the EVO camera mount has 4 possible mounting positions each 2mm apart.




HD VIDEO SYSTEM ISOLATION

A major drawback of the some modern HD video systems is that the body of the unit is grounded, this can cause the conductive carbon fiber plates and frame hardware to be grounded too. In an ideal world this is not necessarily a problem, however in the real world it&#39s an accident waiting to happen.
Alongside the required M2 mounting hardware for the Caddx Vista and M1.6 hardware for the DJI O3, impluserc also include a die-cut mylar insulator and custom machined &#39cone rivets&#39 from non-conductive POM.
When installed your HD video system, and also the mounting hardware, is electrically isolated from the frame. This solution adds only 0.5g of extra weight compared to other designs using bulky and heavy 3D prints.




ANTENNA MOUNTING

Included in every kit is a 3D printed antenna mount for the your HD video system or other similar antennas.


APEXLR KIT CONTENTS

Carbon fiber frame parts
Hardware and standoffs
Aluminium and TPU camera mount
Mylar and POM HD video isolation parts
HD video antenna mount
Injection molded skids and bumper
Injection molded wire covers
Rubber and velcro battery pads
Diamond files
Battery strap

Specifications

Lower Main: 2mm
Upper Main: 2.5mm
Top: 2mm
Arm Brace: 3.5mm
Arms: 6mm

Arm Braces: 4mm
Motor Mounting Pattern: 16x16,19x19
Stack Mounting: 20x20mm &ampamp 30x30mm
VTX Mounting: 20x20mm and 25x25mm

Includes

1x ImpulseRC ApexLR EVO HD O3 Long Range 7&quot Frame Kit


The ApexLR EVO  7" Frame is the ideal companion for exploration and videography that demands extra range. It has special arm geometry for motors not usually found in deadcat-style frames, and a special design that keeps the DJI O3 Air Unit and HD Camera electrically isolated. This EVO version boasts an aluminum camera

ImpulseRC ApexLR EVO HD O3 Deadcat Long Range 7" Frame Kit from WREKD Co.

ImpulseRC ApexLR EVO HD O3 Deadcat Long Range 7

The ApexLR 7" Frame for Longer-Range Exploration and Videography. Compatible with DJI O3, the EVO version brings improvements such as a redesigned aluminum camera mount, isolation of the HD video system or optimized protection for the many HD and analog cameras on the market thanks to the pivoting TPU inserts. Once ins

ImpulseRC ApexLR EVO (O3) 7

IMPULSERC

The ApexLR EVO  7" Frame is the ideal companion for exploration and videography that demands extra range. It has special arm geometry for motors not usually found in deadcat-style frames, and a special design that keeps the DJI O3 Air Unit and HD Camera electrically isolated. This EVO version boasts an aluminum camera mount, video isolation, and TPU inserts to fit many HD and analog cameras.
Be sure to check out our 7" frame selection and all our ImpulseRC products!


TENSION BRACES

As prop size increases, the longer arms required cause vibration issues which negatively impact flight performance and video stability. The ApexLR EVO uses a unique tension brace design between the arms to increase stiffness and shift the resonant frequency of the assembly.
Pre-loading the arms in this way allows us to keep vibration to a manageable level while still using 5.5mm thick arms for a 7" prop. The new approach saves 20g in carbon weight alone compared to equivalent 8mm thick arms.
The ApexLR EVO is a variation on the typical 'dead cat' frame which have been modified to keep the front and rear motors aligned, allowing them to maintain the much loved compressed-x geometry in the motor layout.
This ensures the frame remains balanced and flight characteristics are not compromised, unlike the classic 'dead cat' design which moves the rear motors closer to the body and severely impacts handling.


CAMERA MOUNT

Included with the ApexLR EVO is a newly redesigned aluminium camera mount and 3D printed insulation inserts. This keeps the camera firmly locked in place and reduces vibrations, whilst ensuring it is electrically isolated from the frame.
With the many different HD and analog cameras on the market there is a large variation between models in the distance from the front of the lens to the mounting bolts. To give the camera the best possible protection, whilst also keeping the frame out of shot, it is critical to be able to adjust the position of the camera forwards and backwards within the frame.
By rotating the TPU inserts 180 degrees, as well as alternating between using the upper or lower bolt as the pivot point, the EVO camera mount has 4 possible mounting positions each 2mm apart.




HD VIDEO SYSTEM ISOLATION

A major drawback of the some modern HD video systems is that the body of the unit is grounded, this can cause the conductive carbon fiber plates and frame hardware to be grounded too. In an ideal world this is not necessarily a problem, however in the real world it's an accident waiting to happen.
Alongside the required M2 mounting hardware for the Caddx Vista and M1.6 hardware for the DJI O3, impluserc also include a die-cut mylar insulator and custom machined 'cone rivets' from non-conductive POM.
When installed your HD video system, and also the mounting hardware, is electrically isolated from the frame. This solution adds only 0.5g of extra weight compared to other designs using bulky and heavy 3D prints.




ANTENNA MOUNTING

Included in every kit is a 3D printed antenna mount for the your HD video system or other similar antennas.


APEXLR KIT CONTENTS

Carbon fiber frame parts
Hardware and standoffs
Aluminium and TPU camera mount
Mylar and POM HD video isolation parts
HD video antenna mount
Injection molded skids and bumper
Injection molded wire covers
Rubber and velcro battery pads
Diamond files
Battery strap

Specifications

Lower Main: 2mm
Upper Main: 2.5mm
Top: 2mm
Arm Brace: 3.5mm
Arms: 6mm

Arm Braces: 4mm
Motor Mounting Pattern: 16x16,19x19
Stack Mounting: 20x20mm &amp 30x30mm
VTX Mounting: 20x20mm and 25x25mm

Includes

1x ImpulseRC ApexLR EVO HD O3 Long Range 7" Frame Kit


TBS Source Aureo 7" Ultralight Frame

The SOURCE AUREO is an ultralight 7" frame, made for pilots who crave for range. Made with a rohacell like material sandwiched between 2 layers of carbon, the result is a super lightweight 7" frame - @49.5g. It fits and protects all the up-to-date components and is optimized for range. The SOURCE AUREO is your perfect

TBS Source Aureo 7

WREKD Co.

The SOURCE AUREO is an ultralight 7" frame, made for pilots who crave range. Made with a foam core-like material sandwiched between 2 layers of carbon, the result is a super lightweight 7" frame - @49.5g. It fits and protects all the up-to-date components and is optimized for range. The SOURCE AUREO is your perfect long-range cruiser and is recommended for pro pilots only.
ABOUT THE PROJECT
The SOURCE AUREO project is a collaborative FPV frame project initiated by Team BlackSheep. The frame is donated to the community to empower creators and makers and integrate best practices and current trends faster into a continuously manufactured product. In return, it allows the local distribution network to have cheap and direct access to a good frame in order to allow them to compete in an increasingly predatory marketplace.
The hope is for this frame to enable broad access to FPV thanks to a low price point, great documentation, and wide availability of compatible parts and accessories, without violating other people’s intellectual property.
GET INVOLVED!

Project discussion: Coming Soon
Project files: Coming Soon
3D Printed files on Thingiverse: Coming Soon
3D Printed Parts (STL) Coming Soon

PACKAGE CONTAINS:

1 x Frame
1 x Nylon SLS Printed Pod
1 x Screw Set (Motor Screws Included!)

TECHNICAL SPECIFICATIONS:


Wheelbase: 260mm

Plate: 7mm

Motor Mount: 19x19, 16x16, 12x12

Stack Mout: 4mm

Frame weight: 49.5g



The SOURCE AUREO is an ultralight 7" frame, made for pilots who crave range. Made with a foam core-like material sandwiched between 2 layers of carbon, the result is a super lightweight 7" frame - @49.5g. It fits and protects all the up-to-date components and is optimized for range. The SOURCE AUREO is your perfect lon

The SOURCE AUREO is an ultralight 7&quot frame, made for pilots who crave range. Made with a foam core-like material sandwiched between 2 layers of carbon, the result is a super lightweight 7&quot frame - @49.5g. It fits and protects all the up-to-date components and is optimized for range. The SOURCE AUREO is your perfect long-range cruiser and is recommended for pro pilots only.
ABOUT THE PROJECT
The SOURCE AUREO project is a collaborative FPV frame project initiated by Team BlackSheep. The frame is donated to the community to empower creators and makers and integrate best practices and current trends faster into a continuously manufactured product. In return, it allows the local distribution network to have cheap and direct access to a good frame in order to allow them to compete in an increasingly predatory marketplace.
The hope is for this frame to enable broad access to FPV thanks to a low price point, great documentation, and wide availability of compatible parts and accessories, without violating other people’s intellectual property.
GET INVOLVED!

Project discussion: Coming Soon
Project files: Coming Soon
3D Printed files on Thingiverse: Coming Soon
3D Printed Parts (STL) Coming Soon

PACKAGE CONTAINS:

1 x Frame
1 x Nylon SLS Printed Pod
1 x Screw Set (Motor Screws Included!)

TECHNICAL SPECIFICATIONS:


Wheelbase: 260mm

Plate: 7mm

Motor Mount: 19x19, 16x16, 12x12

Stack Mout: 4mm

Frame weight: 49.5g



Unleash the power of range with the TBS Source Aureo 7" Ultralight Frame - super lightweight, optimized for long-distance flights. Pro pilots only.

TBS Source Aureo 7" Ultralight Frame from WREKD Co.

Lumenier

Lumenier QAV-S 2 JohnnyFPV SE 7" Frame Kit

LUMENIER

Introducing the Lumenier QAV-S 2 JohnnyFPV Special Edition frame, a cutting-edge masterpiece designed to elevate your FPV drone experience. This frame boasts an innovative X-Lock arm retention system featuring a lateral locking mechanism that enhances rigidity and ease of use. The arms can effortlessly fold with only one screw per side. The frame's aluminum FPV camera protection ensures superior camera support, with customizable carbon plates compatible with various cameras, including vibration isolation options optimized for image stabilization. With 6mm thick arms, the QAV-S 2 7" frame achieves an unparalleled balance of durability and weight at 182g (frame only).Capture stunning footage with the injection-molded GoPro mount, compatible with the industry-standard pattern. It maintains backward compatibility with QAV-S series mount patterns, providing flexibility for users. The O3 compatible mounting system adds versatility, allowing direct mounting of the O3 air unit, supported by a 5mm full aluminum mounting kit for optimal wire routing. The adjustable aluminum XT60 and accessory mount at the rear provide options for hard-mounted XT60 connection and various accessory placements, ensuring adaptability for antennas, GPS, and rear-facing action cameras. Elevate your FPV cinematography with the Lumenier QAV-S 2 JohnnyFPV Special Edition frame – where innovation meets performance.
Check out the rest of our Lumenier products or the rest of our 7" drone frames.
Features

Made in Collaboration with expert FPV pilot JohnnyFPV
Frame made of High-Quality Lumenier components
Adjustable Aluminum XT60 and Accessory Mount
Backward-compatible mounting patterns
Aluminum FPV Camera Protection
Balanced Durability and Weight
Injection-Molded GoPro Mount
DeadCat Arm Configuration
O3 Compatible Mounting
Arm Braces for Rigidity
X-Lock Arm Retention



BALANCED DURABILITY AND WEIGHTThe QAV-S 2 JohnnyFPV Edition builds on the durability of its predecessor with upgraded 6mm thick arms in addition to the aluminum X-lock and FPV camera protection. At 133g (frame only - without accessories) this combination provides an industry-leading balance of weight and durability for even the most demanding applications.

X-LOCK ARM RETENTIONThe QAV-S 2 introduces a new lateral X-Lock arm system. This all-aluminum arm locking system improves the QAV-S design in both rigidity and ease of use, providing two-axis clamping that is mechanically isolated from the main plates and flight controller stack. The new lock system also allows the arms to fold with only one screw per side for easy transportation.

ALUMINUM FPV CAMERA PROTECTIONThe new FPV camera mounting solution offers excellent camera protection and support for various cameras through customizable carbon plates. The frame includes plates with damped mounts tested and optimized for the O3 camera and plates with mounts for a range of other camera options. If you want to create your own, the M2 mount points on the aluminum guards easily allow for custom mounts. Your imagination is the limit.

INJECTION MOLDED GOPRO MOUNTThe QAV-S 2 uses the same GoPro mount pattern used by other Lumenier frames, allowing a durable injection molded GoPro mount to attach with a single screw.

BACKWARD-COMPATIBLE MOUNTING PATTERNSFor those who still want to use printed GoPro and antenna mounts, the QAV-S 2 brings the JohnnyFPV frame into line with the mount patterns from the other QAV-S series frames. The new edition now uses the same mounting pattern and standoff placement as the other frames in the series. All previous QAV-S* mounts and Bardwell Special Edition frames will fit the JohnnyFPV Edition without modification. *Original QAV-S JohnnyFPV Special Edition mounts are no longer compatible

O3 COMPATIBLE MOUNTINGThe rear plate adds 25.5 M1.6 mount holes to mount the O3 air unit to the frame directly. The frame kit also includes a 5mm full aluminum mounting kit to allow for perfect wire routing for both the O3 air unit and a rear XT60 connector.

ADJUSTABLE ALUMINUM XT60 AND ACCESSORY MOUNTA custom rear mounting solution allows for a hard mounted XT60 connection as well as a range of accessory mounting options for antennas, GPS, and rear-facing action cameras. Adjustable angles allows for the perfect position regardless of the accessory being used. The frame kit includes plates for the injection molded GoPro mount and GPS mounts with both single and dual antenna options, as well as a single antenna only option.

FOLDING ARMSThe new lock system on the QAV-S 2 JohnnyFPV SE allows the arms to fold with only one screw per side for easy transportation. Simply remove the side screws and wedges, and you are now able to fold the arms.
Specifications

Rear Stack Dimensions: 20x20 (potentially 30x30 with adapter)
Custom Parts: 6061 Aluminum (Bronze Gold)
Standoffs: 7075 Aluminum (Bronze Gold)
Screws: Black Zinc Steel 12.9 grade
Weight: 182g (without accessories)
Middle Stack Dimensions: 30x30
Arm: 6mm 3K Carbon Fiber
Frame Size: 220mm

Lumenier QAV-S 2 JohnnyFPV Manual
IMPORTANT NOTES

The new QAV-S 2 arms will work with the original QAV-S frame, but the original QAV-S arms will not work with the new QAV-S 2 frame.


Includes

1x Lumenier QAV-S 2 JohnnyFPV SE 7" Frame Kit



1x JohnnyFPV QAV-S 2 Rear GoPro Mount Plate Dual Antenna
1x JohnnyFPV QAV-S 2 Rear GPS Dual Antenna Mount Plate
1x JohnnyFPV QAV-S 2 Battery Pad (Black Silicon Rubber)
1x JohnnyFPV QAV-S 2 Rear Adjustable Mount Right
2x JohnnyFPV QAV-S 2 Camera Plate for Grommets
1x JohnnyFPV QAV-S 2 Rear Adjustable Mount Left
1x JohnnyFPV QAV-S 2 Rear GPS XT60 Mount Plate
1x JohnnyFPV QAV-S 2 20mm Camera Plate Right
1x JohnnyFPV QAV-S 2 20mm Camera Plate Left
1x JohnnyFPV QAV-S 2 Rear GoPro Mount Plate
1x JohnnyFPV QAV-S 2 Rear FPV Antenna Plate
1x JohnnyFPV QAV-S 2 Pro Mount Spacer Plate
1x JohnnyFPV QAV-S 2 Rear Base Mount Right
1x JohnnyFPV QAV-S 2 Aluminum Guard Right
1x 14 Gauge Silicon Wire (Pair, Red and Black)
1x JohnnyFPV QAV-S 2 6mm FC Isolator 6mm
1x JohnnyFPV QAV-S 2 Rear Base Mount Left
1x JohnnyFPV QAV-S 2 Aluminum Guard Left
2x JohnnyFPV QAV-S 2 6mm Arm Wedge
2x JohnnyFPV QAV-S 2 7 Inch Arm Brace
2x JohnnyFPV QAV-S 2 7 Inch Arm Front
2x JohnnyFPV QAV-S 2 7 Inch Arm Rear
1x JohnnyFPV QAV-S 2 Split Plate Front
1x JohnnyFPV QAV-S 2 Split Plate Rear
1x Lumenier QAV-PRO Gopro Mount
2x 5mm O3 Air Unit Mount 20mm
1x JohnnyFPV QAV-S 2 Top Plate
2x Heatshrink 5mm Diameter
2x Lumenier Battery Strap
4x Knurled Standoff
1x XT60E-M (Black)
1x Hardware Set
4x Foam Pads



Introducing the Lumenier QAV-S 2 JohnnyFPV Special Edition frame, a cutting-edge masterpiece designed to elevate your FPV drone experience. This frame boasts an innovative X-Lock arm retention system featuring a lateral locking mechanism that enhances rigidity and ease of use. The arms can effortlessly fold with only o

Introducing the Lumenier QAV-S 2 JohnnyFPV Special Edition frame, a cutting-edge masterpiece designed to elevate your FPV drone experience.&nbsp

Introducing the Lumenier QAV-S 2 JohnnyFPV Special Edition frame, a cutting-edge masterpiece designed to elevate your FPV drone experience.

Lumenier QAV-S 2 JohnnyFPV SE 7” Frame Kit

PIRAT

PIRAT Hook Frame (5", 6", 7")

Get a precise flying experience with the new&nbspPIRAT Hook V2 Frame! The V2 frame now features more durability (even in reverse),&nbspCaddx Vista integration, and&nbspadaptivity to all camera sizes.&nbspDeveloped in collaboration with&nbspPDEVX&nbspFPV&nbsppilot.

Get a precise flying experience with the new PIRAT Hook V2 Frame! The V2 frame now features more durability (even in reverse), Caddx Vista integration, and adaptivity to all camera sizes. Developed in collaboration with PDEVX

PIRAT Hook V2 FPV Drone Frame Kit

Introducing FPV Pilot Fincky's favorite frame from the French FPV brand PiratFrames!

PIRAT Hook Frame (5&quot, 6&quot, 7&quot)

PIRAT Sloop V3 Frame (5", 6", 7")

Introducing&nbspFPV Pilot&nbspJ-True's&nbspfavorite frame from the French FPV brand PiratFrames!

Introducing FPV Pilot J-True's favorite frame from the French FPV brand PiratFrames!

PIRAT Sloop V3 Frame (5&quot, 6&quot, 7&quot)

Lumenier QAV-R 2 Deadcat Freestyle Quadcopter Frame (5", 6", 7")

The QAV-R 2 Deadcat Frame retracted front arms make sure your props are never in view in your camera footage. The body of the frame is also extended to give more room for mounting options such as DJI's FPV Air Unit.&nbspFly freestyle your way with the Lumenier QAV-R 2 Deadcat Freestyle Frame.20x20 &amp 30x30 mounting in center and rearNo props in viewXL body for tons of room for gear

The QAV-R 2 Deadcat Frame retracted front arms make sure your props are never in view in your camera footage. The body of the frame is also extended to give more room for mounting options such as DJI's FPV Air Unit. Fly freestyle your way with t

Lumenier QAV-R 2 Deadcat Freestyle Quadcopter Frame (5&quot, 6&quot, 7&quot)

XILO

XILO Phreakstyle Slam Freestyle Quadcopter Frame - 5"/6"/7"

The Phreakstyle Slam Freestyle Quadcopter Frame Kit is XILO's take on the FPV freestyle airframe. The Phreakstyle offers freestyle FPV pilots a frame with all the space and features you want - at an affordable price.

XILO Phreakstyle Slam Freestyle Quadcopter Frame Kit - 5"/6"/7"

XILO Phreakstyle Slam Freestyle Quadcopter Frame Kit - 5&quot/6&quot/7&quot

Armattan

Armattan Badger 6" Frame

The humble badger is the namesake of Armattan's newest flagship.  With a design based off of the Marmotte frame, the Badger updates it with removable arms: carefully designed to ensure a rock-solid construction.

Armattan Badger Frame

The Badger One of the oldest and most loved memes on the internet The humble badger is the namesake of Armattan's newest flagship.  With a design based off of the Marmotte frame, the Badger updates it with removable arms: carefully designed to ensure a rock-solid construction. The Cage This is the newest revision of Ar

Armattan Badger 6

HolyBro

Holybro S500 ARF V2- 480mm Quadcopter Platform Frame

Holybro

The motors on the S500 V2 have been upgraded to 2216 (high-quality motor) the props have been upgraded to 10 inches and the motor mounts have been reinforced.

The motors on the S500 V2 have been upgraded to 2216 (high-quality motor); the props have been upgraded to 10 inches and the motor mounts have been reinforced.

Holybro S500 ARF V2- 480mm Quadcopter Platform - Frame Kit

Lumenier QAV-R 2 Slam Freestyle Quadcopter Frame

The QAV-R 2 Slam is the worthy successor to the original QAV-R that many pilots fell in love with back in 2015. The QAV-R keeps many design elements from the original but adds modern compatibility and features that are preferred by today's pilots.Whether it's on the race course or shooting HD footage zipping down a mountainside, you'll feel like this frame was made just for you.

The QAV-R 2 Slam is the worthy successor to the original QAV-R that many pilots fell in love with back in 2015. The QAV-R keeps many design elements from the original but adds modern compatibility and features that are preferred by today's pilots.
W

Lumenier QAV-R 2 Freestyle Quadcopter Frame

The QAV-R 2 is the worthy successor to the original QAV-R that many pilots fell in love with back in 2015. The QAV-R keeps many design elements from the original but adds modern compatibility and features that are preferred by today's pilots.Whether it's on the race course or shooting HD footage zipping down a mountainside, you'll feel like this frame was made just for you.

The QAV-R 2 is the worthy successor to the original QAV-R that many pilots fell in love with back in 2015. The QAV-R keeps many design elements from the original but adds modern compatibility and features that are preferred by today's pilots.
Whethe

Lumenier QAV-PRO Mega Whoop 7" Frame Kit - Cinequads Edition

The Lumenier QAV-PRO Mega Whoop - Cinequads Edition is a professional 7" prop-guarded cinematic drone that is capable of handling large payloads. This advanced quadcopter is equipped with durable carbon fiber and aluminum components, providing complete propeller safeguarding. This frame is specifically designed to accommodate your cinema camera, and with the addition of the optional cinema camera mounting kit and X8 upgrade kit, this setup has a lot to offer and ensures an exceptional QAV-PRO experience. This whoop is a great tool to add to your cinematic arsenal and can be used in many scenarios where additional safety and stability are needed.
Check out the rest of our Lumenier products or the rest of our 7" drone frames.CINEQUADSLumenier has once again teamed up with Cinequads… the world-renowned German FPV cinematography company. Cinequad’s input and knowledge from having many years in the professional FPV industry have been highly valuable in the creation of industry-leading professional FPV products. Together, Lumenier and Cinequads are releasing the QAV-PRO line… which is the composition of professional FPV cinematic drones. These quads are tailored to get that perfect shot. Lumenier has pushed the limits with these drone kits by incorporating high-tech designs with high-quality materials.Combining Cinequads' professional experience and optimized workflow with Lumenier's high-quality design and manufacturing, we are excited to bring you the next professional class of FPV Cine drones... the Lumenier QAV-PRO line.


Features

Additional XT30 connectors allow cinema cameras to be powered by the drone to reduce the overall weight
Supports cinematic cameras, such as the RED Komodo and DSLR cameras.
Designed in Germany by Cinequads in collaboration with Lumenier
Configured for camera centering, allowing even weight distribution
Designed for internal electronic mounting for added protection
Switchable camera plates for 19x19 or 20x20 FPV cameras
Aluminum XT90 connector mount for cinematic batteries
Rear, front, or center cinema camera mounting options
Aluminum rear-end structural brace with LiPo strap
Symmetric motor arms with minimal masking
Durable carbon tubes with nylon landing feet
Organized aluminum cable mounting system
Vertical aluminum Crossfire antenna mount
Specially designed 4mm O3 heatsinks
50x50mm internal LiPo battery cage
Ducted for indoor/outdoor safety
Isolated O3 Camera Mount
Universal GoPro Mount
Pusher style frame
TPU GPS Mount



SWITCHABLE FPV CAMERA MOUNTING SYSTEMThe QAV-PRO Mega Whoop was specially designed with the O3 unit in mind. The increased airflow design, heatsink mounts, and aluminum camera mounts provide the perfect setup to utilize your O3 Unit in an optimized way, and the isolated O3 camera mount helps with stabilization. This unique camera mounting system also allows the pilot to use either 19X19 or 20X20mm FPV cameras. This camera mounting system can be flipped to allow space for your personal camera needs. The combination of aluminum brackets and durable carbon plates keeps your camera secure and safe.

O3 HEATSINK MOUNTSThese custom O3 mounts feature a heatsink design to reduce temperatures during flight and provide a longer flight time while keeping your O3 secure.

REAR FRAME FEATURESThe rear of this frame is equipped with multiple aluminum features. The rear brackets have secure slots for LiPo straps to ensure your battery does not move in flight, and the battery cage holds up to 50x50mm batteries. The mounts for the Crossfire antenna and XT90 connectors ensure your components stay safe in place during flights.

DUCTED FRAME DESIGN WITH SYMMETRIC MOTOR ARMSThe QAV-PRO Mega Whoop gives you the option to fly this larger rig with ducted protection. Flying close to people or objects that you need a little more security? No problem! Protect those props and motors while providing safety to spectators. The symmetric motor arms have minimal masking of the prop surface thanks to double-decker-style arms. This design provides a minimal overall height for better aerodynamics.

XT30 CONNECTORS FOR CINEMA CAMERAThese XT30 connectors allow you to power your cinema camera through the drone's battery, eliminating the need for a camera battery, and reducing overall weight for better flight performance.

CLEAN CABLE MANAGEMENTThe integrated cable management system on this frame leaves every FPV pilot with a professional, clean build. Slots for two zip ties are built into the frame, as well as aluminum cable brackets that keep your power cables centered and secure on the build.



Specifications

Connector: XT60 (1) for Battery + XT30 (2) for Cinema Cameras
Model: Lumenier QAV-PRO Mega Whoop 7" Cinequads Edition
FPV Camera Mounting: 20x20 or 19x19
VTX/AIO Mounting Patterns: 25x25mm
Antenna Mount Material: Aluminum
Motor Mounting Pattern: 9x9mm
Standoffs: M2x16mm Aluminum
O3 Heatsink Mounts: Aluminum
Carbon Fiber Thickness: 3mm
Dimensions: 470x400x60mm
Camera Mounts: Aluminum
Cable Mounts: Aluminum
Camera Plates: Carbon
Weight: Approx. 750g

Lumenier QAV-PRO Mega Whoop Manual
Includes

1x Lumenier QAV-PRO Mega Whoop 7" Cinequads Edition Frame Kit



1x Aluminum QAV-PRO Universal Camera Mount Base
1x Lumenier QAV-PRO Mega Whoop Bottom Plate
1x Lumenier QAV-PRO Mega Whoop Middle Plate
1x Lumenier QAV-PRO Mega Whoop Top Plate
1x USB-C to 90° USB-C Extension Cable
1x 4mm O3 Mounting Heatsink Kit
2x Aluminum Camera Mount
2x XT30 3D Printed Mount
1x Lumenier LiPo Strap
1x Foam Battery Shield
4x Rubber Grommets
4x M2 Steel Hex Nut
1x XT60 Connector
2x XT30 Connector
1x Antenna Mount
4x Landing Feet
1x Hardware Kit
1x XT60 Mount
6x Standoffs
6x Zip Ties



The Lumenier QAV-PRO Mega Whoop - Cinequads Edition is a professional 7" prop-guarded cinematic drone that is capable of handling large payloads. This advanced quadcopter is equipped with durable carbon fiber and aluminum components, providing complete propeller safeguarding. This frame is specifically designed to acco

Lumenier QAV-PRO Mega Whoop Cinequads Edition 7" Frame Kit

Foxeer

Foxeer Aura 6" Freestyle Frame

Single replacement front arm for the Foxeer Aura 6" DJI Frame. Check out our Foxeer Aura Frame and Parts Collection and the rest of our Foxeer Products! Package Includes: 1 x  Foxeer Aura 6" DJI Frame Replacement Front Arm (1 Pc.)

Foxeer Aura 6

Single replacement rear arm for the Foxeer Aura 6" DJI Frame. Check out our Foxeer Aura Frame and Parts Collection and the rest of our Foxeer Products! Package Includes: 1 x  Foxeer Aura 6" DJI Frame Replacement Rear Arm (1 Pc.)

iFlight ProTek60 Pro 6" Cinelifter Frame

Almost as if it came out of the "honey, I shrunk the kids" movie from 1989. Things are getting big! Let's introduce our latest member to our ProTek family, the all-new iFlight ProTek60 Cinelifter! We've came a long way with action cameras, offering outstanding quality with little weight and a small footprint. But do yo

iFlight ProTek60 Pro 6inch Cinelifter Frame Kit - Choose Cam Plate

Propeller Size

The props work with the motors to lift your quad off the ground.  Choose a prop size that fits your frame.  Higher pitch props are efficient in fast environments and are less responsive in slow speeds. Lower pitch props are efficient in slower environments and are more responsive in slow speeds. Beginners should try various pitch props to see what works best for them.

Propellers

Motor Stator Size

The motors spin with the propellers to lift your quad off the ground. If you’ve picked a frame already, we show you which motors are appropriate for your frame. Beginners can choose motors with a similar stator size that others have used for the frame you’ve selected. Alternatively, calculate the thrust required for a particular thrust-to-weight ratio and learn to read motor thrust tables to select the best motors for your needs.

Motors

ESC Stack Mount

The ESC(s) controls your motors’ speed. It draws power from the battery to spin the motors based on what the FC tells it to do. Each motor needs an ESC. It’s common today to see 4-in-1 ESCs so you only need to buy a single part. For beginners, choose a 4-in-1 ESC that has a compatible mount with your frame and FC. The biggest consideration is amperage limit. We show you ESCs with appropriate amperage limits based on your frame size. You can calculate how much amperage you need based on your motor and prop choice.

ESCs

FC Stack Mount

The FC is the brain or the CPU of your quad. It has a processor and other components that allow it to listen to your inputs and tells the quad what to do. FCs are commonly sold together with other components integrated or stacked (like ESCs and video transmitters). For beginners, choose a FC with a F4 or F7 processor that has a compatible mount with your frame.

Flight Controllers

Camera Size

The FPV camera captures the image you see through the goggles. An FPV camera may be included with the VTX, particularly with digital VTXs.
