BetaFPV

BetaFPV Pavo35 Cinewhoop 3.5" Micro Frame Kit

BETAFPV

Pavo35 cinewhoop frame features newly engineered supports to reduce vibrations as well as being able to accommodate the strong thrust of 6S motors. The ducts are inspired by rocket nozzles to enhance horizontal stability. This frame has aluminum CNC metal supports &amp built-in XT-60 mount.
Be sure to check out all our 3.5" frames, and the rest of our BetaFPV gear!

Features

The innovative Y-shaped CNC metal support structure can improve the structural strength, torsion resistance, and vibration characteristics of the entire machine compared to aluminum columns, making it respond faster and more smoothly.

Rocket engine-inspired duct design improves lateral stability and increases thrust by 400g compared to without a propeller guard, giving the Pavo35 stronger power and a better flying feel.

The whoop duct is riveted and assembled, and the new appearance and design concept enables more effortless installation and a stronger structure.


Pavo35 Frame Kit
Pavo35 whoop duct can enhance an additional 400g thrust and also a CNC 7075 Aluminum Y shape standoff to eliminate distortion and bending during flight. Powerful and smooth flying is guaranteed. The modular design of the frame guarantees a streamlined appearance, with no protruding wires and the fixed power port design enables effortless one-handed connection. Assembling the frame is a breeze, requiring the simple tightening of the four bottom screws and utilizing the riveting design for convenient detachment of the duct.

The design of the whoop duct fully refers to the aerodynamic principle of the rocket engine nozzle and utilizes different heights and thicknesses between the upper edge and lower edge, through the compression of the inlet air within the duct, a substantial increase in exhaust pressure is achieved. Consequently, an additional thrust of 400g is generated, while simultaneously enhancing the horizontal stability of the cinewhoop. With augmented power and exceptional flight stability, executing challenging maneuvers such as flips and turns on the Pavo35 results in remarkably steady and precise responses. Pilots will experience an enhanced flying sensation.
The Y structural Shape standoff means 8 support force is on the top plate, increasing the structural strength of the quad, which results in smoother turns and minimal vibrations during flight. The CNC standoff is made with aircraft standard material - 7075 Aluminium Alloy to increase strength for ensure that pilots can embark on powerful flights with confidence. Additionally, the duct is securely fastened with only 4 screws, while the remaining connections employ the time-honored Chinese traditional riveting technique to ensure fast assembling and disassembling also including fixed power port design.
Specifications

Item: Pavo35 Brushless Whoop Frame
Wheelbase: 148mm

Top Plate: 3mm T700 carbon fiber

Base Plate: 1.5mm T700 carbon fiber

Gimbal Carbon Plate: 2mm T700 carbon fiber

Column: 7075 aluminum alloy CNC

Battery Holder: 7075 aluminum alloy CNC

Whoop Duct: PC injection-molded translucent gray


Whoop Duct Diameter: 92mm
Battery Connector: Fixed XT60

Camera Installation Size: 20mm (compatible with 19mm)

HD VTX Installation Size: 25.5x25.5mm M1.6/20x20mm M2

HD VTX Antenna Mounting Hole Size: 4mm

Flight controller Mounting Hole Size: 25.5x25.5mm

Motor Mounting Hole Size: 4xM2 EQS ø12mm

Weight: 113.9g

Includes

1x Top Plate
1x Gimbal Carbon Plate

1x Base Plate

2x Battery Tie Holder

4x Y-shaped Aluminum Alloy Bracket

1x Whoop Duct

1x Receiver Holder

1x Amass XT60EW-M Socket (Black)

2x Battery Anti-slip Mat
1x Battery Tie

4x Flight Controller Amping Ball

4x Pan/Tilt Vibration Reduction Ball

4x Pan/Tilt Screws

2x Inner Hex Flat Head Screw M2.5x5

10x Inner Hex Flat Head Screw M2x6

4x Inner Hex Flat Head Screw M2x8

4x Inner Hex Flat Head Screw M2x10

4x Nylon nut M2
1x Accessory package

1x Service Card

1x Frame Manual



Pavo35 cinewhoop frame features newly engineered supports to reduce vibrations as well as being able to accommodate the strong thrust of 6S motors. The ducts are inspired by rocket nozzles to enhance horizontal stability. This frame has aluminum CNC metal supports &amp; built-in XT-60 mount.  Be sure to check out all o

Pavo35 cinewhoop frame features newly engineered supports to reduce vibrations as well as being able to accommodate the strong thrust of 6S motors. The ducts are inspired by rocket nozzles to enhance horizontal stability. This frame has aluminum CNC metal supports &ampamp built-in XT-60 mount.
Be sure to check out all our 3.5&quot frames, and the rest of our BetaFPV gear!

Features

The innovative Y-shaped CNC metal support structure can improve the structural strength, torsion resistance, and vibration characteristics of the entire machine compared to aluminum columns, making it respond faster and more smoothly.

Rocket engine-inspired duct design improves lateral stability and increases thrust by 400g compared to without a propeller guard, giving the Pavo35 stronger power and a better flying feel.

The whoop duct is riveted and assembled, and the new appearance and design concept enables more effortless installation and a stronger structure.


Pavo35 Frame Kit
Pavo35 whoop duct can enhance an additional 400g thrust and also a CNC 7075 Aluminum Y shape standoff to eliminate distortion and bending during flight. Powerful and smooth flying is guaranteed. The modular design of the frame guarantees a streamlined appearance, with no protruding wires and the fixed power port design enables effortless one-handed connection. Assembling the frame is a breeze, requiring the simple tightening of the four bottom screws and utilizing the riveting design for convenient detachment of the duct.

The design of the whoop duct fully refers to the aerodynamic principle of the rocket engine nozzle and utilizes different heights and thicknesses between the upper edge and lower edge, through the compression of the inlet air within the duct, a substantial increase in exhaust pressure is achieved. Consequently, an additional thrust of 400g is generated, while simultaneously enhancing the horizontal stability of the cinewhoop. With augmented power and exceptional flight stability, executing challenging maneuvers such as flips and turns on the Pavo35 results in remarkably steady and precise responses. Pilots will experience an enhanced flying sensation.
The Y structural Shape standoff means 8 support force is on the top plate, increasing the structural strength of the quad, which results in smoother turns and minimal vibrations during flight. The CNC standoff is made with aircraft standard material - 7075 Aluminium Alloy to increase strength for ensure that pilots can embark on powerful flights with confidence. Additionally, the duct is securely fastened with only 4 screws, while the remaining connections employ the time-honored Chinese traditional riveting technique to ensure fast assembling and disassembling also including fixed power port design.
Specifications

Item: Pavo35 Brushless Whoop Frame
Wheelbase: 148mm

Top Plate: 3mm T700 carbon fiber

Base Plate: 1.5mm T700 carbon fiber

Gimbal Carbon Plate: 2mm T700 carbon fiber

Column: 7075 aluminum alloy CNC

Battery Holder: 7075 aluminum alloy CNC

Whoop Duct: PC injection-molded translucent gray


Whoop Duct Diameter: 92mm
Battery Connector: Fixed XT60

Camera Installation Size: 20mm (compatible with 19mm)

HD VTX Installation Size: 25.5x25.5mm M1.6/20x20mm M2

HD VTX Antenna Mounting Hole Size: 4mm

Flight controller Mounting Hole Size: 25.5x25.5mm

Motor Mounting Hole Size: 4xM2 EQS ø12mm

Weight: 113.9g

Includes

1x Top Plate
1x Gimbal Carbon Plate

1x Base Plate

2x Battery Tie Holder

4x Y-shaped Aluminum Alloy Bracket

1x Whoop Duct

1x Receiver Holder

1x Amass XT60EW-M Socket (Black)

2x Battery Anti-slip Mat
1x Battery Tie

4x Flight Controller Amping Ball

4x Pan/Tilt Vibration Reduction Ball

4x Pan/Tilt Screws

2x Inner Hex Flat Head Screw M2.5x5

10x Inner Hex Flat Head Screw M2x6

4x Inner Hex Flat Head Screw M2x8

4x Inner Hex Flat Head Screw M2x10

4x Nylon nut M2
1x Accessory package

1x Service Card

1x Frame Manual



BetaFPV Pavo35 Cinewhoop 3.5" Micro Frame Kit from WREKD Co.

BetaFPV Pavo35 Cinewhoop 3.5

BETAFPV Pavo35 Cinewhoop Frame Kit is the revolutionary framework that the product team has developed after countless hours of applying aerodynamics.

BETAFPV Pavo35 Cinewhoop Frame Kit

Frame Size

The frame is typically the first part to pick because it determines what kind of flying you’ll be doing the most. Start by picking a frame type, and narrow down the options by propeller size. The frame holds your quad parts together and heavily impacts what the quad can do.

Frames

Frame Kit

Frame Stack Mount

FPV Camera Mount

Frame Type

Five33

Five33 TinyTrainer V2 3" Micro Frame Kit

Tiny Trainer V2

Everything about the V1, just better.

The biggest complaints over the 2 years Tiny Trainers have been flying around the world are



"I hate when I break the base plate in a hard crash. I have to swap over my entire build to a new plate, ending my day of flying."





" I can't stand that I have to unscrew 4 screws AND cut 4 Zip ties just to open up the body of the drone"





"I'm tired of messing with TPU camera mounts, my printer never works, and I hate buying prints"





"I prefer mounting batteries with a battery strap, my other micros even let me use rubber bands!"



Removable Arms

Tiny Trainer V2 comes standard with 3mm thick, ONE screw arm removal. Not only that, it uses steel M3 screws, so you never have to worry about stripping a screw when tightening your arms. Break an arm in the field? Take off your motor, pull the arm screw and bolt your new one on. You're back in the air within 5 minutes.

Quick Fix Canopy Design

Taking the canopy off the Tiny Trainer V1 got old fast, now its as simple as loosening 2 screws. Once the back 2 screws are loosened (not removed) the entire body of the Tiny Trainer V2 unfolds, giving you access to 100 percent of the internals of the drone.  You're ready to go fly, pull the hood back down, tighten up your screws, and rip! This drone is easier to work on than ever.

Integrated Injection Molded Camera Mount

No more dealing with 3D printed camera mounts, The Tiny Trainer V2 integrates a beautiful nano cam mount into the front of the Canopy. 2 mounting points available allowing a 30-60 degree mount and 5-25 degree mount! All while being fully integrated in the injection Molded Canopy.

Customizable Battery Solution

Armandos design allows for the use of the battery tray V2 (recommended for 550 mah 3s), Micro battery strap, and even rubber bands. You can use nearly ANY battery on a Tiny Trainer V2.



STL Files available here: https://www.printables.com/model/368444-five33-tinytrainerv2-tpu-parts









Tiny Trainer V2 Everything about the V1, just better. The biggest complaints over the 2 years Tiny Trainers have been flying around the world are "I hate when I break the base plate in a hard crash. I have to swap over my entire build to a new plate, ending my day of flying." " I can't stand that I have to unscrew 4 sc

FIVE33












Tiny Trainer V2: improved on the V1 with an arm removal system that uses steel M3 screws, quick-fix canopy design, and integrated injection-molded camera mount. Arms are 3mm thick, break one in the field? Just take off the motor, unscrew the arm, and bolt on a new one. Canopy opens with two screws for full access to internals. Camera mount supports 30-60 and 5-25 degree angles. The perfect frame looking to train those tight lines in races.











Check out our other 3" frames, and FIVE33 Flying Gear!
STL Files available here: https://www.printables.com/model/368444-five33-tinytrainerv2-tpu-parts


 Specifications

Canopy Color: Black
Motor Bolt Mounting: 9x9mm &amp 12x12mm

Stack Mounting: 16x16mm &amp 25.5x25.5mm
Arm Thickness: 3mm

Includes

1x FIVE33 TinyTrainer V2 3" Micro Frame Kit w/out TPU


Tiny Trainer V2: improved on the V1 with an arm removal system that uses steel M3 screws, quick-fix canopy design, and integrated injection-molded camera mount. Arms are 3mm thick, break one in the field? Just take off the motor, unscrew the arm, and bolt on a new one. Canopy opens with two screws for full access to in

FIVE33 TinyTrainer V2 3" Micro Frame Kit w/out TPU

Tiny Trainer V2 Everything about the V1, just better. The biggest complaints over the 2 years Tiny Trainers have been flying around the world are “I hate when I break the base plate in a hard crash. I have to swap over my entire build to a new plate, ending my day of flying.” ” I can’t stand that I have to unscrew 4 sc

Five33 TinyTrainer V2 Full Kit W/Canopy & Battery Tray

Tiny Trainer V2

Everything about the V1, just better.

The biggest complaints over the 2 years Tiny Trainers have been flying around the world are



&quotI hate when I break the base plate in a hard crash. I have to swap over my entire build to a new plate, ending my day of flying.&quot





&quot I can&#39t stand that I have to unscrew 4 screws AND cut 4 Zip ties just to open up the body of the drone&quot





&quotI&#39m tired of messing with TPU camera mounts, my printer never works, and I hate buying prints&quot





&quotI prefer mounting batteries with a battery strap, my other micros even let me use rubber bands!&quot



Removable Arms

Tiny Trainer V2 comes standard with 3mm thick, ONE screw arm removal. Not only that, it uses steel M3 screws, so you never have to worry about stripping a screw when tightening your arms. Break an arm in the field? Take off your motor, pull the arm screw and bolt your new one on. You&#39re back in the air within 5 minutes.

Quick Fix Canopy Design

Taking the canopy off the Tiny Trainer V1 got old fast, now its as simple as loosening 2 screws. Once the back 2 screws are loosened (not removed) the entire body of the Tiny Trainer V2 unfolds, giving you access to 100 percent of the internals of the drone.  You&#39re ready to go fly, pull the hood back down, tighten up your screws, and rip! This drone is easier to work on than ever.

Integrated Injection Molded Camera Mount

No more dealing with 3D printed camera mounts, The Tiny Trainer V2 integrates a beautiful nano cam mount into the front of the Canopy. 2 mounting points available allowing a 30-60 degree mount and 5-25 degree mount! All while being fully integrated in the injection Molded Canopy.

Customizable Battery Solution

Armandos design allows for the use of the battery tray V2 (recommended for 550 mah 3s), Micro battery strap, and even rubber bands. You can use nearly ANY battery on a Tiny Trainer V2.



STL Files available here: https://www.printables.com/model/368444-five33-tinytrainerv2-tpu-parts









Five33 TinyTrainer V2 Frame Kit from WREKD Co.

Five33 TinyTrainer V2 Frame Kit

NewBeeDrone

NewBeeDrone SavageBee V1.8 65mm 3" Frame

NewBeeDrone SavageBee 3" Toothpick Frame
The SavageBee frame was specially designed to fit any brushless NewBeeDrone whoop flight controller to build a lightweight 1s or 2s toothpick micro drone.
At 2.5mm thick, the base plate is durable but also has no unnecessary structural weight from the precise cutouts.
Easy to Build
Other 3 inch toothpick frames require meticulous, difficult, and tiny soldering. With the NewBeeDrone Hummingbird Pro and BeeBrain BLV3 flight controllers, building this toothpick is easy! The only soldering necessary will be to connect the motors to the ESC. The BeeBrain BLV3 has large soldering pads to accommodate for custom builds.

Specifications

Carbon Fiber: 2.5mm thickness
Geometry: X frame
Diagonal Motor Distance: 115mm
Motor Mounting Pattern: 9x9 mm square

Build Recommendations


Flight Controller: NewBeeDrone BeeBrain BLV3 AIO Flight Controller (FC + ESC + Rx + Vtx)


Motors: NewBeeDrone Flow 1202 8420KV (2s) or 11420KV (1s)


FPV Camera: NewBeeDrone BeeEye FPV Camera


Canopy: NewBeeDrone Goober Canopy


Propellers: Gemfan 3018 3 Inch Propellers


Recommended 1s Batteries:

NewBeeDrone Nitro Nectar Gold 1s 300 mAh
GNB 1s 450 mAh
GNB 1s 520 mAh

Recommended 2s Batteries:


2x NewBeeDrone Nitro Nectar Gold 300 mAh with Y-Connector


GNB 2s 300 mAh

Note: the included battery mount only fits 1x 250 mAh or 300 mAh 1s battery. To mount a 2s battery, rubber bands are recommended.



NewBeeDrone SavageBee 3" Toothpick Frame The SavageBee frame was specially designed to fit any brushless NewBeeDrone whoop flight controller to build a lightweight 1s or 2s toothpick micro drone. At 2.5mm thick, the base plate is durable but also has no unnecessary structural weight from the precise cutouts. Easy to Bu

NewBeeDrone SavageBee V1.8 Frame 65mm/3inch

NewBeeDrone SavageBee 3&quot Toothpick Frame
The SavageBee frame was specially designed to fit any brushless NewBeeDrone whoop flight controller to build a lightweight 1s or 2s toothpick micro drone.
At 2.5mm thick, the base plate is durable but also has no unnecessary structural weight from the precise cutouts.
Easy to Build
Other 3 inch toothpick frames require meticulous, difficult, and tiny soldering. With the NewBeeDrone Hummingbird Pro and BeeBrain BLV3 flight controllers, building this toothpick is easy! The only soldering necessary will be to connect the motors to the ESC. The BeeBrain BLV3 has large soldering pads to accommodate for custom builds.

Specifications

Carbon Fiber: 2.5mm thickness
Geometry: X frame
Diagonal Motor Distance: 115mm
Motor Mounting Pattern: 9x9 mm square

Build Recommendations


Flight Controller: NewBeeDrone BeeBrain BLV3 AIO Flight Controller (FC + ESC + Rx + Vtx)


Motors: NewBeeDrone Flow 1202 8420KV (2s) or 11420KV (1s)


FPV Camera: NewBeeDrone BeeEye FPV Camera


Canopy: NewBeeDrone Goober Canopy


Propellers: Gemfan 3018 3 Inch Propellers


Recommended 1s Batteries:

NewBeeDrone Nitro Nectar Gold 1s 300 mAh
GNB 1s 450 mAh
GNB 1s 520 mAh

Recommended 2s Batteries:


2x NewBeeDrone Nitro Nectar Gold 300 mAh with Y-Connector


GNB 2s 300 mAh

Note: the included battery mount only fits 1x 250 mAh or 300 mAh 1s battery. To mount a 2s battery, rubber bands are recommended.



NewBeeDrone SavageBee V1.8 Frame 65mm/3inch from WREKD Co.

Quadifier

Quadifier Mamba Racing 3" Micro Frame Kit

The Quadifier Mamba is a 3 inch race frame that is designed to be nimble, agile, and efficient. I have always been a picky person when deciding on a frame. The cobra is a frame that fit all of my requirements. It has the strength and looks to make your jaw drop. Choose between blue or red for your TPU color on your quad.
Be sure to check out all our micro frames, and all our Quadifier products!

Features

Designed for 20x20 stacks

Stretch X for more efficient flight

3.5mm unibody bottom plate
2mm top plate

Fits only nano 14x14 size cameras

Specification


Stack Mounting: 20x20
FPV Camera Mount: 14mm Micro cam
Motor Mount Pattern: 9x9 M2 ,12x12 M2
Main Plate Thickness: 3.5mm
Frame Shape: Slight Stretched X
Motor to Motor: 160mm
Arm Thickness: 3.5mm
Frame Weight With TPU: 30g


Includes

1x Quadifier Mamba Racing 3" Micro Frame Kit - Choose Your Color
1x TPU Kit


The Quadifier Mamba is a 3 inch race frame that is designed to be nimble, agile, and efficient. I have always been a picky person when deciding on a frame. The cobra is a frame that fit all of my requirements. It has the strength and looks to make your jaw drop. Choose between blue or red for your TPU color on your qua

Quadifier Mamba Racing 3" Micro Frame Kit - Choose Your Color

The Quadifier Mamba is a 3 inch race frame that is designed to be nimble, agile, and efficient. I have always been a picky person when deciding on a frame. The cobra is a frame that fit all of my requirements. It has the strength and looks to make your jaw drop.
Be sure to check out all our micro frames, and all our Quadifier products!
Features

Designed for 20x20 stacks

Stretch X for more efficient flight

3.5mm unibody bottom plate
2mm top plate

Fits only nano 14x14 size cameras

Specification


Stack Mounting: 20x20
FPV Camera Mount: 14mm Micro cam
Motor Mount Pattern: 9x9 M2 ,12x12 M2
Main Plate Thickness: 3.5mm
Frame Shape: Slight Stretched X
Motor to Motor: 160mm
Arm Thickness: 3.5mm
Frame Weight With TPU: 30g


Includes

1x Quadifier Mamba Racing 3&quot Micro Frame Kit
1x TPU Kit


The Quadifier Mamba is a 3 inch race frame that is designed to be nimble, agile, and efficient. I have always been a picky person when deciding on a frame. The cobra is a frame that fit all of my requirements. It has the strength and looks to make your jaw drop.  Be sure to check out all our micro frames, and all our Q

Quadifier Mamba Racing 3" Micro Frame Kit from WREKD Co.

Quadifier Mamba Racing 3

The Quadifier Mamba is a 3 inch race frame that is designed to be nimble, agile, and efficient. I have always been a picky person when deciding on a frame. The cobra is a frame that fit all of my requirements. It has the strength and looks to make your jaw drop. Choose between blue or red for your TPU color on your quad.
Be sure to check out all our micro frames, and all our Quadifier products!

Features

Designed for 20x20 stacks

Stretch X for more efficient flight

3.5mm unibody bottom plate
2mm top plate

Fits only nano 14x14 size cameras

Specification


Stack Mounting: 20x20
FPV Camera Mount: 14mm Micro cam
Motor Mount Pattern: 9x9 M2 ,12x12 M2
Main Plate Thickness: 3.5mm
Frame Shape: Slight Stretched X
Motor to Motor: 160mm
Arm Thickness: 3.5mm
Frame Weight With TPU: 30g


Includes

1x Quadifier Mamba Racing 3&quot Micro Frame Kit - Choose Your Color
1x TPU Kit


Quadifier Mamba Racing 3" Micro Frame Kit - Choose Your Color from WREKD Co.

The Quadifier Mamba is a 3 inch race frame that is designed to be nimble, agile, and efficient. I have always been a picky person when deciding on a frame. The cobra is a frame that fit all of my requirements. It has the strength and looks to make your jaw drop.
Be sure to check out all our micro frames, and all our Quadifier products!
Features

Designed for 20x20 stacks

Stretch X for more efficient flight

3.5mm unibody bottom plate
2mm top plate

Fits only nano 14x14 size cameras

Specification


Stack Mounting: 20x20
FPV Camera Mount: 14mm Micro cam
Motor Mount Pattern: 9x9 M2 ,12x12 M2
Main Plate Thickness: 3.5mm
Frame Shape: Slight Stretched X
Motor to Motor: 160mm
Arm Thickness: 3.5mm
Frame Weight With TPU: 30g


Includes

1x Quadifier Mamba Racing 3" Micro Frame Kit
1x TPU Kit


The Quadifier Mamba is a 3 inch race frame that is designed to be nimble, agile, and efficient. I have always been a picky person when deciding on a frame. The cobra is a frame that fit all of my requirements. It has the strength and looks to make your jaw drop. Check out all our Racing Frames and the rest of our Quadi

Quadifier Mamba 3

Quadifier Baby Diamondback 3.5" Micro Freestyle Frame Kit

The Quadifier Baby Diamond back is a 3.5 inch freestyle frame that is designed to be nimble, agile, and efficient. I have always been a picky person when deciding on a frame. The Baby DiamondBack is a frame that fit all of my requirements. It has the strength and looks to make your jaw drop.
Be sure to check out all our micro frames, and all our Quadifier products!
Features

Designed for 20x20 stack

3mm arms

Fits micro 19x19 size cameras

Specification


Stack Mounting: 20x20
FPV Camera Mount: 19mm Micro cam
Motor Mount Pattern: 9x9 M2 ,12x12 M2
Main Plate Thickness: 2mm
Frame Shape: Squished X
Motor to Motor: 160mm
Arm Thickness: 4mm
Frame Weight With TPU: 65g


Includes

1x Quadifier Baby Diamondback 3.5&quot Freestyle Frame Kit
1x TPU Kit


The Quadifier Baby Diamond back is a 3.5 inch freestyle frame that is designed to be nimble, agile, and efficient. I have always been a picky person when deciding on a frame. The Baby DiamondBack is a frame that fit all of my requirements. It has the strength and looks to make your jaw drop. Be sure to check out all ou

Quadifier Baby Diamondback Freestyle 3.5" Micro Frame Kit (Rev2) - 4mm Arms from WREKD Co.

Quadifier Baby Diamondback Freestyle 3.5

Quadifier Baby Diamondback Freestyle 3.5" Micro Frame Kit (Rev2) - 4mm Arms

The Quadifier Baby Diamond back is a 3.5 inch freestyle frame that is designed to be nimble, agile, and efficient. I have always been a picky person when deciding on a frame. The Baby DiamondBack is a frame that fit all of my requirements. It has the strength and looks to make your jaw drop.  Choose between blue or red for your TPU color on your quad.
Be sure to check out all our 3.5" frames, and all our Quadifier products!
Features

Designed for 20x20 stack

3mm arms

Fits micro 19x19 size cameras

Specification


Stack Mounting: 20x20
FPV Camera Mount: 19mm Micro cam
Motor Mount Pattern: 9x9 M2 ,12x12 M2
Main Plate Thickness: 2mm
Frame Shape: Squished X
Motor to Motor: 160mm
Arm Thickness: 4mm
Frame Weight With TPU: 65g


Includes

1x Quadifier Baby Diamondback 3.5" Freestyle Frame Kit
1x TPU Kit


The Quadifier Baby Diamond back is a 3.5 inch freestyle frame that is designed to be nimble, agile, and efficient. I have always been a picky person when deciding on a frame. The Baby DiamondBack is a frame that fit all of my requirements. It has the strength and looks to make your jaw drop.  Choose between blue or red

Quadifier Baby Diamondback Freestyle 3.5" Micro Frame Kit (Rev2) - 4mm Arms - Choose Your Color

Quadifier Baby Diamondback Freestyle 3.5" Micro Frame Kit (Rev2) - 4mm

The Quadifier Baby Diamond back is a 3.5 inch freestyle frame that is designed to be nimble, agile, and efficient. I have always been a picky person when deciding on a frame. The Baby DiamondBack is a frame that fit all of my requirements. It has the strength and looks to make your jaw drop.
Be sure to check out all our micro frames, and all our Quadifier products!
Features

Designed for 20x20 stack

3mm arms

Fits micro 19x19 size cameras

Specification


Stack Mounting: 20x20
FPV Camera Mount: 19mm Micro cam
Motor Mount Pattern: 9x9 M2 ,12x12 M2
Main Plate Thickness: 2mm
Frame Shape: Squished X
Motor to Motor: 160mm
Arm Thickness: 4mm
Frame Weight With TPU: 65g


Includes

1x Quadifier Baby Diamondback 3.5" Freestyle Frame Kit
1x TPU Kit


The Quadifier Baby Diamond back is a 3 inch freestyle frame that is designed to be nimble, agile, and efficient. I have always been a picky person when deciding on a frame. The Baby Diamond Back is a frame that fit all of my requirements. It has the strength and looks to make your jaw drop. Check out all our 3" Frames

Quadifier Baby Diamondback 3

The Quadifier Baby Diamond back is a 3.5 inch freestyle frame that is designed to be nimble, agile, and efficient. I have always been a picky person when deciding on a frame. The Baby DiamondBack is a frame that fit all of my requirements. It has the strength and looks to make your jaw drop.  Choose between blue or red for your TPU color on your quad.
Be sure to check out all our 3.5&quot frames, and all our Quadifier products!
Features

Designed for 20x20 stack

3mm arms

Fits micro 19x19 size cameras

Specification


Stack Mounting: 20x20
FPV Camera Mount: 19mm Micro cam
Motor Mount Pattern: 9x9 M2 ,12x12 M2
Main Plate Thickness: 2mm
Frame Shape: Squished X
Motor to Motor: 160mm
Arm Thickness: 4mm
Frame Weight With TPU: 65g


Includes

1x Quadifier Baby Diamondback 3.5&quot Freestyle Frame Kit
1x TPU Kit


Quadifier Baby Diamondback Freestyle 3.5" Micro Frame Kit (Rev2) - 4mm Arms - Choose Your Color from WREKD Co.

Luma Quad

Luma Quads Luma 30 Cinewhoop 3" Frame Kit

Luma Quads












The Luma 30 is an ultra-lightweight and super high-performance 3&quot cinewhoop that can be powered by the same 6S setup as its predecessor, the Luma 3, while still being able to carry a full-size GoPro. It has the same symmetrical bolt patterns on its top and bottom plates that allow it to be built in &quotpuller&quot or &quotpusher&quot configurations, plus a 15mm slammed deck height for a low center of gravity and room for O3 Air Unit, Vista or analog VTX. Weighing just 85g (Frame hardware and prints) and 238g when fully built (without Gopro), it offers longer flight times and improved maneuverability over other 3&quot whoops. The only drawback is the durability of the injection-molded guards, which will break if you hit anything hard. To make sure customers are satisfied, they have included five guards in each kit. This version comes with black ducts and blue tpu.
Check out our selection of 3&quot Frame Kits as well as our Luma Quads Products!











Features

HD Vista / analog compatible.
Slammed 15mm stack height.
Both Mini, Micro, and Nano FPV camera mounts are included - supporting all FPV cameras from 20-14mm.
Support for all 3&quot propellers.
Front Standard GoPro mount (suits any GoPro mounting style camera)
Symmetrically designed to be built in either &quotPuller&quot or &quotPusher&quot configurations.
Both SMA and Vista/ Airunit 03 Rear mount with VTX antenna and Immortal T Style Antenna Mount included.
Download the 3d model .stl files for this kit here.

Come on, can any other 3&quot Cinewhoop do moves like this?


The Ideal setup

  Specifications

Stack Mounting: 20x20mm and 25.5x25.5mm

Rear Mounting: 20x20mm
Motor Mount Pattern: 12x12mm M2 &ampamp 16x16mm M3

Top Plate Thickness: 2mm
Bottom Plate Thickness: 2.5mm
Motor to Motor: 157.5mm

Frame Weight: 85g  (238g built with no battery or HD cam)


Includes

1x Luma Quads Luma 30 Cinewhoop 3&quot Micro Frame Kit - Black


LUMA 30 FRAME ASSEMBLY GUIDE. V1.0



Kit contents:
HARDWARE BAG BREAKDOWN:





Bag A - MAIN
Quantity




M2 8mm Bolt

12x


M2 15mm Standoff
6x








Bag B - STACK




M2 14mm Bolt
4x




M2 Plastic Nut

4x






Bag C - REAR STACK





M2 18mm Bolt

4x




M2 Steel Nut

4x






Bag D - MOTORS





M2 10mm Bolt
16x


M2 Washer
16x








Bag E - HD MOUNT




M2 8mm Bolt
2x


M2 10mm Bolt
2x


M2 Steel Nut
4x


M2 Steel Washer
4x


M5 Steel Nut
1x










CARBON PARTS.




2mm Top-plate
1x


2.5mm Bottom-plate
1x





3D PRINTED PARTS.





Front FPV Camera mounts
2x


Front GoPro Hard-mount
1x


Rear Immortal T &ampamp Vista Antenna Mount
1x


Rear Immortal T &ampamp SMA Antenna Mount
1x


25.5x25.5 Stack RX Mount
1x


Rear 20x20 Analog RX/VTX Mount
1x






Plastic Parts.




3&quot Prop Guards
6x




Extras.





Zipties
4x


Luma 250mm Lipo Strap.
2x






Assembly guide.
The Luma 30 is designed to be built in either Standard or Pusher configuration.
The following guide is for Standard configuration, if you want to build the Luma 30 as a Pusher the two carbon plates as well as the guards need to be flipped upside down and you attach the HD mount to the Bottom plate and the standoffs to the Top plate instead.
1) HD Mount
Insert 1x M5 Steel Nut into the GP mount as shown.



Secure the Gopro mount to the top plate using 2x 8mm M2 bolts washers and steel nuts through the front 2 holes of the mount.



2) Main Frame.
Install 6x 15mm Standoff onto bottom plate.


Secure with 6x 8mm M2 bolts from below.


Insert front FPV camera mounts over front 2 standoffs.

Insert Rear antenna mount over rear 2 standoffs.

Align top plate over the standoffs

Secure with 4x 8mm M2 bolts

Insert 2 more 8mm bolts with M2 washers through the back 2 holes on the GoPro mount into the middle two standoffs.

3) Prop Guards and bumpers
Align and orientate the prop guards as shown.



Secure the guards and bumpers using 16x 10mm M2 bolts and M2 washers.
These are screwed through the bumpers, carbon plate and guards into the base of the motors.
NOTE: M2 BOLTS HAVE SKINNY CAPHEADSDO NOT FORGET TO INSTALL THE WASHERS!DEPENDING ON WHAT MOTORS YOU RUN IT MAY BE NESSASARY TO EXPAND THE CENTER HOLE IN THE GUARDSBY A FRACTION OF A MM TO ALLOW THE BASE SCREW TO SPIN FREELY.
BE SURE NOT TO LET THE MOTOR BOLTS TOUCH THE WINDINGS OF THE MOTORS
4) Rear AntennaSecure the Immortal T antenna Into the rear mount using zipties.
5) Other
The included 25.5x25.5mm or 20x20mm RX mounts can be used either on top of main stack to secure an RX if using Vista or in the rear 20x20mm stack mount position for rear mounted..

The Luma 30 is an ultra-lightweight and super high-performance 3" cinewhoop that can be powered by the same 6S setup as its predecessor, the Luma 3, while still being able to carry a full-size GoPro. It has the same symmetrical bolt patterns on its top and bottom plates that allow it to be built in "puller" or "pusher"

Luma Quads Luma 30 Cinewhoop 3" Micro Frame Kit from WREKD Co.

Luma Quads Luma 30 Cinewhoop 3

Luma Quads Luma 30 Cinewhoop 3" Micro Frame Kit












The Luma 30 is an ultra-lightweight and super high-performance 3" cinewhoop that can be powered by the same 6S setup as its predecessor, the Luma 3, while still being able to carry a full-size GoPro. It has the same symmetrical bolt patterns on its top and bottom plates that allow it to be built in "puller" or "pusher" configurations, plus a 15mm slammed deck height for a low center of gravity and room for O3 Air Unit, Vista or analog VTX. Weighing just 85g (Frame hardware and prints) and 238g when fully built (without Gopro), it offers longer flight times and improved maneuverability over other 3" whoops. The only drawback is the durability of the injection-molded guards, which will break if you hit anything hard. To make sure customers are satisfied, they have included five guards in each kit. This version comes with black ducts and blue tpu.
Check out our selection of 3" Frame Kits as well as our Luma Quads Products!











Features

HD Vista / analog compatible.
Slammed 15mm stack height.
Both Mini, Micro, and Nano FPV camera mounts are included - supporting all FPV cameras from 20-14mm.
Support for all 3" propellers.
Front Standard GoPro mount (suits any GoPro mounting style camera)
Symmetrically designed to be built in either "Puller" or "Pusher" configurations.
Both SMA and Vista/ Airunit 03 Rear mount with VTX antenna and Immortal T Style Antenna Mount included.
Download the 3d model .stl files for this kit here.

Come on, can any other 3" Cinewhoop do moves like this?


The Ideal setup

  Specifications

Stack Mounting: 20x20mm and 25.5x25.5mm

Rear Mounting: 20x20mm
Motor Mount Pattern: 12x12mm M2 &amp 16x16mm M3

Top Plate Thickness: 2mm
Bottom Plate Thickness: 2.5mm
Motor to Motor: 157.5mm

Frame Weight: 85g  (238g built with no battery or HD cam)


Includes

1x Luma Quads Luma 30 Cinewhoop 3" Micro Frame Kit - Black


LUMA 30 FRAME ASSEMBLY GUIDE. V1.0



Kit contents:
HARDWARE BAG BREAKDOWN:





Bag A - MAIN
Quantity




M2 8mm Bolt

12x


M2 15mm Standoff
6x








Bag B - STACK




M2 14mm Bolt
4x




M2 Plastic Nut

4x






Bag C - REAR STACK





M2 18mm Bolt

4x




M2 Steel Nut

4x






Bag D - MOTORS





M2 10mm Bolt
16x


M2 Washer
16x








Bag E - HD MOUNT




M2 8mm Bolt
2x


M2 10mm Bolt
2x


M2 Steel Nut
4x


M2 Steel Washer
4x


M5 Steel Nut
1x










CARBON PARTS.




2mm Top-plate
1x


2.5mm Bottom-plate
1x





3D PRINTED PARTS.





Front FPV Camera mounts
2x


Front GoPro Hard-mount
1x


Rear Immortal T &amp Vista Antenna Mount
1x


Rear Immortal T &amp SMA Antenna Mount
1x


25.5x25.5 Stack RX Mount
1x


Rear 20x20 Analog RX/VTX Mount
1x






Plastic Parts.




3" Prop Guards
6x




Extras.





Zipties
4x


Luma 250mm Lipo Strap.
2x






Assembly guide.
The Luma 30 is designed to be built in either Standard or Pusher configuration.
The following guide is for Standard configuration, if you want to build the Luma 30 as a Pusher the two carbon plates as well as the guards need to be flipped upside down and you attach the HD mount to the Bottom plate and the standoffs to the Top plate instead.
1) HD Mount
Insert 1x M5 Steel Nut into the GP mount as shown.



Secure the Gopro mount to the top plate using 2x 8mm M2 bolts washers and steel nuts through the front 2 holes of the mount.



2) Main Frame.
Install 6x 15mm Standoff onto bottom plate.


Secure with 6x 8mm M2 bolts from below.


Insert front FPV camera mounts over front 2 standoffs.

Insert Rear antenna mount over rear 2 standoffs.

Align top plate over the standoffs

Secure with 4x 8mm M2 bolts

Insert 2 more 8mm bolts with M2 washers through the back 2 holes on the GoPro mount into the middle two standoffs.

3) Prop Guards and bumpers
Align and orientate the prop guards as shown.



Secure the guards and bumpers using 16x 10mm M2 bolts and M2 washers.
These are screwed through the bumpers, carbon plate and guards into the base of the motors.
NOTE: M2 BOLTS HAVE SKINNY CAPHEADSDO NOT FORGET TO INSTALL THE WASHERS!DEPENDING ON WHAT MOTORS YOU RUN IT MAY BE NESSASARY TO EXPAND THE CENTER HOLE IN THE GUARDSBY A FRACTION OF A MM TO ALLOW THE BASE SCREW TO SPIN FREELY.
BE SURE NOT TO LET THE MOTOR BOLTS TOUCH THE WINDINGS OF THE MOTORS
4) Rear AntennaSecure the Immortal T antenna Into the rear mount using zipties.
5) Other
The included 25.5x25.5mm or 20x20mm RX mounts can be used either on top of main stack to secure an RX if using Vista or in the rear 20x20mm stack mount position for rear mounted Analog VTX/RX.

IMPORTANT:Do not let electrical components come in contact with the carbon, use spacers that came with your with FC stack and the included RX/VTX Mounts to space your components away from carbon.




Ummagawd

Ummagawd Botgrinder Grinderino 3.5" Micro Frame Kit

UMMAGAWD













Once again, Botgrinder and the Ummagawd team make another absolute banger of a frame. - Imagine a Demibot-level frame but in a smaller package!  This frame will fit a single board whoop-style AIO or a 20 x 20 stack. The rear of the frame provides plenty of space to fit a VTX of your choice, and just the same, the front will accommodate any camera. Now updated to fit both 9x9 &amp 12x12 motor mounts! And, despite its size, it's still under 250g all-up weight!
















Be sure to check out all our 3.5" frames, as well as the rest of our Ummagawd selection!



Specifications


Arms: 4mm

Top Plate: 2mm

Bottom Plate: 2mm

Mid Plate: 2mm

Standoffs: 6mm OD 7075 Aluminum

FC Mounting: 20x20 and 25.5x25.5 (whoop style)

VTX Mounting: 20x20 and 25.5x25.5 (whoop style)

Frame Weight: 65g
Motor Mounting Pattern: 9mm x 9mm &amp12mm x 12mm

Includes

1x Ummagawd Botgrinder Grinderino 3.5" Freestyle Micro Frame Kit

1x Top Plate
4x Arms

1x Bottom Plate

1x Mid Plate (with press nuts)

1x Hardware Kit

1x Ummagrip Battery Pad

2x Battery Straps

1x Set of TPU FPV Camera Mounts


Once again, Botgrinder and the Ummagawd team make another absolute banger of a frame. - Imagine a Demibot-level frame but in a smaller package!  This frame will fit a single board whoop-style AIO or a 20 x 20 stack. The rear of the frame provides plenty of space to fit a VTX of your choice, and just the same, the front

Introducing the Grinderino. If you love your Demibot, but wish you had one that's juuuust a little smaller, your wishes have been granted! When Botgrinder asked if we can make him a 3.5" frame, he said he wants something just as good as the Demibot but in a smaller package. It took a bit of adjustment, but I think we h

Ummagawd Botgrinder Grinderino 3.5













Once again, Botgrinder and the Ummagawd team make another absolute banger of a frame. - Imagine a Demibot-level frame but in a smaller package!  This frame will fit a single board whoop-style AIO or a 20 x 20 stack. The rear of the frame provides plenty of space to fit a VTX of your choice, and just the same, the front will accommodate any camera. Now updated to fit both 9x9 &ampamp 12x12 motor mounts! And, despite its size, it&#39s still under 250g all-up weight!
















Be sure to check out all our 3.5&quot frames, as well as the rest of our Ummagawd selection!



Specifications


Arms: 4mm

Top Plate: 2mm

Bottom Plate: 2mm

Mid Plate: 2mm

Standoffs: 6mm OD 7075 Aluminum

FC Mounting: 20x20 and 25.5x25.5 (whoop style)

VTX Mounting: 20x20 and 25.5x25.5 (whoop style)

Frame Weight: 65g
Motor Mounting Pattern: 9mm x 9mm &ampamp12mm x 12mm

Includes

1x Ummagawd Botgrinder Grinderino 3.5&quot Freestyle Micro Frame Kit

1x Top Plate
4x Arms

1x Bottom Plate

1x Mid Plate (with press nuts)

1x Hardware Kit

1x Ummagrip Battery Pad

2x Battery Straps

1x Set of TPU FPV Camera Mounts


Ummagawd Botgrinder Grinderino 3.5" Micro Frame Kit from WREKD Co.

SpeedyBee

SpeedyBee Bee35 Pro 3.5" Micro Frame Kit - LED Version

RUNCAM

The brand-new Bee35 Pro - Now available with customizable LED light strip!
The SpeedyBee Bee35 3.5-Inch Frame Kit is the perfect tool for any cinewhoop pilot looking for a bit more power to capture stunning pictures and videos, freestyle cruising, and exploring your flight zones. Durable, effective, and resilient, the frame kit is great for both beginners and veterans with its tough prop guards that can survive rough handling.
Looking for the non-pro version, check out the SpeedyBee Bee35!
Be sure to check out all our 3.5" frames, and all our Speedy Bee products!
Features

Custom-made aluminum alloy head to protect the O3 effectively without obstruction.
Customized silicone shock absorption O3 lens, eliminates the 'jelly' effect.
Custom-designed bottom aluminum alloy for heat dissipation, integrating seamlessly with O3 and RunCam Link. Includes a convenient Type-C port and memory card slot for easy frequency tuning.
Compatibility with 20x20mm, 25x25mm, and 30.5x30.5mm stacks.
Battery support featuring both horizontal and vertical binding designs for enhanced durability and easy installation.
Connects to the flight controller without disassembling the drone, supporting both Type-C and micro interfaces.
Ultra-strong injection-molded protective ring with a cutout for simple LED light strip installation.
A comprehensive set of printed parts: GoPro mount / 121GPS mount / multifunctional antenna mount / T-shaped antenna mount.
Adjustable GPS mount for MASTER 5 V2 GPS, including a standard 121GPS mount.
Option for a detachable shock-absorbing gimbal (sold separately).

Quick Release Solution
Only 6 screws are to be removed for freeing drone body and propeller guard.



Aerospace-grade Aluminum Front Plate
The aviation-grade aluminum headpiece provides excellent protection for the lens, and it is embedded with custom silicone damping material, resulting in effective anti-vibration performance for the lens. The GyroFlow effect is enhanced for better stability.

100% efficient heat dissipation
We have found that the O3 video transmitter shuts down due to high CPU temperatures during prolonged high-temperature operation. To address this issue, we have specially designed a 7075-T aerospace-grade aluminum component for the O3 video transmitter, doubling its heat dissipation efficiency! Additionally, it features 20x20 mounting screw holes, making it compatible with Link, TX800, and other 20-hole video transmitters.
Note: The test data is conducted at an ambient temperature of 26 degrees Celsius. The actual performance may vary depending on the temperature of the usage environment.

Custom-made aerospace-grade aluminum components
Specially designed to solve the TF card insertion issue of O3 without disassembly. Easily insert the card without any hassle. It also features a dedicated frequency position for O3 and Link video transmitters, making it super convenient for Type-C connection!

H-FOV135°
135° wide-angle without dark corners.

Two battery installation methods
Super convenient battery strap design allows for horizontal or vertical battery mounting.





Super durable injection-molded ring
Made of high-strength imported composite material with built-in LED strip mounting groove.
Compatible with Meteor LED
Offers seven preset basic effects and allows for wireless customization of your personal lighting styles through the app.




Compatible with flight towers
Supports installation of various flight towers and AIO (All-In-One) boards in sizes of 20x20, 25.5x25.5 (45° 90°), and 30.5x30.520-hole MINI flight tower —— Recommended (Perfect fit)25.5-hole AIO flight controller —— Recommended (Perfect fit)30.5-hole standard flight tower —— Not recommended (Installation is compact and requires some hands-on skills)






Multi-function antenna mount
Type-C adapter cable directly plugs into the flight controller without disassembling the aircraft.






Specifications

Wheelbase: 153mm
Top Plate Thickness: 3.5mm
Bottom Plate Thickness: 2mm
Camera Mounting Distance: 19/20mm
ESC/Motor Mounting Height: 24mm
Flight Stack Mounting Holes: 20x20/25.5x25.5/30.5x30.5mm
Video Transmitter Mounting Holes: 20x20/25.5x25.5
Propeller Size: 90mm
Motor Mounting Holes: 12x12mm
Weight: 138g
CNC Heat Sink: 15g
Camera Gimbal: 28g
Recommended Motor: 1806/2004/2006
Recommended KV: 4S/2500-3500KV, 6S/1800-2300KV
Recommended Battery: 900-1500mAh 4S/6S

Includes

1x SpeedyBee Bee35 Pro 3.5" Frame - LED Version



The brand-new Bee35 Pro - Now available with customizable LED light strip! The SpeedyBee Bee35 3.5-Inch Frame Kit is the perfect tool for any cinewhoop pilot looking for a bit more power to capture stunning pictures and videos, freestyle cruising, and exploring your flight zones. Durable, effective, and resilient, the

SpeedyBee Bee35 Pro 3.5" Micro Frame - LED Version

The brand-new Bee35 Pro - Now available with customizable LED light strip!
The SpeedyBee Bee35 3.5-Inch Frame Kit is the perfect tool for any cinewhoop pilot looking for a bit more power to capture stunning pictures and videos, freestyle cruising, and exploring your flight zones. Durable, effective, and resilient, the frame kit is great for both beginners and veterans with its tough prop guards that can survive rough handling.
Looking for the non-pro version, check out the SpeedyBee Bee35!
Be sure to check out all our 3.5&quot frames, and all our Speedy Bee products!
Features

Custom-made aluminum alloy head to protect the O3 effectively without obstruction.
Customized silicone shock absorption O3 lens, eliminates the &#39jelly&#39 effect.
Custom-designed bottom aluminum alloy for heat dissipation, integrating seamlessly with O3 and RunCam Link. Includes a convenient Type-C port and memory card slot for easy frequency tuning.
Compatibility with 20x20mm, 25x25mm, and 30.5x30.5mm stacks.
Battery support featuring both horizontal and vertical binding designs for enhanced durability and easy installation.
Connects to the flight controller without disassembling the drone, supporting both Type-C and micro interfaces.
Ultra-strong injection-molded protective ring with a cutout for simple LED light strip installation.
A comprehensive set of printed parts: GoPro mount / 121GPS mount / multifunctional antenna mount / T-shaped antenna mount.
Adjustable GPS mount for MASTER 5 V2 GPS, including a standard 121GPS mount.
Option for a detachable shock-absorbing gimbal (sold separately).

Quick Release Solution
Only 6 screws are to be removed for freeing drone body and propeller guard.



Aerospace-grade Aluminum Front Plate
The aviation-grade aluminum headpiece provides excellent protection for the lens, and it is embedded with custom silicone damping material, resulting in effective anti-vibration performance for the lens. The GyroFlow effect is enhanced for better stability.

100% efficient heat dissipation
We have found that the O3 video transmitter shuts down due to high CPU temperatures during prolonged high-temperature operation. To address this issue, we have specially designed a 7075-T aerospace-grade aluminum component for the O3 video transmitter, doubling its heat dissipation efficiency! Additionally, it features 20x20 mounting screw holes, making it compatible with Link, TX800, and other 20-hole video transmitters.
Note: The test data is conducted at an ambient temperature of 26 degrees Celsius. The actual performance may vary depending on the temperature of the usage environment.

Custom-made aerospace-grade aluminum components
Specially designed to solve the TF card insertion issue of O3 without disassembly. Easily insert the card without any hassle. It also features a dedicated frequency position for O3 and Link video transmitters, making it super convenient for Type-C connection!

H-FOV135°
135° wide-angle without dark corners.

Two battery installation methods
Super convenient battery strap design allows for horizontal or vertical battery mounting.





Super durable injection-molded ring
Made of high-strength imported composite material with built-in LED strip mounting groove.
Compatible with Meteor LED
Offers seven preset basic effects and allows for wireless customization of your personal lighting styles through the app.




Compatible with flight towers
Supports installation of various flight towers and AIO (All-In-One) boards in sizes of 20x20, 25.5x25.5 (45° 90°), and 30.5x30.520-hole MINI flight tower —— Recommended (Perfect fit)25.5-hole AIO flight controller —— Recommended (Perfect fit)30.5-hole standard flight tower —— Not recommended (Installation is compact and requires some hands-on skills)






Multi-function antenna mount
Type-C adapter cable directly plugs into the flight controller without disassembling the aircraft.






Specifications

Wheelbase: 153mm
Top Plate Thickness: 3.5mm
Bottom Plate Thickness: 2mm
Camera Mounting Distance: 19/20mm
ESC/Motor Mounting Height: 24mm
Flight Stack Mounting Holes: 20x20/25.5x25.5/30.5x30.5mm
Video Transmitter Mounting Holes: 20x20/25.5x25.5
Propeller Size: 90mm
Motor Mounting Holes: 12x12mm
Weight: 138g
CNC Heat Sink: 15g
Camera Gimbal: 28g
Recommended Motor: 1806/2004/2006
Recommended KV: 4S/2500-3500KV, 6S/1800-2300KV
Recommended Battery: 900-1500mAh 4S/6S

Includes

1x SpeedyBee Bee35 Pro 3.5&quot Frame - LED Version



SpeedyBee Bee35 Pro 3.5" Micro Frame - LED Version from WREKD Co.

SpeedyBee Bee35 Pro 3.5

SpeedyBee Bee35 3.5" Cinewhoop Frame Kit

The brand-new Bee35 FPV drone offers robust power,crash-resistant protective frames, and exceptional battery life.
The SpeedyBee Bee35 3.5-Inch Frame Kit is the perfect tool for any cinewhoop pilot looking for a bit more power to capture stunning pictures and videos, freestyle cruising, and exploring your flight zones. Durable, effective, and resilient, the frame kit is great for both beginners and veterans with its tough prop guards that can survive rough handling.
Choose between Bee35 or the Bee35 Pro, where with the Pro version, you get an advanced heat sink for your VTX.
Be sure to check out all our 3.5" frames, and all our Speedy Bee products!
Features

Customized aluminum alloy front end to effectively protect unobstructed O3.

Customized silicone gel shock absorption for the O3 lens, eliminating jello effect.

Customized aluminum alloy heat dissipation device at the bottom, seamlessly
Integrated with O3 and runcam link transmission, while also facilitating type-c and memory card insertion for convenient adjustments.
Flight tower compatibility: Hole patterns for 2020mm/25.5x25.5mm/30.5x30.5mm.

Adjustable GPS mount compatible with both GPS and MASTER 5 V2 GPS mounts, with 121GPS mount included standard.

Supports detachable shock-absorbing gimbal.

H-FOV 135° wide-angle without dark corners.

Super durable injection-molded ring.















Specifications

Wheelbase: 153mm

Top Plate Thickness: 3.5mm

Bottom Plate Thickness: 2mm

Camera Mounting Distance: 19/20mm

ESC/Motor Mounting Height: 24mm

Flight Stack Mounting Holes: 20x20/25.5x25.5/30.5x30.5mm

Video Transmitter Mounting Holes: 20x20/25.5x25.5

Propeller Size: 90mm

Motor Mounting Holes 12x12mm

Weight: 138g

CNC Heat Sink: 15g

Camera Gimbal: 28g

Recommended Motor: 1806/2004/2006

Recommended KV: 4S/2500-3500KV,6S/1800-2300KV

Recommended Battery: 900-1500mAh 4S/6S

Manual
English 中文 Lens Damping TPU STL
Includes

1x SpeedyBee Bee35 3.5" Micro Frame Kit - Choose Version
1x Hardware, Prints and Accessories


The brand-new Bee35 FPV drone offers robust power,crash-resistant protective frames, and exceptional battery life. The SpeedyBee Bee35 3.5-Inch Frame Kit is the perfect tool for any cinewhoop pilot looking for a bit more power to capture stunning pictures and videos, freestyle cruising, and exploring your flight zones.

SpeedyBee Bee35 Cinewhoop 3.5" Micro Frame Kit - Choose Version

SpeedyBee Bee35/Bee35 Pro Cinewhoop 3.5" Micro Frame Kit - Choose Version

The brand-new Bee35 FPV drone offers robust power,crash-resistant protective frames, and exceptional battery life.
The SpeedyBee Bee35 3.5-Inch Frame Kit is the perfect tool for any cinewhoop pilot looking for a bit more power to capture stunning pictures and videos, freestyle cruising, and exploring your flight zones. Durable, effective, and resilient, the frame kit is great for both beginners and veterans with its tough prop guards that can survive rough handling.
Choose between Bee35 or the Bee35 Pro, where with the Pro version, you get an advanced heat sink for your VTX.
Be sure to check out all our 3.5&quot frames, and all our Speedy Bee products!
Features

Customized aluminum alloy front end to effectively protect unobstructed O3.

Customized silicone gel shock absorption for the O3 lens, eliminating jello effect.

Customized aluminum alloy heat dissipation device at the bottom, seamlessly
Integrated with O3 and runcam link transmission, while also facilitating type-c and memory card insertion for convenient adjustments.
Flight tower compatibility: Hole patterns for 2020mm/25.5x25.5mm/30.5x30.5mm.

Adjustable GPS mount compatible with both GPS and MASTER 5 V2 GPS mounts, with 121GPS mount included standard.

Supports detachable shock-absorbing gimbal.

H-FOV 135° wide-angle without dark corners.

Super durable injection-molded ring.















Specifications

Wheelbase: 153mm

Top Plate Thickness: 3.5mm

Bottom Plate Thickness: 2mm

Camera Mounting Distance: 19/20mm

ESC/Motor Mounting Height: 24mm

Flight Stack Mounting Holes: 20x20/25.5x25.5/30.5x30.5mm

Video Transmitter Mounting Holes: 20x20/25.5x25.5

Propeller Size: 90mm

Motor Mounting Holes 12x12mm

Weight: 138g

CNC Heat Sink: 15g

Camera Gimbal: 28g

Recommended Motor: 1806/2004/2006

Recommended KV: 4S/2500-3500KV,6S/1800-2300KV

Recommended Battery: 900-1500mAh 4S/6S

Manual
English 中文 Lens Damping TPU STL
Includes

1x SpeedyBee Bee35 3.5&quot Micro Frame Kit - Choose Version
1x Hardware, Prints and Accessories


SpeedyBee Bee35 Cinewhoop 3.5" Micro Frame Kit - Choose Version from WREKD Co.

SpeedyBee Bee35 Cinewhoop 3.5

Diatone

Diatone Roma L3 3" Micro Frame

DIATONE

This deadcat-esque frame is perfect for those of you who are looking to build a smooth flying cruiser that keeps props out of view.
Throw in a 20x20 stack or a nice AIO for this frame.
Need spares? Check out our Diatone Roma L3 Collection.
Check out the rest of our Micro Frame Kits and our Diatone products!
Specifications

Prop Size: 3inch
FC Mounting: 20×20/26.5×26.5mm（M2）
Motor Mounting: 9mm/12mm
Camera Spacing: 20mm
Top Plate: 1.5mm
Medium Plate: 1.5mm
Bottom Plate: 1.5mm
Arm：3mm
Aluminum alloy：7075
carbon fiber: T300 3K
Wheelbase：147mm
Weight：43g

Includes

1x Diatone Roma L3 3" Micro Frame


This deadcat-esque frame is perfect for those of you who are looking to build a smooth flying cruiser that keeps props out of view. Throw in a 20x20 stack or a nice AIO for this frame. Need spares? Check out our Diatone Roma L3 Collection. Check out the rest of our Micro Frame Kits and our Diatone products! Specificati

The Roma L3 from Diatone is a freestyle quad with an ultra resistant design.  Check out our entire Roma L3 Collection with Replacement Parts! Check out all our Frames, and the rest of our Diatone Products! Specifications: Wheelbase ：147mm Weight ：43g Prop Size ：3inch FC Mounting: 20×20/26.5×26.5mm（M2） Motor Mounting:9m

Diatone Roma L3 3inch Frame Kit

Diatone's newest micro-frame uses a deadcat configuration that keeps propellers out of view while you cruise!

Diatone Roma L3 3" Frame Kit

Diatone Roma L3 3&quot Frame Kit

DiatoneUSA

This deadcat-esque frame is perfect for those of you who are looking to build a smooth flying cruiser that keeps props out of view.
Throw in a 20x20 stack or a nice AIO for this frame.
Need spares? Check out our Diatone Roma L3 Collection.
Check out the rest of our Micro Frame Kits and our Diatone products!
Specifications

Prop Size: 3inch
FC Mounting: 20×20/26.5×26.5mm（M2）
Motor Mounting: 9mm/12mm
Camera Spacing: 20mm
Top Plate: 1.5mm
Medium Plate: 1.5mm
Bottom Plate: 1.5mm
Arm：3mm
Aluminum alloy：7075
carbon fiber: T300 3K
Wheelbase：147mm
Weight：43g

Includes

1x Diatone Roma L3 3&quot Micro Frame


Diatone Roma L3 3" Micro Frame from WREKD Co.

Diatone Roma L3 3

FPV Cycle

FPV Cycle CineSplore 3" Frame

NEW!!CineSplore Blog containing recommendations and more details about the setupThis is a mega-cinewhoop frame not unlike any other 3” ducted design. It is NOT intended to be an acrobatic machine. It is intended for slow-ish, stable, controlled flight with the payload of a GoPro Hero 8 or similar with a TPU mount. The

FPVCycle CineSplore Frame

FPVCycle

NEW!!CineSplore Blog containing recommendations and more details about the setupThis is a mega-cinewhoop frame not unlike any other 3” ducted design. It is NOT intended to be an acrobatic machine. It is intended for slow-ish, stable, controlled flight with the payload of a GoPro Hero 8 or similar with a TPU mount. The frame is specifically designed to be lightweight (by comparison to others), durable, easy to build/repair and cost effective to maintain. It has two 20x20 mounting platforms and one Toothpick style whoop board mount (two separate stack platforms). It is designed to fit analog components or the Vista unit. The GoPro/HD mounting platform is the same as on the CineGlide and Fouride. Camera mounts for one will be easy to swap from frame to frame.This platform performs best with the FPVCycle 2203 3450kv motor, 4S 1100mah battery, V2 Ducts, and 25mm standoffs because the V2 Ducts are shorter. The basic ducts are from the CLOUD-149. They provide adequate prop protection/safety for most situations and are decently durable while being extremely cost effective. Unfortunately, even with the genuine FPVCycle 2203 3450kv motor, you will still have some washout in extreme situations and minor yaw lock problems in gusty or confined environments such as a narrow corridor/hallway. The V3 Ducts fix most of these issues and are a bolt on replacement for the original ducts. If you are an experienced FPV pilot with developed fine motor control skills in this area, you will appreciate the V3 Ducts quite a bit. If you are novice to intermediate level, you’ll definitely notice a difference but it may not be quite as significant to you.Compared to a typical Cinewhoop with your standard issue ~1506 and any prop, this platform running FPVCycle 2203 3450kv and the V2 ducts is dramatically improved. The motors account for about 75% of that improvement.  Dropping the standoff height to 25mm is just icing on the cake if you care to do so
Note: Tge ducts do NOT fit the frame perfectly on purpose. When screwed into place the ducts are held under tension and are somewhat oval. When fresh props are inserted, they will rub against that walls of that duct. Arm the quad and get the props spinning, then hover for a few seconds to allow them to grind into place. It will be loud during this process and then it will quiet down considerably. This sort of fit actually improves efficiency a but but more importantly, reduces overall vibrations in the system because it&#39s all held under tension. Again, this imperfection is on purpose and 100% if the ducts do not fit perfectly.
Print files:GoPro 5, 6, 7, adjustable angle mount

Please please please check your FC orientation, motor orientation and prop orientation BEFORE the first flight. Always test arm with your controller and NO props on and check to make sure everything is working right. Note that this frame is designed to use a whoop board but in a square configuration. Not diamond.  If you are using a whoop board, at the absolute minimum you will need to yaw the board at least 45deg in the flight firmware settings to have it in the correct orientation.  Also, because of how whoop boards mount motors on the corners, it&#39s easy to end up with mixed numbered motors. Remapping motors is not difficult. There will be a video uploadeded to this description page soon with quick details on how to remap.

Details:

55g without ducts
101g with basic ducts
125g with V2 Ducts
155mm diagonal size motor center to motor center
~215mm sideways width from end duct to end of duct
~182mm front to back from end of duct to end of duct
12x12 M2 motor mounting platform ONLY
Two 20x20 stacks or one 20x20 and one Toothpick board
Toothpick/whoop mount fits 25.4x25.4 through 26.5x26.5 size
TPU FPV cam mount made for mini size, will stretch to fit micro too
100% DJI Vista support and strongly encouraged
Recommended motor: FPVCycle 2203 - 3450kv
Recommended prop: Gemfan 75mm Cinewhoop prop

Recommended build:

FPVCycle 2203 motor
Gemfan 3” (75mm) Cinewhoop prop
GoPro/camera mounts
30A 4S good cheap whoop board

V2 Ducts (optional)

V3 Ducts (optional)

25mm standoffs (optional with V2 Ducts)

Click Here for Build Guide
Click Here for Build Guide and Discussion

Video Build Guide:

Installing CineSplore StanFPV Ducts:

FPVCycle CineSplore Frame from WREKD Co.

Axis Flying

AxisFlying Manta HD Squashed X O3 Freestyle 3.6" Frame Kit

AxisFlying

Take your FPV experience to the next level with the Axisflying Manta 3.6 frame kit. This 3.6&quot frame offers longer flight times and flies like a 5&quot drone for an exceptionally durable and fast ride. Enjoy superior speed and control every time you take to the skies.
Axisflying combines CNC aluminum parts with high-quality carbon plates to bring the MANTA series of freestyle frames with a unique and innovative design in the industry.
This frame has a longer body for electronics space and has been specially designed around carrying the DJI O3 Air Unit!
Be sure to check out all our 3.5&quot frames, and all our Axis Flying Products!
Features

MANTA 3.6 frame is specially designed for 3.6-inch Freestyle and Cinematic, launched in Squashed X.

Squashed X design for a flexible flight experience, props are not visible from the FPV camera, more suitable for freestyle with high maneuverability.

The frame adopts the innovative CNC aluminum structure design with high-strength carbon plates making the overall structure very strong, stable, and safe.




Specifications

Name: Manta 3.6&quot
Structure: Squashed X
Wheelbase&quot 162mm
Bottom Plate Thickness: 3mn
Top Plate Thickness: 2mm
Carbon Material: T700
Bottom Plate Distance: 20mm
Arm Thickness: 4mm
Lens Space: 14-20mm
Stack Mounting: 20x20m (m2) &ampamp 30.5x30.5mm (M3)
VTX Mounting: 20x20m &ampamp 25.5x25.5m (M2)
Prop Size: 3.6 inch Max
Motor Mounting: 12x12mm (M2)
Weight: 108g (TPU inc)

Includes

1x AxisFlying Manta Squashed X 3.5&quot Micro Freestyle Frame Kit


Take your FPV experience to the next level with the Axisflying Manta 3.6 frame kit. This 3.6" frame offers longer flight times and flies like a 5" drone for an exceptionally durable and fast ride. Enjoy superior speed and control every time you take to the skies. Axisflying combines CNC aluminum parts with high-quality

AxisFlying Manta Squashed X HD O3 Freestyle 3.6" Micro Frame Kit from WREKD Co.

AxisFlying Manta Squashed X HD O3 Freestyle 3.6

AxisFlying Manta Squashed X HD O3 Freestyle 3.6" Micro Frame Kit

AXIS FLYING

Take your FPV experience to the next level with the Axisflying Manta 3.6 frame kit. This 3.6" frame offers longer flight times and flies like a 5" drone for an exceptionally durable and fast ride. Enjoy superior speed and control every time you take to the skies.
Axisflying combines CNC aluminum parts with high-quality carbon plates to bring the MANTA series of freestyle frames with a unique and innovative design in the industry.
This frame has a longer body for electronics space and has been specially designed around carrying the DJI O3 Air Unit!
Be sure to check out all our 3.5" frames, and all our Axis Flying Products!
Features

MANTA 3.6 frame is specially designed for 3.6-inch Freestyle and Cinematic, launched in Squashed X.

Squashed X design for a flexible flight experience, props are not visible from the FPV camera, more suitable for freestyle with high maneuverability.

The frame adopts the innovative CNC aluminum structure design with high-strength carbon plates making the overall structure very strong, stable, and safe.




Specifications

Name: Manta 3.6"
Structure: Squashed X
Wheelbase" 162mm
Bottom Plate Thickness: 3mn
Top Plate Thickness: 2mm
Carbon Material: T700
Bottom Plate Distance: 20mm
Arm Thickness: 4mm
Lens Space: 14-20mm
Stack Mounting: 20x20m (m2) &amp 30.5x30.5mm (M3)
VTX Mounting: 20x20m &amp 25.5x25.5m (M2)
Prop Size: 3.6 inch Max
Motor Mounting: 12x12mm (M2)
Weight: 108g (TPU inc)

Includes

1x AxisFlying Manta Squashed X 3.5" Micro Freestyle Frame Kit


AxisFlying CineON C35 V2 Cinewhoop 3.5" Frame Kit











The AxisFlying CineON C30 V2 Cinewhoop 3&quot Micro Frame Kit is a powerful and lightweight piece of engineering, built for maximum durability and performance. It has a unique 4-screw blade guard swap for easy maintenance, and supports 19x19mm camera mounting for DJI O3 cameras. Featuring CNC aluminum camera side plates, and a 3D printed GPS mount on the tail, this kit is an all-in-one solution for advanced aerial photography.
Choose the color of your prop guards between blue-green clear and grey clear!










Check out our other 3&quot frames and all our Axis Flying Products!
Features

Fully upgraded redesign and new appearance
Camera side plates have been upgraded to CNC aluminum parts
Compatible with DJI O3 Cameras
Supports cameras with a 19x19mm mounting
The tail has been equipped with a 3D printed GPS mount





Specifications

Wheelbase: 138mm
Top plate: 3.2mm
Bottom plate: 2mm
Arm: 3.2mm
FC mounting holes: 25.5mm x 25.5mm M2 / 20mm x 20mm M2
VTX mounting holes: 25.5mm x 25.5mm / 20mm x 20mm
Motor mounting holes: 9mm x 9mm / 12mm x 12mm
Camera installation space: 14-20mm
Suitable propeller size: 3″propeller
Weight: 127g (without TPU)

Includes


1x AxisFlying CineON C30 V2 Cinewhoop 3&quot Micro Frame Kit
1x Battery Ant-Slip Pad
1x 3D Printed Parts Set
1x Hardware Set

1x Main Plate
2x LiPo Strap
1x Top Plate



The AxisFlying CineON C30 V2 Cinewhoop 3" Micro Frame Kit is a powerful and lightweight piece of engineering, built for maximum durability and performance. It has a unique 4-screw blade guard swap for easy maintenance, and supports 19x19mm camera mounting for DJI O3 cameras. Featuring CNC aluminum camera side plates, a

AxisFlying CineON C30 V2 Cinewhoop 3" Micro Frame Kit - Choose Color from WREKD Co.

AxisFlying CineON C30 V2 Cinewhoop 3

AxisFlying CineON C30 V2 Cinewhoop 3" Micro Frame Kit - Choose Color




The Axisflying CineON C35 V2 Cinewhoop 3.5&quot Micro Frame Kit is tailored for cinematic use. This versatile C35 V2 drone is ideal for capturing cinematic shots both indoors and outdoors. With careful market research and input from skilled pilots, Axisflying has created a high-performing drone that offers stable flight, minimal noise, and up to 9 minutes of flying time.



Be sure to check out all our 3.5&quot frames, and all our Axis Flying Products!
Features

Better wind resistance for smoother footage - C224 Motor, more torque and power

Provide adequate security for the whoop - High performance 40A/F722 AIO

No jello for more stable footage - Triangular shock-absorbing gimbal

The strength has been improved ,don&#39t worry about crash - The frame is fixed with 6 customized M3-7075 standoffs

Reducing the risk of lost drone - The drone and the frame kit are equipped with beeper as standard

Newly designed ducted aerodynamic layout to effectively reduce flight noise

Independent receiver storage, convenient for binding

Support 12mm/9mm motor mounting

27mm height, compatible with most VTXs


Specifications

Wheelbase: 152mm
Weight: 140.7g
Bottom plate thickness: 2mm
Top plate thickness: 3.5mm
Carbon plate material: T700
Bottom-to-top distance: 27mm
Motor mounting: 9x9mm &ampamp 16x16mm
VTX mounting: 20mm/25.5mm (M2)
Stack mounting: 20mm/25.5mm (M2)

Camera Space: 14~20mm
Prop size: Max 3.5mm

Includes

1x AxisFlying CineON C35 V2 Cinewhoop 3.5&quot Micro Frame Kit - Clear Gray Prop Guard


The Axisflying CineON C35 V2 Cinewhoop 3.5" Micro Frame Kit is tailored for cinematic use. This versatile C35 V2 drone is ideal for capturing cinematic shots both indoors and outdoors. With careful market research and input from skilled pilots, Axisflying has created a high-performing drone that offers stable flight, m

AxisFlying CineON C35 V2 Cinewhoop 3.5" Micro Frame Kit - Clear Gray Prop Guard from WREKD Co.

AxisFlying CineON C35 V2 Cinewhoop 3.5

AxisFlying CineON C35 V2 Cinewhoop 3.5" Micro Frame Kit - Clear Gray Prop Guard











The AxisFlying CineON C30 V2 Cinewhoop 3" Micro Frame Kit is a powerful and lightweight piece of engineering, built for maximum durability and performance. It has a unique 4-screw blade guard swap for easy maintenance, and supports 19x19mm camera mounting for DJI O3 cameras. Featuring CNC aluminum camera side plates, and a 3D printed GPS mount on the tail, this kit is an all-in-one solution for advanced aerial photography.
Choose the color of your prop guards between blue-green clear and grey clear!










Check out our other 3" frames and all our Axis Flying Products!
Features

Fully upgraded redesign and new appearance
Camera side plates have been upgraded to CNC aluminum parts
Compatible with DJI O3 Cameras
Supports cameras with a 19x19mm mounting
The tail has been equipped with a 3D printed GPS mount





Specifications

Wheelbase: 138mm
Top plate: 3.2mm
Bottom plate: 2mm
Arm: 3.2mm
FC mounting holes: 25.5mm x 25.5mm M2 / 20mm x 20mm M2
VTX mounting holes: 25.5mm x 25.5mm / 20mm x 20mm
Motor mounting holes: 9mm x 9mm / 12mm x 12mm
Camera installation space: 14-20mm
Suitable propeller size: 3″propeller
Weight: 127g (without TPU)

Includes


1x AxisFlying CineON C30 V2 Cinewhoop 3" Micro Frame Kit
1x Battery Ant-Slip Pad
1x 3D Printed Parts Set
1x Hardware Set

1x Main Plate
2x LiPo Strap
1x Top Plate






The Axisflying CineON C35 V2 Cinewhoop 3.5" Micro Frame Kit is tailored for cinematic use. This versatile C35 V2 drone is ideal for capturing cinematic shots both indoors and outdoors. With careful market research and input from skilled pilots, Axisflying has created a high-performing drone that offers stable flight, minimal noise, and up to 9 minutes of flying time.



Be sure to check out all our 3.5" frames, and all our Axis Flying Products!
Features

Better wind resistance for smoother footage - C224 Motor, more torque and power

Provide adequate security for the whoop - High performance 40A/F722 AIO

No jello for more stable footage - Triangular shock-absorbing gimbal

The strength has been improved ,don't worry about crash - The frame is fixed with 6 customized M3-7075 standoffs

Reducing the risk of lost drone - The drone and the frame kit are equipped with beeper as standard

Newly designed ducted aerodynamic layout to effectively reduce flight noise

Independent receiver storage, convenient for binding

Support 12mm/9mm motor mounting

27mm height, compatible with most VTXs


Specifications

Wheelbase: 152mm
Weight: 140.7g
Bottom plate thickness: 2mm
Top plate thickness: 3.5mm
Carbon plate material: T700
Bottom-to-top distance: 27mm
Motor mounting: 9x9mm &amp 16x16mm
VTX mounting: 20mm/25.5mm (M2)
Stack mounting: 20mm/25.5mm (M2)

Camera Space: 14~20mm
Prop size: Max 3.5mm

Includes

1x AxisFlying CineON C35 V2 Cinewhoop 3.5" Micro Frame Kit - Clear Gray Prop Guard


AxisFlying CineON C35 V2 Cinewhoop 3.5" Micro Frame Kit - Clear Gray P

Fractal Engineering

Fractal Engineering Fractal Wingman 1S 18650 Foldable 3" Micro Frame Kit

FRACTALENGINEERING












The first and only 3″ 1S 18650 quadcopter with foldable, soft-mounted arms and 20+ mins of flight time! Fractal Engineering's foldable take on the 18650 1S 3" long-range trend. Introducing the Wingman, a quad like this is more known for having a powerband more suited for cruising/exploration/surveillance than freestyle/racing. Though this is still very capable of freestyle, as shown in Infinity Loops video on this quad.
Check out our other 3" frames, and our Fractal Engineering Products!













Here's what Fractal has to say about this frame

Have you ever wished you had an extra sidekick quad to help you recover your main machine from a tree?
Or perhaps one you could deploy from the comfort of your car to recon a new spot without the hassle of going out and walking there?
Or maybe just an ultra-compact video rig to give your loved one an excuse to rip a few packs under the pretense of documenting your vacation?

Well, the Wingman is all of that, and much more!
The idea for this frame stemmed from Dave C’s nano long-range, concept -obviously!-
I was immediately hooked on the idea of being able to pop a single, general-purpose 18650 li-ion cell on a quad and cruise around longer than with any of my freestyle rigs
Back then the only frame option was the original 3D printed one
I knew I could greatly improve upon the concept by utilizing carbon fiber, but I also knew that by the time I would be ready to release, I wouldn’t be the only one with a CF arms nano LR
So I decided to up it a notch I’ve had this idea of folding arms in my head for a while, and the lightweight, low load use case of that format would be the best proving ground for it
Over a year in the making, after many iterations and countless hours of testing and tuning later what is the result?





The first-ever foldable and soft mounted arms in FPV
The major unique feature of this frame kit is obviously the folding arms
And the way it manages to achieve this feature in such an integrated manner is where the whole secret sauce resides
This 3″ 1S format offers the possibility to push incredibly intricate ideas down to an incredibly simple execution thanks to the low prop load
In this case, I’ve chosen to make the top and bottom plates clamped to the standoffs,
While using the same standoffs as pivots for the arms, themselves sandwiched between 2 TPU shims and a nylon spacer to press them down in position
Those TPU shims also serve 2 purposes at the same time they primarily provide friction for the quick deployment of the arms, while also dampening the junctions
This helps reduce the number of vibrations transmitted to the FPV and HD camera (more on that in a bit) and the FC gyro, enabling smooth footage and easy tuning


























Ultra-lightweight, durable and compact design
The spaceframe carbon fiber body was meticulously designed to only keep material where absolutely necessary
This includes protecting all the electronics and maintaining a rigid platform,
While pocketing everything else for lightweight and airflow
Making it only 24g frame only, or 60g ready to fly excl. battery
Quick-release arm mechanism
For being designed around ease of use and quick deployment, I went for a friction fit with a light detent to hold the arms open
Just simply pull the arms out until the detent clicks, and push them back in when you’re done
That means no manual latch, no thumbscrew, no positive lock
This also means that in the event of a crash the arms might fold and you would need to go get it…
…But you’re also more likely to be able to take off again without any damage, as I’ve found during testing that the folding appears to absorb a lot of energy that might have snapped something otherwise












In any event, let that be clear that this remains a stable and soft cruiser above all you won’t have much fun going bando bashing with it I can almost guarantee it
To sum it up
just a great tool to always have with you, just so many uses for it

Toss it in your bag when you’re going on vacation for drone videos (also a great excuse for your wife to bring a quad)
Use it to recon new spots to rip without going out of the car (walking? like with your legs?)
Search and rescue! Take advantage of the long flight time to look for a lost quad (I hope you find it brother/sister)
Attach a string to the back, fly around that branch you got your main quad stuck on, bring it back and give it a good tug (watch your head)
Or even get that whoop you got stuck on that roof (I know you could just climb up the gutter but come on it’s 2022)
Guerilla dive! pull it out of pocket, deploy it in a second, rip that huge building tower (you know which one), fold it back in your pocket and bail
Or simply just cruise around for a relaxing chill flight, perhaps to wind down after a hard charger sesh (if you got the patience for it)
… or whatever else you want it to be!















Includes

1x Fractal Engineering Fractal Wingman 1S 18650 Foldable 3" Micro Frame Kit
1x Top plate
1x Bottom plate
2x Front plates
4x Arms
1x 18650 Tray
4x M2 x 10mm alu standoffs
4x M4 x 6mm nylon spacer
10x M2 x 5mm steel screw (for the standoffs)
4x M1.7 x 5mm steel self-threading screw (for the 18650 Tray)
1x TPU cam holder
2x TPU shim set
4x M2 x 10mm steel screw (for the stack)
10x M2 nylon nuts (for the stack)
10x M2 x 4mm socket screws (for the motors)



The first and only 3″ 1S 18650 quadcopter with foldable, soft-mounted arms and 20+ mins of flight time! Fractal Engineering's foldable take on the 18650 1S 3" long-range trend. Introducing the Wingman, a quad like this is more known for having a powerband more suited for cruising/exploration/surveillance than freestyle

Fractal Engineering Fractal Wingman 1S 18650 Foldable 3" Micro Frame K












The first and only 3″ 1S 18650 quadcopter with foldable, soft-mounted arms and 20+ mins of flight time! Fractal Engineering&#39s foldable take on the 18650 1S 3&quot long-range trend. Introducing the Wingman, a quad like this is more known for having a powerband more suited for cruising/exploration/surveillance than freestyle/racing. Though this is still very capable of freestyle, as shown in Infinity Loops video on this quad.
Check out our other 3&quot frames, and our Fractal Engineering Products!













Here&#39s what Fractal has to say about this frame

Have you ever wished you had an extra sidekick quad to help you recover your main machine from a tree?
Or perhaps one you could deploy from the comfort of your car to recon a new spot without the hassle of going out and walking there?
Or maybe just an ultra-compact video rig to give your loved one an excuse to rip a few packs under the pretense of documenting your vacation?

Well, the Wingman is all of that, and much more!
The idea for this frame stemmed from Dave C’s nano long-range, concept -obviously!-
I was immediately hooked on the idea of being able to pop a single, general-purpose 18650 li-ion cell on a quad and cruise around longer than with any of my freestyle rigs
Back then the only frame option was the original 3D printed one
I knew I could greatly improve upon the concept by utilizing carbon fiber, but I also knew that by the time I would be ready to release, I wouldn’t be the only one with a CF arms nano LR
So I decided to up it a notch I’ve had this idea of folding arms in my head for a while, and the lightweight, low load use case of that format would be the best proving ground for it
Over a year in the making, after many iterations and countless hours of testing and tuning later what is the result?





The first-ever foldable and soft mounted arms in FPV
The major unique feature of this frame kit is obviously the folding arms
And the way it manages to achieve this feature in such an integrated manner is where the whole secret sauce resides
This 3″ 1S format offers the possibility to push incredibly intricate ideas down to an incredibly simple execution thanks to the low prop load
In this case, I’ve chosen to make the top and bottom plates clamped to the standoffs,
While using the same standoffs as pivots for the arms, themselves sandwiched between 2 TPU shims and a nylon spacer to press them down in position
Those TPU shims also serve 2 purposes at the same time they primarily provide friction for the quick deployment of the arms, while also dampening the junctions
This helps reduce the number of vibrations transmitted to the FPV and HD camera (more on that in a bit) and the FC gyro, enabling smooth footage and easy tuning


























Ultra-lightweight, durable and compact design
The spaceframe carbon fiber body was meticulously designed to only keep material where absolutely necessary
This includes protecting all the electronics and maintaining a rigid platform,
While pocketing everything else for lightweight and airflow
Making it only 24g frame only, or 60g ready to fly excl. battery
Quick-release arm mechanism
For being designed around ease of use and quick deployment, I went for a friction fit with a light detent to hold the arms open
Just simply pull the arms out until the detent clicks, and push them back in when you’re done
That means no manual latch, no thumbscrew, no positive lock
This also means that in the event of a crash the arms might fold and you would need to go get it…
…But you’re also more likely to be able to take off again without any damage, as I’ve found during testing that the folding appears to absorb a lot of energy that might have snapped something otherwise












In any event, let that be clear that this remains a stable and soft cruiser above all you won’t have much fun going bando bashing with it I can almost guarantee it
To sum it up
just a great tool to always have with you, just so many uses for it

Toss it in your bag when you’re going on vacation for drone videos (also a great excuse for your wife to bring a quad)
Use it to recon new spots to rip without going out of the car (walking? like with your legs?)
Search and rescue! Take advantage of the long flight time to look for a lost quad (I hope you find it brother/sister)
Attach a string to the back, fly around that branch you got your main quad stuck on, bring it back and give it a good tug (watch your head)
Or even get that whoop you got stuck on that roof (I know you could just climb up the gutter but come on it’s 2022)
Guerilla dive! pull it out of pocket, deploy it in a second, rip that huge building tower (you know which one), fold it back in your pocket and bail
Or simply just cruise around for a relaxing chill flight, perhaps to wind down after a hard charger sesh..

Fractal Engineering Fractal Wingman 1S 18650 Foldable 3" Micro Frame Kit from WREKD Co.

Fractal Engineering Fractal Wingman 1S 18650 Foldable 3

GEPRC

GEPRC GEP-CL35 CineLog 35 3.5" Frame

Summary：
The CineLog35 Frame developed by CEPRC for mounting GP camera is now officially released.
CL35 is improved and developed on the basis of CL30. It supports the installation of mainstream AIO FC with 26.5mm x 26.5mm holes. The VTX installation hole is 20mm x 20mm, which can be directly installed with VISTA HD image transmission.The propeller guard adopts an integrated design, and the overall structure is firmer.Upgrade the power system, choose the 12mm x 12mm motor hole position, compared to CL30, it can install a larger 15-18-20 series motor, with a 3.5-inch propeller, it has a stronger power output. Improve the damping rings, the shooting effect is more stable and clearer.It has an stronger mounting compatibility, you can use 3D prints to install the full size GP8、GP9、GP10 camera or use the base to install naked camera GP8, Insta 360 GO2 and Caddx Peanut cameras.
We pursue lighter body weight, better flying feel, and more extended functions.

Specification:

 	Model: GEP-CL35
 	Motor to Motor: 142mm
 	Top plate: 2.5mm
 	Bottom plate: 2.0mm
 	Arm Plate:3.5mm
 	FC mounting hole: 25.5mm x 25.5mm
 	VTX hole position: 20mm x 20mm
 	Motor hole position: 12mm x 12mm
 	Camera installation space: 14~19mm
 	Propeller guard internal diameter: 95mm
 	Suitable propeller size: 3.5 inch propeller
 	Dimension: 203mm x 203mm x 42mm（Include propeller guard）
 	Weight:130.7g（Include propeller guard,GP camera camera mount,3D printings）

Feature:


Integrated protection guard design, the overall structure is firmer and durable.


Improve the damping rings, the shooting effect is more stable and clearer.


CineLog35 has a great mount compatibility, you can install GP10, GP9, GP8, or Naked camera GP8,Insta 360 GO2 camera and Caddx Peanut camera.


12mm x 12mm motor holes can be installed with 15-18-20 motors, and the power output is strong with 3.5-inch propellers.


The design of open holes on the side of the propeller guard greatly reduces the noise during flight.


Independent receiver cabin,and binding is convenient and fast.


Include:

 	1 x Top Plate 2.5mm
 	1 x Arm Plate 3.5mm
 	1 x Bottom Plate 2.0mm
 	2 x Propeller guards
 	1 x Power cable combination
 	1  x  Screw combination
 	1  x  Screwdriver combination
 	1  x  3D Print mountings combination
 	1 x Other Parts

Summary： The CineLog35 Frame developed by CEPRC for mounting GP camera is now officially released. CL35 is improved and developed on the basis of CL30. It supports the installation of mainstream AIO FC with 26.5mm x 26.5mm holes. The VTX installation hole is 20mm x 20mm, which can be directly installed with VISTA HD image [...]

GEP-CL35 Frame - GEPRC

GEP-CL35 Frame

The&nbspCineLog35&nbsphas improved upon the basis of the CineLog30. Featuring an integrated protection guard design, the overall structure is firmer and durable.

The CineLog35 has improved upon the basis of the CineLog30. Featuring an integrated protection guard design, the overall structure is firmer and durable.

GEPRC Cinelog 35 3.5" GEP-CL35 CineWhoop - Frame Kit

GEPRC Cinelog 35 3.5&quot GEP-CL35 CineWhoop - Frame Kit

The CineLog35 Frame developed by CEPRC for mounting GoPro camera is now officially released. CL35 is improved and developed on the basis of CL30. It supports the installation of mainstream AIO FC with 26.5mm x 26.5mm holes. The VTX installation hole is 20mm x 20mm, which can be directly installed with VISTA HD image tr

GEPRC GEP-CL35 Cinewhoop 3.5

Camera Size

The FPV camera captures the image you see through the goggles. An FPV camera may be included with the VTX, particularly with digital VTXs.

FPV Cameras

GEPRC GEP-CL30 CineLog 30 3" Frame

framesThe latest 3-inch rack CL30 developed by GEPU is now officially released. CL30 is improved and developed on the basis of CL25. It continues the 26.5×26.5mm FC hole position and 20x20mm image transmission hole position. It can be installed with the mainstream FC AIO and VISTA and most of the analog VTX on the mark

GEPRC GEP-CL30 Cinewhoop 3

This&nbspGEP-CL30&nbspFrame kit&nbspis for the&nbspGEPRC CineLog30&nbspcinewhoop.

This GEP-CL30 Frame kit is for the GEPRC CineLog30 cinewhoop.

GEPRC CineLog 30 3" GEP-CL30 Frame Kit

GEPRC CineLog 30 3&quot GEP-CL30 Frame Kit

Summary：
The latest 3-inch rack CL30 developed by GEPRC is now officially released.
CL30 is improved and developed on the basis of CL25. It continues the 26.5x26.5mm FC hole position and 20x20mm image transmission hole position. It can be installed with the mainstream FC AIO and VISTA and most of the analog VTX on the market. The 9x9mm motor holes can be installed with 1404-1408 motors, and the power output is strong with 3-inch blades. Improved the shock absorption design of the damping platform to provide more stable shooting effect.Ultra-light body weight. Naked camera GP8 and Insta 360 Go2 camera can be installed with GP camera mount.
We pursue lighter body weight, better flying feel, and more extended functions frame.

Specification:

 	Brand: GEPRC
 	Model: GEP-CL30
 	Motor to Motor: 126mm
 	Top plate: 2.0mm
 	Bottom plate: 2.0mm
 	Arm Plate3.0mm
 	FC mounting hole: 25.5mm x 25.5mm
 	VTX hole position: 20mm x 20mm
 	Motor hole position: 9mm x 9mm
 	Camera installation space: 14~19mm
 	Propeller guard internal diameter: 79mm
 	Suitable propeller size: 3 in propeller
 	Dimension: 180mm x 180mm x 38mm（Includes propeller guard）
 	Weight:62.6g（Includes propeller guard, GP camera mount, 3D printings）

Feature:


Small size, light weight, good flying feel.


Improved the shock absorption design of the damping platform to provide a more stable shooting effect.


The 9x9mm motor holes can be installed with 1404-1408 motors, and the power output is strong with 3-inch blades.


Naked camera GP8 and Insta 360 Go2 camera can be installed with GP camera mount.


A 3D print is designed for the receiver to facilitate the installation and binding of the receiver.


Include:
Carbon Plate:

 	1 x Top Plate 2.0mm
 	1 x Arm Plate 3.0mm
 	1 x bottom Plate 2.0mm

Screws:

 	2 x Knurled nut M2
 	4 x Aluminum Column M2x3.5x25
 	2 x M2x4mm cup head screws
 	28 x M2x6.5mm round head screws
 	10 x M2x8mm round head screws
 	7 x M2x9mm round head screws
 	4 x M2x10mm round head screws
 	1 x M2x12mm cup head screw
 	4 x M2x16mm cup head screws
 	1 x M2 Rivet nut
 	4 x M2 Lock nuts
 	8 x M2 Iron nuts
 	8 x M2 * 6.5mm damping rings
 	9 x damping platform rings

3D Printings:

 	1 x 19x19mm Camera Mount
 	1 x VTX Antenna Mount
 	1 x TBS T-shaped Antenna Mount
 	1 x TBS NanoRX Mount
 	1 x Camera Protector

Injection Parts:

 	6 x 3 in Propeller Guard
 	1 x GP Camera Mount

Other Parts:

 	4 x EVA Damping Ring of Guards
 	2 x 3M Double Tapes
 	2 x Silicone Pads
 	2 x Landing Pads
 	1 x M15x200mm Battery Strap
 	1 x M15x150mm Battery Strap
 	1 x L-shaped (1.5mm)
 	1 x Antenna Tubes

Summary： The latest 3-inch rack CL30 developed by GEPRC is now officially released. CL30 is improved and developed on the basis of CL25. It continues the 26.5×26.5mm FC hole position and 20x20mm image transmission hole position. It can be installed with the mainstream FC AIO and VISTA and most of the analog VTX on the [...]

GEP-CL30 Frame Kits - GEPRC

GEP-CL30 Frame Kits

iFlight

iFlight ProTek35 3.5" HD Cinewhoop Frame

This frame kit is for the&nbspiFlight ProTek35 HD&nbspCinewhoop.

This frame kit is for the iFlight ProTek35 HD Cinewhoop.

iFlight ProTek35 3.5" HD Cinewhoop Frame Kit

iFlight ProTek35 3.5&quot HD Cinewhoop Frame Kit

After our very popular 3inch Cinematic EVA bumper BumbleBee and Green Hornet CineWhoop series, iFlight was trying to increase performance and reduce weight for an even better and longer flight experience for a wide variety of use.  iFlight's all-new 3.5inch project is finally ready for all you content creators or those

ProTek35 HD CineWhoop Frame Kit

BetaFPV Pavo30 3" Cinewhoop Frame (Without Carbon Fiber)

This frame kit is for the Pavo30 Whoop Quadcopter, which is a 3-inch pusher drone developed by BETAFPV.
